适合页岩储层的强抑制防塌水基钻井液体系

王佩平

downloadPDF
文章导航 > 钻井液与完井液  > 2021 >  38(2): 176-182
王佩平. 适合页岩储层的强抑制防塌水基钻井液体系[J]. 钻井液与完井液, 2021, 38(2): 176-182. doi: 10.3969/j.issn.1001-5620.2021.02.008
引用本文: 王佩平. 适合页岩储层的强抑制防塌水基钻井液体系[J]. 钻井液与完井液, 2021, 38(2): 176-182. doi: 10.3969/j.issn.1001-5620.2021.02.008
shu
WANG Peiping. A Strongly Inhibitive Anti-Sloughing Water Base Drilling Fluid for Shale Reservoir Drilling[J]. DRILLING FLUID & COMPLETION FLUID, 2021, 38(2): 176-182. doi: 10.3969/j.issn.1001-5620.2021.02.008
Citation: WANG Peiping. A Strongly Inhibitive Anti-Sloughing Water Base Drilling Fluid for Shale Reservoir Drilling[J]. DRILLING FLUID & COMPLETION FLUID, 2021, 38(2): 176-182. doi: 10.3969/j.issn.1001-5620.2021.02.008
shu

适合页岩储层的强抑制防塌水基钻井液体系

doi: 10.3969/j.issn.1001-5620.2021.02.008

  • 中石化西南石油工程有限公司钻井一分公司, 成都 610500

基金项目:

“十三五”国家科技重大专项“大型油气田及煤层气开发”（2016ZX05060）

详细信息
    作者简介:

    王佩平,高级工程师,1971年生,1997年毕业于西南石油学院化学工程专业,现在主要从事钻井液技术管理等方面的研究工作。E-mail:3079621869@qq.com

  • 中图分类号: TE254.3

A Strongly Inhibitive Anti-Sloughing Water Base Drilling Fluid for Shale Reservoir Drilling

  • Drilling No.1 Branch of Sinopec Southwest Petroleum Engineering Co., Ltd., Chengdu, Sichuan 610500

    摘要
  • 摘要: 针对威远地区页岩气井W-X1井长水平段钻进时存在井壁失稳、漏失以及摩阻较大等问题，以多氨基页岩抑制剂HCA-3、复合封堵剂和高效润滑剂RMLUB-1为主要处理剂，研制了一套适合该区块页岩储层的强抑制防塌水基钻井液体系，并对其综合性能进行了评价。结果表明：该钻井液体系具有良好的流变性能、较低的滤失量以及较好的润滑性能，能够满足页岩储层水平井钻井施工对钻井液性能的基本要求；该钻井液体系与其他水基钻井液相比，其能够更好地降低页岩岩样的Zeta电位值，具有更强的抑制能力；该钻井液体系的高温高压PPA滤失量和滤失速率均与油基钻井液相当，并且能够较好地阻缓压力传递，具有较强的封堵能力；此外，该钻井液体系还具有较强的抗污染能力，加入不同的盐、钻屑粉和膨润土后，体系性能变化不大。强抑制防塌水基钻井液体系在威远地区W-X1井三开水平段成功进行了应用，现场各分段钻井液性能稳定，施工过程顺利，未出现井壁失稳、起下钻遇阻等复杂井下情况，井眼稳定，且提高了钻井效率，取得了良好的施工效果。



    Abstract: Drilling the long horizontal section of the shale gas well W-X1 in Weiyuan area has encountered downhole problems such as borehole wall instability, mud losses and high friction between the drilling string and the borehole wall. A water base drilling fluid with strong inhibitive capacity and anti-sloughing ability was developed to deal with these problems. The drilling fluid was formulated mainly with a poly amino shale inhibitor HCA-3, a compound plugging agent and a high efficiency lubricant RMLUB-1. Evaluation of the formulated drilling fluid showed that it has good rheology, low filtration rate and good lubricity, and is able to satisfy the basic needs of horizontal drilling of shale gas wells. Compared with other water base drilling fluids, this drilling fluid has better shale inhibitive capacity because it can reduce the Zeta-potential of shales to a much lower level. The PPA filtration rate and API filtration rate are all comparable to those of oil base muds, and this water base drilling fluid is able to prevent pressure transmission across the borehole wall and has high plugging capacity. Furthermore, this drilling fluid has good resistance to contamination; the properties of the drilling fluid do not change a lot when salts, drilled cuttings or bentonite clay is/are added. This drilling fluid has been successfully used in drilling the horizontal section (3rd interval) of the well W-X1 in Weiyuan area. During drilling operation, the properties of the drilling fluid were stable and the operation was done smoothly; no borehole wall instability, drag and resistance during tripping of drill string have ever been encountered, and drilling efficiency was enhanced.



    • HTML全文
    • 参考文献(18)
  • [1] 邵晓州, 余川, 付勋勋, 等. 页岩气研究新进展及开发瓶颈分析[J]. 断块油气田, 2012, 19(6):764-766.

    SHAO Xiaozhou, YU Chuan, FU Xunxun, et al. New research progress and development bottleneck analysis of shale gas[J]. Fault-Block Oil and Gas Field, 2012, 19(6):764-766.
    [2] 靳平平, 欧成华, 马中高, 等. 蒙脱石与相关黏土矿物的演变规律及其对页岩气开发的影响[J]. 石油物探, 2018, 57(3):344-355.

    JIN Pingping, OU Chenghua, MA Zhonggao, et al. Evolution of montmorillonite and its related clay minerals and their effects on shale gas development[J]. Geophysical Prospecting for Petroleum, 2018, 57(3):344-355.
    [3] 林永学, 王显光. 中国石化页岩气油基钻井液技术进展与思考[J]. 石油钻探技术, 2014, 42(4):7-13.

    LIN Yongxue, WANG Xianguang. Development and reflection of oil-based drilling fluid technology for shale gas of Sinopec[J]. Petroleum Drilling Techiques, 2014, 42(4):7-13.
    [4] 梁文利, 宋金初, 陈智源, 等. 涪陵页岩气水平井油基钻井液技术[J]. 钻井液与完井液, 2016, 33(5):19-24.

    LIANG Wenli, SONG Jinchu, CHEN Zhiyuan, et al. Oil base drilling fluid for drilling shale gas wells in Fuling[J]. Drilling Fluid & Completion Fluid, 2016, 33(5):19-24.
    [5] 陈在君. 高密度无土相油基钻井液研究及在四川页岩气水平井的应用[J]. 钻采工艺, 2015, 38(5):70-72.

    CHEN Zaijun. Development of high density clay-free oilbased drilling fluid and its application in Sichuan shale gas horizontal well[J]. Drilling & Production Technology, 2015, 38(5):70-72.
    [6] 胡友林, 乌效鸣, 岳前升. 江汉油田废弃油基钻井液柴油回收技术[J]. 西安石油大学学报(自然科学版), 2013, 28(3):88-91. HU Youlin, WU Xiaoming, YUE Qiansheng. Recovery technology of the diesel oil in the waste oil-based drilling fluid from Jianghan oilfield[J]. Journal of Xi'an Shiyou University(Natural Science), 2013, 28(3):88-91.
    [7] DEVILLE J P, FRITZ B, JARRETT M. Development of water-based drilling fluids customized for shale reservoirs[J]. SPE Drilling & Completion, 2011, 26(4):484-491.
    [8] MONTILVA J C, OORT E V, BRAHIM R, et al. Using a low-salinity high-performance water-based drilling fluid for improved drilling performance in Lake Maracaibo[C]//SPE Annual Technical Conference and Exhibition, 11-14 November 2007, Anaheim, California, USA. DOI: 10.2118/110366-MS.
    [9] KOSYNKIN D V, CERIOTTI G, Wilson K C, et al. Graphene oxide as a high-performance fluid-loss-control additive in water-based drilling fluids[J]. Acs Applied Materials & Interfaces, 2012, 4(1):222.
    [10] 景岷嘉, 陶怀志, 袁志平. 疏水抑制水基钻井液体系研究及其在页岩气井的应用[J]. 钻井液与完井液, 2017, 34(1):28-32.

    JING Minjia, TAO Huaizhi, YUAN Zhiping. Study of hydrophobic inhibitive water base drilling fluid system and application in shale gas well[J]. Drilling Fluid & Completion Fluid, 2017, 34(1):28-32.
    [11] 李茂森, 刘政, 胡嘉. 高密度油基钻井液在长宁——威远区块页岩气水平井中的应用[J]. 天然气勘探与开发, 2017, 40(1):88-92.

    LI Maosen, LIU Zheng, HU Jia. Application of high density oil-based drilling fluid in shale gas horizontal wells of Changning-Weiyuan bolck[J]. Natural Gas Exploration and Development, 2017, 40(1):88-92.
    [12] 陈庚绪, 刘奥, 王茜, 等. 适用于页岩气井的强抑制防塌高性能水基钻井液体系[J]. 断块油气田, 2018, 25(4):529-532.

    CHEN Gengxu, LIU Ao, WANG Qian, et al. High inhibition and anti-sloughing water-based drilling fluid system for shale gas horizontal wells[J]. Fault-Block Oil and Gas Field, 2018, 25(4):529-532.
    [13] 游云武, 梁文利, 宋金初, 等. 焦石坝页岩气高性能水基钻井液的研究及应用[J]. 钻采工艺, 2016, 39(5):80-82.

    YOU Yunwu, LIANG Wenli, SONG Jinchu, et al. Research and application of high-performance water based drilling fluid for Jiaoshiba shale gas reservoir[J]. Drilling & Production Technology, 2016, 39(5):80-82.
    [14] 刘政, 李俊才, 李轩, 等. CQH-M2高性能水基钻井液及其在威204H11-4井的应用[J]. 钻井液与完井液, 2018, 35(3):32-36.

    LIU Zheng, LI Juncai, LI Xuan, et al. High performance water base drilling fluid CQH-M2 and its application on well Wei204H11-4[J]. Drilling Fluid & Completion Fluid, 2018, 35(3):32-36.
    [15] 林永学, 甄剑武. 威远区块深层页岩气水平井水基钻井液技术[J]. 石油钻探技术, 2019, 47(2):21-27.

    LIN Yongxue, ZHEN Jianwu. Water based drilling fluid technology for deep shale gas horizontal wells in block Weiyuan[J]. Petroleum Drilling Techiques, 2019, 4(72):21-27.
    [16] 景丰, 姚志奇. 延长组页岩气水平井水基钻井液体系研制与应用[J]. 大庆石油地质与开发, 2019, 38(6):155-161.

    JING Feng, YAO Zhiqi. Development and application of the water-based drilling fluid system in Yanchangformation shale-gas horizontal well[J]. Petroleum Geology & Oilfield Development in Daqing, 2019, 38(6):155-161.
    [17] 王平全, 王建龙, 白杨, 等. 新型水基钻井液在延长油田页岩气水平井的应用[J]. 石油与天然气化工, 2018, 47(5):83-88.

    WANG Pingquan, WANG Jianlong, BAI Yang, et al. Application of new water-based drilling fluid in shale gas horizontal wells of Yanchang oilfield[J]. Chemical Engineering of Oil and Gas, 2018, 47(5):83-88.
    [18] 明显森, 贺海, 王星媛. 四川长宁区块页岩气水平井水基钻井液技术的研究与应用[J]. 石油与天然气化工, 2017, 46(5):69-73.

    MING Xiansen, HE Hai, WANG Xingyuan. Research and application of water-based drilling fluid technology of Sichuan Changning block shale-gas horizontal well[J]. Chemical Engineering of Oil and Gas, 2017, 46(5):69-73.
