新型固井触变水泥浆体系

卢海川; 李洋; 宋元洪; 魏继军; 朱智勇; 路彦利

doi:10.3969/j.issn.1001-5620.2016.06.013

新型固井触变水泥浆体系

doi: 10.3969/j.issn.1001-5620.2016.06.013

1. 中国石油集团海洋工程有限公司渤星公司, 天津 300451;
2. 中国石油集团渤海钻探第一固井公司, 河北任丘 062550;
3. 中国石油集团长城钻探固井公司, 辽宁盘锦 124010;
4. 中国石油集团渤海钻探第二固井分公司, 天津 300270

详细信息

作者简介:
卢海川,1985年生,工程师,2012毕业于天津大学材料学专业获硕士学位,主要从事固井材料和水泥浆体系的研究。电话(022)66310332;E-mail:luhc@cnpc.com.cn。

中图分类号: TE256.6
计量
- 文章访问数: 451
- HTML全文浏览量: 138
- PDF下载量: 251
- 被引次数: 0
出版历程
- 收稿日期: 2016-10-09
- 刊出日期: 2016-11-30

A Novel Thixotropic Well Cementing Slurry

1. Bo-Xing Engineering Science & Technology Co., Ltd of CNPC Offshore Engineering Company Limited, Tianjin 300451;
2. The First Cementing Branch of CNPC Bohai Drilling Engineering Company Limited, Renqiu, Hebei 062550;
3. The Cementing Branch of CNPC Greatwall Drilling Company, Panjin, Liaoning 124010;
4. The Second Cementing Branch of CNPC Bohai Drilling Engineering Company Limited, Tianjin 300270

摘要

摘要: 目前油气井固井缺乏成熟的触变水泥浆体系，已有体系常存在触变性不够强、对温度敏感以及综合性能欠佳等问题，限制了其应用。针对以上问题，通过合成两性聚合物与无机纳米材料相结合的方式开发了一种触变剂N-1，合成的聚合物分子量较大（6.0×10⁶左右）且分布较宽，在常温下高分子量组分会溶解很慢，随着温度升高溶解会逐渐加快，为材料较高温度发挥触变作用提供了保障。选用的无机纳米材料为纤维状物质，在水中可以通过吸附和缠结形成网络结构从而体现出触变性。对其微观结构进行了表征，并以其为主剂制备出了一套新型触变水泥浆体系。室内评价实验表明，该水泥浆触变性强，并具有一定的堵漏作用，不加压时几乎不发生漏失，在50℃、2.1 MPa下加量从1.0%升到1.5%时，漏失量从380 mL降为0，其触变性随温度升高不但没变弱反而有所增强，且其失水量低（40 mL）、强度高（62℃下的24 h强度为31.6 MPa）。该体系克服了常见触变水泥浆体系存在的不足，综合性能良好，可满足施工要求。
- 固井 /
- 触变剂 /
- 触变水泥浆 /
- 合成聚合物 /
- 纳米材料 /
- 综合性能
Abstract: Mature thixotropic cement slurries are seldom seen in China presently. Slurries commonly used in oilfelds are of weak thixotropy, temperature sensitive, and have poor overall properties. To solve these problems, a thixotropic agent, N-1, has recently been developed by combining a synthesized amphoteric polymer and an inorganic nano material. The amphoteric polymer has high widely distributed molecular weight (MW, about 6.0×10⁶). At room temperatures, the high MW polymer molecules dissolve very slowly, and the dissolution becomes fast as temperature rises. This feature ensures the amphoteric polymer. The inorganic nano material selected is a fbrous material, which forms a network in water through adsorption and entanglement. N-1 was characterized for its microstructure, and was used as main additive to formulate a novel thixotropic cement slurry. Laboratory evaluation indicated that the cement slurry had strong thixotropy and did not lose without the action of pressure. At a pressure of 2.1 MPa, a cement slurry treated with 1.0%N-1 to 1.5%N-1 had volume of loss from 380 mL down to 0 mL. At elevated temperatures, the thixotropy of the N-1 treated cement was enhanced, instead of weakened, and had low flter loss (40 mL) and high strength (aged at 62℃ for 24 hours, the strength was 31.6 MPa.) Compared with conventional cement slurries, this cement slurry has strong thixotropy and good overall properties, and can satisfy the needs of well cementing.
- Thixotropy /
- Thixotropic cement slurry /
- Synthesized polymer /
- Nano material /
- Overall property /

HTML全文

参考文献(14)

[1]	邱燮和. 超浅调整井固井防水窜技术[J]. 钻井液与完井液, 2013, 30(4):84-87. QIU Xiehe. Water block cementing technology for ultrashallow adjustment wells[J]. Drilling Fluid & Completion Fluid, 2013, 30(4):84-87.
[2]	姚晓. 调整井固井水窜的根源及现行防窜技术评析[J]. 钻井液与完井液, 2001, 18(5):13-16. YAO Xiao. Causes of water channeling during cementing and its preventing technology[J]. Drilling Fluid & Completion Fluid, 2001, 18(5):13-16.
[3]	姚晓, 吴叶成, 黎学年. 国内外固井技术难点及新型水泥外加剂特性评析[J]. 钻井液与完井液, 2005, 22(2):11-16. YAO Xiao, WU Yecheng, LI Xuenian.Evaluation of the key cementing technology and the properties of novel cement additives[J]. Drilling Fluid & Completion Fluid, 2005, 22(2):11-16.
[4]	丁士东, 张卫东. 国内外防气窜固井技术[J]. 石油钻探技术, 2002, 30(5):35-38. DING Shidong, ZHANG Weidong. Domestic ﹠ oversea cementing techniques of gas-channeling prevention[J]. Petroleum Drilling Techniques, 2002, 30(5):35-38.
[5]	卢振义, 诸华军, 王竺, 等.吉林油田浅层气井固井防窜水泥浆体系[J]. 钻井液与完井液, 2011, 28(6):58-60. LU Zhenyi, ZHU Huajun, WANG Zhu, et al. Cementing system for cementing in shallow gas wells of Jilin oilfield[J]. Drilling Fluid & Completion Fluid, 2011, 28(6):58-60.
[6]	钟福海, 宋元洪, 费中明, 等. 缅甸D区块窄密度窗口防漏防窜固井技术探讨[J]. 钻井液与完井液, 2010, 27(5):61-64. ZHONG Fuhai, SONG Yuanhong, FEI Zhongming, et al. Cementing technology on prevention of leaking and channeling with narrow density window in block D in Burma[J]. Drilling Fluid & Completion Fluid, 2010, 27(5):61-64.
[7]	步玉环, 尤军, 姜林林. 触变性水泥浆体系研究与应用进展[J]. 石油钻探技术, 2009, 37(4):110-114. BU Yuhuan, YOU Jun, JIANG Linlin. Research and application of thixotropic cement slurry[J]. Petroleum Drilling Techniques, 2009, 37(4):110-114.
[8]	SABINS, FRED T. Method of using thixotropic cements for combating gas migration problems:US 4524828[P]. 1985.
[9]	HORTON, ROBERT L, PRASEK, et al. Prevention and treatment of lost circulation with crosslinked polymer material:US, 7098172[P].2006.
[10]	HILLEARY N, NELSON R, ROBERT BUCHER R. Downhole preparation and use of thixotropic cement slurries:US 7757765B2[P].2010.
[11]	CHILDS J, SABINS F, TAYLOR M J. Method of using thixotropic cements for combating lost circulation problems:US 4515216[P].1985.
[12]	VIJN J P, DAO B. Delayed thixotropic cement compositions and methods:US 6457523B1[P]. 2002.
[13]	谢承斌, 卢海川, 李洋, 等. 水泥浆触变性评价方法的探索[J]. 钻井液与完井液, 2015, 32(6):57-60. XIE Chengbin, LU Haichuan, LI Yang, et al. Study on evaluation of thixotropy of cement slurry[J]Drilling Fluid & Completion Fluid, 2015, 32(6):57-60.
[14]	姜林林, 王瑞和, 步玉环, 等. 水泥浆触变性评价新方法的试验研究[J]. 石油钻探技术, 2009, 37(5):62-65. JIANG Linlin, WANG Ruihe, BU Yuhuan, et al. A new evaluation method of cement thixotropic property[J]. Petroleum Drilling Techniques, 2009, 37(5):62-65.
