硼修饰纳米二氧化硅交联剂研发及性能评价

熊俊杰; 李春; 杨生文; 安琦; 于吉; 王世华

doi:10.3969/j.issn.1001-5620.2019.02.020

硼修饰纳米二氧化硅交联剂研发及性能评价

doi: 10.3969/j.issn.1001-5620.2019.02.020

中海油能源发展股份有限公司工程技术分公司, 天津 300452

详细信息

作者简介:
熊俊杰,工程师,硕士,现主要从事油气田压裂酸化技术研究等工作。电话13820652392;E-mail:xiongjj@cnooc.com.cn

中图分类号: TE357.12
计量
- 文章访问数: 615
- HTML全文浏览量: 194
- PDF下载量: 191
- 被引次数: 0
出版历程
- 收稿日期: 2018-12-05
- 刊出日期: 2019-04-30

Development and Performance Evaluation of a Boron-modified Nanosilica Crosslinking Agent

CNOOC EnerTech-Drilling & Production Co., Tianjin 300452

摘要

摘要: 针对目前常规有机硼、无机硼交联的瓜胶压裂液普遍存在羟丙基瓜胶用量大、残渣含量高等的问题，笔者先将硅酸钠水解制得纳米二氧化硅，然后将制得的纳米二氧化硅与γ-氨丙基三甲氧基硅烷反应得到表面修饰纳米二氧化硅，再与硼酸进行反应，最后制得可交联的硼修饰纳米二氧化硅交联剂，该交联剂粒径主要分别在7～11 nm，可有效降低瓜胶用量及残渣含量。研究了该交联剂交联的羟丙基瓜胶压裂液，室内研究表明，该压裂液体系各项性能良好：在温度分别为50℃、120℃，剪切速率170 s^-1下连续剪切120 min，最终黏度均大于50 mPa·s；50℃下破胶60 min，破胶液黏度小于5mPa·s；表面张力22.77 mN/m；防膨率89.6%；残渣含量145 mg/L；岩心基质渗透率损害率为9.82%～14.86%，压裂液各项性能良好，羟丙基瓜胶浓度降低20%，残渣含量降低25%，满足现场施工要求。
- 交联剂 /
- 硼修饰纳米二氧化硅 /
- 瓜胶压裂液 /
- 中低温储层 /
- 低温激活剂 /
- 低伤害
Abstract: Field application of guar gum fracturing fluid treated with organoboron and inorganoboron crosslinking agents has been faced with problems such as large amount of guar gum consumed and high residue content of the fracturing fluid. In laboratory research on these problems, nanosilica was first made by the hydrolysis of sodium silicate, and the nanosilica made was then reacted with γ-aminopropyltrimethoxysilane to produce a surface modified nanosilica. The surface modified nanosilica was further reacted with boric acid to produce a boron-modified nanosilica crosslinking agent with particle sizes between 7 nm and 11 nm, and it was able to effectively reduce the amount of guar gum required in mixing fracturing fluid and the residue of fracturing fluids. Study was done on the performance of a hydroxypropyl guar gum fracturing fluid treated with the boron-modified nanosilica as a crosslinking agent, and it was found that the fracturing fluid had good properties. At temperatures 50℃ and 120℃ respectively, shearing of the fracturing fluid at 170 s^-1 for 120 min produced a fracturing fluid with viscosity of greater than 50 mPa.s. At 50℃, after gel breaking for 60 min, the fracturing fluid had viscosity that was less than 5 mPa.s and surface tension of 22.77 mN/m. Core swelling test with the gel-broken fracturing fluid showed that the percent core swelling was 89.6% and the residue content was 145 mg/L. Permeability impairment of a core matrix tested with the fracturing fluid was between 9.82% and 14.86%. Other properties of the fracturing fluid were all satisfactory, the amount of hydroxypropyl guar gum required for mixing fracturing fluid was reduced by 20%, and the residue content of the fracturing fluid mixed was reduced by 25%, satisfying the needs of field operations.
- Crosslinking agent /
- Boron-modified silica /
- Guar gum fracturing fluid /
- Low and medium temperature reservoir /
- Low temperature activator /
- Low damage

HTML全文

参考文献(13)

[1]	LAFITTE V,TUSTIN G J,DERCHUN B,et al. Nanomaterials in fracturing fluid applications[C]. Noordiwijk:Society of Petroleum Engineers,2012.
[2]	韦代延,陈宏伟,朱德武,等. 延川地区浅井超低温压裂液的研究与应用[J]. 石油钻采工艺,2000,28(4):41-43. WEI Daiyan,CHEN Hongwei,ZHU Dewu,et al. Study and application of the fracturing fluid for lowtemperature shallow wells in Yanchuan area[J]. Oil Drilling & Production Technology,2000,28(4):41-43.
[3]	任占春,孙慧毅,秦利平. 羟丙基瓜胶压裂液超低温破胶系统研究[J]. 油田化学,1995,12(3):234-236. REN Zhanchun, SUN Huiyi, QIN Liping. Hydroxypropyl guar gum/borate gelling fracturing fluid with gel breaker for very low temperature reservoirs[J].Oilfield Chemistry, 1995,12(3):234-236.
[4]	李秀花. 近期国内外水基压裂液添加剂的发展概况[J]. 石油与天然气化工,1995,2(1):12-17. LI Xiuhua. Recent development of water-based fracturing fluid additives at home and abroad[J].Chemical Engineering of Oil and Gas,1995,2(1):12-17.
[5]	李希明,陈勇,谭云贤,等. 生物酶破胶研究及应用[J]. 石油钻采工艺,2006,28(2):224-226. LI Ximing, CHEN yong, TAN Yunxian, et al. Study and application of biology viscosity break ferment[J].Oil Drilling & Production Technology,2006,28(2):224-226.
[6]	张文胜. 新型压裂液破胶剂的研究与应用[J]. 钻井液与完井液,2002,19(4):10-12. ZHANG Wensheng. Study and application of a novel gel breaker for fracturing fluid[J]. Drilling Fluid & Completion Fluid,2002,19(4):10-12.
[7]	徐晓峰,郭旭跃,胡佩. 新型压裂液低温破胶体系的研制[J]. 特种油气藏,2004,11(6):89-91. XU Xiaofeng, GUO Xuyue, HU Pei. Development of a new low temperature breaking system of fracture fluid[J]. Special Oil & Gas Reservoirs,2004,11(6):89-91.
[8]	李健萍,王稳桃,王俊英,等. 低温压裂液及其破胶技术研究与应用[J]. 特种油气藏,2009,16(2):72-75. LI Jianping,WANG Wentao,WANG Junying. Study and application of low-temperature fracturing fluid and gel-breaking technique[J]. Special Oil & Gas Reservoirs, 2009,16(2):72-75.
[9]	吴锦平. 低温压裂液破胶技术对浅气层增产技术改造[J]. 钻采工艺,2000,23(5):79-81. WU Jinping. Technological transformation of gel breaking technology of low temperature fracturing fluid for shallow gas reservoir stimulation[J].Drilling & Production Technology,2000,23(5):79-81.
[10]	韩俊华,陈海水,王雅雄,等. 新型压裂液低温破胶活化剂[J]. 石油钻采工艺,2001,23(4):82-85. HAN Junhua, CHEN Haishui, WANG Yaxiong, et al. New type low temperature gel break activator of fracturing fluid[J].Oil Drilling & Production Technology,2001, 23(4):82-85.
[11]	杨建军,叶仲斌,张绍彬,等. 新型低伤害压裂液性能评价及现场试验[J]. 天然气工业,2004,4(6):61-63. YANG Jianjun,YE Zhongbin,ZHANG Shaobin,et al. Evaluation and application of new fracturing fluid with low damage[J].Natural Gas Industry,2004,4(6):61-63.
[12]	徐兵威, 王世彬, 郭建春,等. 低伤害压裂液体系伤害性研究与应用[J]. 钻采工艺,2010,33(4):87-89. XU Bingwei,WANG Shibin,GUO Jianchun,et al. Research and application of low damage fracturing fluids system[J].Drilling & Production Technology,2010,33(4):87-89.
[13]	贾文峰,陈作,姚奕明,等. 纳米二氧化硅交联剂的合成及其交联形成羟丙基胍胶压裂液的性能研究[J]. 精细石油化工,2015,32(5):15-18. JIA Wenfeng,CHEN Zuo,YAO Yiming,et al. Fabrication of nanosilica crosslinker and formation of crosslinked hydroxypropyl guar-based fracturing fluid[J]. Speciality Petrochemicals,2015,32(5):15-18.
