强封堵钻井液体系在河南页岩气钻井中的研究和应用

袁青松,  冯辉,  张栋,  李中明,  代磊,  董果果

downloadPDF
文章导航 > 钻井液与完井液  > 2019 >  36(1): 29-35
袁青松, 冯辉, 张栋, 李中明, 代磊, 董果果. 强封堵钻井液体系在河南页岩气钻井中的研究和应用[J]. 钻井液与完井液, 2019, 36(1): 29-35. doi: 10.3969/j.issn.1001-5620.2019.01.006
引用本文: 袁青松, 冯辉, 张栋, 李中明, 代磊, 董果果. 强封堵钻井液体系在河南页岩气钻井中的研究和应用[J]. 钻井液与完井液, 2019, 36(1): 29-35. doi: 10.3969/j.issn.1001-5620.2019.01.006
shu
YUAN Qingsong, FENG Hui, ZHANG Dong, LI Zhongming, DAI Lei, DONG Guoguo. Study of a Strong Plugging Drilling Fluid Used in Shale Gas Drilling in He’nan Province[J]. DRILLING FLUID & COMPLETION FLUID, 2019, 36(1): 29-35. doi: 10.3969/j.issn.1001-5620.2019.01.006
Citation: YUAN Qingsong, FENG Hui, ZHANG Dong, LI Zhongming, DAI Lei, DONG Guoguo. Study of a Strong Plugging Drilling Fluid Used in Shale Gas Drilling in He’nan Province[J]. DRILLING FLUID & COMPLETION FLUID, 2019, 36(1): 29-35. doi: 10.3969/j.issn.1001-5620.2019.01.006
shu

强封堵钻井液体系在河南页岩气钻井中的研究和应用

doi: 10.3969/j.issn.1001-5620.2019.01.006

  • 1. 河南省地质调查院, 郑州 450001;

  • 2. 地下清洁能源勘查开发产业技术创新战略联盟, 郑州 450001;

  • 3. 河南豫矿地质勘查投资有限公司, 郑州 450001

基金项目:

国土资源部第二轮页岩气探矿项目“河南中牟页岩气勘查”（GT2012YQTKQCR0020）；河南省重大科技专项项目“河南页岩气勘查开发及示范应用研究”（151100311000）

详细信息
    作者简介:

    袁青松,工程师,硕士,1989年生,毕业于中国地质大学(武汉)地质工程专业,现从事页岩气钻完井相关技术研究工作。E-mail:yqingsongcug@163.com

  • 中图分类号: TE254.3

Study of a Strong Plugging Drilling Fluid Used in Shale Gas Drilling in He’nan Province

  • 1. He'nan Geological Survey Institute, Zhengzhou, He'nan 450001;

  • 2. Industrial Technology Innovation Strategic Alliance of Underground Clean Energy Exploration and Exploitation, Zhengzhou, He'nan 450001;

  • 3. He'nanYukuang Geological Exploration Investment Co. Ltd., Zhengzhou, He'nan 450001

    摘要
  • 摘要: 河南中牟和温县页岩气区块在直井钻井过程中频繁出现坍塌掉块、井径扩大等井下复杂，通过对储层地质特征以及老井钻井液体系测试分析，造成此现象的主要原因为钻井液封堵性不足。因此基于抑制水化、加强封堵两方面开展钻井液研究，优选封堵剂HSM、HGW和抑制剂HAS，形成一套强封堵、强抑制钻井液体系，并对体系性能进行了测试。室内测试结果表明，该钻井液体系性能优良，100℃老化72 h仍具备较好的流变性；对泥页岩钻屑热滚回收率高达98.5%，10 h线性膨胀率仅为2.34%；封堵性能好，6 h API和HTHP滤失量分别为7.8 mL和9 mL；还具备较强的抗污染能力。现场应用后基本未发生坍塌掉块、井壁失稳现象，井径扩大率从21%降至6%，说明该钻井液体系能够满足该区块的钻井工程需要。



    Abstract: Downhole troubles such as borehole wall collapse and hole enlargement were frequently encountered during shale gas vertical drilling in Zhongmou county and Wen county, He’nan. Analyses of the geological characteristics of the reservoirs and test on the drilling fluids used in offset wells showed that the occurrence of the downhole troubles came from the lack of plugging capacity of the drilling fluid used. Based on this idea, studies were conducted on the formulation of the drilling fluid, focusing on the inhibitive capacity and plugging capacity of the drilling fluid. Two plugging agents, HSM and HGW, and a shale inhibitor HAS were selected to formulate the drilling fluid. Laboratory test of drilling fluid showed that it had good rheology after aging for 72 h at 100 ℃. Percent recovery of shale cuttings in hot rolling test was 98.5%. 10 h linear swelling rate of an artificial shale core tested with the drilling fluid was only 2.34%. 6 h API and HTHP filtration rates were 7.8 mL and 9 mL, respectively, indicating good plugging performance of the drilling fluid. The drilling fluid was also resistant to contamination. In field application, a well drilled with this drilling fluid experienced no borehole wall collapse and sloughing, percent hole enlargement was reduced from 21% to only 6%, proving that the drilling fluid has satisfied the needs of drilling operations in the blocks in question.



    • HTML全文
    • 参考文献(16)
  • [1] 邱庆伦,张古彬,冯辉,等. 河南中牟区块页岩气特征及勘探前景分析[J]. 地质找矿论丛,2018,33(1):70-75.

    QIU Qinglun,ZHANG Gubin,FENG Hui,et al. Analysis of shale gas characteristic and exploration prospect of Henan zhongmu block[J]. Contributions To Geology and Mineral Resources Research,2018,33(1):70-75.
    [2] 李中明,张栋,张古彬,等. 豫西地区海陆过渡相含气页岩层系优选方法及有利区预测[J]. 地学前缘, 2016,23(2):39-47.

    LI Zhongming, ZHANG Dong,ZHANG Gubin,et al. The transitional facies shale gas formation selection and favorable area prediction in the western[J].Earth Science Frontiers,2016,23(2):39-47.
    [3] 刘冲,袁青松,董果果,等.ZXY1井太原-山西组泥页岩压裂层段优选[J]. 中外能源, 2018, 23(3):32-38.

    LIU Chong,YUAN Qingsong,DONG Guoguo,et al. Optimization of fractured shale layer in taiyuan-shanxi formation in well ZXY1[J]. Sino-Global Energy,2018, 23(3):32-38.
    [4] 陈路原. 大牛地气田盒1气藏水平井开发工程技术与实践[J]. 石油钻探技术,2015,43(1):44-51.

    CHEN Luyuan. Technology and practice for horizontal well development in the He-1Gas reservoir of Daniudi gas field[J].Petroleum Drilling Techniques,2015,43(1):44-51.
    [5] 梁涛. 地应力与井壁稳定性关系研究[D]. 中国地质大学,2012. LIANG Tao. Research about the relationship between formation stress and borehole stability[D]. China university of geoscience,2012.
    [6] 雷又层,向兴金.泥页岩分类简述[J].钻井液与完井液, 2007,24(2):63-66

    ,90-91. LEI Youceng,XIANG Xingjin. Briefly classification of mud shale[J].Drilling Fluid & Completion Fluid,2007, 24(2):63-66,90-91.
    [7] 宋碧涛, 马成云, 徐同台, 等. 硬脆性泥页岩钻井液封堵性评价方法[J]. 钻井液与完井液, 2016, 33(4):51-55.

    SONG Bitao, MA Chengyun, XU Tongtai, et al. Methods for evaluating the performance of drilling fluids plugging fractures in hard and brittle shales[J].Drilling Fluid & Completion Fluid, 2016,33(4):51-55.
    [8] 杨野.适用于长页岩井段的强抑制水基钻井液研究[D]. 西南石油大学,2017. YANG Ye. Study on highly inhibitive water-based drilling fluid used in long shale segment[D].Southwest petroleum university,2017.
    [9] 刘亚元,刘焕玉,左凤江,等. 京11平1井钻井液技术[J]. 钻井液与完井液,2007,24(5):33-35

    ,88. LIU Yayuan,LIU Huanyu,ZUO Fengjiang,et al. The drilling fluid technology of jing 11 ping 1 well[J]. Drilling Fluid & Completion Fluid,2007,24(5):33-35,88.
    [10] 李磊. 防塌钻井液配方研究[D]. 西安石油大学,2011. LI Lei. Study on the formula of anti-sloughing drilling fluid[D]. Southwest petroleum university,2011.
    [11] 张翔宇. 胺基硅醇强抑制封堵防塌钻井液体系研究与应用[J]. 天然气勘探与开发,2016,39(3):76-79

    , 11-12. ZHANG Xiangyu. Plugging and anti-collapse drilling fluid system using amidocyanogen silanok inhibitor[J]. Natural Gas Exploration and Development,2016,39(3):76-79,11-12.
    [12] 邱春阳, 叶洪超, 王兴胜, 等.诺1井钻井液技术及复杂情况处理[J]. 钻井液与完井液, 2017, 34(6):46-51.

    QIU Chunyang,YE Hongchao,WANG Xingsheng, et al. Drilling fluid technology used in drilling well Nuo-1 and handling of downhole complications[J]. Drilling Fluid & Completion Fluid, 2017,34(6):46-51.
    [13] 张坤,刘南清,王强,等. 强抑制封堵钻井液体系研究及应用[J]. 石油钻采工艺,2017,39(5):580-583.

    ZHANG Kun, LIU Nanqing, WANG Qiang, et al. Research and application of drilling fluid with strong inhibition and sealing capacity[J]. Oil Drilling & Production Technology, 2017, 39(5):580-583.
    [14] 王晓军,李俊杞,孙云超,等. 强抑制水基钻井液在连续管侧钻井中的应用[J]. 石油钻采工艺,2018,40(1):33-39.

    WANG Xiaojun, LI Junqi, SUN Yunchao, et al. Application of strong-inhibition water based drilling fluid to side tracking of coiled tubing[J]. Oil Drilling & Production Technology, 2018, 40(1):33-39.
    [15] 舒曼,赵明琨,许明标. 涪陵页岩气田油基钻井液随钻堵漏技术[J]. 石油钻探技术,2017,45(3):21-26.

    SHU Man,ZHAO Mingkun,XU Mingbiao. Plugging while drilling technology using oil-based drilling fluid in Fuling Shale Gas Field[J]. Petroleum Drilling Techniques,2017,45(3):21-26.
    [16] 崔贵涛,李宝军,王兆政. 微乳液强抑制强封堵钻井液在SACHA区块的应用[J]. 石油钻探技术,2015, 43(6):20-23.

    CUI Guitao,LI Baojun,WANG Zhaozheng. The application of strong-inhibition plugging microemulsion drilling fluid in SACHA Block[J]. Petroleum Drilling Techniques,2015,43(6):20-23.
