基于改性植物多酚的高温高密度环保型水基钻井液

刘自广; 宋丰博; 尤志良; 卓绿燕; 彭云涛; 项春芬; 蒋官澄

doi:10.3969/j.issn.1001-5620.2021.03.004

基于改性植物多酚的高温高密度环保型水基钻井液

doi: 10.3969/j.issn.1001-5620.2021.03.004

1. 中石化中原石油工程有限公司钻井二公司, 河南濮阳 475001;
2. 大港油田石油工程研究院, 天津 300280;
3. 中国石油长城钻探工程有限公司钻井液公司, 辽宁盘锦 124200;
4. 渤海钻探第五钻井工程分公司, 河北河间 062465;
5. 中国石油大学(北京)石油工程学院, 北京 102249

详细信息

作者简介:

中图分类号: TE254.3
计量
- 文章访问数: 543
- HTML全文浏览量: 136
- PDF下载量: 81
- 被引次数: 0
出版历程
- 收稿日期: 2021-02-07

A high-temperature and High-Density Environmentally-Friendly Water-Based Drilling Fluids Based on Modified Plant Polyphenols

1. The Second Drilling Company of Sinopec Zhongyuan Oilfield Service Corporation, Puyang, Henan 475001;
2. Research Institute of Petroleum Engineering, PetroChina Dagang Oilfield Company, Tianjin 300280;
3. China Petroleum Drilling Fluid, A Branch of GWDC, CNPC, Panjin, Liaoning 124200;
4. No. 5 Drilling Engineering Company, BHDC, Hejian, Hebei 062465;
5. College of Petroleum Engineering, China University of Petroleum, Beijing 102249

摘要

摘要: 为提高环保型水基钻井液的耐温性能和密度上限，通过对天然多酚类植物提取物进行接枝改性，分别研制了降滤失剂EHT-FL和分散剂EHT-TH，并利用红外光谱对2种合成产物进行了表征。室内性能评价结果表明，降滤失剂EHT-FL和分散剂EHT-TH均具有良好的抗高温性能，且EC₅₀分别达2.38×10⁵ mg/L和4.49×10⁵ mg/L，无生物毒性；EHT-FL加量为2.0%时，淡水基浆在200℃老化后的中压滤失量和高温高压滤失量分别为7.2 mL和23.6 mL；EHT-TH加量为1.0%时，高密度水基钻井液（ρ=2.0 g/cm³）在200℃老化后的表观黏度由106.5 mPa·s降低至66.5 mPa·s，高温增稠现象消失。在降滤失剂EHT-FL和分散剂EHT-TH的基础上，配伍其他环境友好型处理剂，研制出一套抗高温高密度（ρ=2.0 g/cm³）环保型水基钻井液体系。该体系具有合理的流变与滤失性能，抗温达210℃，抗盐侵25%，抗钙侵1%，抗劣质土侵10%，EC₅₀为4.19×104 mg/L，BOD₅/COD_Cr为29.23，重金属含量低于标准值，对环境友好，能满足深井复杂地层钻井的需求。
- 水基钻井液 /
- 高温 /
- 高密度 /
- 降滤失剂 /
- 分散剂 /
- 植物多酚 /
- 环境保护
Abstract: To improve the high-temperature resistance and density upper limit of environmentally friendly water-based drilling fluids, the fluid-loss reducer EHT-FL and the thinner EHT-TH were developed by modifying plant extracts of natural polyphenol. Two synthesized products were characterized by infrared spectroscopy. In laboratory experiments, the fluid-loss reducer EHT-FL and the thinner EHT-TH exhibited good high-temperature resistance. And the EC₅₀ reached 2.38×10⁵ mg/L and 4.49×10⁵ mg/L, respectively, with no biological toxicity. The medium-pressure and high-temperature/high-pressure fluid-loss of freshwater-based mud with 2.0% EHT-FL are only 7.2 mL and 23.6 mL after aging at 200℃. When the dosage of EHT-TH is 1.0%, the apparent viscosity of high-density water-based drilling fluid (ρ=2.0 g/cm³) after aging at 200℃ decreases from 106.5 mPa·s to 66.5 mPa·s, and the high-temperature thickening phenomenon disappears. Based on the excellent temperature-resistance of EHT-FL and EHT-TH, a high-temperature and high-density (ρ=2.0 g/cm³) environmentally friendly water-based drilling fluid has been developed. This drilling fluid has reasonable rheological and fluid-loss properties. It has high-temperature resistance of 210℃ and resistance to 25% salt contamination, 1% calcium contamination, and 10% inferior soil contamination. EC₅₀ of this drilling fluid is 4.19×104 mg/L, BOD₅/COD_Cr is 29.23, heavy metal content is lower than the standard value, non-toxic, biodegradable. Therefore, this environmentally friendly drilling fluid can meet the drilling needs of deep-wells complex formations.
- Water-based drilling fluid /
- High temperature /
- High density /
- Fluid loss reducer /
- Dispersant /
- Plant polyphenols /
- Environmental protection

HTML全文

参考文献(19)

[1]	马永生,蔡勋育,赵培荣. 深层、超深层碳酸盐岩油气储层形成机理研究综述[J]. 地学前缘,2011,18(4):181-192. MA Yongsheng,CAI Xunyu,ZHAO Peirong. The research status and advances in porosity evolution and diagenesis of deep carbonate reservoir[J].Earth Science Frontiers,2011,18(4):181-192.
[2]	常晓峰,孙金声,吕开河,等. 一种新型抗高温降滤失剂的研究和应用[J]. 钻井液与完井液,2019,36(4):420-426. CHANG Xiaofeng, SUN Jinsheng, LYU Kaihe, et al. Research and application of a novel high temperature filter loss reducer[J]. Drilling Fluid & Completion Fluid, 2019,36(4):420-426.
[3]	范胜,周书胜,方俊伟,等. 高温低密度油基钻井液体系室内研究[J]. 钻井液与完井液,2020,37(5):561-565. FAN Sheng,ZHOU Shusheng,FANG Junwei,et al. Laboratory study on high temperature low density oil base drilling fluids[J].Drilling Fluid & Completion Fluid, 2020,37(5):561-565.
[4]	王立锋,王杰东,冯纪成,等. 塔河油田超深定向井KCl-阳离子乳液聚磺钻井液技术[J]. 石油钻探技术, 2012,40(3):73-77. WANG Lifeng,WANG Jiedong,FENG Jicheng,et al. KCl-cationic emulsion polymer-sulfonate drilling fluid for ultra-deep directional well in Tahe oilfield[J]. Petroleum Drilling Techniques,2012,40(3):73-77.
[5]	周启成,单海霞,位华,等. 环保型生物质合成树脂降滤失剂[J]. 钻井液与完井液,2020,37(5):593-596. ZHOU Qicheng,SHAN Haixia,WEI Hua,et al. A synthetic resin filter loss reducer made from environmentally friendly biomasses[J].Drilling Fluid & Completion Fluid,2020,37(5):593-596.
[6]	夏景刚,史野,左洪国,等. 一种环保型抗高温钻井液技术[J]. 钻井液与完井液,2020,37(1):59-63. XIA Jinggang,SHI Ye,ZUO Hongguo, et al. An environmentally friendly high temperature drilling fluid technology[J].Drilling Fluid & Completion Fluid,2020, 37(1):59-63.
[7]	吴鑫磊,闫丽丽,王立辉,等. 环保型钻井液用降滤失剂研究进展[J]. 钻井液与完井液,2018,35(3):8-16. WU Xinlei,YAN Lili, WANG Lihui,et al. Progress in the study of environmentally friendly drilling fluid filtration reducer[J]. Drilling Fluid & Completion Fluid, 2018,35(3):8-16.
[8]	王伟吉. 抗温环保纳米纤维素降滤失剂的研制及特性[J]. 钻井液与完井液,2020,37(4):421-426. WANG Weiji. Development and characteristics of a high temperature environmentally friendly nanocellulose filter loss reducer[J].Drilling Fluid & Completion Fluid, 2020,37(4):421-426.
[9]	张耀元,马双政,陈金定,等. 抗高温改性淀粉降滤失剂的制备与性能[J]. 钻井液与完井液,2019,36(6):694-699. ZHANG Yaoyuan, MA Shuangzheng, CHEN Jinding, et al. Preparation and performance of a high temperature modified starch filter loss reducer[J].Drilling Fluid & Completion Fluid,2019,36(6):694-699.
[10]	陈思琪,邱正松,钟汉毅,等. 钻井液用淀粉微球降滤失剂的制备及性能评价[J]. 钻井液与完井液,2019, 36(4):414-419. CHEN Siqi,QIU Zhengsong,ZHONG Hanyi,et al. Preparation and performance evaluation of a drilling fluid microspherestarch filter loss reducer[J]. Drilling Fluid & Completion Fluid,2019,36(4):414-419.
[11]	张洁,景云天,朱宝忠,等. 复合植物酚改善淀粉类钻井液处理剂的抗温性能[J]. 钻井液与完井液,2020, 37(3):288-293. ZHANG Jie,JING Yuntian,ZHU Baozhong,et al. Improve high temperature performance of drilling starch with compound phytophenol[J].Drilling Fluid & Completion Fluid,2020,37(3):288-293.
[12]	张礼华, 胡人峰, 沈青. 植物多酚在高分子材料中的应用研究进展[J]. 高分子通报,2007(8):50-56. ZHANG Lihua,HU Renfeng, SHEN Qing. Application of plant polyphenols in polymer materials[J]. Chinese Polymer Bulletin,2007(8):50-56.
[13]	杨丽丽,杨潇,蒋官澄,等. 含离子液体链段抗高温高钙降滤失剂[J]. 钻井液与完井液,2018,35(6):8-14. YANG Lili,YANG Xiao,JIANG Guancheng, et al.A high temperature calcium resistant filter loss reducer containing ionic liquid segments[J].Drilling Fluid & Completion Fluid,2018,35(6):8-14.
[14]	YANG Lili,JIANG Guancheng,SHI Yawei,et al. Application of ionic liquid to a high-performance calciumresistant additive for filtration control of bentonite/waterbased drilling fluids[J]. Journal of Materials Science, 2017,52(11):6362-6375.
[15]	陶怀志. 抗高温抗盐钙水基钻井液降滤失剂合成、表征与作用机理研究[D]. 成都:西南石油大学,2012. TAO Huaizhi. Synthesis,characterization and mechanism of high temperature,salt and calcium-resistant waterbased drilling fluid additive[D].Chengdu:Southwest Petroleum University,2012.
[16]	HUANG Weian,ZHAO Cong,QIU Zhengsong,et al. Synthesis,characterization and evaluation of a quadripolymer with low molecular weight as a water based drilling fluid viscosity reducer at high temperature (245℃)[J]. Polymer International,2015,64(10):1352-1360.
[17]	黄维安,邱正松,徐加放,等. 超高温抗盐聚合物降滤失剂的研制及应用[J]. 中国石油大学学报(自然科学版),2011,35(1):155-158. HUANG Weian,QIU Zhengsong,XU Jiafang,et al. Development and application of ultra-high temperature anti-salt polymer fluid loss reducer[J]. Journal of China University of Petroleum,2011,35(1):155-158.
[18]	王成文,王桓,薛毓铖,等. 高密度水泥浆高温沉降稳定调控热增黏聚合物研制与性能[J]. 石油学报, 2020,41(11):128-136. WANG Chengwen,WANG Huan,XUE Yucheng,et al. Development and performance of thermo-viscosifying polymer for high temperatire sedimentation control of high-density cement slurry[J]. Acta Petrolei Sinica, 2020,41(11):128-136.
[19]	蒋官澄,刘凡,任妍君,等. 抗高温抗高钙降滤失剂DF-1的研制与评价[J]. 油田化学,2015,32(1):1-6. JIANG Guancheng,LIU Fan,REN Yanjun,et al. Preparation and evaluation of high temperature- and high calcium-resistant fluid loss additive DF-1[J].Oilfield Chemistry,2015,32(1):1-6.
