Optimization of a High Temperature Low Corrosivity Acid Fluid for Application at 180℃ High Temperature
-
摘要: 针对高温深井酸化施工井下温度高、井下管柱和工具腐蚀严重的恶劣工况,笔者通过分子结构设计和合成,研发了抗180℃高温的新型高温缓蚀剂,并在此基础上优选其他助剂构建了2套抗180℃高温低腐蚀酸液体系。实验结果表明:①该缓蚀剂在180℃下,N80钢片在常规酸腐蚀速度为70 g/m2·h,具有良好的缓蚀性能;②体系无沉淀,不分层,具有良好的配伍性能和较高的抗滤失性;③在180℃下,N80钢片在0.4%和0.8%胶凝酸体系的平均腐蚀速率分别为87.3g/m2·h、95.8 g/m2·h。现场应用表明,抗180℃高温低腐蚀酸液体系满足高温深井酸压施工井下管柱和工具安全要求,施工结束后出井油管内壁光滑,酸压前后酸液性能表现良好,井下安全正常。Abstract: A new high temperature corrosion inhibitor has been developed though molecular structure design and synthesis to deal with problems encountered in high temperature deep well acidification, such as high bottom hole temperature and corrosion of downhole string and downhole tools. The corrosion inhibitor, which can be used at 180℃, was used with other optimized additives to formulate 2 sets of low corrosivity acid fluids for operation at 180℃. Laboratory experimental results showed that:1) the corrosion rate N80 steel in the presence of the corrosion inhibitor at 180℃ was 70 g/m2·h, indicating that the corrosion inhibitor developed has very good corrosion inhibiting capacity. 2) precipitation and stratification were not observed in the acid fluids formulated with the corrosion inhibitor, meaning that the additives used to formulate the acid fluids have good compatibility and filtration control capacity. 3) at 180℃, the average corrosion rates of N80 steel plate in 0.4% and 0.8% gel acids were 87.3 g/(m2·h) and 95.8 g/(m2·h), respectively. In high temperature deep well acid fracturing operation, the high temperature low corrosivity acid fluids had almost no negative effect on downhole strings and downhole tools; tubing strings pulled out of hole after operation had smooth inner walls. The acid fluids had good properties before and after acid fracturing operation, and the well was in safe conditions throughout the operation.
-
Key words:
- High temperature /
- Low corrosivity /
- Acid fluid /
- formulation optimization /
- Application
-
[1] 黄魁元, 郑家燊. 缓蚀剂科技发展历程的回顾与展望[C]//第十一届全国缓蚀剂学术研讨会论文集. 北京:中国腐蚀与防护学会, 1999:1-12. HUANG Kuiyuan, ZHENG Jiashen. Review and Prospect of the development of corrosion inhibitor technology[C]//Proceedings of the 11th National Symposium on corrosion inhibitors. Beijing:China Society of corrosion and protection, 1999:1-12. [2] 王秀梅, 礼航. 酸性介质有机缓蚀剂研究进展[J]. 腐蚀与防护, 2012, 33(1):224-226.WANG Xiumei, LI Hang. Research progress of organic corrosion inhibitors in acid medium[J].Corrosion and Protection, 2012, 33(1):224-226. [3] 陈振宇. 缓蚀剂开发与应用[M]. 北京化学工业出版社, 2012:15-19. CHEN Zhenyu. Development and application of corrosion inhibitor[M]. Beijing Chemical Industry Press, 2012:15-19. [4] RANI BEA, BASU BBJ. Green inhibitors for corrosionprotection of metals and alloys:an overview[J]. International Journal of Corrosion, 2012:380217. [5] 王慧龙, 郑家燊. 环境友好缓蚀剂的研究进展[J]. 腐蚀科学与防护技术, 2002, 14(5):275-279.WANG Huilong, ZHENG Jiashen.Research progress of environmentally friendly corrosion inhibitors[J]. Corrosion Science and Protection Technology, 2002, 14(5):275-279. [6] KESAVAN D, GOPIRAMAN M, SULOCHANA N. Green inhibitors forcorrosion of metals:a review[J]. Chemical Science Reviewand Letters, 2012(1):1-8. [7] 吴刚, 郝宁眉, 廉兵杰, 等. 吡啶类缓蚀剂及其在Al (111)表面吸附行为的密度泛函理论分析[J]. 化工学报, 2013, 64(7):2565-2572.WU Gang, HAO Ningmei, LIAN Bingjie, et al. Density functional theory analysis of pyridine inhibitors and their adsorption behavior on Al (111) surface[J]. Journal of Chemical Engineering, 2013, 64(7):2565-2572. [8] GUO L, ZHU SH, ZHANG ST, et al.Theoretical studies ofthree triazole derivatives as corrosion inhibitors for mild steel inacidic medium[J].Corrosion Science, 2014, 87:366-375. [9] 王红艳, 卢永斌, 白方林, 等. 一种新型Mannich碱酸化缓蚀剂的合成及性能评价[J]. 腐蚀科学与防护技术, 2013, 25(2):133-137.WANG Hongyan, LU Yongbin, BAI Fanglin, et al. Synthesis and performance evaluation of a new mannich alkali acidizing inhibitor[J].Corrosion Science and Protection Technology, 2013, 25(2):133-137。 [10] 李泽锋, 王改红, 姬随波. 吸附型缓速酸体系的开发与应用[J]. 钻井液与完井液, 2019, 36(1):115-119.LI Zefeng, WANG Gaihong, JI Suibo. Development and application of an adsorptive retarded acid[J]. Drilling Fluid & Completion Fluid, 2019, 36(1):115-119. [11] 余东合, 范秋菊, 修书志, 等. 新型低伤害络合酸体系评价实验[J]. 石油钻采工艺, 2017, 39(6):760-765.YU Donghe, FAN Qiuju, XIU Shuzhi, et al. Evaluation experiment of low-damage chelating acid system[J]. Oil Drilling & Production Technology, 2017, 3(6):760-765. [12] CRADDOCK H A, CAIRD S, WILKINSON H. A new class of "green" corrosion inhibitors:Development and application[J].SPE 104241, 2007. [13] 黄志宇, 何雁. 表面及胶体化学[M]. 北京:石油工业出版社, 2000. HUANG Zhiyu, HE Yan. Surface and colloidal chemistry[M]. Beijing:Petroleum Industry Press, 2000. [14] 刘春兰, 许月峰. 增溶剂的增溶原理及其在制剂生产中的应用[J]. 药业纵横, 2008, 17(4):13-14.LIU Chunlan, XU Yuefeng. Solubilization principle of solubilizer and its application in preparation production[J]. Pharmaceutical Industry, 2008, 17(4):13-14. [15] 李晖, 罗斌, 唐祖兵, 等. 新型耐高温酸化缓蚀剂XAI-180的研发与性能评价[J]. 天然气工业, 2019, 39(9):89-95.LI Hui, LUO Bin, TANG Zubing, et al.Research, development and performance evaluation of XAI-180,a new acid corrosion inhibitor with high temperature resistance[J].Natural Gas Industry, 2019, 39(9):89-95.
