页岩气井用乳液型超分子压裂液制备与应用

张晓虎; 于世虎; 周仲建; 孙亚东; 李嘉

doi:10.3969/j.issn.1001-5620.2019.01.023

页岩气井用乳液型超分子压裂液制备与应用

doi: 10.3969/j.issn.1001-5620.2019.01.023

中国石油集团川庆钻探工程有限公司井下作业公司, 成都 610051

基金项目:

国家专项“大型油气田及煤层气开发课题三，储层改造关键流体研发”（2017ZX05023003006）

详细信息

作者简介:
张晓虎,工程师,主要从事油气田压裂酸化方向的研究及现场服务工作。电话15892893967;E-mail:zhangxhu@cnpc.com.cn

中图分类号: TE357.12
计量
- 文章访问数: 841
- HTML全文浏览量: 226
- PDF下载量: 213
- 被引次数: 0
出版历程
- 收稿日期: 2018-12-05
- 刊出日期: 2019-02-28

Preparation and Application of an Emulsion Supramolecular Fracturing Fluid for Shale Gas Development

CCDC Downhole Service Company, Chengdu, Sichuan 610051

摘要

摘要: 为满足页岩气高效化、清洁化生产的需求，采用反相乳液聚合制备乳液状疏水缔合聚合物ASNP，与自制增效剂SD-Z复配形成页岩用乳液型超分子压裂液SMF-1。该体系满足现配现用需求，无需额外添加剂，仅改变加量就能实现滑溜水、线性胶、胶液的自由切换。SMF-1滑溜水体系具有优异的降阻效果，0.08%加量下对清水和返排液的降阻率在70%左右，抗盐能力高达10000 mg/L。SMF-1胶液体系具有良好的耐温抗剪切性能，0.6%的SMF-1胶液在110℃、170 s^-1下剪切120 min，黏度始终保持在120 mPa·s以上。SMF-1压裂液属于低黏高弹流体，具有良好的携砂性能，其破胶液黏度低于1.5 mPa·s，残渣含量仅为12.8 mg/L，对岩心伤害率低至11.8%。现场应用切换方便，性能稳定，加砂强度高于同井邻段和邻井同段。
- 压裂液 /
- 滑溜水 /
- 乳液聚合 /
- 超分子 /
- 降阻率
Abstract: To satisfy the needs of producing shale gas efficiently and cleanly, anemulsion-like hydrophobic association polymer ASNP was developed through inverse emulsion polymerization. The ASNP was then compounded with an extender SD-Z to produce an emulsion supramolecular fracturing fluid SMF-1, which can be prepared at the moment of using, without the needing of extra additives. Changing the concentration of ASNP, the fracturing fluid can be turned into slick water, linear gel or colloidal solution. SMF-1 slick water has excellent drag reducing ability, fresh water and fracturing fluid flowed back containing 0.08% SMF-1 have their drag reduced by about 70%, and their salt resistance can be 10000 mg/L. SMF-1 colloidal solution has excellent high temperature and shearing performance, 0.6% SMF-1 solution sheared at 110 ℃ and 170 sup>-1 for 120 min has viscosity that is at least 120 mPa·s throughout the test process. SMF-1 fracturing fluid is a fluid with low viscosity, high elasticity and good sand carrying capacity. SMF-1 fluid after gel breaking has viscosity that is less than 1.5 mPa·s, and the residue content of the gel breaking fluid is only 12.8 mg/L. In core test with the SMF-1 fracturing fluid, permeability impaired by the SMF-1 fluid is as low as 11.8%. In field application, SMF-1 can be switched to different fluids with stable properties, and the sand content is also higher than the fracturing fluid used in the offset section of the same well and in offset wells.
- Fracturing fluid /
- Slick water /
- Emulsion polymerization /
- Supramolecule /
- Rate of drag reduction

HTML全文

参考文献(18)

[1]	蒋廷学,卞晓冰,王海涛,等. 深层页岩气水平井体积压裂技术[J]. 天然气工业,2017,37(1):90-96. JIANG Tingxue,BIAN Xiaomei,WANG Haitao,et al. Volume fracturing of deep shale gas horizontal wells[J]. Natural Gas Industry,2017,37(1):90-96.
[2]	陈鹏飞,刘友权,邓素芬,等. 页岩气体积压裂滑溜水的研究及应用[J]. 石油与天然气化工,2013,42(3):270-273. CHEN Pengfei,LIU Youquan,DENG Sufen,et al. Research and application of slick water for shale volume fracturing[J]. Chemical Engineering of Oil & Gas,2013, 42(3):270-273.
[3]	王林,马金良,苏凤瑞,等. 北美页岩气工厂化压裂技术[J]. 钻采工艺,2012,35(6):48-50. WANG Lin,MA Jinliang,SU Fengrui,et al. North American shale gas factory fracturing technology[J]. Drilling & Production Technology,2012,35(6):48-50.
[4]	程俊,裴金贵,徐仿海,等. 一种新型滑溜水压裂液降阻剂合成与应用研究[J]. 当代化工,2016,45(3):456-459. CHENG Jun,PEI Jingui,XV Fanghai,et al. Study on synthesis and application of a new type slickwater fracturing fluid friction reducer[J].Contemporary Chemical Industry,2016,45(3):456-459.
[5]	吴伟,刘平平,孙昊,等.AAMS-1疏水缔合聚合物压裂液稠化剂合成与应用[J]. 钻井液与完井液,2016, 33(5):114-118. WU Wei,LIU Pingping,SUN Hao,et al. Synthesis and application of a hydrophobically associating polymer viscosifier for fracturing fluids[J]. Drilling Fluid & Completion Fluid,2016,33(5):114-118.
[6]	蒋其辉,蒋官澄,刘冲,等. 超分子压裂液体系的研制及评价[J]. 钻井液与完井液,2015,32(5):73-77. JIANG Qihui,JIANG Guancheng,LIU Chong,et al. Development and evaluation of supramolecular fracturing fluid[J]. Drilling Fluid & Completion Fluid,2015,32(5):73-77.
[7]	贾帅, 崔伟香, 杨江, 等. 新型超分子压裂液的流变性能研究及应用[J]. 油气地质与采收率,2016,23(5):83-87. JIA Shuai,CUI Weixiang,YANG Jiang, et al. Research on rheological properties of a new supramolecular fracturing fluid and its application[J]. Petroleum Geology and Recovery Efficiency, 2016, 23(5):83-87.
[8]	魏娟明,刘建坤,杜凯,等. 反相乳液型减阻剂及滑溜水体系的研发与应用[J]. 石油钻探技术,2015,43(1):27-32. WEI Juanming,LIU Jiankun,DU Kai,et al. The development and application of inverse emulsified friction reducer and slickwater system[J]. Petroleum Drilling Techniques,2015,43(1):27-32.
[9]	魏欣,加文君,曹静,等. 反相乳液法制备P(AM-AAAMPS)聚合物微球[J]. 石油与天然气化工,2014(5):539-542. WEI Xin, JIA Wenjun, CAO Jing, et al. Preparation of P(AM-AA-AMPS) polymer microspheres by inverse emulsion polymerization[J]. Chemical Engineering of Oil & Gas, 2014 (5):539-542.
[10]	吴伟,刘平平,武继辉,等. 反相乳液聚合制备疏水缔合聚合物AAMS-2及其压裂液性能评价[J]. 应用化工,2016,45(2):203-206. WU Wei,LIU Pingping,WU Jihui,et al. Preparation of hydrophobically associating polymer AAMS-2 by inverse emulsion polymerization and its performance as a fracturing fluid thickener[J].Applied Chemical Industry, 2016,45(2):203-206.
[11]	周逸凝, 崔伟香, 杨江, 等. 一种新型超分子复合压裂液的性能研究[J]. 油田化学,2015,32(2):180-184. ZHOU Yining,CUI Weixiang,YANG Jiang, et al. Performance evaluation of a novel supramolecular fracturing fluid[J]. Oilfield Chemistry,2015,32(2):180-184.
[12]	蒲阳峰,罗立锦,张明,等. 超分子活性聚合物型清洁压裂液的研制与评价[J]. 石油化工应用,2017,36(2):140-142. PU Yangfeng,LUO Lijin,ZHANG Ming,et al. The development and evaluation of polymer lean fracturing fluid[J].Petrochemical Industry Application,2017,36(2):140-142.
[13]	张文龙,伊卓,祝纶宇,等. 乳液型压裂液降阻剂的合成及其性能[J]. 石油化工,2015,44(5):607-611. ZHANG Wenlong,YI Zhuo,ZHU Lunyu,et al. Synthesis and performance of drag reducers for slickwater fracturing fluid[J]. Petrochemical Technology,2015,44(5):607-611.
[14]	XU L,HUANG Y,LI J,et al. A new thr eedimensional(3d) multilayer organic material:synthesis, swelling, exfoliation, and application[J].Langmuir, 2013,29(11):3813-3820.
[15]	潘岳, 于小荣, 王海林. AM/AMPS/SSS三元反相乳液聚合体系稳定性研究[J]. 应用化工,2012,41(2):321-323. PAN Yue,YU Xiaorong,WANG Hailin. Study on the stability of AM/AMPS/SSS ternary inverse emulsion polymerization system[J]. Applied Chemical Industry, 2012,41(2):321-323.
[16]	陈馥,何雪梅,卜涛,等. 耐盐减阻剂的制备及性能评价[J]. 精细石油化工,2018(1):51-55. CHEN Fu,HE Xuemei,BU Tao,et al. Preparation and performance evaluation for salt resistance friction reducer[J]. Speciality Petrochemicals,2018 (1):51-55.
[17]	VIRK P S. An elastic sublayer model for drag reduction by dilute solutions of linear macromolecules[J]. Journal of Fluid Mechanics,2006,45(3):417-440.
[18]	张锋三,沈一丁,吴金桥,等. 水包水型疏水缔合聚丙烯酰胺增稠剂的合成及在压裂中的应用[J]. 化工进展,2017,36(8):3058-3065. ZHANG Fengsan,SHEN Yiding,WU Jinqiao,et al. Synthesis of water-in-water hydrophobically associating polyacrylamide and its application in fracturing[J]. Chemical Industry and Engineering Progress,2017, 36(8):3058-3065.
