响应面法优化纳米材料稳定的泡沫钻井液

李强; 李志勇; 张浩东; 孙晗森; 李林源; 李新岗; 王玥

doi:10.3969/j.issn.1001-5620.2020.01.004

响应面法优化纳米材料稳定的泡沫钻井液

doi: 10.3969/j.issn.1001-5620.2020.01.004

1. 中国石油大学(北京) 石油工程学院, 北京 102249;
2. 中联煤层气有限责任公司, 北京 100016

基金项目:

国家科技重大专项课题“新型低伤害强防塌钻井液体系研究”（2016ZX05044003-003）

详细信息

作者简介:
李强,在读硕士研究生,1995年生,主要从事煤层气井用钻井液的研究。E-mail:lqiang0916@163.com

通讯作者:
李志勇,博士,副教授,从事钻井液优化设计、储层保护和钻井废弃物处理等研究。E-mail:lzysoar11@163.com

中图分类号: TE254
计量
- 文章访问数: 805
- HTML全文浏览量: 275
- PDF下载量: 158
- 被引次数: 0
出版历程
- 收稿日期: 2019-08-29
- 刊出日期: 2020-02-28

Study on Foam Drilling Fluid Stabilized with Nanomaterials Optimized with RSM

1. School of Petroleum Engineering, China University of Petroleum, Beijing 102249;
2. China United Coalbed Methane Co., Ltd, Beijing 100016

摘要

摘要: 为提高泡沫钻井液的稳定性，向体系中引入纳米材料，并研究了纳米材料润湿性对于泡沫质量的影响。根据Box-Behnken Design设计原理，采用三因素三水平响应曲面法，优化了起泡剂BS-12、亲水性纳米SiO₂和增黏剂XC的加量，探究了它们之间交互作用对于泡沫综合指数的影响，并以此为基础研制了泡沫钻井液体系。结果表明，纳米材料润湿性会显著影响不同类型起泡剂的泡沫质量，疏水性纳米材料能够提高阴离子起泡剂SDS的泡沫稳定性，但对两性离子起泡剂BS-12的泡沫起泡量和半衰期呈现负相关关系，亲水性纳米材料才能提高两性离子起泡剂BS-12的泡沫稳定性；通过响应曲面优化设计得到的最优浓度配比为：0.6% BS-12+4%纳米SiO₂+0.3% XC。响应曲面分析表明，对于泡沫综合指数的显著性影响程度，纳米材料浓度 > 起泡剂浓度 > XC浓度；纳米稳定的泡沫钻井液体系性能评价表明，该体系表观黏度为42mPa·s，密度为0.81 g/cm³，半衰期达60 h，能长时间保持性能稳定，抑制性强，线性膨胀率较清水下降65%，储层保护效果好，煤岩岩心气测渗透率恢复率在90%以上，携岩效果好，岩屑和煤屑的沉降速度较清水降低92%以上，能够满足现场煤层气钻井的需要。
- 响应曲面法 /
- 泡沫钻井液 /
- 纳米材料 /
- 润湿性 /
- 煤层气
Abstract: Nanomaterials have been used to improve the stability of foam drilling fluids, and the effects of the wettability of the nanomaterials on the foam quality were studied using three-factor three-level response surface methodology (RSM) in accordance with the Box-Behnken Design principle. In the studies the concentrations of the foaming agent BS-12, the hydrophilic nanoSiO₂ and the viscosifier XC were optimized, and the effects of their interaction on the comprehensive performance of the foam were investigated. A new foam drilling fluid was designed based on these studies. It was found in the studies that the wettability of the nanomaterials remarkably affected the foam quality of the foaming agents. Hydrophobic nanomaterials was able to enhance the stability of the foam produced with an ionic foaming agent SDS. Increased treatment of the hydrophobic nanomaterials decreased the foam quality and halflife of the foam produced with an amphoteric foaming agent BS-12. The optimized foam mud was obtained using RSM design, which is: 0.6%BS-12 + 4%Nano SiO₂+0.3%XC. RSM analysis showed that order of magnitude of effect of the concentrations of the three agents on the comprehensive performance of the foam is: nanomaterial > foaming agent > XC. Laboratory evaluation showed that this foam drilling fluid had apparent viscosity of 42 mPa·s, density of 0.81 g/cm³, half life of 60 h, meaning that the foam drilling fluid is able to sustain its stability for a long time. The foam drilling fluid also showed strong shale inhibitive capacity; the linear expansion rate is 65% lower than that of clean water. The recovery rate of coal rock core gas permeability is over 90%, and settling velocity of rock and coal cuttings in the foam drilling fluid was reduced by at least 92% compared with clear water, indicating that the foam drilling fluid had both good reservoir protection performance and good cuttings carrying capacity. The results of the performance evaluation test showed that this foam drilling fluid is able to satisfy the needs of coal-bed methane drilling.
- Response surface methodology /
- Foam drilling fluid /
- Nanomaterial /
- Wettability /
- Coal-bed methane

HTML全文

参考文献(20)

[1]	徐加放,邱正松,何群.可循环微泡沫钻井液的防塌机理及应用研究[J].钻井液与完井液, 2010, 27(4):7-9. XU Jiafang, QIU Zhengsong, HE Qun. Anti collapse mechanism and application of recyclable micro foam drilling fluid[J]. Drilling Fluid&Completion Fluid, 2010, 27(4):7-9.
[2]	PORTER, M, HILL A, VIEIRA P, et al. Optimizing the application of underbalanced drilling through the use of air and foam systems in low-pressure gas reservoirs[C]//SPE/IADC Middle East Drilling Technology Conference and Exhibition-Abu Dhabi, UAE, 2018.
[3]	GROWCOCK F, SIMON G, REA A, et al. Alternative aphron-based drilling fluid[C]//Society of Petroleum Engineers IADC/SPE Drilling Conference, Dallas, Texas, 2004.
[4]	姚金星,万里平,高攀明,等.聚合物纳米组装微泡沫钻井液体系及其性能评价[J].石油钻采工艺, 2018, 40:577-581. YAO Jinxing, WAN Liping, GAO Panming, et al.Polymer nano assembly micro foam drilling fluid system and its performance evaluation[J]. Oil Drilling&Production Technology, 2018 , 40:577-581.
[5]	赵雄虎,高飞,鄢捷年,等.纳米钻井液材料GY-2室内研究[J].油田化学, 2010, 27:357-359, 365. ZHAO Xionghu, GAO Fei, YAN Jienian, et al. Laboratory study on nano drilling fluid material GY-2[J]. Oilfield Chemistry, 2010, 27:357-359, 365.
[6]	光新军,豆宁辉,贾云鹏,等.纳米技术在石油工程中的应用前景[J].钻采工艺, 2019, 42:34-37, 38. GUANG Xinjun, DOU Ninghui, JIA Yunpeng, et al. Application prospect of nanotechnology in petroleum engineering[J]. Drilling&Production Technology, 2019, 42:34-37, 38.
[7]	彭宝亮,罗健辉,王平美,等.用于低渗透油田调剖的纳米颗粒稳定泡沫体系研究进展[J].油田化学, 2017, 34:745-748. PENG Baoliang, LUO Jianhui, WANG Pingmei, et al. Research progress of nanoparticle stabilized foam system for profile control in low permeability oilfield[J]. Oilfield Chemistry, 2017 , 34:745-748.
[8]	LAKSHMI M D, RAJPUT G, PANDYA N, et al. Enhanced foam ability and foamst a bility of polyoxyethylene cholesteryl ether in occurrence of ionic surfactants[J]. Colloids and Surfaces A:Physicochemical and Engineering Aspects, 2018, 551:81-86.
[9]	赵江玉,蒲万芬,李一波,等.耐高温高盐泡沫体系筛选与性能评价[J].天然气与石油, 2014, 32:65-69. ZHAO Jiangyu, PU Wanfen, LI Yibo, et al. Screening and performance evaluation of high temperature and high salt foam system[J]. Natural Gas and Oil, 2014 , 32:65-69.
[10]	赵国玺.表面活性剂化学[M].北京:北京大学出版社, 1984. ZHAO Guoxi. Surfactant chemistry[M]. Beijing, Peking University Press, 1984.
[11]	ZHANG S, LAN Q, LIU Q, et al. Aqueous foams stabilized by Laponite and CTAB[J]. Colloids&Surfaces A Physicochemical&Engineering Aspects, 2008, 317:406-413.
[12]	孙乾,李兆敏,李松岩,等. SiO₂纳米颗粒稳定的泡沫体系驱油性能研究[J].中国石油大学学报(自然科学版), 2014:124-131. SUN Qian, LI Zhaomin, LI Songyan, et al. Study on oil displacement performance of SiO₂ nanoparticle stabilized foam system[J]. Journal of China University of Petroleum (Edition of Natural Science), 2014:124-131.
[13]	黄晋,孙其诚.液态泡沫渗流的机理研究进展[J].力学进展, 2007:269-278. HUANG Jin, SUN Qicheng. Research progress in the mechanism of liquid foam seepage[J]. Advances in Mechanics, 2007:269 -278.
[14]	宋水祥,罗溪梅,马鸣泽,等.泡沫稳定性研究进展[J].矿冶, 2019, 28:30-34. SONG Shuixiang, LUO Ximei, MA Mingze, et al. Research progress of foam stability[J]. Mining and Metallurgy, 2019 , 28:30-34.
[15]	李莉,张赛,何强,等.响应面法在试验设计与优化中的应用[J].实验室研究与探索, 2015, 34:41-45. LI Li, ZHANG Sai, HE Qiang, et al.Application of response surface methodology in experimental design and optimization[J]. Research and Exploration in Laboratory, 2015 , 34:41-45.
[16]	BOX G E P, WILSON K B J R. On the experimental attainment optimum conditions[J]. Stat, 1951, 13(1):1-45.
[17]	李靖嵩,曹静,周明,等. CR052111/APP-4二元泡沫体系的室内研究[J].钻采工艺, 2015, 38:91-94, 96. LI Jingsong, CAO Jing, ZHOU Ming, et al. Laboratory study on binary foam system APP-4/CR052111[J]. Drilling&Production Technology, 2015, 38:91-94, 96.
[18]	KHATAEE A R, DEHGHAN G. Optimization of biological treatment of a dye solution by macroalgae Cladophora sp. using response surface methodology[J]. Journal of the Taiwan Institute of Chemical Engineers, 2011, 42:26-33.
[19]	尹少华,林国,彭金辉,等.响应曲面法优化微波干燥碳酸稀土的实验研究[J].稀有金属, 2016, 40, 350-355. YIN Shaohua, LIN Guo, PENG Jinhui, et al. Experimental study on microwave drying of Rare earth carbonate by response surface methodology[J]. Rare Metals, 2016 , 40:350-355.
[20]	李宾飞,黄梦梅,李兆敏,等.泡沫性能综合评价实验设计[J].实验技术与管理, 2017, 34:187-190. LI Binfei, HUANG Mengmei, LI Zhaomin, et al. Experimental design of foam performance comprehensive evaluation[J]. Experimental Technology and Management, 2017 , 34:187-190.
