基于赫巴流变模式的旋转套管顶替效率计算

程永钦; 李黔; 尹虎; 石建刚; 宋琳; 熊超; 李世平

doi:10.3969/j.issn.1001-5620.2019.02.017

基于赫巴流变模式的旋转套管顶替效率计算

doi: 10.3969/j.issn.1001-5620.2019.02.017

1. 西南石油大学石油与天然气工程学院, 成都 610500;
2. 中石油新疆油田分公司工程技术研究院, 新疆克拉玛依 834000

基金项目:

国家科技重大专项“沙砾岩致密油小井眼水平井固井完井技术研究”（ZX201705070-003）

详细信息

作者简介:
程永钦,1994年生,在读硕士研究生,研究方向为油气井工程专业。电话13881949421;E-mail:1633825598@qq.com

中图分类号: TE256
计量
- 文章访问数: 745
- HTML全文浏览量: 235
- PDF下载量: 232
- 被引次数: 0
出版历程
- 收稿日期: 2018-12-27
- 刊出日期: 2019-04-30

Calculation of Displacement Efficiency When Casing String is Rotating Based on Herschel-Bulkley Model

1. Southwest Petroleum University, School of Petroleum Engineering, Chengdu 610500;
2. Engineering Technology Research Institute of PetroChina Xinjiang Oilfield Branch, Karamay 834000

摘要

摘要: 旋转套管是提高固井顶替效率的重要措施。为了定量计算注水泥时旋转套管的顶替效率，使用微元分析法，对旋转套管时水泥浆驱替钻井液状态进行了受力分析，建立了顶替界面达到平衡时的顶替效率计算模型，可以计算出不同旋转套管转速时的不同周向角顶替效率。计算表明，当旋转套管转速大于10 r/min时，会有效减小近井壁钻井液滞留层厚度，适当提高稠度系数，流性指数在0.4～0.7之间时，旋转套管能使顶替效率显著提升。
- 赫巴方程 /
- 旋转套管 /
- 顶替效率 /
- 滞留层 /
- 边界位置
Abstract: Rotating casing string during well cementing is an important measure of increasing displacement efficiency. To quantitatively calculate the displacement efficiency when casing string is being rotated during pumping of cement slurry, infinitesimal method is used to analyze the stresses exerted on the cement slurry which is displacing drilling fluid while the casing string is being rotated, and a model was established for calculating the displacement efficiency of cement slurry when the displacement interface reaches an equilibrium. Using this model, different circumferential displacement efficiencies at different casing string rotational speeds can be worked out. Calculation using the model showed that when the rotational speed was greater than 10, the thickness of the stagnant retention layer of drilling fluid on the surface of the borehole wall can reduced. When the consistency coefficient of the cement slurry was increased, and the flow index was between 0.4 and 0.7, rotating casing string can remarkably increase displacement efficiency.
- Herschel-Bulkley equation /
- Rotational casing sting /
- Displacement efficiency /
- Retention layer /
- Boundary location

HTML全文

参考文献(9)

[1]	刘崇建,黄柏宗,徐同台,等. 油气井注水泥理论与应用[M]. 石油工业出版社, 2001. LIU Chongjian, HUANG Baizong, XU Tongtai, et al. Theory and application of oil and gas well cementing[M]. Petroleum Industry Press, 2001.
[2]	高永海, 孙宝江,刘东清,等. 环空水泥浆顶替界面稳定性数值模拟研究[J]. 石油学报, 2005, 26(5):119-122. GAO Yonghai,SUN Baojiang,LIU Dongqing, et al. Numerical simulation study on the interface stability of annulus cement slurry replacement[J]. Acta Petrolei Sinica, 2005, 26(5):119-122.
[3]	刘崇建, 刘孝良, 刘乃震,等. 提高小井眼水泥浆顶替效率的研究[J]. 天然气工业, 2003, 23(2):46-49. LIU Chongjian, LIU Xiaoliang, LIU Naizhen, et al. Study on improving the efficiency of cement slurry displacement in small wells[J]. Natural Gas Industry, 2003, 23(2):46-49.
[4]	王显诚, 丁保刚. 旋转套管对固井质量的影响[J]. 石油钻探技术, 1995(1):47-49. WANG Xiancheng, DING Baogang. Influence of rotary casing on cementing quality[J]. Petroleum Drilling Technology, 1995 (1):47-49.
[5]	王金堂, 孙宝江, 李昊,等. 大位移井旋转套管固井顶替模拟分析[J]. 中国石油大学学报(自然科学版), 2015(3):89-97. WANG Jintang, SUN Baojiang, LI Hao, et al. Simulation analysis of displacement cementing displacement in extended reach wells[J]. Journal of China University of Petroleum (Natural Science Edition), 2015(3):89-97.
[6]	步玉环, 郭胜来, 马明新,等. 复杂井眼条件下旋转套管速度对固井质量的影响[J]. 石油学报, 2011, 32(3):529-533. BU Yuhuan, GUO Shenglai,MA Mingxin, et al. Effect of rotary casing speed on cementing quality under complex borehole[J]. Acta petrota Sinica, 2011, 32(3):529-533.
[7]	邓建民. 固井钻井液零滞留临界静切力计算方法[J]. 天然气工业, 2008, 28(5):72-73. Deng Jianmin. Zero residual critical static force calculation method for cementing drilling fluid[J]. Natural Gas Industry, 2008, 28(5):72-73
[8]	张景富. 钻井流体力学[M]. 石油工业出版社, 1994. Zhang Jingfu. Drilling fluid mechanics[M]. Petroleum Industry Press, 1994.
[9]	费祥麟. 高等流体力学[M]. 西安交通大学, 1989. Fei Xianglin. Advanced fluid mechanics[M]. Xi'an Jiao Tong University, 1989.
