靖南区块漏失井固井工艺研究

吴阳,  肖志海,  沈小刚,  郭一兵,  金志轩

downloadPDF
文章导航 > 钻井液与完井液  > 2017 >  34(6): 95-99
吴阳, 肖志海, 沈小刚, 郭一兵, 金志轩. 靖南区块漏失井固井工艺研究[J]. 钻井液与完井液, 2017, 34(6): 95-99. doi: 10.3969/j.issn.1001-5620.2017.06.018
引用本文: 吴阳, 肖志海, 沈小刚, 郭一兵, 金志轩. 靖南区块漏失井固井工艺研究[J]. 钻井液与完井液, 2017, 34(6): 95-99. doi: 10.3969/j.issn.1001-5620.2017.06.018
shu
WU Yang, XIAO Zhihai, SHEN Xiaogang, GUO Yibing, JIN Zhixuan. Study on Well Cementing Techniques for Wells with Lost Circulation in Jingnan Area[J]. DRILLING FLUID & COMPLETION FLUID, 2017, 34(6): 95-99. doi: 10.3969/j.issn.1001-5620.2017.06.018
Citation: WU Yang, XIAO Zhihai, SHEN Xiaogang, GUO Yibing, JIN Zhixuan. Study on Well Cementing Techniques for Wells with Lost Circulation in Jingnan Area[J]. DRILLING FLUID & COMPLETION FLUID, 2017, 34(6): 95-99. doi: 10.3969/j.issn.1001-5620.2017.06.018
shu

靖南区块漏失井固井工艺研究

doi: 10.3969/j.issn.1001-5620.2017.06.018

  • 川庆钻探工程有限公司长庆固井公司, 陕西榆林 718500

基金项目:

川庆钻探工程有限公司研究项目“苏里格小套管固井工艺技术推广应用”（CQ2015D-48-4-3）。

详细信息
    作者简介:

    吴阳,毕业于西安石油大学材料工程学院,主要从事固井技术研究工作。电话18591937520;E-mail:xiaozhihai06011@163.com。

  • 中图分类号: TE256.9

Study on Well Cementing Techniques for Wells with Lost Circulation in Jingnan Area

  • CCDC Changqing Cementing Company, Yulin, Shaanxi 710018

    摘要
  • 摘要: 为了提高苏里格气田靖南区块漏失井填充段固井质量，考察了不同堵漏剂对水泥浆性能的影响，研制了一套适合该区块的轻珠堵漏水泥浆体系。首先优选出植物颗粒（A）、纤维混合物QD-2和复合纤维DF-NIN堵漏剂，并通过正交实验可知，3种堵漏剂的质量分数分别按照2%、2%和3%复配堵漏效果最好，水泥石的抗压强度为7.6 MPa。通过堵漏性能评价可知，水泥浆的漏失量大幅度降低，且基本性能均满足固井质量要求。通过对该区块地质特征进行调研，制定出一套新的固井工艺技术，该工艺技术在靖南区块试验8井次，其一界面固井质量合格率均在95%以上，二界面固井质量合格率均在99%以上。这说明轻珠堵漏水泥浆体系及漏失井固井工艺能大幅提升填充段固井质量，最大程度地满足漏失井全井段封固质量的要求。



    Abstract: A cementing slurry treated with light weight plastic beads has been developed to improve well cementing job quality of the gravel-packing section of a well in Jingnan block, Sulige gas field. Lost circulation has been frequently encountered in this area, hence different lost circulation materials (LCMs) were studied for their effects on the properties of the cementing slurry developed. Three LCMs, a plant particle (A), a mixed fiber QD-2 and a compound fiber DF-NIN, were studied through orthogonal experiment. It has been found that when the three LCMs were added into cement slurries in concentrations of 2%, 2% and 3% respectively, best performance of lost circulation control can be obtained, and the cement slurry had compressive strength of 7.6 MPa. In laboratory lost circulation test, the volume of slurry lost was greatly reduced, and the basic properties of the cement slurry were able to satisfy the needs of well cementing. A set of well cementing techniques were established based on the investigation of the geological characteristics of the formations. The cement slurry and the techniques developed have been applied in Jingnan area for 8 times, the percent of pass of cementing between cement sheath and casing string was 95%, and this number was 99% for the cementing between cement sheath and borehole wall, demonstrating that the light weight lost circulation control cement slurry is able to greatly improve the quality of cementing job in the gravel-packing section of a well, and satisfy the needs at utmost of sealing a whole well.



    • HTML全文
    • 参考文献(17)
  • [1] 丁士东. 国内外固井技术现状及发展趋势[J]. 钻井液与完井液,2002,19(5):35-39.

    DING Shidong.Present state and developing trend of cementing technology at home and abroad[J].Drilling Fluid & Completion Fluid,2002,19(5):35-39.
    [2] 姚晓,周保中,赵元才,等. 国内油气田漏失性地层固井防漏技术研究[J]. 天然气工业,2005,25(6):41-44.

    YAO Xiao,ZHOU Baozhong,ZHAO Yuancai,et al. Leak resistance techniques of thief zone cementing in domestic oil and gas fields[J].Natural Gas Industry, 2005,25(6):41-44.
    [3] 康雪林,王延东. 延长气田易漏失井固井前井眼准备技术[J]. 钻采工艺,2009,32(5):119-120.

    KANG Xuelin,WANG Yandong.Borehole preparation technology before cementing in yanchang oilfield absorption well[J].Drilling & Production Technology, 2009,32(5):119-120.
    [4] 曾艳军,姚平均,陈道元,等. 延长气田易漏失井不规则井眼固井技术[J]. 石油钻采工艺,2013,35(2):52-55.

    ZENG Yanjun,YAO Pingjun,CHEN Daoyuan,et al.Irregular borehole cementing technology in leakage wells of yanchang gas field[J].Oil Drilling & Production Technology,2013,35(2):52-55.
    [5] ROBERT BROOKS,JACK NEWBERRY,PAUL COOK,et al.Preventing annular gas flow in conjunction with 2 stage cementing[Z].SPE 116447.
    [6] 李雨威,王乐,王胜,等. 低压漏失井固井水泥浆体系的研究[J]. 石油与天然气化工,2009,38(1):69-71.

    LI Yuwei,WANG Le,WANG Sheng,et al.The study of cement slurry system in leaking control well[J]. Chemical Engineering of Oil & Gas,2009,38(1):69-71.
    [7] 潘国臣,刘锋,徐伟,等. 塔河油田严重漏失井挤水泥堵水工艺研究[J]. 钻采工艺,2013(2):12-14. PAN Guochen,LIU Feng,XU Wei,et al.Study on cement squeeze water plugging technology of the serious absorption well in tabe oilfield[J].Drilling & Production Technology,2013

    (2):12-14.
    [8] 周剑,高德伟,严海兵. 早强低密度水泥浆体系提高低压易漏井固井质量[J]. 天然气工业,2012,32(4):72-74.

    ZHOU Jian, GAO Dewei, YAN Haibing.A early strength and low density cement slurry system used to improve cementing in low pressure thief zones[J].Natural Gas Industry,2012,32(4):72-74.
    [9] KULAKOFSKY D,PAREDES J L,HALLIBURTON J M.Ultralightweight cementing technology sets world record for liner cementing with a 5.4 Lbm/gal slurry density[Z].SPE 98124.
    [10] 韩玉玺,李云贵,单素华. 孔隙-裂缝性漏失层防漏堵漏技术[J]. 油田化学,2010,27(3):239-241.

    HAN Yuxi,LI Yungui,SHAN Suhua.The research on leak protection and sealing technology of porous-fractured leakage bed[J].Oilfield Chemistry,2010,27(3):239-241.
    [11] 邹建龙,朱海金,张清玉,等.BCE-200S防漏外加剂体系的研究与应用[J]. 钻井液与完井液,2007,24(4):47-49.

    ZOU Jianlong,ZHU Haijin,ZHANG Qingyu,et al. Study on and application of the lost circulation material BCE-200S[J].Drilling Fluid & Completion Fluid,2007, 24(4):47-49.
    [12] 杨旭东,姚平均,曹平,等. 中原油田濮7区块漏失井固井技术[J]. 石油钻采工艺,2012(4):33-35. YANG Xudong,YAO Pingjun,CAO Ping,et al. Cementing technology for mud loss well at pu7

    block in Zhongyuan oilfield[J].Oil Drilling & Production Technology,2012(4):33-35.
    [13] 王悦坚. 塔河油田恶性漏失堵漏与大幅度提高地层承压技术[J]. 钻井液与完井液,2013(4):33-36. WANG Yuejian.Technology on mud lost contol of sever lost circulation and improving formation pressure containment in Tahe oilfield[J].Drilling Fluid & Completion Fluid,2013

    (4):33-36.
    [14] CARRASCO-TEJA M,FRIGAARD I A,B.SEymour. Cement Horizontal wells:Complete Zonal Isolation Without Casing Rotation[J].SPE 114955.
    [15] 宋有胜,邹建龙,赵宝辉,等. 高石梯-磨溪区块高压气井尾管固井技术[J]. 钻井液与完井液,2017,34(2):111-116.

    SONG Yousheng,ZOU Jianlong,ZHAO Baohui,et al. Cementing the φ177.8 mm liner in the block Gaoshiti-Moxi[J].Drilling Fluid & Completion Fluid,2017,34(2):112-116.
    [16] 田宝振,李清洁,覃毅,等. 塔中碎屑岩井自愈合水泥浆固井技术[J]. 钻井液与完井液,2016,33(6):84-90.

    TIAN Baozhen,LI Qingjie,QIN Yi,et al.Cementing wells penetrating clastic rocks with self-healing cement in block tazhong[J].Drilling Fluid & Completion Fluid, 2016,33(6):84-90.
    [17] BINMOQBIL K H,Al-OTAIBI M A,AL-FAIFI M G, et al.Cleanup of oil-based mud filter cake using an in-situ acid generator system by a single-stage treatment[R].SPE 126065,2009
