新型可延迟膨胀类堵漏剂的合成与性能评价

史野; 左洪国; 夏景刚; 王先洲; 周志强; 雷鸣; 王波

doi:10.3969/j.issn.1001-5620.2018.04.011

新型可延迟膨胀类堵漏剂的合成与性能评价

doi: 10.3969/j.issn.1001-5620.2018.04.011

中国石油集团渤海钻探工程有限公司第五钻井工程分公司, 河北河间 062450

基金项目:

渤海钻探2017年重大科技研发项目“新型堵漏材料研制”（2017ZD09K-01）。

详细信息

作者简介:
史野,工程师,1987年生,2015年毕业于吉林大学应用化学专业,现在主要从事钻井液技术研究及现场管理工作。电话(0317)2582938;E-mail:shiye425@126.com。

中图分类号: TE254.4
计量
- 文章访问数: 727
- HTML全文浏览量: 207
- PDF下载量: 248
- 被引次数: 0
出版历程
- 收稿日期: 2018-02-26
- 刊出日期: 2018-07-30

Synthesis and Evaluation of a New Swelling Deferrable Lost Circulation Material

No.5 Drilling Branch of Bohai Drilling Engineering Company Limited, Hejian, Hebei 062450

摘要

摘要: 现有的凝胶堵漏剂吸水膨胀速度过快，导致堵漏剂难以进入漏层；部分进入漏层的堵漏剂，因提前膨胀致使填塞层强度低，堵漏效果差。采用丙烯酸（AA）、丙烯酸甲酯（MA）、2-丙烯酰胺-2-甲基丙磺酸衍生物（AMPSA）、N，N’-亚甲基双丙烯酰胺（MBA）为原料合成可延迟膨胀堵漏剂BZYD-1，对其进行表征，评价了其可延迟性能及承压堵漏能力。结果表明：所合成的可延迟膨胀堵漏剂BZYD-1热稳定性好，抗温达150℃；室温时，清水浸泡几乎不发生吸水膨胀，碱性条件下浸泡4 h膨胀率不大于50%；80℃时，碱性条件下吸水膨胀率达到17.8倍，具有显著的延迟膨胀效果，承压能力为4 MPa。该延迟膨胀堵漏剂具有较好的应用前景。
- 可延迟 /
- 堵漏 /
- 吸水膨胀 /
- 共聚物
Abstract: Gel lost circulation material (LCM) presently in use swells fast when absorbing water, making it difficult for the LCM to enter into the flow channel in formation through which mud is lost. Part of the LCM entering the flow channel forms plugs of low strength in the flow channels because of early swelling, resulting in poor mud loss control. A swelling deferrable lost circulation material (LCM), BZYD-1, has been synthesized with acryl acid (AA), methyl acrylate (MA), 2-acrylamide-2-methyl propane sulfonic acid derivative (AMPSA), and N,N'-methylene-bis-acrylamide (MBA), and characterized. Laboratory evaluation showed that BZYD-1 had good thermal stability, and was resistant to high temperature to 150℃. At room temperature, BZYD-1 did not swell in fresh water, and rate of swelling after soaking for 4 hours in alkaline water was less than 50%. At 80℃, BZYD-1 soaked in alkaline water swelled to 17.8 times of its original size, demonstrating remarkable deferred swelling. The swollen BZYD-1 had pressure bearing capacity of 4 MPa. This swelling deferrable LCM has good application prospect.
- Deferrable /
- Lost circulation control /
- Swelling through water absorption /
- Copolymer

HTML全文

参考文献(8)

[1]	赵巍,李波,高云文,等. 诱导性裂缝防漏堵漏钻井液研究[J]. 油田化学,2013,30(1):1-4. ZHAO Wei, LI Bo, GAO Wenyun, et al. Study on leakage prevention and leakage drilling fluid with inducible cracks[J].Oilfield Chemistry, 2013,30(1):1-4.
[2]	汪建军,李艳,刘强,等. 新型多功能复合凝胶堵漏性能评价[J]. 天然气工业,2005,25(9):101-103. WANG Jianjun, LI Yan, LIU Qiang, et al. Performance evaluation of a new multifunction composite gel[J]. Natural Gas Industry, 2005, 25(9):101-103.
[3]	贾佳,郭建华,赵雄虎,等. 吸水膨胀类堵漏材料性能评价与研究[J]. 钻井液与完井液,2012,29(4):16-26. JIA Jia, GUO Jianhua, ZHAO Xionghu, et al. Research and evaluation on water-absorption swelling resin LCM[J]. Drilling Fluid & Completion Fluid, 2012,29(4):16-26.
[4]	应春业,高元宏,段隆臣,等. 新型吸水膨胀堵漏剂的研发与评价[J]. 钻井液与完井液,2017,34(4):38-44. YING Chunye, GAO Yuanhong, DUAN Longchen, et al. Develoment and evaluation of a new water swelling lost circulation materal[J]. Drilling Fluid & Completion Fluid, 2017,34(4):38-44.
[5]	王海涛,张远丰,李魁广,等. 吸水膨胀树脂的堵漏应用效果[J]. 中国煤炭地质,2012,24(8):95-97. ZHANG Haitao, ZHANG Yuanfeng, LI Kuiguang, et al. Application effect of water swelling resin[J]. Coal Geology of China,2012,24(8):95-97.
[6]	赖小林,王中华,郭建华,等. 吸水材料在石油钻井堵漏中的应用[J]. 精细石油化工进展, 2010, 11(2):17-20. LAI Xiaolin, WANG Zhonghua, GUO Jianhua, et al. Application of water-absorbent materialsin petroleum drilling loss contro[J]. Advance In Fine Petrochemcals, 2010, 11(2):17-20.
[7]	张歧安,徐先国,董维,等. 延迟膨胀颗粒堵漏剂的研究与应用[J]. 钻井液与完井液,2006,23(2):21-25. ZHANG Qi'an, XU Xianguo, DONG Wei,et al. Study and application of granular postponed-swelling LCM[J]. Drilling Fluid & Completion Fluid, 2006,23(2):21-25.
[8]	李娟,刘文堂,沈士军. 吸水树脂堵漏材料的研究进展[J]. 油田化学,2011,28(1):111-114. LI Juan, LIU Wentang, SHEN Shijun. Research progress on water absorbent polymer used as lost-control materials[J]. Oilfield Chemistry, 2011,28(1):111-114.
