Preparation and Performance Study of an Octaamino Star-Shaped Low Molecular Weight Polymer Inhibitor
-
摘要: 目前使用的超支化多胺小分子抑制剂存在伯胺基团密度较低、在高pH值环境中抑制性不足等缺陷。针对此情况,以季戊四醇为原料,通过两步反应,制得了具有规整分子结构与高胺基密度的八胺基星形小分子(OASS)。分子模拟结果表明,OASS在黏土表面的吸附密度与季戊四胺(PTTA)、3,3-双(2-氨基乙基)-1,5-戊二胺(BAPD)差别不大,但单分子吸附能大幅高于PTTA、BAPD,表明3种多胺小分子在黏土表面的吸附中心均由胺基提供,且胺基密度高的OASS具有更强的吸附能力。吸附性能测定表明,OASS在25℃下的饱和吸附量只有1.12 mmol/L,达到饱和吸附量时所需的物质的量浓度仅为10 mmol/L。抑制黏土造浆、线性膨胀与滚动回收等室内实验结果表明,OASS对黏土与泥页岩岩屑造浆的抑制性能均显著优于PTTA与BAPD;与现场钻井液的配伍性实验表明,OASS不会影响钻井液老化前后的流变性能,且可改善降滤失性能,并提高泥页岩在钻井液中的滚动回收率。研究结果证明,OASS具有优异的抑制性能,且可与不同钻井液体系形成良好配伍。
-
关键词:
Abstract: The hyperbranched low molecular weight polyamine inhibitors presently in use have some deficiencies such as low density of primary amino groups and lack of inhibitive capacity in high pH environment. To overcome these deficiencies, an octaamino star-shaped low molecular weight polymer (OASS) with regular molecular structure and high density of amino groups was developed through twostep reaction with pentaerythritol as the raw material. Molecular simulation of OASS showed that the adsorption density of OASS on the surfaces of clays is almost the same as that of pentaerythrityltetramine (PTTA) and 3,3-bis(2-aminoethyl)-1,5-pentanediamine (BAPD), but the adsorption energy of a single molecule layer of OASS is significantly greater than that of PTTA and BAPD, indicating that the adsorption centers of the three polyamines on the clay surfaces are all provided by the amino groups, and OASS which has the highest amino group density has the highest adsorption capacity. Test on the adsorption capacity of OASS showed that at 25℃, the saturated adsorption capacity of OASS is only 1.12 mmol/L, and the molar concentration of OASS at saturated adsorption capacity I sonly 10 mmol/L. Laboratory experiment on the capacity of OASS in inhibiting clay yield and linear expansion, and in percent recovery of drilled cuttings in hot roller test showed that OASS is remarkably superior to PTTA and BAPD in inhibiting the yield of shale cuttings. Laboratory experiment also showed that OASS is compatible with filed drilling fluids and does not affect the rheology of the drilling fluids before and after aging. OSAA also helped improve the filtration control property of the drilling fluids. The results of the study have prove d that OASS has excellent inhibitive capacity and is well compatible with different drilling fluids. -
[1] 张馨, 邱正松, 钟汉毅, 等. 新型超高温页岩抑制剂特性实验研究[J]. 钻井液与完井液, 2017, 34(1):9-15. ZHANG Xin, QIU Zhengsong, ZHONG Hanyi, et al. Experimental study on a new ultrahigh temperature shale inhibitor[J]. Drilling Fluid & Completion Fluid,2017, 34(1):9-15 [2] ZHONG Hanyi, QIU Zhengsong, SUN Dong, et al. Inhibitive properties comparison of different polyetheramines in water-based drilling fluid[J]. Journal of Natural Gas Science and Engineering, 2015, 26:99-107. [3] ZHONG Hanyi, QIU Zhengsong, HUANG Weian, et al. Shale inhibitive properties of polyether diamine in waterbased drilling fluid[J]. Journal of Natural Gas Science and Engineering, 2011, 78:510-515. [4] XIE Gang, LUO Pingya, DENG Mingyi, et al. Investigation of the inhibition mechanism of the number of primary amine groups of alkylamines on the swelling of bentonite[J]. Applied Clay Science, 2017, 136:43-50. [5] XIE Gang, LUO Pingya, DENG Mingyi, et al. Intercalation behavior of branched polyethyleneimine into sodium bentonite and its effect on rheological properties[J]. Applied Clay Science, 2017, 141:95-103. [6] XIE Gang, LUO Pingya, DENG Mingyi, et al. Investigating the role of alkyl chain length of the inhibitors on its intercalation inhibiting mechanism in sodium montmorillonite[J]. Energy & Fuels, 2019, 33(6):5182-5190. [7] 潘一, 廖松泽, 杨双春, 等. 耐高温聚胺类页岩抑制剂的研究现状[J]. 化工进展,2020, 39(2):686-695.PAN Yi, LIAO Songze, YANG Shuangchun, et al. Research on high temperature resistant polyamine shale inhibitors[J]. Chemical Industry and Engineering Progress, 2020, 39(2):686-695. [8] 马京缘, 潘谊党,于培志, 等. 近十年国内外页岩抑制剂研究进展[J]. 油田化学, 2019, 36(1):181-187.MA Jingyuan, PAN Yidang, YU Peizhi, et al. Research progress on shale inhibitors at home and abroad in recent ten years[J]. Oilfield Chemistry, 2019, 36(1):181-187. [9] 宣扬, 蒋官澄, 宋然然, 等. 超支化聚乙烯亚胺作为钻井液页岩抑制剂研究[J]. 中国石油大学学报(自然科学版),2017, 41(6):178-186.XUAN Yang, JIANG Guancheng, SONG Ranran, et al. Study on hyper-branched poly(ethyleneimine) as shale inhibitor in water-based drilling fluid[J]. Journal of China University of Petroleum(Edition of Natural Science), 2017, 41(6):178-186. [10] 宋然然, 蒋官澄, 宣扬, 等. 超支化聚乙烯亚胺作为高效水基钻井液页岩抑制剂的研究[J]. 油田化学, 2017, 34(3):390-396.SONG Ranran, JIANG Guancheng, XUAN Yang, et al. Hyper-branched polyethyleneimine using as efficient shale inhibitor for water-based drilling fluid[J]. Oilfield Chemistry, 2017, 34(3):390-396. [11] 汤志川, 邱正松,钟汉毅, 等. 新型聚酰胺-胺树枝状聚合物页岩抑制特性研究[J]. 钻井液与完井液, 2016, 33(6):28-32.TANG Zhichuan, QIU Zhengsong, ZHONG Hanyi, et al. Shale inhibition characteristics of a new polyamide-amine dendrimer[J]. Drilling Fluid & Completion Fluid, 2016, 33(6):28-32. [12] ZHONG Hanyi, QIU Zhengsong, ZHANG Daoming, et al. Inhibiting shale hydration and dispersion with amine-terminated polyamidoamine dendrimers[J]. Journal of Natural Gas Science and Engineering, 2016, 28:52-60. [13] 钟汉毅, 邱正松, 黄维安, 等. PAMAM树枝状聚合物抑制泥页岩水化膨胀和分散特性[J]. 中南大学学报(自然科学版), 2016, 47(12):4132-4139.ZHONG Hanyi, QIU Zhengsong, HUANG Wei'an, et al. Properties of PAMAM dendrimers in inhibiting shale hydration and dispersion[J]. Journal of Central South University(Science and Technology),2016, 47(12):4132-4139. [14] 李龙, 马茶, 苑旭波, 等. 树枝状聚合物的合成及其在油田化学中的应用[J]. 现代化工, 2012, 32(6):16-21.LI Long, MA Cha, YUAN XuBo, et al. Synthesis and application of dendrimers in oilfield chemistry[J]. Modern Chemical Industry, 2012, 32(6):16-21. [15] TEIXEIRA G T,LOMBA R F T,FRANCISCO A D S, et al. Hyperbranched polyglycerols obtained from environmentally benign monomer as reactive clays inhibitors for water-based drilling Fluids[J]. Journal of Applied Polymer, 2014, 131(12):2-7. [16] 魏运洋, 邵云. 季戊四胺的改良合成[J]. 含能材料, 2002, 10(2):49-51.WEI Yunyang, SHAO Yun. An improved synthesis of pentaerythrityl tetramine[J]. Energetic Materials, 2002, 10(2):49-51. [17] 谭勇. 季戊四胺及衍生物多烯类酰胺单体的合成[D]. 保定:河北大学, 2008. TAN Yong. Synthesis of pentaerythramide and its derivatives polyene amide monomers[D]. Baoding Hebei University, 2011. [18] 董艳飞. 促智药普拉西坦及其中间体N,N-二异丙基乙二胺的合成[D]. 天津:天津大学, 2007. DONG Yanfei. Synthesis of the nootropic drug pramiracetam and its intermediate N,N-diisopropy lethylenediamine[D]. Tianjin:Tianjin University, 2007. [19] 郭文宇, 彭波,操卫平, 等. 钻井液用低聚胺类页岩抑制剂的结构与性能[J]. 钻井液与完井液, 2014, 32(1):26-29.GUO Wenyu, PENG Bo, CAO Weiping, et al. Molecular structure and performance of oligomeric amine shale inhibitor[J]. Drilling Fluid & Completion Fluid, 2015, 32(l):26-29.
