Study and Application of Well Test Fluid for HTHP Wells in Ying-Qiong Basin in South China Sea
-
摘要: 南海莺琼盆地高温、高压、高含CO2气体、低孔低渗等复杂地质条件要求测试液具有良好的抗温稳定性、沉降稳定性、抗CO2污染能力及储层保护能力。由于前期无专用高温高压测试液,导致复杂情况频发,经过多年研究与实践,在完钻使用的钻井液中引入抗高温降滤失剂Calovis,适当提高测试液碱度,合理控制测试液的MBT,配合使用超细重晶石加重,同时提高测试液的返排性能,形成了一套高温高压井测试液技术。该测试液在莺琼盆地2口高温高压探井测试作业得到成功应用,其中一口井CO2含量达到23%,井底温度超过200℃,测试液密度达到2.33 g/cm3,射孔压力及环空压力传递正常,静置7 d后,封隔器解封顺利,测试液性能未发生恶化,测试产量均超过预期产量,完成全部测试任务。Abstract: Drilling fluids with good thermal stability, settling stability, CO2 contamination resistance and reservoir protection are required to drill wells in the Ying-Qiong Basin in South China Sea where high temperature, high pressure, CO2, and low porosity/low permeability prevail. Downhole troubles have been frequently encountered because of lack of special high temperature high pressure (HTHP) test fluid previously. In many years of study and field practices a set of HTHP test fluid technology has been developed by introducing a high temperature filter loss reducer Calovis into drill-in fluids used, increasing the pH value of the test fluid appropriately, controlling the MBT of the test fluids in a reasonable range, weighting the test fluids with ultra-fine barite, and enhancing the flowback properties of the test fluids. The test fluids have been successfully used on 2 HTHP exploratory wells in the Ying-Qiong Basin. One of the well had CO2 content of 23%, bottom hole temperature over 200℃, and the density of the test fluid used was 2.33 g/cm3. Perforation pressure and annular pressure were transmitted normally. After standing for 7 days, the packer was retrieved successfully, and the properties of the test fluid were not deteriorating. The tested production rate was higher than the expected production rate. All test tasks have been satisfactorily completed.
-
[1] 李相方,梁政,邓雄,等. 高温高压气井测试技术[M]. 北京:石油工业出版社,2007. LI Xiangfang,LIANG Zheng,DENG Xiong, et a1. Testing technology of high temperature and high pressure gas well[M]. Beijing:Petroleum Industry Press,2007. [2] 唐宇祥,廖成锐. 四川盆地元坝气田钻井液转化为完井液的工艺技术[J]. 天然气工业,2015,35(5):73-78.TANG Yuxiang,LIAO Chengrui.Technology of transforming drilling fluid into completion fluid in the Yuanba Gasfield, SichuanBasi[J]. Natural Gas Industry, 2015, 35(5):73-78. [3] 梁明熙. 海上高温高压井测试技术[J]. 天然气工业, 1999,19(1):76-79.LIANG Mingxi. High temperature and high pressure well testing techniques[J]. Natural Gas Industry, 1999, 19(1):76-79. [4] 董星亮. 南海西部高温高压井测试技术现状及展望[J]. 石油钻采工艺,2016,38(6):723-729,736. DONG Xingliang.Status and prospect of testing technologies for HTHP wells in western south China sea[J]. Oil Drilling & Production Technology, 2016, 38(6):723-729,736. [5] 赵文,谢克姜. 南海海域高温高压钻井液技术[J]. 石油钻采工艺,2007,29(6):87-89.ZHAO Wen,XIE Kejiang. High temperature and pressure drilling fluid technology in south china sea[J]. Oil Drilling & Production Technology, 2007,29(6):87-89. [6] 张勇. 南海莺琼地区高温高压钻井技术的探索[J]. 天然气工业,1999,19(1):71-75.ZHANG Yong. A study of the drilling techniques of high temperature and high pressure wells in Yingqiong resion of south China sea[J]. Natural gas industry, 1999,19(1):71-75. [7] 赵启彬,刘振江,王尔钧. 海上高温高压井测试工艺优化研究[J]. 钻采工艺,2015,38(1):32-34.ZHAO Qibin,LIU Zhenj i ang,WANG Er jun. Improvement and application of offshore HPHT well testing technology[J]. Drilling & Production Technology, 2015, 38(1):32-34. [8] 王文立. 高性能测试完井液的评价与应用[J]. 石油钻采工艺,2005,27(1):29-30.WANG Wenli. Evaluation and application of the goodproperty completion fluid for ultra-deep well test[J]. Oil Drilling & Production Technology,2005,27(1):29-30. [9] 孟文波,李蔚萍,张崇,等. 深水储层保护型测试液研究及在陵水17-2气田的应用[J]. 钻井液与完井液, 2015,32(5):23-26.MENG Wenbo,LI Weiping,ZHANG Chong, et al. Protective test fluid for deepwater reservoir:study and application in block Lingshui 17-2[J]. Drilling Fluid & Completion Fliud, 2015, 32(5):23-26. [10] 邱正松,韩成,黄维安,等. 微粉重晶石高密度钻井液性能研究[J]. 钻井液与完井液,2014,31(1):12-15.QIU Zhengsong,HAN Cheng,HUANG Weian, et al. The research and evaluation of high-density drilling fluid weighted by micronized barite[J]. Drilling Fluid & Completion Fliud, 2014, 31(1):12-15. [11] 韩成,邱正松,黄凯文,等. 表面活性剂与加重材料相互作用对钻井液性能影响的研究[J]. 钻井液与完井液,2014,31(6):9-12.HAN Cheng,QIU Zhengsong,HUANG Kaiwen, et al. Effects of interactions between weighting materials and surfactants on properties of drilling fluids[J]. Drilling Fluid & Completion Fliud, 2014, 31(6):9-12. [12] 邱正松,韩成,黄维安. 国外高密度微粉加重剂研究进展[J]. 钻井液与完井液,2014,31(3):78-82.QIU Zhengsong,HAN Cheng,HUANG Weian. The research progress of high-density micronized weighting agent abroad[J]. Drilling Fluid & Completion Fliud, 2014, 31(3):78-82.
