纳米孔缝下压裂液对页岩中甲烷运移的影响

王海燕,  郭丽梅,  胥云,  刘萍,  管保山,  吴家全,  薛延萍

downloadPDF
文章导航 > 钻井液与完井液  > 2018 >  35(3): 105-109
王海燕, 郭丽梅, 胥云, 刘萍, 管保山, 吴家全, 薛延萍. 纳米孔缝下压裂液对页岩中甲烷运移的影响[J]. 钻井液与完井液, 2018, 35(3): 105-109. doi: 10.3969/j.issn.1001-5620.2018.03.018
引用本文: 王海燕, 郭丽梅, 胥云, 刘萍, 管保山, 吴家全, 薛延萍. 纳米孔缝下压裂液对页岩中甲烷运移的影响[J]. 钻井液与完井液, 2018, 35(3): 105-109. doi: 10.3969/j.issn.1001-5620.2018.03.018
shu
WANG Haiyan, GUO Limei, XU Yun, LIU Ping, GUAN Baoshan, WU Jiaquan, XUE Yanping. Effect of Fracturing Fluid on the Migration of Methane in Shale with Nano-sized Fractures[J]. DRILLING FLUID & COMPLETION FLUID, 2018, 35(3): 105-109. doi: 10.3969/j.issn.1001-5620.2018.03.018
Citation: WANG Haiyan, GUO Limei, XU Yun, LIU Ping, GUAN Baoshan, WU Jiaquan, XUE Yanping. Effect of Fracturing Fluid on the Migration of Methane in Shale with Nano-sized Fractures[J]. DRILLING FLUID & COMPLETION FLUID, 2018, 35(3): 105-109. doi: 10.3969/j.issn.1001-5620.2018.03.018
shu

纳米孔缝下压裂液对页岩中甲烷运移的影响

doi: 10.3969/j.issn.1001-5620.2018.03.018

  • 1. 中国石油勘探开发研究院, 北京 065007;

  • 2. 天津科技大学化工与材料学院, 天津 300457

基金项目:

国家重大项目“井筒工作液新材料新体系基础研究”（2016A-3903），国家重大专项“储层改造关键流体研发”（2017ZX05023003）

详细信息
    作者简介:

    王海燕,高级工程师,1972年生,毕业于中国石油大学(北京)油气井工程专业,现主要从事压裂酸化产品开发及应用。电话(010)69213729;E-mial:wanghaiy69@petrochina.com.cn。

  • 中图分类号: TE357.12

Effect of Fracturing Fluid on the Migration of Methane in Shale with Nano-sized Fractures

  • 1. Research Institute of Petroleum Exploration and Development, Beijing 065007;

  • 2. College of Material Science and Chemical Engineering, Tianjin University of Science and Technology, Tianjin 300457

    摘要
  • 摘要: 压裂体积改造以及页岩自身性质都会产生大量纳米级微孔缝，通过模拟计算、实验数据并结合现场数据研究水滞留在页岩中对甲烷解吸运移的影响，通过经验公式计算得出，纳米环境下甲烷以间隙填充和水合溶解方式与水形成水溶气。分子动力学模拟显示水在纳米环境中分子有序度增加，链间氢键力减少，流动阻力小，扩散系数比宏观环境增大2个数量级；纳米通道内水中溶入甲烷后，扩散系数比单纯纳米环境中水大2个数量级，链间氢键力更小，流动几乎无阻力。页岩的毛细渗透可以使水进入纳米孔缝，吸附在页岩表面无法返排，造成返排率低。水进入页岩中竞争吸附置换甲烷，减少甲烷吸附量，有利于产能，但在低含水饱和度环境下，甲烷在水中溶解会造成一定永久残留，预吸水活性炭吸附解吸实验数据显示，当水量与孔容体积相当时，与干活性炭比较，甲烷吸附量减少60%，而溶解等综合因素无法解吸的甲烷残留最高为13.5%，几乎无自由水返出，综合结果水的存在正向贡献大。



    Abstract: Spatial fracture-network generated fracturing and the characteristics of shale itself produce large amount of nano-sized fractures in the shale. The effect of water retained in shale on desorption and migration of methane was studied through simulation, experiment and data from filed operations. Calculation with empirical equations showed that in nano-sized environment, methane fills the nano-sized fractures and is dissolved into water to form a water dissolved gas. Simulation with molecular dynamics showed that in nano-sized environment the degree of order of water molecules is increased, the hydrogen bond force between molecular chains is decreased. Low flow resistance in the nano-sized environment led to a coefficient of diffusion that was two orders of magnitude greater than that of the macro environment. When methane was dissolved in the water existed in nano-sized channels, the coefficient of diffusion of water molecules was two orders of magnitude greater than that of the water with no dissolved methane in nano-sized environment, and the hydrogen bond force was much lower. In this condition there is almost no flow resistance. Capillary penetration take place in shale formation drives water into nano-sized fractures, and is therefore adsorbed onto the surfaces of shale. The adsorption of water makes it difficult for the water to flow back, resulting in very low flowback efficiency. Water entering into shale competes with methane for adsorption onto the surfaces of shale and displaces methane, reducing the adsorption quantity of methane and is hence beneficial to increasing production rate. On the other hand, at low water saturation, some small amount of methane dissolved permanently in water. Data from adsorption-desorption experiment with active carbon with pre-absorbed water showed that, when the volume of water is equivalent to the pore adsorption quantity of methane on the surface of dry active carbon, and the amount of residue methane that is unable to desorb because of dissolution in water is 13.5% at most. In this condition there is almost no water flowback. All factors considered, the existence of water is beneficial to hydrocarbon production.



    • HTML全文
    • 参考文献(20)
  • [1] 张磊,康钦军,姚军,等. 页岩压裂中压裂液返排率低的孔隙尺度模拟与解释[J]. 科学通报,2014,32(59):3197-3203.

    ZHANG Lei,KANG Qinjun,YAO Jun,et al.The explanation of low recovery of fracturing fluid in shale hydraulic fracturing by pore-scale simulation[J].Chin Sci Bull,2014,59:3197-3203.
    [2] HORN A D.Breakthrough mobile water treatment converts 75% of fracturing flowback fluid to fresh water and lowers CO2 emissions[C]//SPE Americas E&P Environmental and Safety Conference.Society of Petroleum Engineers, 2009.
    [3] VIDIC R D,BRANTLEY S L,VANDENBOSSCHE J M, et al.Impact of shale gas development on regional water quality[J].Science,2013,340(6134):1235009.
    [4] 李贤庆,王元,郭曼,等. 川南地区下古生界页岩气储层孔隙特征研究[J]. 天然气地球科学,2015,26(8):1464-1470.

    LI Xianqing,WANG Yuan,GUO Man,et al.Pore characteristics of shale gas rese rvoirsfrom the lower paleoic in the south of Sichuan basin[J].Natural Gas Geoscience,2015,26(8):1464-1470.
    [5] 赵文智,王红军,徐春春,等. 川中地区须家河组天然气藏大范围成藏机理与富集条件[J]. 石油勘探与开发,2010,37(2):146-156.

    ZHAO Wenzhi,WANG Hongjun,XU Chunchun,et al. Reservoir-forming mechanism and enrichment conditions of the extensive Xujiahe formation gas reservoirs, central Sichuan basin[J].Petroleum Exploration and Development,2010,37(2):146-156.
    [6] 王世谦,罗启后,邓鸿斌,等. 四川盆地西部侏罗系天然气成藏特征[J]. 天然气工业,2001,21(2):1-8.

    WANG Shiqian,LUO Qihou,DENG Hongbin,et al. Characteristics of forming jurassic gas reservoirs in the west part of Sichuan basin[J].Natural Gas Industry, 2001,21(2):1-8.
    [7] 侯宇光,何生,易积正,等. 页岩孔隙结构对甲烷吸附能力的影响[J]. 石油勘探与开发,2014,41(2):248-256.

    HOU Yuguang,HE Sheng,YI Jizheng,et al.Effect of pore structure on methane sorption capacity of shales[J]. Petroleum Exploration and Development,2014,41(2):248-256.
    [8] 孙艳. 多孔介质储气研究[D]. 天津大学,2007. SUN Yan.Studies on gas storage in porous media[D]. Tianjin University,2007.
    [9] 李伟,秦胜飞,胡国艺,等. 水溶气脱溶成藏[J]. 石油勘探与开发,2011,38(6):662-669.

    LI Wei,QIN Shengfei,HU Guoyi,et al. Accumulation of water-soluble gas by degasification[J].Petroleum Exploration and Development,2011,38(6):662-669.
    [10] 付晓泰,王振平,卢双舫. 气体在水中的溶解机理及溶解度方程[J]. 中国科学B辑,1996,26(2):124-130.

    FU Xiaotai,WANG Zhenpeng,LU Shuangfang,et al. Gas dissolution mechanism and solubility equation in water[J].Science in China(Series B),1996,26(2):124-130.
    [11] 赵玉集,郭为,熊伟,等. 页岩等温吸附/解吸影响因素研究[J]. 天然气地球科学,2014,25(6):940-946.

    ZHAO YUji,GUO Wei,XIONG Wei,et al.Study of pmpact factors on shale gas adsorption and desorption[J]. Natural Gas Geoscience,2014,25(6):940-946.
    [12] 欧志鹏. 纳米孔隙中甲烷扩散的分子动力学研究[D]. 西南石油大学,2014. OU Zhipeng.Molecular dynamics study of methane diffusion in nanopores[D].Southwest Petroleum University,2014.
    [13] MACDONALD R J, FRANTZ JR J H,MERRIAM G W, et al. Application of innovative technologies to fractured devonian shale reservoir exploration and development activities[C]//SPE Eastern Regional Meeting. Society of Petroleum Engineers,2003.
    [14] 邹桂敏. 分子在纳米微孔材料中扩散行为的分子动力学模拟研究[D]. 中北大学,2011. ZHOU Guimin.Study on the molecular diffusion in nanoporous materials by molecular dynamics simulation[D]. North University of China,2011.
    [15] 谈荣日,邵建群.SPC、SPC/E和TIP3P模型水的结构和性质[J]. 现代机械,2011(4):92-94. TAN Rongri,SHAO Jianqun.Structures and properties of SPC,SPC/E,TIP3

    P water[J].Modern Machinery,2011(4):92-94.
    [16] 冯梅,叶超,陈艳燕,等. 受限在纳米水环境空间中的甲烷分子[J]. 浙江师范大学学报,2014,27(2):183-186.

    FENG Mei,YE Chao,CHEN Yanyan,et al.Methane molecules confined in nanotube filed with water[J]. Journal of Zhejiang Normal University,2014,27(2):183-186.
    [17] 张磊,张义平,陈奕羲,等. 压裂裂缝对页岩储层压力影响模拟研究[J]. 煤炭技术,2017,36(6):69-71.

    ZHANG Lei,ZHANG Yiping,CHENG Yixi,et al. Simulation study on effect of fracturing fracture on shale reservoir pressure[J].Coal Technology,2017,36(6):69-71.
    [18] 刘真光,邱正松,钟汉毅,等. 页岩储层超临界CO2压裂液滤失规律实验研究[J]. 钻井液与完井液,2016, 33(1):113-117.

    LIU Zhenguang,QIU Zhengsong,ZHONG Hanyi,et al. Study on filtration property of hypercritical CO2 fracturing fluid for shale reservoirs[J].Drilling Fluid & Completion Fluid,2016,33(1):113-117.
    [19] 李勇明,彭瑀,王中泽. 页岩气压裂增产机理与施工技术分析[J]. 西南石油大学学报:自然科学版,2013, 35(2):90-96.

    LI Yongming,PENG Yu,WANG Zhongze. Analysis of shale gas fracture stimulation mechanism and operating techniques[J].Journal of Southwest Petroleum University:Science & Technology Edition,2013,35(2):90-96.
    [20] 安凤山. 天然气成矿系统分析与讨论——以川西塌陷致密砂岩领域为例[M]. 石油与天然气质地文集第六集,北京地质出版社,1997:48-62. AN Fengshan.Analysis and discussion on natural gas system-take tight sandstones in western Sichuan depression for example[M].Oil &gas geology collection No6,Beijing Geological Publishing House,1997

    :48-62.
