克深243井盐膏层大尺寸套管固井技术

刘方义,  高飞,  李若华,  张小建,  田宝振,  姚泊汗,  韩自立

downloadPDF
文章导航 > 钻井液与完井液  > 2019 >  36(2): 240-244
刘方义, 高飞, 李若华, 张小建, 田宝振, 姚泊汗, 韩自立. 克深243井盐膏层大尺寸套管固井技术[J]. 钻井液与完井液, 2019, 36(2): 240-244. doi: 10.3969/j.issn.1001-5620.2019.02.019
引用本文: 刘方义, 高飞, 李若华, 张小建, 田宝振, 姚泊汗, 韩自立. 克深243井盐膏层大尺寸套管固井技术[J]. 钻井液与完井液, 2019, 36(2): 240-244. doi: 10.3969/j.issn.1001-5620.2019.02.019
shu
LIU Fangyi, GAO Fei, LI Ruohua, ZHANG Xiaojian, TIAN Baozhen, YAO Bohan, HAN Zili. Cementing of Large-sized Casing through Salt and Gypsum Interbeds in Well Keshen-243[J]. DRILLING FLUID & COMPLETION FLUID, 2019, 36(2): 240-244. doi: 10.3969/j.issn.1001-5620.2019.02.019
Citation: LIU Fangyi, GAO Fei, LI Ruohua, ZHANG Xiaojian, TIAN Baozhen, YAO Bohan, HAN Zili. Cementing of Large-sized Casing through Salt and Gypsum Interbeds in Well Keshen-243[J]. DRILLING FLUID & COMPLETION FLUID, 2019, 36(2): 240-244. doi: 10.3969/j.issn.1001-5620.2019.02.019
shu

克深243井盐膏层大尺寸套管固井技术

doi: 10.3969/j.issn.1001-5620.2019.02.019

  • 1. 渤海钻探工程公司第一固井分公司, 河北任丘 062552;

  • 2. 渤海钻探工程公司井下作业分公司, 河北任丘 062552;

  • 3. 渤海钻探工程公司国际钻采物资供应分公司, 天津 300457

基金项目:

中国石油集团渤海钻探工程有限公司项目“塔里木库车山前钻完井技术研究”（2018ZD14Y）部分研究成果

详细信息
    作者简介:

    刘方义,工程师,2009年毕业于长江大学石油工程专业,现在主要从事固井管理与现场工程技术工作。电话19990632188;E-mail:liufangy@cnpc.com.cn

  • 中图分类号: TE256

Cementing of Large-sized Casing through Salt and Gypsum Interbeds in Well Keshen-243

  • 1. No.1 Cementing Branch of CNPC Bohai Drilling Engineering Company Limited, Renqiu, Hebei 062552;

  • 2. Downhole Operation Branch of CNPC Bohai Drilling Engineering Company Limited, Renqiu, Hebei 062552;

  • 3. International Drilling Materials Supply Company(Bidding Center), BHDC, Tianjin 300457

    摘要
  • 摘要: 克深243井是部署在新疆拜城县的一口评价井，三开钻进至库姆格列木群盐岩段中途完钻，井深5532 m，井底静止温度127.6℃，钻井液密度2.43 g/cm3，地层压力为132 MPa，下入φ273.05 mm+φ293.45 mm复合大尺寸套管进行双级固井。固井存在地层承压能力低井段易漏、盐膏层蠕变、水泥浆压稳防窜性能要求高、长封固段顶部强度发展缓慢等难题，通过选用微锰与GM-1加重剂共同干混保证水泥浆密度，选用2种防窜剂提高水泥浆防窜性能，将高温降失水剂和低温降失水剂复配使用，降低缓凝剂的加量，避免大温差下顶部水泥浆出现超缓凝，加以配套的固井工艺措施，该井段固井施工顺利，固井质量合格。



    Abstract: Keshen-243 is an appraisal well located 29 km to Baicheng County, Xinjiang. The 3rd interval of this well was drilled to 5,532 m, and two-stage cementing was to be conducted to cement the hole penetrating Kumugeliemu group (salt rocks). Bottom hole static temperature of the 3rd interval was 127.6℃, mud weight was 2.43 g/cm3, and the maximum formation pressure was 132 MPa. Casing strings of φ273.05 mm + φ293.45 mm in diameter were to be run into the hole and cemented. Several problems were expected during casing running, such as low pressure bearing of the formations to be cemented which may result in lost circulation, creeping of the salt/gypsum interbeds, channeling of cement slurry and slow setting of the top cement slurry when cementing long open hole section etc. In formulating the cement slurry to address these problems, a micro powder manganese mineral and another weighting agent GM-1 were dry mixed together into the cement slurry to ensure its density, two anti-channeling agents used to improve the anti-channeling performance of the cement slurry, and a combination of high temperature and low temperature filtrate loss reducers to improve the filtration property of the cement slurry. The amount of cement retarder was reduced to avoid long retarding period of the top cement slurry under the circumstance of big temperature differences. All these selected additives, plus the cementing techniques engineered, made the two-stage cementing operation through salt-gypsum interbedded formations smoothly done even when there was lost circulation flowed by mud kick. The cementing job was qualified.



    • HTML全文
    • 参考文献(11)
  • [1] 肖平,张晓东,梁红军,等. 通井钻具组合刚度匹配研究[J]. 机电产品开发与创新,2011,24(3):33-34.

    XIAO Ping,ZHANG Xiaodong,LIANG Hongjun,et al. Study on rigidity matching of the drifting downhole assembly[J]. Development & Innovation of Machinery & Electrical Products, 2011,24(3):33-34.
    [2] 冯克满,朱江林,王同友,等. 颗粒级配技术的超高密度水泥浆体系研究[J]. 长江大学学报(自然科学版), 2010,7(2):54-57. FENG Keman, ZHU Jianglin, WANG Tongyou, et al. Ultrahigh high density slurry system based on grain composition[J]. Journal of Yangtze University(Natural Science Edition), 2010, 7(2):54-57.
    [3] 林志辉, 王贵宏, 李志斌, 等. 超高密度抗盐水泥浆体系的研究[J]. 钻井液与完井液, 2005, 22(S1):59-62.

    LIN Zhihui, WANG Guihong, LI Zhibin, et al. A ultrahigh density salt torlerant cement slurry[J]. Drilling Fluid & Completion Fluid,2005,22(S1):59-62.
    [4] 刘群英,王野,范莉,等. 膏盐层固井水泥浆技术[J] 钻井液与完井液,2005,22(2):59-61.

    LIU Qunying, WANG Ye, FAN Li, et al. Cement slurry technology for gypsum-salt rock[J]. Drilling Fluid & Completion Fluid,2005,22(2):59-61.
    [5] 庄建山, 宋元洪, 高飞, 等. 塔里木山前区块超深井尾管塞流固井技术[J]. 钻井液与完井液, 2016,33(4):83-86.

    ZHUANG Jianshan,SONG Yuanhong,GAO Fei,et al. Plug flow liner cementing technology for ultra deep well in piedmont Tarim[J]. Drilling Fluid & Completion Fluid, 2016,33(4):83-86.
    [6] 赵启阳,张成金,严海兵,等. 提高油基钻井液固井质量的冲洗型隔离液技术[J]. 钻采工艺,2017,40(5):88-90

    ,94. ZHAO Qiyang, ZHANG Chengjin, YAN Haibing, et al. Flushing-type isolation fluid technology for improving cementing quality of oil-based drilling fluid[J]. Drilling & Production Technology,2017,40(5):88-90,94.
    [7] 黄文红,李爱民,张新文,等. 油基泥浆固井清洗液评价方法初探及性能研究[J]. 新疆石油天然气,2006, 2(2):33-35.

    HUANG Wenhong, LI Aimin, ZHANG Xinwen, et al. Preliminary study on evaluation method and performance of oil-based mud cementing cleaning fluid[J]. Xinjiang Petroleum and Natural Gas,2006,2(2):33-35.
    [8] 孙清华, 彭明旺, 夏宏南, 等. 低压易漏井提高固井质量的研究与应用[J]. 断块油气田, 2006, 2(2):33-35.

    SUN Qinghua, PENG Mingwang, XIA Hongnan, et al. Research and application on technology of improving cement quality in low pressure and easy leaking wells[J]. Fault-Block Oil and Gas Field,2006,2(2):33-35.
    [9] 刘超, 周训耀. 固井工程中盐膏层蠕变危害分析[J]. 重庆科技学院学报(自然科学版),2011,13(1):22-24. LIU Chao, ZHOU Xunyao. Harm of salt bed creeping in well cementation[J].Journal of Chongqing University of Science and Technology(Natural Sciences Edition), 2011,13(1):22-24.
    [10] 郭文猛, 宋元洪, 刘振通, 等. 正、反注水泥固井工艺在塔中油田的应用[J]. 内蒙古石油化工, 2013(4):10-12. GUO Wenmeng, SONG Yuanhong, LIU Zhentong, et al. Application of cementing technology with positivenegative cementing in Tazhong oilfield[J].Inner Mongolia Petrochemical Industry,2013

    (4):10-12.
    [11] 文湘杰. 控压固井技术在B3O4井的应用[J]. 石油地质与工程,2011,25(3):134-136.

    WEN Xiangjie. Application of pressure control cementing technology in well B3O4[J]. Petroleum Geology and Engineering, 2011,25(3):134-136.
