环保型高性能水基钻井液在山前超深井中的应用

李家学,  张绍俊,  李磊,  孙东山,  张超,  王涛

downloadPDF
文章导航 > 钻井液与完井液  > 2017 >  34(5): 20-26
李家学, 张绍俊, 李磊, 孙东山, 张超, 王涛. 环保型高性能水基钻井液在山前超深井中的应用[J]. 钻井液与完井液, 2017, 34(5): 20-26. doi: 10.3969/j.issn.1001-5620.2017.05.004
引用本文: 李家学, 张绍俊, 李磊, 孙东山, 张超, 王涛. 环保型高性能水基钻井液在山前超深井中的应用[J]. 钻井液与完井液, 2017, 34(5): 20-26. doi: 10.3969/j.issn.1001-5620.2017.05.004
shu
LI Jiaxue, ZHANG Shaojun, LI Lei, SUN Dongshan, ZHANG Chao, WANG Tao. Application of Environmentally Friendly High Performance Water Base Muds in Ultra Depp Well Drilling in Piedmont Area[J]. DRILLING FLUID & COMPLETION FLUID, 2017, 34(5): 20-26. doi: 10.3969/j.issn.1001-5620.2017.05.004
Citation: LI Jiaxue, ZHANG Shaojun, LI Lei, SUN Dongshan, ZHANG Chao, WANG Tao. Application of Environmentally Friendly High Performance Water Base Muds in Ultra Depp Well Drilling in Piedmont Area[J]. DRILLING FLUID & COMPLETION FLUID, 2017, 34(5): 20-26. doi: 10.3969/j.issn.1001-5620.2017.05.004
shu

环保型高性能水基钻井液在山前超深井中的应用

doi: 10.3969/j.issn.1001-5620.2017.05.004

  • 1. 塔里木油田公司油气工程研究院, 新疆库尔勒 841000;

  • 2. 塔里木油田公司库车油气开发部, 新疆库尔勒 841000;

  • 3. 能新科(中国)科技有限公司, 北京 100022

基金项目:

国家重大专项“前陆冲断带超深井安全快速钻井技术（2016ZX05051002）”部分研究成果。

详细信息
    作者简介:

    李家学,高级工程师,博士,1979年生,毕业于西南石油大学油气井工程专业,现在从事钻井液技术研究工作。电话(0996)2174315;E-mail:liji3211979@163.com。

  • 中图分类号: TE254.3

Application of Environmentally Friendly High Performance Water Base Muds in Ultra Depp Well Drilling in Piedmont Area

  • 1. Research Institute of Oil and Gas Engineering, PetroChina Tarim Oilfield Division, Korla, Xinjiang 841000;

  • 2. Department of Kuche Oil and Gas Development, PetroChina Tarim Oilfield Division, Korla, Xinjiang 841000;

  • 3. EntiPetrotech Corp, Beijing 100022

    摘要
  • 摘要: 针对库车山前构造超深、超高压、高温、高含盐地层常规高密度水基钻井液性能调控维护困难，钻进时阻卡等事故频发，安全钻达目的层极其困难等问题，试验应用了环境保护型高性能水基钻井液。该钻井液是由多元高性能井眼稳定剂、纳米成膜封堵剂、高效润滑剂、特殊提速剂等组成，具有抑制性强、流变性和润滑性良好、环境友好、保护储层等性能。该环境保护型高性能水基钻井液在库车山前x井进行了试验应用，应用表明高性能水基钻井液性能稳定，抑制性强，润滑性能好，相比于应用油基钻井液的邻井，机械钻速快6.6%，无事故，井下复杂相对很少。该环境保护型高性能水基钻井液体系环保指标检测合格，产生的岩屑呈土本色，生物毒性小，是环境敏感地区复杂地层提高钻井清洁生产水平的途径之一。



    Abstract: High density water base drilling fluids have been used to drill ultra-deep, high temperature, ultra-high pressure wells penetrating salt formations in the piedmont structure in Kuche County, Xinjiang. Challenges encountered using conventional water base drilling fluids included difficulties in mud property maintenance, tight hole and pipe sticking. An environmentally friendly high performance water base drilling fluid formulated with borehole wall stabilizer, nano filming agent, high performance lubricant and specially designed fast drilling agent was tested in field operations. The high performance drilling fluid had high inhibitive capacity and good rheology and lubricity, and was environmentally friendly. It also helped protect reservoirs from being damaged. The application of this drilling fluid in a well drilled in the piedmont structure in Kuche has proved its performance as said above. Rate of penetration (ROP) of the well was 6.6% faster than the ROP of an offset well drilled with oil base drilling fluid. No drilling accidents have ever occurred, and occurrence of downhole complications was greatly reduced. This high performance low bio-toxicity water base drilling fluid has passed environment protection inspection. Drill cuttings produced were in their original colors, and were not colored by the drilling fluid. This environmentally friendly high performance drilling fluid has provided a means of drilling complex formations in environmentally sensitive area.



    • HTML全文
    • 参考文献(17)
  • [1] 王书琪,唐继平,张斌,等. 塔里木山前构造带高密度钻井液堵漏技术[J]. 钻井液与完井液,2006,23(1):76-77.

    WANG Shuqi, TANG Jiping, ZHANG Bin, et al. Sealing loss of high density drilling fluid in foothill structural zone of Tarim[J]. Drilling Fluid & Completion Fluid, 2006,23(1):76-77.
    [2] 尹达,叶艳,李磊,等,塔里木山前构造克深7井盐间高压盐水处理技术[J]. 钻井液与完井液,2012,29(5):6-8.

    YIN Da, YE Yan, LI Lei, et al. High pressure salt water treatment technology of well Keshen7 in foothill structural zone of Tarim[J]. Drilling Fluid & Completion Fluid, 2012,29(5):6-8.
    [3] JINZHI ZHU, LONG LI, LEI LI, et al. Application of UDM-2 drilling fluid technology in the development of upper-deep of oil and gas resources in Tarim basin[J]. SPE 176933-MS,2015.
    [4] 安文华, 王书琪,王泽华. 东秋8井下尾管高密度油基防卡钻井液研究与应用[J]. 钻井液与完井液,2003, 20(6):13-16.

    AN Wenhua, WANG Shuqi, WANG Zhehua. Study on high density oil-based drilling fluid and its application for liner running in well Dongqiu-8[J]. Drilling Fluid & Completion Fluid, 2003,20(6):13-16.
    [5] 张跃, 张博, 吴正良,等. 高密度油基钻井液在超深复杂探井中的应用[J]. 钻采工艺,2013,36(6):96-97.

    ZHANG Yue, ZHANG Bo, WU Zhengliang. et al. Application of high density oil-based drilling fluid in ultra-deep wells[J]. Drilling & Production Technology. 2013,36(6):96-97.
    [6] 杨振杰,环保钻井液技术现状及发展趋势[J]. 钻井液与完井液,2004,21(2):39-42.

    YANG Zhenjie. Present state of environmental protection drilling fluid and its development direction[J]. Drilling Fluid & Completion Fluid, 2004, 21(2):39-42.
    [7] 邹盛礼,吴晓花,杜小勇,等,抗高温环保钻井液体系研究[J]. 油气田环境保护,2011,21(5):51-53.

    ZOU Shenli, WU Xiaohua, DU Xiaoyong, et al. On antihigh temperature environment friendly drilling fluid[J]. Environmental Protection of Oil & Gas Fields,2011, 21(5):51-53.
    [8] 瞿凌敏,熊新民,邓建玲,库车坳陷复合盐层高密度环保钻井液技术研究[J]. 油气田环境保护,2011,21(5):37-40.

    QU Lingmin, XIONG Xinmin, DENG Jianling, et al. High density environment-friendly drilling fluids in complex salt bed of kuqa depression[J].Environmental Protection of Oil & Gas Fields. 2011,21(5):37-40.
    [9] 赵虎,龙大清,司西强,等. 烷基糖苷衍生物钻井液研究及其在页岩气井的应用[J]. 钻井液与完井液, 2016,33(6):23-27.

    ZHAO Hu, LONG Daqing, SI Xiqiang, et al. Study on alkyl polyglucoside derivative drilling fluid and its use in shale gas drilling[J].Drilling Fluid & Completion Fluid, 2016, 33(6):23-27.
    [10] 李蔚萍,向兴金,舒福昌,等,高效环保型水基洗井液室内研究与性能评价[J]. 精细石油化工,2007,8(10):1-4.

    LI Weiping, XIANG Xinjin, SHU Fuchang, et al. Laboratory study on high efficient environment-friengly water-based well-cleaning fluid[J]. Advances in Fine Petrochemicals, 2007,8(10):1-4.
    [11] 张金波,彭小红,高峰,等,环保钻井液Bio-Pro体系在乍得的成功应用[J]. 钻井液与完井液,2009,26(1):67-68.

    ZHANG Jinbo, PENG Xiaohong, GAO Feng, et al. The successful use of Bio-Pro drilling fluid in Chad[J]. Drilling Fluid & Completion Fluid, 2009, 26(1):67-68.
    [12] 龙大清,樊相生,王昆,等. 应用于中国页岩气水平井的高性能水基钻井液[J]. 钻井液与完井液,2016, 33(1):17-21.

    LONG Daqing,FAN Xiangsheng,WANG Kun, et al. High performance water base drilling fluid for shale gas drilling[J]. Drilling Fluid & Completion Fluid,2016,33(1):17-21.
    [13] 张克勤,何纶,安淑芳,等. 国外高性能水基钻井液介绍[J]. 钻井液与完井液,2007, 24(3):69-72.

    ZHANG Keqin, HE Lun, AN Shufang. et al. An introduction to the high performance water base muds abroad[J]. Drilling Fluid & Completion Fluid, 2007, 24(3):68-73.
    [14] 闫丽丽, 李丛俊, 张志磊,等. 基于页岩气"水替油" 的高性能水基钻井液技术[J]. 钻井液与完井液,2015, 32(5):1-6.

    YAN Lili, LI Congjun, ZHANG Zhilei. et al. High Performance water base drilling fluid for shale gas drilling[J]. Drilling Fluid & Completion Fluid, 2015, 32(5):1-6.
    [15] DEVILLE J P, FRITZ B, JARRETT M. Development of water-based drilling fluids customized for shale reservoirs[C]. SPE 140868,2011.
    [16] 赵欣, 邱正松, 高永会, 等. 缅甸西海岸深水气田水基钻井液优化设计[J]. 石油钻探技术, 2015, 43(1):13-18.

    ZHAO Xin,QIU Zhengsong,GAO Yonghui,et al. Design optimization for water-based drilling fluids in a deepwater gas field on the Western Coast of Myanmar[J]. Petroleum Drilling Techniques,2015,43(4):13-18.
    [17] 邸伟娜,闫娜,叶海超. 国外页岩气钻井液技术新进展[J]. 钻井液与完井液,2014,31(6):76-81.

    DI Weina,YAN Na,YE Haichao.Overseas new progressesin nano drilling fluid technology for shale drilling[J]. Drilling Fluid & Completion Fluid,2014,31(6):76-81.
