TC4钛合金在有机盐完井液中的腐蚀性能

摘要: 针对钛合金在苛刻油田环境中的适用性，通过模拟腐蚀失重实验以及电化学测试分析，研究了TC4钛合金在高温高压完井液中的抗腐蚀及电化学腐蚀行为。结果表明，在总压为10 MPa，密度为1.4 g/cm³的甲酸钾完井液环境中经过360 h腐蚀，TC4钛合金有较高的腐蚀速率，其抗腐蚀性能较差，在210℃时，腐蚀速率达0.1361 mm/a。TC4钛合金阳极极化曲线均有钝化区，随温度升高，自腐蚀电流密度增大，腐蚀倾向性增大。电化学阻抗谱有明显的容弧特征，电荷转移电阻随温度升高减小很快，钝化膜的保护性减弱，表明TC4钛合金在高温高压甲酸钾完井液中的抗腐蚀性逐渐降低。
- TC4钛合金 /
- 腐蚀速率 /
- 极化曲线 /
- 阻抗
Abstract: Aiming at applicability of titanium alloy in harsh oilfield environment, the corrosion resistance and electrochemical corrosion behavior of TC4 titanium alloy in high temperature and high pressure completion fluid were studied with simulated corrosion weightlessness test and electrochemical test analysis. The results show that TC4 titanium alloy has high corrosion rate and poor corrosion resistance after 360 h corrosion in potassium formate completion fluid with total pressure of 10 MPa and density of 1.4 g/cm³. The corrosion rate reaches 0.1361 mm/a at 210℃. The anodic polarization curves of TC4 titanium alloy all have passivation zones at different temperatures. With the increase of temperature, the self-corrosion current density and corrosion tendency increase. The electrochemical impedance spectroscopy (EIS) has obvious arc capacitance characteristics. The charge transfer resistance decreases rapidly with the increase of temperature, and the protectivity of passive film decreases. This indicates that the corrosion resistance of TC4 titanium alloy in high temperature and high pressure potassium formate completion fluid decreases gradually.
- TC4 alloy /
- Corrosion rate /
- Polarization curve /
- Impedance

HTML全文

参考文献(18)

[1]	杨向同, 肖伟伟, 刘洪涛, 等. 甲酸盐对套管/油管腐蚀速率评价方法与影响因素[J]. 钻井液与完井液, 2016, 33(6):51-57. YANG Xiangtong, XIAO Weiwei, LIU Hongtao, et al. Method of evaluating corrosion rate of formates to casing and tubing strings and the influencing[J].Drilling Fluid & Completion Fluid, 2016, 33(6):51-57.
[2]	赵国仙, 吕祥鸿. 塔里木油田国产油套管订货补充技术条件制定及推广应用[R]. 库尔勒:塔里木油田公司油气工程院, 2011. ZHAO Guoxian, LYU Xianghong.Formulation and application of supplementary technical conditions for ordering domestic oil casings in Tarim oilfield[R].Korla:Institute of oil and gas engineering, Tarim Oilfield Company, 2011.
[3]	杜伟, 李鹤林. 海洋石油装备材料的应用现状及发展建议(下)[J]. 石油管材与仪器, 2015, 1(6):1-5. DU Wei, LI Helin. Application status and development suggestions on offshore oil equipment materials(Part Ⅱ)[J]. Petroleum Tubular Goods & Instruments,2015,1(6):1-5.
[4]	訾群. 钛合金研究新进展及应用现状[J]. 钛工业进展, 2008(2):23-27. ZI Qun.New development of titanium alloy and its application actuality[J].Titanium Industry Progress, 2008 (2):23-27.
[5]	HARGRAVE B, GONZALEZ M, MASKOS K, et al. Titanium Alloy Tubing for HPHT OCTG Applications. 65th NACE Annual Conference, San Antonio, Texas, March 14-18, 2010[R].Houston:Omnipress, 2010.
[6]	MANUEL GONZALEZ, MASKOS KRYSTIAN, HARGRAVE, et al.Titanium alloy tubing for HPHT applications[C]//SPE International.Society of Petroleum Engineers, 2008.
[7]	刘强, 惠松骁, 宋生印, 等. 油气开发用钛合金油井管选材及工况适用性研究进展[J]. 材料导报, 2019, 33(5):841-853. LIU Qiang, HUI Songxiao, SONG Shengyin, et al. Materials selection of titanium alloy OCTG used for oil and gas exploration and their applicability under service condition:a survey[J].Material Reports, 2019, 33(5):841-853.
[8]	李渭亮, 张慧娟, 杜春朝, 等.CO₂ 渗入对C110管柱在甲酸盐完井液中腐蚀行为的影响[J]. 材料保护, 2018, 51(10):47-49. LI Weiliang, ZHANG Huijuan, DU Chunchao, et al. Effect of CO 2 on the corrosion behavior of C110 carbon steel in formate solution environment[J].Material Protection, 2018, 51(10):47-49.
[9]	张智, 郑钰山, 李晶, 等. 含CO₂ 甲酸盐完井液中超级13Cr不锈钢的局部腐蚀性能[J]. 材料保护, 2018, 51(8):26-31. ZHANG Zhi, ZHENG Yushan, LI Jing, et al. Localized corrosion resistance of super 13Cr stainless steel in formate completion fluid containing CO₂[J]. Material Protection, 2018, 51(8):26-31.
[10]	杨向同, 吕祥鸿, 谢俊峰, 等. 高强15Cr马氏体不锈钢在有机盐完井液中的腐蚀行为[J]. 腐蚀与防护, 2018, 39(12):901-905 , 911. YANG Xiangtong, LU Xianghong, XIE Junfeng, et al. Corrosion behavior of high strength 15Cr martensitic stainless steel in organic salt completion fluid[J]. Corrosion & Protection, 2018, 39(12):901-905, 911.
[11]	吕祥鸿, 高文平, 谢俊峰, 等. 钛合金油管在苛刻井下环境中的抗腐蚀性能研究[J]. 热加工工艺, 2017, 46(6):58-62. LYU Xianghong, GAO Wenping, XIE Junfeng, et al. Study on corrosion resistance of titanium alloy tube in harsh downhole environment[J].Hot Working Technology, 2017, 46(6):58-62.
[12]	TOTOLIN V, PEJAKOVI V, CSANYI T, et al. Surface engineering of Ti₆Al₄V surfaces for enhanced tribocorrosion performance in artificial seawater[J]. Materials & Design, 2016, 104:10-18.
[13]	林玉珍, 杨德钧. 腐蚀和腐蚀控制原理[M]. 北京:中国石化出版社, 2007:203-209. LIN Yuzhen, YANG Dejun. Principles of corrosion and corrosion control[M].Beijing:Sinopec press, 2007:203 -209.
[14]	谢飞, 杨晓峰, 王丹, 等. 库尔勒土壤模拟溶液的pH对X80管线钢电化学腐蚀行为的影响[J]. 机械工程材料, 2015, 39(4):59-62. XIE Fei, YANG Xiaofeng, WANG Dan, et al. Effect of pH value of soil simulation solution on electrochemical corrosion behavior of X80 pipeline steel[J].Mechanical Engineering Materials, 2015, 39(4):59-62.
[15]	GROWCOCK F, JASINSKI R J.Time-resolved impedance spectroscopy of mild steel in concentrated hydrochloric acid[J].Journal of Electrochemical Society, 136(8):23102-314.
[16]	谢丽华, 陈长风, 李鹤林, 等. 镍基合金和铬在高温下的腐蚀电化学特征[J]. 西安石油大学学报(自然科学版), 2012, 27(2):76. XIE Lihua, CHEN Changfeng, LI Helin, et al. Electrochemical characteristics of corrosion of nickel base alloy and chromium at high temperature[J].Journal of Xi'an University of Petroleum(Natural Science Edition), 2012, 27(2):76.
[17]	WILLIAM C.WEST, ZACHARY D.HOOD, SHIBA P.Adhikah,et al. Reduction of charge-transfer resistance at the solid electrolyte-electrode interface by pulsed laser deposition of films from a crystalline Li₂PO₂N source[J]. Journal of Power Sources, 2016:116-122.
[18]	吕祥鸿, 张晔, 谢俊锋, 等. 高pH值完井液中超级13Cr油管的腐蚀失效及SCC机制[J]. 中国石油大学学报(自然科学版), 2020, 44(1 ):141-148. LYU Xianghong, ZHANG Ye, XIE Junfeng, et al. Corrosion failure and SCC mechanism of super 13Cr tubings in high pH completion fluid[J].Journal of China University of Petroleum(Edition of Natural Science), 2020, 44(1):141-148.
