水基钻井液硫酸铝污染处理工艺

祝学飞; 席云飞; 游伟

doi:10.3969/j.issn.1001-5620.2020.02.010

水基钻井液硫酸铝污染处理工艺

doi: 10.3969/j.issn.1001-5620.2020.02.010

川庆钻探工程有限公司新疆分公司, 新疆库尔勒 841000

详细信息

作者简介:
祝学飞,工程师,1983生,主要从事钻井液技术工作。电话13899081413;E-mail:253183111@qq.com

中图分类号: TE254
计量
- 文章访问数: 640
- HTML全文浏览量: 182
- PDF下载量: 215
- 被引次数: 0
出版历程
- 收稿日期: 2019-12-18
- 刊出日期: 2020-04-28

Treatment of Aluminum Sulphate Contamination to Water Base Drilling Fluids

CCDC Xinjiang Branch, Korla, Xinjiang 841000

摘要

摘要: KS19井三开φ311.2 mm井眼在钻至6243~6387 m井段时，使用的高密度KCl-聚磺水基钻井液被含有硫酸铝的清洁化生产用工业废水污染，流变性每日不断呈现上涨趋势至发生突变，一是φ₆与φ₃读值、初切值、动切力均上涨较高，而其他参数均比较正常；二是上水罐、过渡槽钻井液表面粗糙，大量针眼型气泡包裹其中，流态缓慢；三是循环系统加重泵上水困难、泥浆泵抖动严重，泵冲泵压变化较大，钻进期间被迫使用灌注泵辅助泥浆泵上水。分别在套管鞋、井底分2次进行循环调整处理，采用稀释置换、气泡界面张力改变、提高碱度进行中和、流变性改变、提高油含量等至恢复正常钻进，上水罐、过渡槽钻井液仅包裹有少量针眼型气泡，泥浆泵、加重泵上水正常。
- 硫酸铝 /
- 污染 /
- 突变 /
- 处理
Abstract: A high density KCl-polymer sulfonate drilling fluid was used to drill the third interval (φ311.2 mm) of the well KS-19. When drilling between 6243 m and 6387 m, the drilling fluid was contaminated by industrial waste water containing aluminum sulphate. The drilling fluid was experiencing rheology increase every day, or abrupt change sometimes. Several changes can be seen of the drilling fluid after being contaminated. First, the φ₆ and φ₃ readings, 10s gel strength and yield of the drilling fluid were increased to higher values, other drilling fluid parameters remained normal. Second, the mud in the suction pit and mud ditches had coarse surface and plenty of pinhole bubbles were trapped in the mud, making the mud flow very slowly. Third, the mud became difficult to pump, the mud pump trembled seriously, and the pump strokes per minute and pump pressure were unstable, changing in wide ranges. Charging pumps had to be used during drilling to pump the mud. To resolve these problems, the mud was circulated when the drill bit was at the casing shoe and the bottom of the hole to adjust its properties. Several measures, such as dilution and displacement, changing of the surface tension of the bubbles, neutralization with high pH value, changing rheology and increasing oil content of the mud, were taken to improve the properties of the mud. Drilling was then resumed and there were only small amount of bubbles found in the suction pit and ditches. Circulation was resumed to normal condition.
- Aluminum sulphate /
- Contamination /
- Abrupt change /
- Treatment

HTML全文

参考文献(11)

[1]	徐云龙, 徐堆, 张晓明, 等. 钻井液不落地技术在白鹭湖井工厂的应用[J]. 钻井液与完井液,2016,33(6):63-67. XU Yunlong, XU Dui, ZHANG Xiaoming, et al. Application of drilling fluid non-landing technology in Egret Lake well factory[J]. Drilling Fluid & Completion Fluid, 2016, 33(6):63-67.
[2]	孟繁萍, 段丽杰. 浅析油田固体废弃物对环境的影响及处置措施[J]. 能源环境保护, 2010, 24(5):37-41. MENG Fanping, DUAN Lijie. Analysis of the impact of solid waste in oil fields on the environment and disposal measures[J]. Energy Environmental Protection, 2010, 24(5):37-41.
[3]	秦宗伦, 牛晓, 周奇军, 等. 中国钻井液污水及废弃钻井液脱水处理装置[J]. 钻井液与完井液, 2011, 28(5):78-80. QIN Zonglun, NIU Xiao, ZHOU Qijun, et al.China drilling liquid sewage and waste drilling liquid dehydration treatment device[J]. Drilling Fluid & Completion Fluid, 2011, 28(5):78-80.
[4]	陈伟红, 李明玉, 唐启红, 等. 聚硅硫酸铝在中原油田注水处理中的应用[J]. 化学研究, 2001, 12(1):36-38. CHEN Weihong, LI Mingyu, TANG Qihong, et al. Application of poly aluminum silicate in water injection treatment in Zhongyuan oilfield[J].Chemical Studies, 2001, 12(1):36-38.
[5]	中华人民共和国化工行业标准:工业硫酸铝国家标准.[S]. 北京:化学工业出版社, 2013. China Chemical Industry Standard:National Standard for Industrial Aluminum Sulfate[S].Beijing:Chemical Industry Press, 2013.
[6]	马慧, 朱成军. 超细水泥处理深井钻井液HCO₃^-和CO₃^2-污染[J]. 钻井液与完井液, 2011, 28(3):88-91. MA Hui, ZHU Chengjun.Ultra-fine cement treatment of HCO₃^- and CO₃^2- contamination of drilling fluids in deep wells[J].Drilling Fluid & Completion Fluid, 2011, 28(3):88-91.
[7]	冯丽, 雷伏涛, 祝学飞, 等. 碳酸根、碳酸氢根污染的钻井液处理及机理研究[J]. 天然气与石油, 2015, 33(2):53-55. FENG Li, LEI Futao, ZHU Xuefei, et al. Study on drilling fluid treatment and mechanism of carbonate and hydrogen carbonate[J]. Natural Gas and Oil, 2015, 33(2):53-55.
[8]	关少增, 关世桥. 新疆库车盆地的地层时代和沉积环境[J]. 化工矿产地质, 2002, 24(1):1-6. GUAN Shaozeng, GUAN Shiqiao. Stratigraphic era and sedimentary environment in Kuche basin, Xinjiang[J]. Chemical Mineral Geology, 2002, 24(1):1-6.
[9]	祝学飞, 孙俊, 徐思绪, 等. HT2井三开水基钻井液CO₃^2-和HCO₃^-污染处理工艺[J]. 钻井液与完井液, 2019, 36(1):36-40. ZHU Xuefei, SUN Jun, XU Sixu, et al. Treatment of CO₃^2- and HCO₃^- contamination in water base drilling fluid used in drilling the 3rd interval of the well HT2[J]. Drilling Fluid & Completion Fluid, 2019, 36(1) 36-40.
[10]	祝学飞,周华安,孙俊,等.CT1井盐膏层钻井液技术[J]. 天然气与石油, 2017, 35(4):88-92. ZHU Xuefei, ZHOU Huaan, SUN Jun, et al.CT1 well salt-layer drilling fluid technology[J].Natural Gas and Oil, 2017, 35(4):88-92.
[11]	晏军, 于长海, 梁冲, 等. 纳米石蜡乳液封堵材料的合成与性能评价[J]. 钻井液与完井液, 2018, 35(2):73-77. YAN Jun, YU Changhai, LIANG Chong, et al. Synthesis and performance evaluation of nanometer paraffin emulsion plugging materials[J]. Drilling Fluid & Completion Fluid, 2018, 35(2):73-77.
