储气库注采井水泥环破坏机理实验研究

舒刚,  刘健,  冯逢,  张杨,  周浪,  陈浩,  汪传磊

downloadPDF
文章导航 > 钻井液与完井液  > 2020 >  37(4): 507-511,520
舒刚, 刘健, 冯逢, 张杨, 周浪, 陈浩, 汪传磊. 储气库注采井水泥环破坏机理实验研究[J]. 钻井液与完井液, 2020, 37(4): 507-511,520. doi: 10.3969/j.issn.1001-5620.2020.04.017
引用本文: 舒刚, 刘健, 冯逢, 张杨, 周浪, 陈浩, 汪传磊. 储气库注采井水泥环破坏机理实验研究[J]. 钻井液与完井液, 2020, 37(4): 507-511,520. doi: 10.3969/j.issn.1001-5620.2020.04.017
shu
SHU Gang, LIU Jian, FENG Feng, ZHANG Yang, ZHOU Lang, CHEN Hao, WANG Chuanlei. Experimental Study on Failure Mechanism of Cement Sheath in Injection Production Well of Gas Storage[J]. DRILLING FLUID & COMPLETION FLUID, 2020, 37(4): 507-511,520. doi: 10.3969/j.issn.1001-5620.2020.04.017
Citation: SHU Gang, LIU Jian, FENG Feng, ZHANG Yang, ZHOU Lang, CHEN Hao, WANG Chuanlei. Experimental Study on Failure Mechanism of Cement Sheath in Injection Production Well of Gas Storage[J]. DRILLING FLUID & COMPLETION FLUID, 2020, 37(4): 507-511,520. doi: 10.3969/j.issn.1001-5620.2020.04.017
shu

储气库注采井水泥环破坏机理实验研究

doi: 10.3969/j.issn.1001-5620.2020.04.017

  • 1. 中国石油西南油气田分公司工程技术研究院, 成都 610017;

  • 2. 西南石油大学石油与天然气工程学院, 成都 610500;

  • 3. 中国石油西南油气田分公司致密油气勘探开发项目部, 成都 610051;

  • 4. 中国石油西南油气田分公司川东北气矿, 四川达州 635000

基金项目:

中国石油西南油气田分公司科技项目“长期强注强采工况下注采井井筒完整性关键技术研究”（20190303-20）资助

详细信息
    作者简介:

    舒刚,工程师,硕士研究生,主要从事井筒完整性、完井试油方面的研究。电话(028)86010334;E-mail:shugang@petrochina.com.cn

  • 中图分类号: TE256

Experimental Study on Failure Mechanism of Cement Sheath in Injection Production Well of Gas Storage

  • 1. Engineering Technology Research Institute of Petrochina Southwest Oil and Gas Field Company, Chengdu, Sichuan 610017;

  • 2. College of Petroleum Engineering, Southwest Petroleum University, Chengdu, Sichuan 610500;

  • 3. Tight Oil and Gas Project Department of Petrochina Southwest Oil and Gas Field Company, Chengdu, Sichuan 610051;

  • 4. Northeast Sichuan Gas Mine of Petrochina Southwest Oil and Gas Field Company, Dazhou, Sichuan 635000

    摘要
  • 摘要: 储气库注采井的注气与采气、环空带压与泄压等情况使井筒反复承受加载卸载，水泥环因此受到不同程度的损害，严重时导致地层气体窜入环空。为了研究注采井水泥环的破坏机理，针对某储气库B环空上部水泥环的工况条件，开展了水泥环承受8.1 MPa和13.6 MPa循环内压的实验模拟，并对水泥环进行了密封性、渗透率、SEM电镜扫描、微CT扫描分析，探究水泥环微裂缝和孔隙的变化情况。实验表明，8.1 MPa的内压循环30次未造成水泥环气窜，13.6 MPa的内压循环23次则导致气窜，与某储气库出现浅层气窜入B环空的情况相符；循环载荷可导致水泥环产生微裂缝，随着循环载荷压力值的增加，取样渗透率逐渐小幅度增加，微裂缝产生越多，裂缝扩展越大，甚至出现贯穿缝；微环隙由水泥环微观结构破坏持续累积造成，对于固井质量良好的环空，水泥环发生微观结构破坏是气窜的本质原因；水泥环微观结构破坏和界面产生微环隙均可直接引起气窜，主导者受多种因素影响而变化。实验结果揭示了循环载荷下注采井水泥环的破坏机理以及与气窜的关联性，对储气库运行优化和新建储气库的井筒质量控制具有指导意义。



    Abstract: Gas injection and gas production from a gas storage well and pressure accumulation and unloading of the annular space of the well result in repeated loading and unloading of the wellbore, leading to the failure of the cement sheath, or even gas invasion from formation into the well. To study the failure mechanisms of the cement sheath of a gas injector (also acted as a gas producer), a laboratory experiment was conducted in which the cement sheath was subjected to the action of internal circulation pressure of 8.1 MPa and 13.6 MPa, according to the work conditions of the cement sheath in the upper part of the annular space B of a gas storage. The cement sheath was studied for the change of micro fractures and pores in it by analyzing its sealing property and permeability as well as SEM and CT analyses. In the experiment, there was no gas channeling through the cement sheath after 30 times of circulation at 8.1 MPa; when the circulation pressure was increased to 13.6 MPa, 23 times of gas channeling were found in 30 times of circulation. This experimental result is in accordance with the situation of shallow gas channeling into the annular space B. Cyclic loading may result in micro fractures in the cement sheath, and with the increase in the amplitude of the cyclic load, the permeability of the sheath sample increased at a small amplitude. The more the number of the micro fractures in the cement sheath, the wider and longer the micro fractures extended, and some micro fractures even ran through the whole sheath. Micro-annulus path around the cement sheath were resulted from the accumulation of failures of the micro structure of the cement sheath. For a well with high quality cementing job, the failure of the microstructure of the cement sheath is essentially the cause of gas channeling. Microstructure failure in a cement sheath and micro-annulus path around the cement sheath both can directly result in gas channeling, though the dominant cause of the gas channeling is affected by many factors. The experimental results have revealed the mechanisms of failure of the cement sheath under cyclic loading in a gas injection and producing well and the relevance between the cyclic loading and gas channeling, and are of instructive significance on the optimization of gas storage operation and quality control of the wellbore of a new gas storage.



    • HTML全文
    • 参考文献(17)
  • [1] 朱达江. 气井环空带压机理研究[D]. 成都:西南石油大学, 2014. ZHU Dajiang. Research on mechanism of sustained casing pressure gas wells[D]. Chengdu:Southwest Petroleum University, 2014.
    [2] 徐钰. 相国寺储气库井筒完整性研究[D]. 成都:西南石油大学, 2018. XU Yu. Study on well integrity of Xiangguosi gas storage[D]. Chengdu:Southwest Petroleum University, 2018.
    [3] 刘文忠. 相国寺储气库注采井完整性技术探索与实践[J]. 钻采工艺, 2017, 40(2):27-30.

    LIU Wenzhong. Probe on and practice practice of well integrity technology for injection-production wells at Xiangguosi underground gas storage[J]. Drilling & Production Technology, 2017, 40(2):27-30.
    [4] RAVI K, MORONI N, BARBIERI E, et al. Intelligent and interventionless zonal isolation for well integrity in Italy[R]. SPE 119869, 2009.
    [5] ARASH SHADRAVAN, JERSOME SCHUBERT, MAHMOOD AMANI, et al. HPHT cement sheath integrity evaluation method for unconventional wells[R]. SPE 168321, 2014.
    [6] DE ANDRADE J, SANGESLAND S, SKORPA R, et al. Experimental laboratory setup for visualization and quantification of cement-sheath integrity[R]. SPE 173871, 2016.
    [7] 陈朝伟, 蔡永恩. 套管-地层系统套管载荷的弹塑性理论分析[J]. 石油勘探与开发, 2009, 36(2):242-246.

    CHEN Zhaowei, CAI Yong'en. Study on casing load in a casing-stratum system by elastoplastic theory[J]. Petroleum Exploration and Development, 2009, 36(2):242-246.
    [8] 刘洋, 严海兵, 余鑫, 等. 井内压力变化对水泥环密封完整性的影响及对策[J]. 天然气工业, 2014, 34(4):95-98.

    LIU Yang, YANG Haibing, YU Xin, et al. Negative impacts of borehole pressure change on cement sheath sealing integrity and counter measure[J]. Natural Gas Industry, 2014, 34(4):95-98.
    [9] 艾正青, 张峰, 丁辉, 等. 温度对水泥石机械性能非线性影响规律及原因分析[J]. 钻井液与完井液, 2018, 35(4):78-81.

    AI Zhengqing, ZHANG Feng, DING Hui, et al. Effects of temperature on mechanical property of set cement and analysis thereof[J].Drilling Fluid & Completion Fluid, 2018, 35(4):77-81.
    [10] 万浩东, 杨远光. 储气库井弹性自愈合水泥浆体系及其性能评价[J]. 石油钻采工艺, 2018, 40(6):732-735.

    WAN Haodong, YANG Yuanguang. Elastic self-healing water mud system of gas storage well and its performance evaluation[J]. Oil Drilling & Production Pechnology, 2018, 40(6):732-735.
    [11] 李忠洋, 王磊, 师志虎, 等. 新型水泥环完整性可视化和量化试验装置[J]. 石油机械, 2018, 46(6):25-32.

    LI Zhongyang, WANG Lei, SHI Zhihu, et al. Experimental setup for visualization and quantification of cement sheath integrity[J]. China Petroleum Machinery, 2018, 46(6):25-32.
    [12] 卢亚锋, 郑友志, 佘朝毅, 等. 基于水泥石实验数据的水泥环力学完整性分析[J]. 天然气工业,2013,33(5):77-81.

    LU Yafeng, ZHENG Youzhi, SHE Chaoyi, et al. Analysis of cement-sheath mechanical integrity based on the experiment data of cement paste[J]. Natural Gas Industry, 2013, 33(5):77-81.
    [13] 初纬, 沈吉云, 杨云飞, 等. 连续变化内压下套管-水泥环-围岩组合体微环隙计算[J]. 石油勘探与开发, 2015, 42(3):379-385.

    CHU Wei, SHEN Jiyun, YANG Yunfei, et al. Calculation of micro-annulus size in casing-cement sheath-formation system under continuous internal casing pressure change[J]. Petroleum Exploration and Development, 2015, 42(3):379-385.
    [14] 刘仍光, 张林海, 陶谦, 等. 循环应力作用下水泥环密封性实验研究[J]. 钻井液与完井液, 2016, 33(4):74-78.

    LIU Rengguang, ZHANG Linhai, TAO Qian, et al. Experimental study on airtightness of cement sheath under alternating stress[J]. Drilling Fluid & Completion Fluid, 2016, 33(4):74-78.
    [15] 唐毅. 储气库注采载荷对储层段水泥环完整性的影响研究[D]. 成都:西南石油大学, 2017. TANG Yi. Study on the effect of loading pressure on the integrity of cement sheath in gas storage[D]. Chengdu:Southwest Petroleum University, 2017.
    [16] 易成, 范永魁, 朱红光, 等. 基于韧性的混凝土轴压疲劳损伤演化研究[J]. 工程力学, 2010, 27(8):113-119.

    YI Cheng, FAN Yongkui, ZHU Hongguang, et al. Research on fatigue damage of concrete under uniaxial compression on the basis of toughness[J].Engineering Mechanics, 2010, 27(8):113-119.
    [17] 刘健. 油气井水泥石力学行为本构方程与完整性评价模型研究[D]. 成都:西南石油大学, 2013. LIU Jian. Research on constitutive equations and evaluation models of mechanical integrity of cement stone[D]. Chengdu:Southwest Petroleum University, 2013.
