饶阳凹陷页岩油储层应力敏感规律

王秀影; 吴通; 蔡军; 熊战; 郭广峰; 张明

doi:10.3969/j.issn.1001-5620.2020.02.009

饶阳凹陷页岩油储层应力敏感规律

doi: 10.3969/j.issn.1001-5620.2020.02.009

王秀影¹,
吴通²,
蔡军³,
熊战⁴,
郭广峰⁵,
张明⁶

1. 华北油田公司工程技术研究院, 河北任丘 062550;
2. 中国石油大学(北京), 北京 102249;
3. 华北油田公司勘探事业部, 河北任丘 062550;
4. 中石油渤海钻探第二钻井公司河北廊坊 065000;
5. 内蒙古煤炭建设工程总公司钻井定向工程处, 呼和浩特 010020;
6. 华北油田公司第一采油厂, 河北任丘 062550

基金项目:

中国石油天然气股份有限公司重大专项“华北油田持续有效稳产勘探开发关键技术研究与应用”（2017E-15）

详细信息

作者简介:
王秀影,现在主要从事钻完井技术研究。电话18631768029;E-mail:cyy_wxy@petrochina.com.cn

中图分类号: TE258
计量
- 文章访问数: 901
- HTML全文浏览量: 313
- PDF下载量: 134
- 被引次数: 0
出版历程
- 收稿日期: 2019-11-27
- 刊出日期: 2020-04-28

Patterns of Stress Sensitivity of the Shale Oil Reservoirs in Raoyang Depression

1. Engineering Technology Research Institute of Huabei Oilfield Company, Renqiu, Hebei 062550;
2. China University of Petroleum, Beijing 102249;
3. Exploration Department of Huabei Oilfield Company, Renqiu, Hebei 062550;
4. The Second Drilling Company, BHDC, Langfang, HEbei 065000;
5. Drilling Orientation Engineering Office of Inner Mongolia Coal Construction Engineering Corporation, Hohhot, Inner Mongolia 010020;
6. Huabei Oilfield Company First Oil Production Plant, Renqiu, Hebei 062550

摘要

摘要: 饶阳凹陷页岩油储量丰富，但页岩容易发生应力敏感，需测试该区块的应力敏感程度，寻找应力敏感规律，为生产制度提供基础数据。室内利用X-射线衍射全岩分析、荧光薄片及电镜扫描等方法，分析了储层矿物的组成、微观结构及连通度共11组，储层应力敏感性流动实验3组，利用数据拟合的方法获得该区块的应力敏感在渗透率损失20%时的规律，净应力与黏土及脆性矿物含量的公式为P_c=-0.09796m_c+0.2385m_b-7.8145；不可逆渗透率伤害率与黏土及脆性矿物含量公式为K_i=93.24+0.2797m_c-0.6809m_b的关系；其中，不可逆渗透率伤害率为52.09%，在渗透率损失20%时对应的净应力在3 MPa以内，进一步分析其原因是由于不同黏土含量造成不同的微裂缝的开合程度，但是脆性矿物含量决定不可逆渗透率伤害率及渗透率损失20%时对应的净应力值。结果表明，饶阳凹陷地区的页岩油储层应力敏感与与黏土矿物含量呈负相关，与脆性矿物含量呈正相关。同时通过研究页岩油储层应力敏感性规律的拟合方法，为再解决上述类似储层由于岩样样本数量少，利用有限的岩心柱塞表征整个地层的敏感规律，提供一种新的测试方法。
- 非常规油气 /
- 页岩油 /
- 储层伤害 /
- 黏土 /
- 非黏土矿物 /
- 应力敏感性 /
- 破碎性储层
Abstract: The Raoyang depression is enriched with abundant shale oil. It is well known that shale formations are generally developed with stress sensitivity, therefore the degree of stress sensitivity in this area should be measured and patterns of stress sensitivity be found to provide basic data for field production. Eleven sets of experiments on the mineral composition, microstructure and connectivity of the reservoir formations, and three sets of flow experiments on reservoir stress sensitivity were conducted using XRD whole mineral analyses, fluorescent thin layer analyses and SEM. At permeability loss of 20%, the stress sensitivity patterns of the Raoyang depression was obtained with data fitting. The relationship between net stress, clay content and brittle mineral content is this:-0.09796m_c+0.2385m_b-7.8145. The relationship between irreversible permeability loss, clay content and brittle mineral content is this:93.24+0.2797m_c-0.6809m_b. The percent irreversible permeability loss is 52.09% and the net stress corresponding to permeability loss of 20% is within 3 MPa. Further analyses showed that different opening sizes of the micro fractures resulted from different clay contents are responsible for the relationships, the content of brittle minerals decides the irreversible permeability impairment and the net stress corresponding to 20% of permeability loss. The experimental results showed that stress sensitivity in the shale oil reservoirs in Raoyang depression is negatively correlated to the content of clay content, and is positively corelated to the content of brittle minerals. When the amount of reservoir rock samples is not enough to characterize the patterns of the whole formation, the data fitting method described in this study provides a way of using limited core plugs to realize the goal of whole formation characterization.
- Unconventional oil n gas /
- Shale oil /
- Reservoir damage /
- Clay /
- Non-clay mineral /
- Stress sensitivity /
- Fractured reservoir

HTML全文

参考文献(17)

[1]	袁选俊, 谯汉生. 渤海湾盆地富油气凹陷隐蔽油气藏勘探[J]. 石油与天然气地质, 2002, 23(2):130-133. YUAN Xuanjun, QIAO Hansheng.Exploration of subtle reservoir in prolific depression of Bohai Bay Basin[J].Oil & Gas Geology, 2002, 23(2):130-133.
[2]	侯凤香, 刘井旺, 李熹微, 等. 冀中坳陷饶阳凹陷二次勘探实践[J]. 中国石油勘探, 2017(5):25-36. HOU Fengxiang, LIU Jingwang, LI Xiwei, et al. Secondary exploration practice in Raoyang sag, Jizhong depression, Bohai Bay Basin[J].China Petroleum Exploration, 2017 (5):25-36.
[3]	陈方文, 赵红琴, 王淑萍, 等. 渤海湾盆地冀中坳陷饶阳凹陷沙一下亚段页岩油可动量评价[J]. 石油与天然气地质, 2019, 40(3):593-601. CHEN Fangwen, ZHAO Hongqin, WANG Shuping, et al.Evaluation of movable shale oil reserves in the Es1L of the Raoyang sag, Jizhong Depression[J].Oil & Gas Geology, 2019, 40(3):593-601.
[4]	邹才能, 杨智, 崔景伟, 等. 页岩油形成机制、地质特征及发展对策[J]. 石油勘探与开发, 2013, 40(1):14-26. ZOU Caineng, YANG Zhi, CUI Jingwei, et al. Formation mechanism, geological characteristics and development strategy of nonmarine shale oil in China[J]. Petroleum Exploration & Development, 2013, 40(1):14-26.
[5]	管保山, 刘玉婷, 梁利, 等. 页岩油储层改造和高效开发技术[J]. 石油钻采工艺, 2019, 41(2):212-223. GUAN Baoshan, LIU Yuting, LIANG Li,et al.Shale oil reservoir reconstruction and efficient development technology[J].Oil Drilling & Production Technology, 2019, 41(2):212-223.
[6]	姜在兴, 张文昭, 梁超, 等. 页岩油储层基本特征及评价要素[J]. 石油学报, 2014, 35(1):184-196. JIANG Zaixing, ZHANG Wenzhao, LIANG Chao, et al. Characteristics and evaluation elements of shale oil reservoir[J].Acta Petrolei Sinica, 2014, 35(1):184-196.
[7]	朱维耀, 马东旭, 朱华银, 等. 页岩储层应力敏感性及其对产能影响[J]. 天然气地球科学, 2016, 27(5):892-897. ZHU Weiyao, MA Dongxu, ZHU Huayin, et al.Stress sensitivity of shale gas reservoir and its influence on productivity[J].Natural Gas Geoscience, 2016, 27(5):892-897.
[8]	郑力会, 刘皓, 曾浩, 等. 流量替代渗透率评价破碎性储层工作流体伤害程度[J]. 天然气工业, 2019, 39(12):74-80. ZHENG Lihui, LIU Hao, ZENG Hao, et al.Evaluation of working fluid damage in fractured reservoirs using flow rate instead of permeability[J].Natural Gas Industry, 2019, 39(12):74-80.
[9]	兰林, 康毅力, 陈一健, 等. 储层应力敏感性评价实验方法与评价指标探讨[J]. 钻井液与完井液, 2005, 22(3):1-4. LAN Lin, KANG Yili, CHEN Yijian, et al.Discussion on evaluation methods for stress sensitivities of low permeability and tight sandstone reservoirs[J].Drilling Fluid & Completion Fluid, 2005, 22(3):1-4.
[10]	朱培鑫, 钟家文. 裂缝性页岩储层的应力敏感实验研究[J]. 石化技术, 2018, 25(10):146-175. ZHU Peixin, ZHONG Jiawen.Experimental study on stress sensitivity of fractured shale reservoir[J]. Petrochemical Industry Technology, 2018, 25(10):146-175.
[11]	何金钢, 康毅力, 游利军, 等. 矿物成分和微结构对泥质岩储层应力敏感性的影响[J]. 天然气地球科学, 2012, 23(1):129-134. HE Jingang, KANG Yili, YOU Lijun, et al. Effects of mineral composition and microstructure on stress sensitivity of mud rocks[J].Natural Gas Geoscience, 2012, 23(1):129-134.
[12]	陆辉, 杨胜来, 谢丽. 低渗透油藏压降漏斗影响因素研究[J]. 科学技术与工程, 2012, 12(4):770-773. LU Hui, YANG Shenglai, XIE Li.Influence factors of low permeability reservoir pressure drop funnel[J].Science Technology and Engineering, 2012, 12(4):770-773.
[13]	陈天宇, 冯夏庭, 杨成祥, 等. 含气页岩渗透率的围压敏感性和各向异性研究[J]. 采矿与安全工程学报, 2014, 31(4):639-643. CHEN Tianyu, FENG Xiating, YANG Chengxiang, et al. Research on confining pressure sensitivity and anisotropy for gas shale permeability[J].Journal of Mining and Safety Engineering, 2014, 31(4):639-643.
[14]	朱维耀, 马东旭. 页岩储层有效应力特征及其对产能的影响[J]. 天然气地球科学, 2018, 29(6):845-852. ZHU Weiyao, MA Dongxu. Effective stress characteristics in shale and its effect on shale gas productivity[J].Journal of Natural Gas Geoscience, 2018, 29(6):845-852.
[15]	常防震, 陈宝, 朱嵘. 黏土微结构特征与变形机理研究进展[J]. 地下空间与工程学报, 2009, 5(S2):1573-1579. CHANG Fangzhen, CHEN Bao, ZHU Rong.Advances in study on microstructural characteristic and deformation mechanism of clay[J].Chinese Journal of Underground Space and Engineering, 2009, 5(S2):1573-1579.
[16]	钟大康, 周立建, 孙海涛, 等. 储层岩石学特征对成岩作用及孔隙发育的影响-以鄂尔多斯盆地陇东地区三叠系延长组为例[J]. 石油与天然气地质, 2012, 33(6):890-899. ZHONG Dakang, ZHOU Lijian, SUN Haitao, et al. Influences of petrologic features on diagenesis and pore development:an example from the triassic Yanchang formation in longdong area, Ordos Basin[J].Oil & Gas Geology, 2012, 33(6):890-899.
[17]	黄知娟, 潘丽娟, 路辉, 等. 大数据分析顺北油田SHB-X井试采产液量骤降原因[J]. 石油钻采工艺, 2019, 41(3):341-347. HUANG Zhijuan, PAN Lijuan, LU Hui, et al.The reasons for sudden production drop by big data analysis in trial production for Well SHB-X in Shunbei oilfield[J]. Oil Drilling & Production Technology, 2019, 41(3):341-347.
