WU Wenbing, ZHONG Jie, LIU Tao, et al.An environmentally friendly ultra-high temperature low solids seawater-based drilling fluid[J]. Drilling Fluid & Completion Fluid，2025, 42（4）：472-477 doi: 10.12358/j.issn.1001-5620.2025.04.005
Citation: WU Wenbing, ZHONG Jie, LIU Tao, et al.An environmentally friendly ultra-high temperature low solids seawater-based drilling fluid[J]. Drilling Fluid & Completion Fluid，2025, 42（4）：472-477 doi: 10.12358/j.issn.1001-5620.2025.04.005
shu

An Environmentally Friendly Ultra-High Temperature Low Solids Seawater-Based Drilling Fluid

doi: 10.12358/j.issn.1001-5620.2025.04.005
  • 1.

    School of Petroleum Engineering, China University of Petroleum (East China), Qingdao, Shandong 266580

  • 2.

    CNPC Offshore Engineering Co., Ltd., Tianjin 300074

  • Received Date: 2025-01-21
  • Rev Recd Date: 2025-02-23
  • Publish Date: 2025-07-31
    Abstract
  • The failure of a drilling fluid at high temperatures is one of the main causes of complex downhole accidents. The depths of wells around the Bohai Bay are close to 6,000 m, and the bottom hole temperatures are expected to exceed 200℃. To prevent wellbore collapse and the failure of the drilling fluids, protect the oil and gas reservoirs and the marine environment, high-temperature resistant drilling fluid additives were optimally selected, the high-temperature resistance mechanisms of the additives were explored, and as a result of these researches, an environmentally friendly ultra-high temperature low-solids seawater-based drilling fluid with a temperature resistance of 200℃ and a density of 1.9 g/cm3 was formulated and applied in the well Gaitan-1. The research results and field application effects show that after hot rolled at 200℃ for 16 hours, the filtration rate of this drilling fluid is only 15 mL. It has many advantages such as low filtration rate, high inhibitive capacity, good lubricity, good suspending and carrying capacity, as well as reservoir protection capability. The well was drilled successfully, the rate of wellbore enlargement was small, and the composition of the drilling fluid was simple and environmentally friendly, satisfying the requirements of marine environmental protection. This drilling fluid has helped solve the technical difficulties encountered in oil and gas drilling in deep high-temperature and high-pressure formations in the Bohai Sea area, providing technical support for the exploration and development of deep oil and gas in this area in the future, and also providing a sample for the application of ultra-high temperature low-solids drilling fluids in other deep formations and environmentally sensitive areas.



    • FullText(HTML)
  • loading
    • References(17)
  • [1]
    GAUTAM S, GURIA C. An improved prediction of frictional pressure drop using an accurate shear rate equation for high-yield stress drilling fluids at the surface and downhole conditions[J]. Journal of Petroleum Science and Engineering, 2022, 218:110981. doi: 10.1016/j.petrol.2022.110981
    [2]
    陈晓辉, 李日辉, 温珍河, 等. 渤海海域地质环境稳定性定量评价[J]. 海洋地质前沿,2024,40(3):14-21.

    CHEN Xiaohui, LI Rihui, WEN Zhenhe, et al. Quantitative evaluation of the geological environment stability in the Bohai Sea[J]. Marine Geology Frontiers, 2024, 40(3):14-21.
    [3]
    杨鹏, 吕开河, 隗虎, 等. 抗高温海水无黏土相钻井液研究[J]. 钻井液与完井液,2012,29(6):21-23,27. doi: 10.3969/j.issn.1001-5620.2012.06.007

    YANG Peng, LYU Kaihe, KUI Hu, et al. Research on high temperature seawater base clay-free drilling fluid system[J]. Drilling Fluid & Completion Fluid, 2012, 29(6):21-23,27. doi: 10.3969/j.issn.1001-5620.2012.06.007
    [4]
    李秀灵, 赵怀珍, 蓝强, 等. 抗高温低固相钻井液在桩古斜411井的应用[J]. 承德石油高等专科学校学报,2023,25(2):46-52. doi: 10.3969/j.issn.1008-9446.2023.02.010

    LI Xiuling, ZHAO Huaizhen, LAN Qiang, et al. Application of anti-temperature low-solid drilling fluid in Zhuanggu X-411 well[J]. Journal of Chengde Petroleum College, 2023, 25(2):46-52. doi: 10.3969/j.issn.1008-9446.2023.02.010
    [5]
    WANG C Q, JIN L, LIU X Y, et al. Preparation and evaluation of high-temperature filtrate reducer for solid-free water-based drilling fluid[J]. Polymer Engineering& Science, 2022, 62(8):2411-2418.
    [6]
    孙金声, 杨景斌, 白英睿, 等. 深层超深层钻井液技术研究进展与展望[J]. 石油勘探与开发,2024,51(4):889-898. doi: 10.11698/PED.20240128

    SUN Jinsheng, YANG Jingbin, BAI Yingrui, et al. Research progress and development of deep and ultra-deep drilling fluid technology[J]. Petroleum Exploration and Development, 2024, 51(4):889-898. doi: 10.11698/PED.20240128
    [7]
    闫海建, 贾东林, 李焕, 等. 水基钻井液用抗高温耐盐降滤失剂的制备与性能评价[J]. 当代化工,2024,53(8):1786-1791. doi: 10.3969/j.issn.1671-0460.2024.08.005

    YAN Haijian, JIA Donglin, LI Huan, et al. Preparation and performance evaluation of high temperature and salt resistant fluid loss reducer for water-based drilling fluids[J]. Contemporary Chemical Industry, 2024, 53(8):1786-1791. doi: 10.3969/j.issn.1671-0460.2024.08.005
    [8]
    鞠菲. 复杂深井耐高温复合处理剂合成及其水基钻井液性能研究[D]. 北京: 中国石油大学(北京), 2023.

    JU Fei. Synthesis of complex deep well high-temperature resistant composite treatment agent and study of its water-based drilling fluid performance[D]. Beijing: China University of Petroleum(Beijing), 2023.
    [9]
    赵幸滨, 李艳飞, 王涛, 等. 新型水基钻完井液降滤失剂作用机理及性能评价[J]. 当代化工,2024,53(3):636-639. doi: 10.3969/j.issn.1671-0460.2024.03.027

    ZHAO Xingbin, LI Yanfei, WANG Tao, et al. Mechanism and performance evaluation of new filtrate reducer for water-based drilling and completion fluid[J]. Contemporary Chemical Industry, 2024, 53(3):636-639. doi: 10.3969/j.issn.1671-0460.2024.03.027
    [10]
    宋永涛, 周丰, 余维初, 等. 基于季戊四醇的超支化降滤失剂的合成及性能评价[J]. 钻井液与完井液,2022,39(5):587-595. doi: 10.12358/j.issn.1001-5620.2022.05.009

    SONG Yongtao, ZHOU Feng, YU Weichu, et al. The synthesis and evaluation of a Pentaerythritol-Based hyperbranched polymer filter loss reducer[J]. Drilling Fluid & Completion Fluid, 2022, 39(5):587-595. doi: 10.12358/j.issn.1001-5620.2022.05.009
    [11]
    张高波, 李培海, 乔汉, 等. 控制水基钻井液高温高压滤失量的方法及途径[J]. 钻井液与完井液,2022,39(4):406-414,422. doi: 10.12358/j.issn.1001-5620.2022.04.002

    ZHANG Gaobo, LI Peihai, QIAO Han, et al. Methods of controlling low HTHP filtration rate of water based drilling fluids[J]. Drilling Fluid & Completion Fluid, 2022, 39(4):406-414,422. doi: 10.12358/j.issn.1001-5620.2022.04.002
    [12]
    邹君. 抗温抗盐水基钻井液提切剂研选与评价[D]. 北京: 中国石油大学(北京), 2023.

    ZOU Jun. Selection and evaluation of shear-reducing agents for anti-temperature and anti-salt water-based drilling fluids[D]. Beijing: China University of Petroleum(Beijing), 2023.
    [13]
    张立格. 环保型合成基钻井液体系的研究与评价[D]. 北京: 中国石油大学(北京), 2022.

    ZHANG Lige. Research and evaluation of environmental protection synthetic drilling fluid system[D]. Beijing: China University of Petroleum(Beijing), 2022.
    [14]
    庞少聪, 安玉秀, 田野. 抗高温钻井液体系国内外研究进展与发展建议[J]. 钻探工程,2024,51(4):82-92.

    PANG Shaocong, AN Yuxiu, TIAN Ye. Research progress and development suggestions of high-temperature resistant drilling fluid systems at home and abroad[J]. Drilling Engineering, 2024, 51(4):82-92.
    [15]
    周辉. 超深井高密度抗高温钻井液研究与应用[J]. 石化技术,2024,31(11):250-252. doi: 10.3969/j.issn.1006-0235.2024.11.086

    ZHOU Hui. Research and application of High-density and High-temperature resistant drilling fluid for ultra deep wells[J]. Petrochemical Industry Technology, 2024, 31(11):250-252. doi: 10.3969/j.issn.1006-0235.2024.11.086
    [16]
    张健. 新型抗高温高密度有机盐钻井液体系研究[J]. 能源化工,2021,42(6):62-66. doi: 10.3969/j.issn.1006-7906.2021.06.012

    ZHANG Jian. Study on a new high temperature resistance and high density organic salt drilling fluid system[J]. Energy Chemical Industry, 2021, 42(6):62-66. doi: 10.3969/j.issn.1006-7906.2021.06.012
    [17]
    张帆, 傅相友, 严福寿, 等. 深部取心钻探井超高温聚磺钻井液体系的研究[J]. 中国石油和化工标准与质量,2019,39(5):139-140. doi: 10.3969/j.issn.1673-4076.2019.05.070

    ZHANG Fan, FU Xiangyou, YAN Fushou, et al. Research on ultra-high temperature polysulfur drilling fluid system in deep coring drilling wells[J]. China Petroleum and Chemical Standard and Quality, 2019, 39(5):139-140. doi: 10.3969/j.issn.1673-4076.2019.05.070
