Cementing Wells Penetrating Clastic Rocks with Self-healing Cement in Block Tazhong
-
摘要: 塔里木油田塔中区块碎屑岩地层结构复杂、成岩性差、韧性小、脆性高,钻井施工过程中井壁易垮塌、剥落,导致形成“大肚子”、“糖葫芦”等不规则井眼;生产套管固井存在二叠系承压能力较低、易漏,地层油水同层、砂泥互层、砂层薄含油层多、油层水层相隔很近,油水互窜,难压稳,固井质量要求高等难点。针对这些难点,通过水泥浆气窜机理研究,采用硅粉、减轻增强材料BCE-610S、中温缓凝剂BXR-200L、减阻剂BCD-210L、自愈合剂BCY-200S、防窜降失水剂BCG-200L,研究出了密度为1.35 g/cm3的领浆与密度1.88 g/cm3的尾浆。该水泥浆体系具有稳定性好、流动性好、零析水,失水量低(小于50 mL)、弹性模量接近于7 GPa,抗压强度高,防窜能力强等特点。同时优化水泥浆柱结构实现平衡压力固井,应用固井软件模拟提高顶替效率,形成了一套适合塔中碎屑岩井固井的自愈合水泥浆固井技术。塔中4口井固井结果显示,4口井全井封固质量合格,主力油气层段封固优质,有效解决了塔里木碎屑岩固井施工难题。Abstract: The clastic formations in the Block Tazhong have complex structures, poor lithological characters and toughness, and high brittleness. During drilling operation, wells penetrating the clastic formation have experienced borehole collapse and sloughing, and borehole of irregular sizes was formed. Cementing of the production casing string has long been facing with diffculties such as low formation pressure and mud losses in the Permian system, coexistence of oil and water in the same zone, interbedding of sandstone and shale, thin sandstones and hence multiple pay zones, short distance between a pay zone and a water zone, and inter-channeling of oil and water, etc. Based on the study on the mechanism of gas-channeling in cement slurry, a leading slurry with density of 1.35 g/cm3, and a tail slurry with density of 1.88 g/cm3 were formulated with several additives, such as silica powder, lightweight material BCE-610S, medium temperature retarder BXR-200L, drag reducer BCD-210L, self-healing agent BCY-200S and anti-channeling flter loss reducer BCG-200L. This cement slurry had good stability, mobility, zero free water, low fltration rate (flter loss<50 mL), elastic modulus near 7 GPa, high compressive strength, and ability of anti-channeling. By optimizing the composition of the cement slurry column in hole, pressure balancing during well cementing was realized. Using well cementing software, the displacing effciency was improved. As a set of self-healing cementing technology, it has been used in 4 wells in Tazhong, all cementing jobs successful, especially the main pay zones which were cemented with excellent job quality, effectively solved the diffculties in well cementing in clastic rock formations.
-
[1] 顾家裕, 宁从前, 贾进华. 塔里木盆地碎屑岩优质储层特征及成因分析[J]. 地质评论, 1998, 44(1):83-89.GU Jiayu, NING Congqian, JIA Jinhua. High-quality reservoir features and genetic analysis of clastic rocks in the Tarim basin[J].Geology Reviews, 1998, 44(1):83-89. [2] 沈磊, 孙万兴, 吴洪波, 等. 浅谈提高塔中油田碎屑岩固井质量的方法[J]. 化工管理, 2015, 15:99. SHEN Lei, SUN Wanxing, WU Hongbo, et al. On improving tower oilfield cementing clastic methodological quality[J]. Chemical Management, 2015, 15:99. [3] 钟福海, 孙万兴, 钟德华, 等. 中古514井超长封固段固井技术[J]. 钻井液与完井液, 2013, 30(3):64-66.ZHONG Fuhai, SUN Wanxing, ZHONG Dehua, et al.Cementing technology of cementing section of well Zhonggu514[J].Drilling Fluid & Completion Fluid, 2013, 30(3):64-66. [4] 李万兴. 国内外防气窜固井技术研究[J]. 中国石油和化工标准与质量, 2013, 15:93. LI Wanxing. Domestic and foreign anti-gas channeling cementing technique[J].China Petroleum and Chemical Industry Standards and Quality, 2013, 15:93. [5] 李勇. 国内外防气窜技术现状及研究方向建议[J]. 西部探矿工程, 2013, 7:48-51. LI Yong.Domestic and foreign anti-gas channeling technology status and research recommendations[J]. Exploration Engineering, 2013, 7:48-51. [6] 张顺平, 张森, 覃毅, 等. 威远页岩气水平井高密度防窜水泥浆固井技术[J]. 钻井液与完井液, 2016, 33(1):63-67.ZHANG Shunping, ZHANG Sen, QIN Yi, et al.Antichanneling high density cement slurry technology for horizontal shale gas well in Weiyuan[J].Drilling Fluid & Completion Fluid, 2016, 33(1):63-67. [7] 雷鑫宇, 陈大钧, 李小可, 等. 油井水泥缓释自修复技术研究[J]. 钻井液与完井液, 2013, 30(5):60-62.LEI Xinyu, CHEN Dajun, LI Xiaoke, et al.Oil well cement repair-release treatment technology research[J]. Drilling Fluid & Completion Fluid, 2013, 30(5):60-62. [8] 汪汉花, 高莉莉. 固井水泥石力学性能研究现状浅析[J]. 西部探矿工程, 2010, 4:70-73. WANG Hanhua, GAO Lili. Analysis of mechanical properties of cement cementing the status quo[J]. Exploration Engineering, 2010, 4:70-73. [9] 靳建洲, 解文, 张华, 等.大港板南储气库白6库1井尾管固井技术[J].钻井液与完井液, 2014, 31(6):58-61.JIN Jianzhou, XIE Wen, ZHANG Hua, et al. Technology for liner cementing in well 1 of Storage Bai-6, Bannan, Dagang[J]. Drilling Fluid & Completion Fluid, 2014, 31(6):58-61. [10] 秦国宏, 宋元洪, 刘书东, 等. 平衡压力固井工艺在束探1H(P)井的应用[J]. 钻井液与完井液, 2013, 30(5):63-66.QIN Guohong, SONG Yuanhong, LIU Shudong, et al. Application of balanced pressure cementing technology in well Shutan 1H (P)[J].Drilling Fluid & Completion Fluid, 2013, 30(5):63-66. [11] 贾永江. 平衡压力固井技术在塔河油田尾管固井中的应用[J]. 钻采工艺, 2012, 35(4):101-103.JIA Yongjiang. Application of balanced pressure cementing technology in Tahe oilfield liner cementing[J]. Drilling & Production technology, 2012, 35(4):101-103. [12] 郭丽梅, 耿国伟, 霍丙夏. 新型自愈合水泥研制[J]. 钻井液与完井液, 2014, 31(6):55-57.GUO Limei, GENG Guowei, HUO Bingxia. Development of new self-healing cement[J].Drilling Fluid & Completion Fluid, 2014, 31(6):55-57. [13] 丁士东, 张卫东. 国内外防气窜固井技术[J]. 石油钻探技术, 2002, 30(5):35-38.DING Shidong, ZHANG Weidong. Domestic & oversea cementing techniques of gas-channeling prevention[J]. Petroleum Drilling Techniques, 2002, 30(5):35-38. [14] 郭进忠, 罗霄, 华苏东, 等. 抗冲击防窜水泥浆体系性能研究[J]. 钻井液与完井液, 2010, 27(4):59-61.GUO Jinzhong, LUO Xiao, HUA Sudong, et al.Study on tough and anti-channeling cement slurry[J].Drilling Fluid & Completion Fluid, 2010, 27(4):59-61.
