宽带暂堵转向多缝压裂技术在苏里格气田的应用

韩福勇,  倪攀,  孟海龙

downloadPDF
文章导航 > 钻井液与完井液  > 2020 >  37(2): 257-263
韩福勇, 倪攀, 孟海龙. 宽带暂堵转向多缝压裂技术在苏里格气田的应用[J]. 钻井液与完井液, 2020, 37(2): 257-263. doi: 10.3969/j.issn.1001-5620.2020.02.021
引用本文: 韩福勇, 倪攀, 孟海龙. 宽带暂堵转向多缝压裂技术在苏里格气田的应用[J]. 钻井液与完井液, 2020, 37(2): 257-263. doi: 10.3969/j.issn.1001-5620.2020.02.021
shu
HAN Fuyong, NI Pan, MENG Hailong. Application of Diversion through Broadband Temporary Plugging Multi-Fracture Fracturing Technology in Sulige Gas Field[J]. DRILLING FLUID & COMPLETION FLUID, 2020, 37(2): 257-263. doi: 10.3969/j.issn.1001-5620.2020.02.021
Citation: HAN Fuyong, NI Pan, MENG Hailong. Application of Diversion through Broadband Temporary Plugging Multi-Fracture Fracturing Technology in Sulige Gas Field[J]. DRILLING FLUID & COMPLETION FLUID, 2020, 37(2): 257-263. doi: 10.3969/j.issn.1001-5620.2020.02.021
shu

宽带暂堵转向多缝压裂技术在苏里格气田的应用

doi: 10.3969/j.issn.1001-5620.2020.02.021

  • 1. 天津石油职业技术学院, 天津 301603;

  • 2. 长庆油田公司第三采气厂, 内蒙古鄂尔多斯 017300

详细信息
    作者简介:

    韩福勇,副研究员,1970年生,1994年毕业于中国石油大学(华东),研究方向为石油与天然气地质勘查。电话(022)29000868;E-mail:syxy_ybhfy@petrochina.com.cn

  • 中图分类号: TE357

Application of Diversion through Broadband Temporary Plugging Multi-Fracture Fracturing Technology in Sulige Gas Field

  • 1. Tianjin Petroleum Institute of Technology, Tianjin 301603;

  • 2. Third Gas Recovery Plant of Changqing Oilfield Company, Ordos, Inner Mongolia 017300

    摘要
  • 摘要: 为了提高水平井裸眼滑套-封隔器完井、套管固井完井、桥塞分段多簇压裂等施工过程中分级压裂多缝封隔的可靠性，在实验室条件下对暂堵材料进行了分散性测试、降解性分析以及抗压破碎能力评价，并将宽带暂堵转向多缝压裂技术在苏里格气田进行现场应用，取得了较好的转向效果。应用结果表明，采用宽带暂堵转向多缝压裂技术，减少了桥塞、封隔器相关的操作，减少了电缆入井次数，降低了施工风险，提高了施工效率；同时，利用压裂产生的多条裂缝或裂缝网络与气藏富含区域连通，增加了裂缝的长期导流能力，对比同区块水平段长度及钻遇条件相当的水平井，试气无阻流量提高21.1%，投产1年，平均单井累产气量增加3.24×106 m3。暂堵剂与纤维在气田储层温度在90~120℃范围内可实现10d以内完全降解，完全符合安全环保生产要求。



    Abstract: To improve the reliability of insulating multi fractures for staged fracturing job in horizontal well completion operation such as open-hole sliding sleeve-packer completion and casing cementing well completion as well as bridge plug segmented multi-cluster fracturing, temporary plugging agents were evaluated in laboratory experiment for their dispersibility, degradability and compression resistance. The diversion through broadband temporary plugging multi-fracture fracturing technology was used in Sulige gas field with good diverting effect. Field application showed that, using diversion through broadband temporary plugging multi-fracture fracturing technology, operation of bridge plug and packer was simplified, number of cable running reduced, operational risk mitigated and operation efficiency improved. Meanwhile, the long-term flow conductivity of fractures can be increased by the connection of multi fractures or fracture network produced by the fracturing operation to gas-rich zones. Compared with offset horizontal wells with similar horizontal lengths and downhole conditions, the open flow rate of gas during well test was increased by 21.1%. After one year of production, the average cumulative gas production of a single well was increased by 3.24×106 m3. The temporary plugging agents and fibers used can be completely degraded in 10 days at reservoir temperature of 90-120℃ in Sulige gas field, fully meeting the requirements of safe and environmentally friendly production.



    • HTML全文
    • 参考文献(16)
  • [1] 房好青, 赵兵, 汪文智, 等. 塔河油田靶向压裂预制缝转向技术模拟研究[J]. 石油钻探技术, 2019, 47(5):97-103.

    FANG Haoqing, ZHAO Bing, WANG Wenzhi, et al. Simulation study on the range of diversion in targeted fracturing of prefabricated fractures in the tahe oilfield[J]. Petroleum Drilling Techniques, 2019, 47(5):97-103.
    [2] 陈勉. 页岩气储层水力裂缝转向扩展机制[J]. 中国石油大学学报(自然科学版), 2013, 37(5):88-94. CHEN Mian.Re-orientation and propagation of hydraulic fractures in shale gas reservoir[J].Journal of China University of Petroleum(Edition of Natural Science), 2013, 37(5):88-94.
    [3] 田守嶒, 陈立强, 盛茂, 等. 水力喷射分段压裂裂缝起裂模型研究[J]. 石油钻探技术, 2015, 43(5):31-36.

    TIAN Shoufu, CHEN Liqiang, SHENG Mao, et al. Modeling of fracture initiation for staged hydraulic jetting fracturing[J]. Petroleum Drilling Techniques, 2015, 43(5):31-36.
    [4] 刘拯民. 大庆油田转向压裂工艺技术研究[J]. 化学工程与装备, 2019(4):50-51. LIU Zhengmin. Research on turning fracturing technology in Daqing oilfield[J].Chemical Engineering & Equipment, 2019

    (4):50-51.
    [5] 赵明伟, 高志宾, 戴彩丽, 等. 油田转向压裂用暂堵剂研究进展[J]. 油田化学, 2018, 35(3):538-544.

    ZHAO Mingwei, GAO Zhibin, DAI Caili, et al. Advancement of temporary plugging agent for fracturing in oilfield[J].Oilfield Chemistry, 2018, 35(3):538-544.
    [6] 尹俊禄, 刘欢, 池晓明, 等. 可降解纤维暂堵转向压裂技术的室内研究及现场试验[J]. 天然气勘探与开发, 2017, 40(3):113-119.

    YIN Junlu, LIU Huan, CHI Xiaoming, et al. Experimental study and field test of degradable fiber based temporary plugging and diversion fracturing technology[J]. Natural Gas Exploration and Development, 2017, 40(3):113-119.
    [7] 杨建委, 郑波. 纤维暂堵转向酸压技术研究及其现场试验[J]. 石油化工应用, 2013, 32(12):34-38.

    YANG Jianwei, ZHENG Bo. Study and field test of the fiber bridging acid fracturing technology[J]. Petrochemical Industry Application, 2013, 32(12):34-38.
    [8] 孙彬峰, 刘洪涛, 刘欣, 等. 多级暂堵转向重复压裂技术探索及在河南油田的应用[J]. 石油地质与工程, 2018, 32(5):107-109.

    SUN Binfeng, LIU Hongtao, LIU Xin, et al. Exploration and application of multi-stage temporary plugging steering and repetitive fracturing technology in Henan oilfield[J]. Petroleum Geology and Engineering, 2018, 32(5):107-109.
    [9] 孙兆海. 低渗透油田扶余油层垂直裂缝缝内转向压裂增产试验[J]. 化学工程与装备, 2017(6):84-86. Sun Zhaohai. Production increase test of turning fracture in vertical fracture of Fuyu reservoir in low permeability oilfield[J]. Chemical Engineering & Equipment, 2017

    (6):84-86.
    [10] 王刚. 低渗透油田缝内转向压裂增产技术研究与应用[J]. 化学工程与装备, 2017(4):63-65. WANG Gang. Research and application of in-fracture directional fracturing stimulation technology in low permeability oilfields[J]. Chemical Engineering & Equipment, 2017

    (4):63-65.
    [11] 陈天应, 彭超, 张鹏名, 等. 苏里格气田转向压裂技术优化及应用[J]. 辽宁化工, 2019, 48(2):163-165.

    CHEN Tianying, PENG Chao, ZHANG Pengming, et al. Optimization and application of steering fracturing technology in Sulige gas field[J]. Liaoning Chemical Industry, 2019, 48(2):163-165.
    [12] 丁邦春, 邱毅, 范利群, 等. 利用测井资料评价暂堵转向工艺在苏里格气田的应用效果[J]. 石油管材与仪器, 2018, 4(5):83-86.

    DING Bangchun, QIU Yi, FAN Liqun, et al. Application effect evaluation of temporary plugging and fracturing technology in Sulige gas field by logging data[J]. Petroleum Instruments, 2018, 4(5):83-86.
    [13] 杨战伟, 段瑶瑶, 王丽伟, 等. 苏里格气田致密气藏压裂改造技术研究应用[J]. 石油地质与工程, 2018, 32(6):99-102.

    YANG Zhanwei, DUAN Yaoyao, WANG Liwei, et al. Sulige gas field fracturing technology research and application[J].Petroleum Geology and Engineering, 2018, 32(6):99-102.
    [14] 李进步, 白建文, 朱李安, 等. 苏里格气田致密砂岩气藏体积压裂技术与实践[J]. 天然气工业, 2013, 33(9):65-69.

    LI Jinbu, BAI Jianwen, ZHU Li'an, et al. Volume fracturing and its practices in Sulige tight sandstone gas reservoirs, Ordos Basin[J]. Natural Gas Industry, 2013, 33(9):65-69.
    [15] 李宪文, 张矿生, 樊凤玲, 等. 鄂尔多斯盆地低压致密油层体积压裂探索研究及试验[J]. 石油天然气学报, 2013, 35(3):142-146

    , 152. LI Xianwen, ZHANG Kuangsheng, FAN Fengling, et al. Exploration and test of volume fracturing of low pressure tight reservoirs in Ordos Basin[J]. Journal of Oil and Gas Technology, 2013, 35(3):142-146, 152.
    [16] 李学垒. 苏里格"三低"油气藏水平井压裂工艺研究与应用[D]. 黑龙江大庆:东北石油大学, 2017. LI Xuelei. Research and application of horizontal well fracturing technology for "Three low" oil and gas reservoir in Sulige[D]. Heilongjiang Daqing:Northeast Petroleum University, 2017.
