Controlling Mud Losses in Well Shunbei 52X with High Temperature Chemical Gels
-
摘要: 顺北52X井是位于塔里木盆地顺托果勒低隆北缘构造的一口勘探井,该井志留系火成岩裂缝发育,地层胶结差、易破碎,承压能力弱,在5600~6200 m井段发生反复的井漏和地层盐水溢流问题,150℃高温地层是阻止化学凝胶堵漏施工的最主要限制因素。为解决上述问题同时拓展化学凝胶的适用温度范围,利用有机凝胶的热塑性、凝胶的复合作用以及改性甲基硅油的缓凝作用,研制出一种新型抗高温化学凝胶。室内实验表明,抗高温化学凝胶的稠化时间能控制在4 h以上,10 h养护抗压强度达3.2 MPa。抗高温化学凝胶在顺北52X井进行的现场试验显示,新凝胶提高了顺北52X井的承压能力,现场试压4.8 MPa,志留系当量密度达到1.40 g/cm3,解决了顺北52X的井漏、出水等地层复杂问题。Abstract: The well Shunbei 52X is an exploratory well located in the north margin of the Shuntuoguole low uplift, Tarim Basin. This well penetrated a section of the easy-to-break Silurian igneous rocks with plenty of fractures, poor cementation and low-pressure bearing capacity. Repeated mud losses and well kicks happened during drilling from 5,600 m to 6,200 m. High formation temperature of 150℃ was the major reason prohibiting the use of chemical gel to stop mud losses. To deal with mud losses encountered and extend the use of chemical gel, a new high temperature chemical gel was developed, making use of the thermoplasticity of organic gel, the compound action of gel and the retarding effect of modified methyl silicone oil. Laboratory experimental results showed that the thickening time of the high temperature chemical gel can be maintained to more than 4 h, and the compressive strength of the chemical gel after aging for 10 hours was 3.2 MPa. The high temperature chemical gel was used on the well Shunbei 52X to control mud losses; the pressure bearing capacity of the formations at which mud losses have happened in the past was increased to 4.8 MPa as tested, and the equivalent circulation density of the Silurian system was raised to 1.40 g/cm3, successfully resolving the mud losses and well kick problems encountered in drilling the well Shunbei 52X.
-
Key words:
- Mud loss /
- Chemical gel /
- Pressure bearing capacity /
- High temperature /
- Tahe oilfield
-
[1] 冯兴强,张忠民,张卫彪. 塔河油田志留系油气成藏特征及勘探方向[J]. 现代地质,2013,27(1):180-185.FENG Xingqiang,ZHANG Zhongmin,ZHANG Weibiao. Silurian hydrocarbon accumulation characteristics and exploration direction in Tahe oilfield[J].Modern Geology,2013,27(1):180-185. [2] 王勋杰. 塔河油田志留系油气成藏特征研究[J]. 石油试验地质,2014(2):171-175. WANG Xunjie.Oil and gas accumulation characteristics of Silurian in Tahe oilfield[J].Petroleum Experimental Geology,2014(2):171-175. [3] 陈曾伟,刘四海,林永学,等. 塔河油田顺西2井二叠系火成岩裂缝性地层堵漏技术[J]. 钻井液与完井液, 2014,31(1):40-43.CHEN Zengwei,LIU Sihai, LIN Yongxue,et al. Leakage stoping technology for permian igneous fractured formations of shunxi 2 well in tahe oilfield[J].Drilling Fluid & Completion Fluid,2014,31(1):40-43. [4] 廉仕学,何龙,李旭华. 塔河油田TK4-3-1井复杂情况处理[J]. 石油钻采工艺,2005,27(4):24-25.LIAN Shixue,HE Long,LI Xuhua.Tahe Oilfield TK4-3-1 well complexity treatment[J].Oil drilling & Petroleum Technology,2005,27(4):24-25. [5] 杨子超,郭春华,王琳,等. 塔河油田TK4-3-1井特大漏失堵漏技术[J]. 石油钻探技术,2016,32(1):63-65.YANG Zichao, GUO Chunhua, WANG Lin,et al. Leakage prevention technology for TK4-3-1 well in Tahe Oilfield[J].Petroleum Drilling Technology,2016,32(1):63-65. [6] 王悦坚. 塔河油田恶性漏失堵漏与大幅度提高地层承压技术[J]. 钻井液与完井液,2013,30(4):33-36.WANG Yuejian.Malignant leakage blocking and large increase of formation pressure technology in Tahe Oilfield[J].Fluid & Completion Fluid,2013,30(4):33-36. [7] 何瑞兵,许杰,王洪伟. 渤海油田断层裂缝性漏失高效堵漏技术[J]. 长江大学学报(自科版),2015,12(32):38-42. HE Ruibing, XU Jie, WANG Hongwei. High-efficiency leak plugging technology for fault fractured leakage in Bohai oilfield[J].Journal of Yangtze University(Natural Science Edition),2015,12(32):38-42. [8] 冯永超. 塔里木油田水泥浆堵漏前置保护液的研究[D]. 陕西西安:西安石油大学,2012. FENG Yongchao.Tarim Oilfield cement slurry plugging pre protection fluid research[D].Shanxi Xi'an:Xi'an Petroleum University,2012. [9] 刘金华,刘四海,龙大清,等. 明1井交联成膜与化学固结承压堵漏技术[J]. 石油钻探技术,2017,45(2):54-60.LIU Jinhua, LIU Sihai, LONG Daqing,et al. Techniques for sealing leakage by cross-linked film formation and chemical consolidation in well Ming1[J]. Petroleum Drilling Technology,2017,45(2):54-60. [10] 王龙. 中121井化学固结+交联成膜技术承压堵漏技术浅析[J]. 西部探矿工程,2013,25(3):36-40.WANG Long.A brief analysis of chemical consolidation +crosslinked film forming technology in no.121 well pressure leak plugging technology[J].Western Exploration Engineering,2013,25(3):36-40. [11] 方俊伟,吕忠楷,何仲,等. 化学凝胶堵剂承压堵漏技术在顺北3井的应用[J]. 钻井液与完井液,2017, 34(6):13-17.FANG Junwei,LYU Zhongkai,HE Zhong,et al. Application of Chemical Gel LCM on Well Shunbei-3[J]. Drilling Fluid & Completion Fluid,2017,34(6):13-17. [12] 王琳,苏长明,钱晓琳,等. 化学固结堵漏剂的研制与应用[J]. 矿山工程,2015(3):128-135 WANG Lin,SU Changming,QIAN Xiaolin,et al. Development and application of chemical consolidation plugging agent[J].Mine Engineering,2015(3):128-135. [13] 王显光,苏长明,薛玉志,等. 防漏堵漏新技术在缅甸D区块的应用[J]. 钻井液与完井液,2011(2):51-54. WANG Xianguang, SU Changming, XUE Yuzhi, et al. Application of new anti-leakage technology in block D of myanmar[J].Drilling Fluid & Completion Fluid,2011, (2):51-54. [14] 何飞,骆金,李亚,等. 纤维素/氧化硅有机-无机杂化复合气凝胶的研究进展[J]. 哈尔滨工业大学学报, 2017,49(5):1-9.HE Fei,LUO Jin,LI Ya,et al.An overview on cellulose/silica organic-inorganic hybrid composite aerogels[J].Journal of Harbin Institute of Technology, 2017,49(5):1-9.
