一种基于阳离子稠化剂的高抗盐压裂液研究及应用

徐克彬; 任勇强; 王中泽; 付玥颖; 杨昱; 刘玉海; 杨小涛

doi:10.3969/j.issn.1001-5620.2017.03.020

一种基于阳离子稠化剂的高抗盐压裂液研究及应用

doi: 10.3969/j.issn.1001-5620.2017.03.020

1. 中石油渤海钻探井下作业分公司, 河北任丘 062552;
2. 中石油渤海钻探工程技术研究院, 天津 300457

基金项目:

中国石油集团渤海钻探工程有限公司重大专项课题"超高温储层改造液体系和核心处理剂研究"（2014ZD05K）；国家科技重大专项"储层改造关键流体研发"（2016ZX05023-3）。

详细信息

作者简介:
徐克彬,高级工程师,现在从事试油测试及修井完井工作。E-mail:xukebin@cnpc.com.cn。

中图分类号: TE357.12
计量
- 文章访问数: 648
- HTML全文浏览量: 207
- PDF下载量: 161
- 被引次数: 0
出版历程
- 收稿日期: 2017-02-05
- 刊出日期: 2017-05-31

Study and Application of a High Temperature Salt-Resistant Fracturing Fluid Formulated with a Cationic Thickening Agent

1. Downhole Operation Branch of CNPC Bohai Drilling Engineering Company Limited, Renqiu, Hebei 062552;
2. Research Institute of Engineering, CNPC Bohai Drilling Engineering Company Limited, Renqiu, Hebei 062552

摘要

摘要: 针对目前压裂作业向着高温油气藏措施改造、节约用水，利用海水、地层高矿化度水配液等非常规领域的拓展，通过对疏水缔合聚合物压裂液增黏机理研究，基于阴阳离子电吸引原理，开发研制了自缔合高抗盐压裂液体系，并对其进行了性能评价和现场应用。研究表明，在阳离子聚合物溶液中加入阴离子表面活性剂十二烷基苯磺酸钠，可以使聚合物分子通过静电吸引作用进行自缔合交联，并通过在分子中引入球状胶束及钙镁离子稳定剂，大幅度增强压裂液的抗温抗盐性能。该压裂液体系黏度可以达到331 mPa·s，耐盐达60 000 mg·L^-1，有良好的抗钙镁性能，岩心伤害性低，在130℃、170 s^-1剪切1 h后黏度保持在50 mPa·s以上，可以满足60~130℃水温配液和压裂施工的要求；并且该压裂液在剪切速率上升时黏度降低，剪切速率下降时黏度又会恢复，可以有效降低摩阻。该体系在华北油田二连地区阿尔3-26井现场应用，采用矿化度达到9 104 mg·L^-1的邻井地层水直接进行配液，提高了施工效率，增油效果显著。体系原料易得、成本价格低，抗盐性明显优于其他压裂液体系，具有良好的应用前景。
- 压裂液 /
- 稠化剂 /
- 自缔合 /
- 耐温性 /
- 抗盐性
Abstract: In view of the current fracturing operations toward high-temperature oil and gas reservoir measures, water saving, mixing fracturing fluid by seawater or high salinity water, and other unconventional areas of development based on the study of the mechanism of hydrophobic associative polymer fracturing fluid, a self-association high salt-resistant fracturing fluid system was developed using the principle of anion and cation suction. Performance evaluation and field application of this kind of fracturing fluid system were carried out. Results show that addition of the anionic surfactant named dodecylbenzenesulfonic acid to the cationic polymer solution made the polymer molecules occur self associative reaction of electrostatic attraction; the addition of spherical micelles, calcium and magnesium ion stabilizer, enhanced the anti-temperature and salt resistance performance of the fracturing fluid.The fracturing fluid system viscosity can reach 331 mPa·s, it's salt resistant to 60,000 mg·L^-1 and it has good resistance to calcium and magnesium,the core damage is lower than other fracturing, and the viscosity can be maintained above 50 mPa·s at 130℃and 170 s^-1 shear 1h, which can meet the requirements of water temperature distribution and fracturing construction at the temperature of 60-130℃. Moreover, the viscosity of the fracturing fluid decreases with the increase of shear rate and the viscosity will be restored when the shear rate decreases,this shows that it can effectively reduce the friction resistance.The system is applied in the field of 3-26 well in the Erlian of North China oil field,It uses the mineralization degree of 9,104 mg·L^-1 of the formation of water directly to the liquid, which can improve the construction efficiency and increase the oil effect obviously.This system is easy to get raw materials, low cost, salt resistance is better than other fracturing fluid system, so it has a good application prospect.
- Fracturing fluid /
- Thickening agent /
- Self-association /
- Temperature resistance /
- Salt resistance

HTML全文

参考文献(13)

[1]	王素兵,叶登胜,尹丛彬,等.非常规气藏增产改造与监测技术实践[J].天然气工业,2012,32(7):38-42. WANG Subing,YE Dengsheng,YIN Congbin,et al.Field practices of unconventional gas reservoir stimulation and monitoring technology[J].Natural gas industry,2012,32(7):38-42.
[2]	李勇明,彭瑀,王中泽.页岩气压裂增产机理与施工技术分析[J].西南石油大学学报,自然科学版,2013,35(2):90-95. LI Yongming,PENG Yu,WANG Zhongze.Analysis of shale gas fracture stimulation mechanism and operating techniques[J].Journal of Southwest Petroleum University (Science &Technology Edition),2013,35(2):90-95.
[3]	任闽燕,姜汉桥,李爱山,等.非常规天然气增产改造技术研究进展及其发展方向[J].油气地质与采收率,2013,20(2):103-108. REN Minyan,JIANG Hanqiao,LI Aishan,et al.Review on study progress of unconventional gas stimulation technology[J].Petroleum Geology and Recovery Efficiency,2013,20(2):103-108.
[4]	邹才能,杨智,朱如凯,等.中国非常规油气勘探开发与理论技术进展[J].地质学报,2015,89(6):979-1007. ZOU Caineng,YANG Zhi,ZHU Rukai,et al.Progress in China's unconventional oil &gas exploration and development and theoretical technologies[J].Acta Geologica Sinica,2015,89(6):979-1007.
[5]	陈作,曾义金.深层页岩气分段压裂技术现状及发展建议[J].石油钻探技术,2016,44(1):6-11. CHEN Zuo,ZENG Yijin.Present situations and prospects of multi-stage fracturing technology for deep shale gas development[J].Petroleum Drilling Techniques,2016,44(1):6-11.
[6]	Alfred R Jennings Jr,曾中立.压裂液发展综述[J].吐哈油气,2006,1(4):71-76.ALFRED R JENNINGS Jr,ZENG ZHONGLI.Review of the development of fracturing fluid[J].Tuha Oil &Gas,2016,44(1):6-11.
[7]	何乐,王世彬,郭建春,等.高矿化度水基压裂液技术研究进展[J].油田化学,2015,32(4):621-627. HE Le,WANG Shibin,GUO Jianchun,et al.Research progress of high-salinity water based fracturing fluids[J].Oilfield Chemistry,2015,32(4):621-627.
[8]	赵军,张劲,肖丽佳,等.耐高温阴离子表面活性剂压裂液的性能评价及现场应用[J].钻采工艺,2015,38(1):86-90. ZHAO Jun,ZHANG Jin,XIAO Lijia,et al.Performance evaluation and field application of high temperature anionic sufactant fracturing fluid[J].Drilling &Production Technology,2015,38(1):86-90.
[9]	李志臻,杨旭,夏冰,等.一种新型无瓜胶电吸引聚合物压裂液体系[J].钻井液与完井液,2014,31(5):85-88. LI Zhizhen,YANG Xu,XIA Bing,et al.A new kind of non guar gum electric attraction polymer fracturing fluid system[J].Drilling Fluid &Completion Fluid,2014,31(5):85-88
[10]	李志臻,杨旭,涂莹红,等.一种聚合物压裂液稠化剂的性能研究及应用[J].钻井液与完井液,2015,32(3):1-6. LI zhizhen,YANG Xu,TU Yinghong,et al.Study and application of a polymer fracturing fluid thickener.[J].Drilling Fluid &Completion Fluid,2015,32(3):1-6
[11]	黄晶,杨旭,刘菲,等.水基压裂用聚电解质复合溶液的研究[J].钻井液与完井液,2015,32(6)81-84. HUANG Jing,YANG Xu,LIU Fei,et al.Study on polyelectrolyte complex solution for water base fracturing[J].Drilling Fluid &Completion Fluid,2015,32(6):81-84.
[12]	尚立涛.超级瓜胶压裂液技术研究与应用[D].东北石油大学,2011.SHANG Litao.A study and application of super guar gum fracturing fluid technology[D].Northeast petroleum university,2011.
[13]	姜阿娜.王家岗油田高凝油储层热污水压裂技术[J].特种油气藏,2013,20(6):126-128. JIANG Ana.Application of hot sewage fracturing fluid in high-pour-point oil reservoir of Wangjiagang oilfield[J].Special Oil and Gas Reservoirs,2013,20(6):126-128.
