ZOU Jun, HAO Shaojun, HAO Tian, et al.Development of high-temperature-resistant and high-density QH-HCF completion fluid system and its application in deep and ultra-deep wells[J]. Drilling Fluid & Completion Fluid，2025, 42（5）：696-704 doi: 10.12358/j.issn.1001-5620.2025.05.017
Citation: ZOU Jun, HAO Shaojun, HAO Tian, et al.Development of high-temperature-resistant and high-density QH-HCF completion fluid system and its application in deep and ultra-deep wells[J]. Drilling Fluid & Completion Fluid，2025, 42（5）：696-704 doi: 10.12358/j.issn.1001-5620.2025.05.017
shu

Development of High-Temperature-Resistant and High-Density QH-HCF Completion Fluid System and Its Application in Deep and Ultra-Deep Wells

doi: 10.12358/j.issn.1001-5620.2025.05.017
  • 1.

    Oil & Gas Process Research Institute, CNPC Qinghai Oilfield Branch, Dunhuang, Gansu 736202

  • 2.

    Research Institute of Exploration and Development of PetroChina Qinghai Oilfield Company, Dunhuang, Gansu 736202

  • Received Date: 2025-04-05
  • Rev Recd Date: 2025-05-18
  • Publish Date: 2025-09-30
    Abstract
  • Addressing the poor suspension stability, rheological deterioration and reservoir damage exhibited by conventional completion fluids in deep and ultra-deep well drilling and completion operations under high-temperature (>200℃) and high-density (>2.0 g/cm3) conditions, this study employs molecular design to develop a high-temperature suspending agent, QH-HSA-III, and uses it as the core to build a novel QH-HCF completion fluid system. QH-HSA-III is synthesized via a terpolymer modification strategy of acrylamide (AM), octadecyl acrylate (ODA) and N-isopropylacrylamide (NIPAM). Through hydrophobic association and thermoresponsive mechanisms, it forms a dynamic three-dimensional network at elevated temperatures, markedly enhancing suspension stability. Laboratory evaluations show that the QH-HCF system maintains an apparent viscosity of 60 mPa·s at 200℃ with a dynamic shear force to plastic viscosity ratio of 0.26. In a 15-day high-temperature settling test, water separation was only 0.3%, cuttings rolling recovery reached 98.5%, particle-size retention was 93.8%, and high-temperature/high-pressure filtration loss remained ≤ 15 mL. In field trials on Well K2-X1 (measured depth 7182 m, bottom-hole temperature 200℃), application of the QH-HCF system reduced circulating pressure loss by 31.8%, achieved a cuttings return rate in excess of 95%, and cut non-productive time by 67%.These results confirm that the QH-HCF completion fluid system delivers outstanding high-temperature stability, dynamic rheological control and reservoir protection, providing robust technical support for the safe and efficient development of deep and ultra-deep wells.



    • FullText(HTML)
  • loading
    • References(23)
  • [1]
    赵金海, 张洪宁, 王恒, 等. 中国石化超深层钻完井关键技术挑战及展望[J]. 钻采工艺, 2024, 47(2): 28-34. doi: 10.3969/J.ISSN.1006-768X.2024.02.04

    ZHAO Jinhai, ZHANG Hongning, WANG Heng, et al. Key technical challenges and prospects of drilling and completion in ultra-deep reservoirs, Sinopec[J]. Drilling & Production Technology, 2024, 47(2): 28-34. doi: 10.3969/J.ISSN.1006-768X.2024.02.04
    [2]
    JIA H, NIU C C, DAI C L. Solid-free flexible colloidal completion fluid with variable density for gas well completion in high-temperature and high-pressure reservoirs: experimental study and pilot test[J]. SPE J, 2022, 27(1): 186-203. doi: 10.2118/208590-PA
    [3]
    谭宾, 张斌, 陶怀志. 深地勘探钻井技术现状及发展思考[J]. 钻采工艺, 2024, 47(2): 70-82. doi: 10.3969/J.ISSN.1006-768X.2024.02.09

    TAN Bin, ZHANG Bin, TAO Huaizhi. Current situation and development of deep exploration key drilling technology[J]. Drilling & Production Technology, 2024, 47(2): 70-82. doi: 10.3969/J.ISSN.1006-768X.2024.02.09
    [4]
    佘朝毅. 四川盆地超深层钻完井技术进展及其对万米特深井的启示[J]. 天然气工业, 2024, 44(1): 40-48.

    SHE Zhaoyi. Progress in ultra-deep drilling and completion technology in the Sichuan basin and its implications for extra-deep wells of more than ten thousand meters in depth[J]. Natural Gas Industry, 2024, 44(1): 40-48.
    [5]
    YANG M, LUO D, CHEN Y, et al. Establishing a practical method to accurately determine and manage wellbore thermal behavior in high-temperature drilling[J]. Applied Energy, 2019, 238(1): 1471-1483.
    [6]
    RANA A, MURTAZA M, RAZA A, et al. Application of high-density brines in drilling and completion fluids: current insights and future perspectives[J]. Energy & Fuels, 2024, 38(8): 6561-6578.
    [7]
    刘岩生, 张佳伟, 黄洪春. 中国深层—超深层钻完井关键技术及发展方向[J]. 石油学报, 2024, 45(1): 312-324.

    LIU Yansheng, ZHANG Jiawei, HUANG Hongchun. Key technologies and development direction for deep and ultra-deep drilling and completion in China[J]. Acta Petrolei Sinica, 2024, 45(1): 312-324.
    [8]
    张文平, 李双明, 张金成, 等. 深层常压页岩气工程技术新进展与发展建议[J]. 石油实验地质, 2023, 45(6): 1151-1159. doi: 10.11781/sysydz2023061151

    ZHANG Wenping, LI Shuangming, ZHANG Jincheng, et al. Progress and development suggestions of deep normal pressure shale gas engineering technology[J]. Petroleum Geology and Experiment, 2023, 45(6): 1151-1159. doi: 10.11781/sysydz2023061151
    [9]
    杨丽丽, 王世博, 张永威, 等. 砂岩热储层防损伤完井液体系研究[J]. 钻井液与完井液, 2023, 40(2): 265-271. doi: 10.12358/j.issn.1001-5620.2023.02.016

    YANG Lili, WANG Shibo, ZHANG Yongwei, et al. Damage preventative completion fluid for sandstone geothermal reservoir[J]. Drilling Fluid & Completion Fluid, 2023, 40(2): 265-271. doi: 10.12358/j.issn.1001-5620.2023.02.016
    [10]
    SINGH R, SHARMA R, RAO G R. Investigation of the effects of ultra-high pressure and temperature on the rheological properties of a novel high-density clear completion fluids using magnesium bromide for applications in HPHT reservoirs[J]. Geomechanics and Geophysics for Geo-Energy and Geo-Resources, 2024, 10(1): 9. doi: 10.1007/s40948-023-00724-y
    [11]
    SINGH R, SHARMA R, RAO G R. Development of a novel high density completion fluid with CuO nanoparticle as promising additive to improve the rheological properties[J]. Results in engineering, 2022, 15: 100520. doi: 10.1016/j.rineng.2022.100520
    [12]
    王信, 谭春, 王志彬, 等. 河探1井超高密度钻井液技术[J]. 钻井液与完井液, 2023, 40(2): 193-201.

    WANG Xin, TAN Chun, WANG Zhibin, et al. Ultra-High density drilling fluid technology for the well Hetan-1[J]. Drilling Fluid & Completion Fluid, 2023, 40(2): 193-201.
    [13]
    邹鹏, 张世林, 黄其, 等. 抗高温高密度无机盐完井液中复合缓蚀剂对P110钢的抑制腐蚀作用与机理[J]. 钻井液与完井液, 2023, 40(2): 272-278.

    ZOU Peng, ZHANG Shilin, HUANG Qi, et al. The inhibitive performance and mechanisms of a compound corrosion inhibitor in inhibiting P110 steel in a high temperature high density inorganic salt completion fluid[J]. Drilling Fluid & Completion Fluid, 2023, 40(2): 272-278.
    [14]
    EBADI R Z, KHAMEHCHI E, KAZEMIHOKMABAD P, et al. A novel formulation of an eco-friendly calcium nitrate-based heavy completion fluid[J]. Scientific Reports, 2024, 14(1): 21256. doi: 10.1038/s41598-024-72277-3
    [15]
    肖波, 陈生怀, 李祝军, 等. 海上高温高压低渗气田清喷排液关键技术[J]. 科技导报, 2025, 43(4): 82-87.

    XIAO Bo, CHEN Shenghuai, LI Zhujun, et al. Key technologies for well cleaning and drainage in offshore high temperature, high pressure and low permeability gas fields[J]. Science & Technology Review, 2025, 43(4): 82-87.
    [16]
    SINGH R, SHARMA R, RAO G R. Overcoming the rheological performance and density limitations using a novel high density magnesium bromide based completion fluid in oil and gas reservoirs[J]. Petroleum Science and Technology, 2024, 42(18): 2430-2448. doi: 10.1080/10916466.2023.2166961
    [17]
    徐靖, 丁文刚, 向兴金. 新型高温低渗气藏修井液体系的研究与应用[J]. 化学与生物工程, 2023, 40(1): 65-68. doi: 10.3969/j.issn.1672-5425.2023.01.012

    XU Jing, DING Wengang, XIANG Xingjin. Research and application of novel workover fluid system for high temperature and low permeability gas reservoir[J]. Chemistry & Bioengineering, 2023, 40(1): 65-68. doi: 10.3969/j.issn.1672-5425.2023.01.012
    [18]
    贾虎, 代昌楼, 李三喜, 等. 一种耐高温密度可调的柔性胶粒新型完井液[J]. 天然气工业, 2022, 42(12): 106-116. doi: 10.3787/j.issn.1000-0976.2022.12.011

    JIA Hu, DAI Changlou, LI Sanxi, et al. A novel high-temperature-resistant, variable-density, flexible colloidal particle completion fluid[J]. Natural Gas Industry, 2022, 42(12): 106-116. doi: 10.3787/j.issn.1000-0976.2022.12.011
    [19]
    李晓东, 熊正强, 万汉平, 等. 深部地热抗高温甲酸盐钻井液体系研究[J]. 地质与勘探, 2022, 58(5): 1091-1098. doi: 10.12134/j.dzykt.2022.05.015

    LI Xiaodong, XIONG Zhengqiang, WAN Hanping, et al. Anti-High temperature formate drilling fluid system for deep geothermal resources[J]. Geology and Exploration, 2022, 58(5): 1091-1098. doi: 10.12134/j.dzykt.2022.05.015
    [20]
    INTISO L, SMITH V C M, TAHIROV T, et al. Assessment of materials compatibility with high density brines completion fluid of HPHT wells[C]//the CORROSION 2018. Phoenix, Arizona, USA: NACE, 2018: NACE-2018-11509.
    [21]
    杨海军, 张家旗, 程荣超, 等. 抗高温油基完井液静沉降稳定性研究及应用[J]. 应用化工, 2022, 51(增刊1): 299-302.

    YANG Haijun, ZHANG Jiaqi, CHENG Rongchao, et al. Static settlement research and application of high temperature resistance oil-based completion fluid[J]. Applied Chemical Industry, 2022, 51(S1): 299-302.
    [22]
    刘昊. 固井清洗剂DQQX-2及其冲洗液体系的研制与应用[J]. 钻井液与完井液, 2024, 41(4): 531-536. doi: 10.12358/j.issn.1001-5620.2024.04.015

    LIU Hao. The development and application of well cementing cleaning agent DQQX-2 and flushing fluid formulated with it[J]. Drilling Fluid & Completion Fluid, 2024, 41(4): 531-536. doi: 10.12358/j.issn.1001-5620.2024.04.015
    [23]
    武磊, 赵宝辉, 侯薇, 等. 油井水泥悬浮剂的研究进展[J]. 油田化学, 2023, 40(4): 736-742.

    WU Lei, ZHAO Baohui, HOU Wei, et al. Research progress of oil well cement suspension[J]. Oilfield Chemistry, 2023, 40(4): 736-742.
