抗盐高性能水泥浆体系研究与应用

丹美涵

doi:10.3969/j.issn.1001-5620.2021.02.020

抗盐高性能水泥浆体系研究与应用

doi: 10.3969/j.issn.1001-5620.2021.02.020

丹美涵

中海油研究总院有限责任公司, 北京 100028

详细信息

作者简介:
丹美涵,工程师,1987年生,硕士毕业于南开大学高分子化学专业,主要从事钻采技术与工程规划研究。E-mail:danmh@cnooc.com.cn

中图分类号: TE256.6
计量
- 文章访问数: 591
- HTML全文浏览量: 166
- PDF下载量: 38
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-11

Study and Application of a High-Performance Salt-Resistant Cement Slurry

DAN Meihan

CNOOC Research Institute Company Limited, Beijing 100028

摘要

摘要: 伊拉克米桑油田井底普遍存在高压盐膏层，由于盐层蠕变致使井径缩小、冲蚀和溶解盐层导致水泥浆含盐量越来越高、密度窗口窄、顶替效率低等难点给固井质量带来挑战。针对目前常用的半饱和NaCl溶液或者（3%～5%） KCl溶液配浆存在的水泥石抗压强度低，界面胶结差的问题，优选含有25% NaCl和5% KCl高盐混合水配制水泥浆，配套抗盐降失水剂、分散剂、缓凝剂等外加剂，解决了因高盐混合水配浆可能带来的水泥浆增稠、触变等问题，构建了一种抗盐高性能水泥浆体系。室内研究表明，该套水泥浆体系能抑制盐的溶解，配制密度为2.39 g/cm³的水泥浆，最低只需加入30%铁矿粉，在降低水泥浆成本的同时大幅度提高了水泥石的抗压强度，使其24 h抗压强度可达48 MPa，较目前应用水平提高近一倍；水泥浆污染后24 h强度依然大于14 MPa，能够保证米桑油田盐膏层固井质量，可在伊拉克米桑油田推广应用。
- 米桑油田 /
- 盐膏层 /
- 抗盐水泥浆 /
- 胶结性能
Abstract: High-pressure salt and gypsum beds prevail in the Missan Oilfield in Iraq. In well cementing, tight hole resulting from the creeping of salt layers, increasing salinity of cement slurries from hole washout and salt dissolution, narrow drilling window and reduced displacing efficiency pose challenges to the well cementing jobs. Cement slurries formulated with semi-saturated NaCl solution and 3%-5% KCl solution are widely used presently and have the shortages of low compressive strength of set cement and poor bonding between casing string and cement sheath and between cement sheath and bore hole wall. To solve these problems, a cement slurry was formulated with a slat solution containing 25% NaCl and 5% KCl, and other additives of choice, such as filter loss reducer, dispersant and retarder. As a high-performance salt-resistant cement slurry, it is free from the high rheology and high thixotropy previously encountered when cement slurries are brought into contact with salt. Laboratory study showed that this cement slurry is able to inhibit the dissolution of salt. A cement slurry of 2.39 g/cm³ can be made with only 30% hematite at a minimum, which not only saves money, but also greatly improves the compressive strength of the set cement. The 24-hour compressive strength of this cement slurry is 48 MPa, almost doubling the compressive strengths of the set cement of cement slurries presently in use. The 24-hour compressive strength of the cement slurry being contaminated is still greater than 14 MPa. These characteristics of the new cement slurry satisfy the needs of cementing the salt and gypsum beds in the Missan Oilfield, Iraq, making the cement slurry worth spreading in this oilfield.
- Missan oilfield /
- Salt and gypsum beds /
- Salt-resistant cement slurry /
- Bonding performance

HTML全文

参考文献(22)

[1]	BILL HUNTER, FARZAD TAHMOURPOUR, RONNIE FAUL. Cementing casing strings across salt zones:An overview of global best practices[J]. SPE Drilling & Completion, 2010, 25(4):426-437.
[2]	薛雷, 杨海席, 王长月, 等. 高压盐膏层固井技术研究及在伊拉克米桑油田的应用[J]. 内蒙古石油化工, 2016, 42(7):77-81. XUE Lei, YANG Haixi, WANG Changyue, et al. Research on cementing technology of high pressure saltpaste layer and its application in Misan oil field in Iraq[J]. Inner Mongolia Petrochemical Industry, 2016, 42(7):77-81.
[3]	蒋凯, 罗宇维, 史元, 等. M油田高压盐膏层固井技术研究与应用[J].中国海上油气, 2013, 25(3):44-49. JIANG Kai, LUO Yuwei, SHI Yuan, et al. Research and application of cementing technology for high pressure salt-gypsum layers in M oilfield[J]. China Offshore Oil and Gas, 2013, 25(3):44-49.
[4]	张春涛. 盐膏层固井技术及应用[J]. 钻采工艺, 2008(3):146-148. ZHANG Chuntao. Cementing technology and application of salt-paste layer[J]. Drilling & Production Technology, 2008 (3):146-148.
[5]	胡勤峰, 杨建政, 刘海龙. 伊拉克M油田盐膏层固井技术与实践[J]. 石油地质与工程, 2020, 34(1):99-102. HU Qinfeng, YANG Jianzheng, LIU Hailong. Cementing technology and practice of salt gypsum layers in Iraq M oilfield[J]. Petroleum Geology and Engineering, 2020, 34(1):99-102.
[6]	许前富, 罗宇维, 冯克满, 等. 一种高密度盐膏层固井水泥浆的研究及应用[J]. 钻井液与完井液, 2014, 31(1):68-71. XU Qianfu, LUO Yuwei, FENG Keman, et al. Research and application of high density cement slurry on salt/gypsum formation[J]. Drilling Fluid & Completion Fluid, 2014, 31(1):68-71.
[7]	聂臻, 许岱文, 邹建龙, 等.HFY油田高压盐膏层固井技术[J]. 石油钻采工艺, 2015, 37(6):39-43. NIE Zhen, XU Daiwen, ZOU Jianlong, et al. Cementing technology for high-pressure salt-anhydrate bed in HFY oilfield[J]. Oil Drilling & Production Technology, 2015, 37(6):39-43.
[8]	彭雷, 许明标. 盐膏层固井用抗温抗盐低滤失聚合物盐水水泥浆体系研究[J]. 石油天然气学报, 2008(2):550-552. PENG Lei, XU Mingbiao. Study on low filtration polymer brine cement slurry system with temperature resistance and salt resistance for cementing salt-paste layer[J]. Journal of Oil and Gas Technology, 2008 (2):550-552.
[9]	袁欢,秦江.高密度盐膏层固井水泥浆的研究及应用[J].中国石油和化工标准与质量, 2017, 37(5):67-68. YUAN Huan, QI Jiang. Research and application of high density salt-paste well cementing slurry[J]. China Petroleum and Chemical Standard and Quality, 2017, 37(5):67-68.
[10]	赵艳. 抗盐水泥浆外加剂的研制与应用[J]. 石油钻探技术, 2001(2):45-46. ZHAO Yan. Development and application of salt water resistant mud admixture[J]. Petroleum Drilling Techniques, 2001 (2):45-46.
[11]	杨培龙, 许明标, 王雷, 等. 巨厚盐膏层固井用过饱和氯化钾水泥浆[J]. 钻井液与完井液, 2016, 33(5):80-83. YANG Peilong, XU Mingbiao, WANG Lei, et al. Oversaturated potassium chloride cement slurry for cementing boreholes penetrating thick salt and gypsum formations[J]. Drilling Fluid & Completion Fluid, 2016, 33(5):80-83.
[12]	陈良, 彭博, 黄敏. 聚合物氯化钾水泥浆体系性能评价及应用研究[J]. 长江大学学报(自科版), 2015, 12(25):14-16. CHEN Liang, PENG Bo, HUANG Min. Performance evaluation and application of polymer potassium chloride cement slurry system in well GK-1[J]. Journal of Yangtze University(Natural Science Edition), 2015, 12(25):14-16.
[13]	艾丽, 李早元, 谢飞燕, 等. 常见无机盐对油井水泥石抗压强度的影响机理[J]. 钻井液与完井液, 2012, 29(4):63-65. AI Li, LI Zaoyuan, XIE Feiyan, et al. Mechanism research on how inorganic salt affect on cement stone compressive strength[J].Drilling Fluid & Completion Fluid, 2012, 29(4):63-65.
[14]	王波, 顾军, 李新宏.NaCl对水泥浆性能的影响[J]. 内蒙古石油化工, 2009, 35(12):10-11. WANG Bo, GU Jun, LI Xinhong. The effect of NaCl on the properties of the cement slurry[J]. Inner Mongolia Petrochemical Industry, 2009, 35(12):10-11.
[15]	何伟, 吴晓琴, 刘芳. 硫酸钙在Ca-Mg-K-Cl-H₂O体系转化过程中溶解度研究[J]. 环境科学与技术, 2010, 33(5):35-38. HE Wei, WU Xiaoqin, LIU Fang. Calcium sulfate solubilities in the Ca-Mg-K-Cl-H₂O system of transformation process[J]. Environmental Science & Technology, 2010, 33(5):35-38.
[16]	朱佳兵, 钟辉, 刘善东, 等. 硫酸钙在高温盐溶液中的溶解度[J]. 化工技术与开发, 2015, 44(12):13-14. ZHU Jiabing, ZHONG Hui, LIU Shandong, et al. Solubility of calcium sulfate in hot salt solution[J]. Technology & Development of Chemical Industry, 2015, 44(12):13-14.
[17]	岳前升, 杨青志, 陈军, 白超峰, 刘阳. 无机盐和有机盐对盐膏层溶解性的影响[J]. 钻井液与完井液, 2013, 30(3):31-33. YUE Qiansheng, YANG Qingzhi, CHEN Jun, et al. Influence of inorganic and organic salt on solubility of gypsum[J]. Drilling Fluid & Completion Fluid, 2013, 30(3):31-33.
[18]	祝学飞, 孙俊, 舒义勇, 等.ZQ2井盐膏层高密度欠饱和盐水聚磺钻井液技术[J]. 钻井液与完井液, 2019, 36(6):716-720. ZHU Xuefei, SUN Jun, SHU Yiyong, et al. A high density undersaturated saltwater drilling fluid for salt and gypsum drilling in Well ZQ2[J]. Drilling Fluid & Completion Fluid, 2019, 36(6):716-720.
[19]	陈永衡, 冯少波, 邓强, 等. 大北X井盐膏层尾管精细控压固井技术[J]. 钻井液与完井液, 2020, 37(4):521-525. CHEN Yongheng, FENG Shaobo, DENG Qiang, et al. Cementing liner string through salt formation in well Dabei-X by precise pressure control[J]. Drilling Fluid & Completion Fluid, 2020, 37(4):521-525.
[20]	祝学飞, 孙俊, 舒义勇, 等. ZQ2井盐膏层高密度欠饱和盐水聚磺钻井液技术[J]. 钻井液与完井液, 2019, 36(6):716-720. ZHU Xuefei, SUN Jun, SHU Yiyong, et al. A high density undersaturated saltwater drilling fluid for salt and gypsum drilling in well ZQ2[J]. Drilling Fluid & Completion Fluid, 2019, 36(6):716-720.
[21]	冯圣凌, 谭显林. 昆仑101井三开高密度欠饱和盐水钻井液技术[J]. 西部探矿工程, 2019, 31(3):70-75. FENG Shengling, TAN Xianlin. Kunlun 101 well high density undersaturated brine drilling fluid technology[J]. West-China Exploration Engineering, 2019, 31(3):70-75.
[22]	陈强, 雷志永. 高密度复合盐水钻井液体系在伊拉克Missan油田盐膏层中的应用[J]. 长江大学学报(自科版), 2017, 14(15):51-55. CHEN Qiang, LEI Zhiyong. Application of hi-density mixed salt drilling fluid system in Missan oilfields of Iraq[J]. Journal of Yangtze University(Natural Science Edition), 2017, 14(15):51-55.
