Study and Application of Stabilization and Differentiated Acidizing Stimulation System for Unconsolidated Sandstone Reservoirs
-
摘要: 中东地区某油田的主力产层之一的砂岩储层以砂岩和泥质粉砂岩为主，胶结物以长石为主，岩石疏松易出砂导致堵塞。常规酸化技术见效慢，可能导致疏松砂岩分散，加剧出砂。本文分析储层出砂堵塞机理，并研发一套针对疏松砂岩储层的复合酸化解堵技术，以“先稳定、后解堵”为思路，能缓解油井堵塞伤害，并维持储层稳定性。本文通过室内试验，研发了高冲刷流速条件下的砂岩稳定剂，在1800 mL/h的流速下，出砂率可稳定控制在0.01%以内。应用不同工作液体系的协同作用原理，以“多除垢、少溶砂”为目标，研发了差异化溶蚀的酸化解堵体系，垢样溶蚀率≥95%，溶砂率<25%，酸液可控制砂岩的溶蚀率，维持岩石结构稳定。现场试验证明，该技术可提高油井平均产量和有效期，为疏松砂岩油田的酸化解堵处理提供了理论基础与实践方向。Abstract: One of Middle East oilfield main production layers is a sandstone reservoir, primarily composed of sandstone and argillaceous siltstone. The rock is loose and prone to sand production. Conventional acidizing technologies are slow-acting and may even cause sand production. This paper analyze the mechanism of sand production and blockage in the reservoir, and develop a composite acidizing stimulation technology targeted at unconsolidated sandstone reservoirs. Based on the principle of "stabilization first, then stimulation," this technology can not only alleviate well blockage damage but also maintain reservoir stability. Through laboratory experiments, this paper developed a sandstone stabilizer suitable for high scouring flow rates. Under a flow rate of 1800 mL/h, the sand production rate can be stably controlled within 0.01%. Meanwhile, by applying the synergistic principle of different working fluid systems and aiming for "more scale removal, less sand dissolution," a differentially dissolving acidizing and descaling system was developed. Laboratory tests show that the dissolution rate of scale samples in the acid system is ≥95%, while the sand dissolution rate is <25%. The acid fluid can effectively alleviate the dissolution of sandstone minerals and maintain rock structure stability. Field tests have demonstrated that the composite acidizing technology, which follows the "stabilize first, then descale" approach, has increased average production and extended the treatment's effective period, effectively mitigating the problem of sand production in the reservoir. This provides a theoretical basis and practical direction for acidizing treatments in unconsolidated sandstone oilfields.
-
表 1 室内测定流量与折合现场产液量对应关系
室内测定流量/(mL·h-1) 1800 3000 4200 5400 折合现场产液量/（m3/（d·m） ) 39.8 66.4 92.9 119.4
下载: 导出CSV
表 2 高强度冲刷岩心渗透率恢复率
石英砂粒径/
mmK0/
mDKd/
mDKd/ K0/
%出砂时流量/
mL·h−10.2～0.6 1630 1504 92.3 1800 2410 2336 96.9 3290 3093 94.0 2240 2132 95.2 1770 1637 92.4
下载: 导出CSV
表 5 不同酸液体系对砂岩和垢样的溶蚀率对比
酸液体系 岩石类型 反应时间/h 溶蚀率/% 15%HCl 砂岩 / 垢样 2 26.0 / 90.0 8%HF 45.0 / 34.0 12%HCl+3%HF 72.0 / 78.0 10%HEDP 31.4 / 88.0 饱和EDTA 16.6 / 39.5
下载: 导出CSV
表 6 酸液对砂岩和垢样的溶蚀能力评价
酸液体系 岩石类型 溶蚀率/% 0.5 h 1 h 1.5 h 2 h 2.5 h 3 h HCl∶HEDP∶EDTA=6∶3∶1 砂岩 / 垢样 9.3 / 42.8 11.4 / 62.2 14.2 / 78.8 18.5 / 82.6 21.5 / 85.2 22.2 / 86.3 HCl∶HEDP∶EDTA=6∶2∶2 10.6 / 40.3 12.4 / 59.1 15.7 / 75.2 19.8 / 80.9 22.5 / 83.5 23.1 / 84.8 HCl∶HEDP∶EDTA=6∶1∶3 11.7 / 45.2 13.6 / 61.6 17.5 / 76.3 20.5 / 81.2 22.8 / 84.4 23.6 / 85.7 HCl∶HEDP∶EDTA=7∶1∶2 9.2 / 40.8 11.9 / 56.4 16.9 / 75.8 19.7 / 80.3 22.3 / 83.2 23.5 / 83.4 HCl∶HEDP∶EDTA=7∶2∶1 10.1 / 41.2 12.8 / 56.0 16.6 / 76.1 20.5 / 79.2 23.7 / 82.0 24.1 / 82.2 HCl∶HEDP∶EDTA=8∶1∶1 13.3 / 38.6 17.4 / 53.2 21.2 / 72.8 25.5 / 75.6 28.8 / 79.8 29.5 / 80.2 HCl∶HEDP∶EDTA=9∶0∶1 13.5 / 43.8 18.7 / 62.2 23.0 / 77.8 26.6 / 82.6 30.1 / 85.2 30.6 / 85.6 HCl∶HEDP∶EDTA=9∶1∶0 13.3 / 44.3 18.2 / 62.6 22.5 / 78.1 26.0 / 82.2 29.5 / 84.8 30.1 / 85.3
下载: 导出CSV
表 7 螯合酸、盐酸和地层水中金属离子含量
配方 金属离子含量/ (mg·L−1) Ca2+ Al3+ Fe3+ 螯合酸 2678 917 1674 盐酸 573 37 71 地层水 3585 326 645
下载: 导出CSV
表 8 酸液解除岩心污染实验结果
岩心编号 孔隙度/% K1/mD K2/mD K3/mD K4/mD R/% M-1 14.86 66.0 42.9 40.3 67.9 101.8 M-2 13.77 25.3 5.5 5.2 26.8 105.9 M-3 18.46 70.7 40.3 38.3 72.3 102.3
下载: 导出CSV
-
[1] TAHA R, HILL A D, SEPEHRNOORI K. Simulation of sandstone-matrix acidizing in heterogeneous reservoirs[J]. Journal of Petroleum Technology, 1986, 38(7): 753-767. doi: 10.2118/13218-pa [2] ELMGERBI A, THONHAUSER G, FINE A, et al. Experimental approach for assessing filter-cake removability derived from reservoir drill-in fluids[J]. Journal of Petroleum Exploration and Production Technology, 2021, 11(11): 4029-4045. doi: 10.1007/s13202-021-01283-2 [3] LEONG V H, BEN MAHMUD H. A preliminary screening and characterization of suitable acids for sandstone matrix acidizing technique: a comprehensive review[J]. Journal of Petroleum Exploration and Production Technology, 2019, 9(1): 753-778. [4] 王庆, 周福建, 阳丹丹, 等. 强非均质砂岩清洁暂堵转向酸化研究: 以塔中志留系为例[J]. 钻井液与完井液, 2024, 41(5): 686-694.WANG Qing, ZHOU Fujian, YANG Dandan, et al. Study on temporary plugging diverted acidification in strong heterogeneous sandstone: A case study of the silurian in Tazhong[J]. Drilling Fluid&Completion Fluid, 2024, 41(5): 686-694 [5] SHAFIQ M U, MAHMUD H B. Sandstone matrix acidizing knowledge and future development[J]. Journal of Petroleum Exploration and Production Technology, 2017, 7(4): 1205-1216. doi: 10.1007/s13202-017-0314-6 [6] HERIANTO M. Improving effective porosity of rocks with matrix acidizing stimulation on sand stone formation[J]. The International Journal of Innovative Research and Development, 2018, 7(9): 282-292. [5]HERIANTO M. Improving effective porosity of rocks with matrix acidizing stimulation on sand stone formation[J]. The International Journal of Innovative Research and Development, 2018, 7(9): 282-292. [7] McCune C C, Ault J W, Dunlap R G. Reservoir properties affecting matrix acid stimulation of sandstones[J]. Journal of Petroleum Technology, 1975, 27(5): 633-640. [6]MCCUNE C C, AULT J W, DUNLAP R G. Reservoir properties affecting matrix acid stimulation of sandstones[J]. Journal of Petroleum Technology, 1975, 27(5): 633-640. [8] UCHENDU C, NWOKE L, AKINLADE O, et al. A new approach to matrix sandstone acidizing using a single step HF system: a niger delta case study[C]//the SPE Annual Technical Conference and Exhibition. San Antonio, Texas, USA: SPE, 2006: SPE-103041-MS. [7]UCHENDU C, NWOKE L, AKINLADE O, et al. A new approach to matrix sandstone acidizing using a single step HF system: a niger delta case study[C]//the SPE Annual Technical Conference and Exhibition. San Antonio, Texas, USA: SPE, 2006: SPE-103041-MS. [9] SMITH F C, HENDRICKSON A R. Hydrofluoric acid stimulation of sandstone reservoirs[J]. Journal of Petroleum Technology, 1965, 17(2): 215-222. doi: 10.2118/980-pa [10] WILLIAM C, GRANT G, CHOODESH A, et al. A sustainable approach to production increase in the zawtika field: sand control assisted with hydrofluoric acidizing[C]//the IADC/SPE Asia Pacific Drilling Technology Conference and Exhibition. Bangkok, Thailand: SPE, 2018: SPE-190975-MS. [11] SONG W, ZHANG K, FENG D Q. Study on stable loose sandstone reservoir and corresponding acidizing technology[J]. Coatings, 2024, 14(6): 667. doi: 10.3390/coatings14060667 [12] 滕学伟, 侯洪涛, 伊善利, 等. 老河口油田酸化充填防砂一体化工艺研究与应用[J]. 石油地质与工程, 2017, 31(3): 127-130. doi: 10.3969/j.issn.1673-8217.2017.03.034TENG Xuewei, HOU Hongtao, YI Shanli, et al. Research and application of integrated acidizing-packing sand control technology in Laohekou oilfield[J]. Petroleum Geology and Engineering, 2017, 31(3): 127-130. doi: 10.3969/j.issn.1673-8217.2017.03.034 [13] 杨龙, 孙宝峰, 何育雄, 等. 低渗砂岩油藏注水井缓速酸深部酸化技术研究[J]. 化学工程师, 2025, 39(5): 60-63,71.YANG Long, SUN Baofeng, HE Yuxiong, et al. Research on retarded acid deep acidification technology for injection wells in low-permeability sandstone reservoirs[J]. Chemical Engineer, 2025, 39(5): 60-63,71. [14] 刘成林, 任杨, 孙林, 等. 海上特低渗砂岩储层酸化增效技术研究与应用[J]. 石油机械, 2022, 50(9): 117-124. doi: 10.16082/j.cnki.issn.1001-4578.2022.09.016LIU Chenglin, REN Yang, SUN Lin, et al. Research and application of acidizing technology in offshore ultra-low permeability sandstone reservoir[J]. China Petroleum Machinery, 2022, 50(9): 117-124. doi: 10.16082/j.cnki.issn.1001-4578.2022.09.016 [15] 贾立新, 龚宁, 莘怡成, 等. 渤海蒸汽吞吐稠油油田出砂预测方法研究[J]. 石油化工应用, 2024, 43(8): 21-25. doi: 10.3969/j.issn.1673-5285.2024.08.004JIA Lixin, GONG Ning, SHEN Yicheng, et al. Study on sand production prediction method in Bohai steam huff and puff heavy oilfield[J]. Petrochemical Industry Application, 2024, 43(8): 21-25. doi: 10.3969/j.issn.1673-5285.2024.08.004 [16] 曹振博, 王龙. 油井出砂原因及防砂技术研究[J]. 石化技术, 2024, 31(7): 110-112.CAO Zhenbo, WANG Long. Research on sand producing reason and sand control technology of oil well[J]. Petrochemical Industry Technology, 2024, 31(7): 110-112. [17] 邱浩, 曹砚锋, 文敏, 等. 海上油气井防砂筛管冲蚀规律和失效预测研究[J]. 中国海上油气, 2023, 35(2): 155-162. doi: 10.11935/j.issn.1673-1506.2023.02.017QIU Hao, CAO Yanfeng, WEN Min, et al. Erosion law and failure prediction of sand control screen in offshore oil and gas wells[J]. China Offshore Oil and Gas, 2023, 35(2): 155-162. doi: 10.11935/j.issn.1673-1506.2023.02.017 -
