Molecular Simulation of the Hydration of Montmorillonite under High-temperature and Highpressure
-
摘要: 页岩中黏土矿物的水化膨胀是影响页岩气井井壁稳定性的一个重要因素,蒙脱石作为黏土矿物的主要成分,其水化机理对于解决页岩气井井壁失稳问题至关重要。为了深入探索高温高压地层环境下蒙脱石的水化机理,利用分子模拟软件从微观角度研究了不同水化程度的蒙脱石在不同温度压力条件下的晶层间距、晶层间物质的移动规律、离子水化参数以及力学参数的变化。研究结果表明:温度增加、压力降低时,蒙脱石层间距随之增加,且温度对层间距的影响较大,层间距范围在1.823~2.042 nm之间;层间水分子和钠离子的扩散速率随温度增加而加快,随压力升高而减慢;低温高压时钠离子的水化配位数较大,配位数范围在2.35~4.35之间;温度增加时,蒙脱石晶体的体积模量、剪切模量以及弹性模量随之减小,泊松比随之增加,而压力对蒙脱石晶体力学参数的影响却恰恰相反。可见,本文的研究结果对于高温高压地层环境下页岩地层水化机理的研究具有重要的理论指导意义。
-
关键词:
Abstract: The hydration expansion of clay minerals in shale is an important factor affecting the sidewall stability of shale gas well. The montmorillonite is the main constituent of clay minerals, and its hydration mechanism is very important to solve the problem of borehole wall instability in shale gas well. In order to further explore the hydration mechanism of the montmorillonite under high temperature and high pressure, molecular simulation software was used to study the inter-layer spacing, inter-layer material movement, ionic hydration properties and mechanical parameters of the montmorillonite under different temperature and pressure conditions from a microscopic perspective. The results show that when the temperature increases and the pressure decreases, the inter-layer spacing of montmorillonite augments, and relatively the temperature has a great influence on the inter-layer spacing, which ranges from 1.823-2.042 nm. The diffusion rate of inter-layer water molecules and sodium ions increases with the increase of temperature and decreases with the increase of pressure. The hydration coordination number of sodium ion is large at low temperature and high pressure, and the coordination number varies from 2.35 to 4.35. When the temperature goes up, the volume modulus, shear modulus and elastic modulus of montmorillonite crystal goes down and poisson's ratio increases, while the effect of pressure on the mechanical parameters of montmorillonite crystal is the opposite. It can be seen that the research results of this paper have important theoretical guiding significance for the research of shale formation hydration mechanism under high temperature and high pressure formation environment.-
Key words:
- Montmorillonite /
- Hydration /
- Molecular simulations /
- High temperature /
- High pressure /
- Mechanical parameters
-
[1] 邓虎. 裂缝性泥页岩的水化稳定性研究及其应用[D]. 成都:西南石油学院,2004.DENG Hu. Study on hydration stability of fractured shale and its application[D]. Chengdu:Southwest petroleum College,2004. [2] SKIPPER N T,SPOSITO G,CHANG F R C. Monte Carlo simulation of interlayer molecular structure in swelling clay minerals. 2. monolayer hydrates[J]. Clays and Clay Minerals,1995,43(3):294-303. [3] CHANG F R C, SKIPPER N T,SPOSITO G. Monte Carlo and molecular dynamics simulations of electrical doublelayer structure in potassium montmorillonite hydrates[J]. Langmuir,1998,14(5):1201-1207. [4] GREATHOUSE J,SPOSITO G. Monte Carlo and Molecular Dynamics Studies of Interlayer Structure in Li (H2O)3-Smectites[J]. The Journal of Physical Chemistry B, 1998,102(13):2406-2414. [5] PARK S H,SPOSITO G. Monte Carlo simulation of total radial distribution functions for interlayer water in Li-, Na-,and k-montmorillonite hydrates[J]. The Journal of Physical Chemistry B,2000, 104(19):4642-4648. [6] HENSEN E J M,SMIT B. Why clays swell[J]. The Journal of Physical Chemistry B,2002,106(49):12664-12667. [7] 王进,曾凡桂,王军霞. 锂,钠,钾水化蒙脱石层间结构的分子动力学模拟[D]. 太原:太原理工大学,2006.WANG Jin,ZEN Fangui,WANG Junxia. Molecular dynamics simulation of Li,Na,K hydrated montmorillonite interlamellar structure[D]. Taiyuan:Taiyuan Science & Technology University,2006. [8] 徐加放,孙泽宁,刘洪军,等. 分子模拟无机盐抑制蒙脱石水化机理[J]. 石油学报,2014, 35(2):377-384.XU Jiafang,SUN Zening,LIU Hongjun,et al. Molecular simulation for inorganic salts inhibition mechanism on montmorillonite hydration[J]. Acta Petrolei Sinica,2014,35(2):377-384. [9] 张亚云,陈勉,邓亚,等. 温压条件下蒙脱石水化的分子动力学模拟[J]. 硅酸盐学报,2018(10):22.ZHANG Yayun,CHENG Mian,DENG Ya,et al. Molecular dynamics simulation of montmorillonite hydration under temperature and pressure[J]. Journal of the Chinese Ceramic Society,2018(10):22. [10] CYGAN R T,LIANG J J,KALINICHEV A G. Molecular models of hydroxide,oxyhydroxide,and clay phases and the development of a general force field[J].The Journal of Physical Chemistry B, 2004,108(4):1255-1266. [11] SKIPPER N T, SPOSITO G, CHANG F C. Monte Carlo simulation of interlayer molecular structure in swelling clay minerals.2. Monolayer hydrates[J]. Clays Clay Minerals, 1995, 43(3):294-303. [12] LOEWENSTEIN W. The distribution of aluminum in the tetrahedra of silicates and aluminates[J]. American Mineralogist Journal of Earth and Planetary Materials, 1954,39(1-2):92-96. [13] ZHENG Y,ZAOUI A,SHAHROUR I. A theoretical study of swelling and shrinking of hydrated Wyoming montmorillonite[J]. Applied Clay Science,2011,51(1-2):177-181. [14] SAMOLETOV A A,DETTMANN C P,CHAPLAIN M A J. Thermostats for "slow" configurational modes[J]. Journal of Statistical Physics,2007,128(6):1321-1336. [15] FRENKEL D,SMIT B. Understanding molecular simulation from algorithms to applications[M]. Elsevier,2001. [16] SHAHRIYARI R,KHOSRAVI A,AHMADZADEH A. Nanoscale simulation of Na-Montmorillonite hydrate under basin conditions,application of CLAYFF force field in parallel GCMC[J]. Mol Phys,2013,111(20):3156-3167. [17] DE PABLO L,CHÁVEZ M L,DE PABLO J J. Stability of Na-,K-,and Ca-montmorillonite at high temperatures and pressures:a Monte Carlo simulation[J]. Langmuir,2005,21(23):10874-10884. [18] ZHENG Y,ZAOUI A. How water and counterions diffuse into the hydrated montmorillonite[J]. Solid State Ionics,2011,203(1):80-85.
