Equipment and Methods of Measuring High Temperature Rheology of Drilling Fluids
-
摘要: 高温深井钻井,井下钻井液高温流变性能好坏直接关系到井眼的安全和钻井的成败,但六速黏度计无法测试钻井液在井底随着温度、压力、剪切速率、时间等参数的变化,流变性能是如何变化的,通过高温高压流变仪评价钻井液的流变和抗温性能是一种科学而有效的评价手段。为模拟井下实际钻井液性能,建立了低剪切速率黏度测试、高温下黏度损失率测试、钻井液动态循环和静置时黏度随时间变化的测试方法,表征了钻井液的携岩性能、抗温流变性能、钻井液循环和静置条件下的高温热稳定性能,反映出了井下真实流变性能。在埕探1井进行了现场试验,说明该测试方法可以为现场工程师分析判断钻井液在井下高温下的性能能否为钻井施工提供实验数据,为高温钻井液体系优化设计、处理剂研发和应用提供科学可靠实验方法,并极大程度上弥补用六速黏度计测试钻井液流变性能的不足和缺陷。
-
关键词:
Abstract: Since the six-speed direct reading viscometer is unable to measure the change of mud rheology with downhole temperature, downhole pressure, downhole shear rate and time, drilling fluid researchers turn to the high temperature high pressure (HTHP) rheometer for evaluating the rheology and thermal stability of drilling fluids, hoping that it will give more scientific and effective test results. To simulate the actual mud properties downhole, several test methods are established, which are test of low shear rate viscosity, test of loss of viscosity at high temperatures and test of changes of mud viscosity with time at dynamic and static conditions. These tests are used to characterize the cuttings carrying capacity, rheology at elevated temperatures and high temperature stability of drilling fluids at dynamic and static conditions, the test results can reveal the actual rheology of the drilling fluids downhole. Field application of the HTHP rheometer in testing the properties of the organic salt drilling fluid used in drilling the well Chengtan-1 indicated that the test method can be used to provide field engineers with accurate data for judging whether the mud properties can meet the requirements of drilling operation under high bottomhole temperatures. The test method and the HTHP rheometer have provided a scientific and reliable way of designing, developing and using high temperature drilling fluids and mud additives, and greatly made up for the shortcomings and defects of using the six-speed viscometer to measure the rheology of drilling fluids. -
[1] 卜海,孙金声,王成彪,等.超高温钻井液的高温流变性研究[J]. 西南石油大学学报:自然科学版,2012, 34(4):122-126.BU Hai, SUN Jinsheng, WANG Chengbiao, et al.Study on the rheological properties of ultra-high temperature drilling fluids[J].Journal of Southwest Petroleum University:Science & Technology Edition,2012,34(4):122-126. [2] JOHN LEE, ARASH SHADRAVAN, STEVE YOUNG. Rheological properties of invert emulsion drilling fluid under extreme HPHT conditions[C] //2012 Drilling Conference and Exhibition, San Diego, California, USA Town & Country Resort & Convention Center:The Conference, 2012:1-9. [3] MAHMOOD AMANI, MOHAMMED AL-JUBOURI. An experimental investigation of the effects of ultra-high pressure and temperature on the rheological properties of water-based drilling fluids[C] //Protecting people and the environment-evolving challenges:Society of Petroleum Engineers,2012:1-9. [4] ROBERT SCHLEMMER, GARY PHOON. A new generation associative polymer extends temperature stability of deepwater drilling fluid[C] //2011 SPE International Petroleum Technology Conference.:Society of Petroleum Engineers, 2011:1-13. [5] KAY A GALINDO, WEIBIN ZHA, HUI ZHOU. High temperature, high performance water-based drilling fluid for extreme high temperature wells[C] //Society of Petroleum Engineers International Symposium on Oilfield Chemistry:The Woodlands, Texas, USA:Society of Petroleum Engineers, 2015:1-9. [6] 刘晓栋,朱红卫,高永会.海洋超高温高压井钻井液设计与测试方法及国外钻井液新技术[J]. 石油钻采工艺,2014,36(5):47-52.LIU Xiaodong,ZHU Hongwei,GAO Yonghui.Drilling fluid design and test method for offshore ultra-HTHP wells and new drilling fluid technology abroad[J].Oil Drilling & Production Technology,2014,36(5):47-52. [7] 赵建刚,赵锴,韩天夫,等.超高温高压流变仪的研制与应用[J]. 钻井液与完井液,2019,36(3):333-337.ZHAO Jiangang, ZHAO Kai, HAN Tianfu, et al. Development and application of an ultra-high temperature ultra-high pressure rheometer[J]. Drilling Fluid & Completion Fluid, 2019,36(3):333-337. [8] 赵怀珍,薛玉志,李公让,等.抗高温水基钻井液超高温高压流变性研究[J]. 石油钻探技术,2009,37(1):5-9.ZHAO Huaizhen,XUE Yuzhi,LI Gongrang,et al. Rheological properties of high-temperature water based drilling fluids at high temperature and high pressure[J]. Petroleum Drilling Techniques,2009,37(1):5-9. [9] RYAN EZELL,DOUGLAS J, HARRISON. Design of improved high-density, thermally-stable drill-in fluid for HTHP applications[C] //ATCE 2008:Society of Petroleum Engineers,2008:1-9.
