Rock-fluid Interaction Mechanisms in Deep Coal Rock-parting Formations and Drilling Fluid Countermeasures in the Daji Block
-
摘要: 针对鄂尔多斯盆地东缘大吉区块深层煤岩水平井井壁失稳难题，从岩心矿物组分、宏微观结构特征、理化性能与力学性质多维度开展系统分析，最终揭示了该区块深层煤岩-夹矸地层的岩-液作用机理。结果表明，煤岩原生割理-裂缝结构的水化强度弱化效应，与深灰色泥质夹矸的微裂缝水化扩张、次生裂缝衍生及黏土矿物水化膨胀效应协同作用，所导致的煤岩-夹矸复合层力学强度衰减，是煤层气水平井水平段井壁失稳的主控因素。基于上述岩-液作用机理的揭示成果，提出“多级封堵-疏水抑制-密度适配-精细管控”协同的井壁稳定技术思路，以“成膜+疏水”核心功能处理剂为技术核心，构建出兼具强封堵、强抑制、强支撑特性的“三强”钻井液体系。室内性能评价结果表明，各项指标均满足工程要求。现场应用表明，该套钻井液体系成功支撑JS6-3P02井顺利完井：该井水平段长度达2062 m，煤层靶体钻遇率100%，水平段钻井周期仅7 d，实现水平段单趟钻完钻且全程无井下复杂事故，是大吉区块首口完钻的2000 m以上深层煤层气长水平段水平井。该套体系成果应用能够满足现场煤层气长水平井钻井的需要，具有较好的推广应用前景。Abstract: To address wellbore instability in deep coalbed methane horizontal wells in the Daji Block on the eastern margin of the Ordos Basin, systematic analyses were conducted of the core mineral composition, macro- and microstructural characteristics, physicochemical properties, and mechanical properties. The rock-fluid interaction mechanisms in the deep coal rock-parting formations in this block were subsequently identified. The results show that the hydration-induced weakening of the primary cleat-fracture system in the coal rock acts synergistically with hydration-induced microfracture dilation, secondary-fracture development, and clay mineral hydration and swelling in the dark-gray argillaceous partings. The resulting deterioration in the mechanical strength of the coal rock-parting composite formation is the dominant factor controlling wellbore instability in the horizontal sections of coalbed methane wells. Based on the identified rock-fluid interaction mechanisms, a synergistic wellbore-stability strategy integrating “multistage plugging, hydrophobic inhibition, density matching, and precise control” is proposed. A drilling fluid system with strong plugging, inhibition, and supporting capabilities is developed using film-forming and hydrophobic functional additives as the core treatment agents. Laboratory performance evaluations show that all performance parameters meet the engineering requirements. Field application demonstrated that this drilling fluid system enabled the successful completion of Well JS6-3P02. The well had a 2062 m horizontal section, achieved 100% penetration of the coal-seam target interval, and required only 7 d to drill the horizontal section. The horizontal section was drilled to total depth in a single bit run without any downhole complications. It was the first deep coalbed methane horizontal well with a horizontal section exceeding 2,000 m to be completed in the Daji Block. The developed drilling fluid system meets the requirements for drilling coalbed methane wells with long horizontal sections and has good potential for wider application.
-
Key words:
- Drilling fluid /
- Coalbed methane /
- Horizontal well /
- Parting /
- Wellbore instability /
- Hydration
-
表 1 煤岩和深灰色泥岩（夹矸）自吸量实验结果
岩性 自吸量/g 1 h 5 h 10 h 煤岩 0.0823 0.268 0.2812 灰色泥岩（夹矸） 0.1189 0.3751 0.3908
下载: 导出CSV
表 2 优化后钻井液体系的抗温性能
实验
条件AV/
mPa·sPV/
mPa·sYP/
PaGel/
Pa/PaFLAPI /
mL老化前 45.5 29 16.5 6/8.5 3.0 80 ℃、16 h 40.5 26 14.5 5/5.5 3.4 老化前 44.5 28 16.5 6/8.5 3.0 100 ℃、16 h 37.5 25 12.5 4/4.5 4.0
下载: 导出CSV
表 3 优化后钻井液体系的抗污染性能
污染物 实验
条件AV/
mPa·sPV/
mPa·sYP/
PaGel/
Pa/PaFLAPI/
mL原始钻井液 老化前 45.5 29.0 16.50 6/8.5 3.0 80 ℃、16 h 40.50 26.0 14.50 5/5.5 3.4 5%NaCl 老化前 42.00 32.5 9.50 5/9.0 3.2 80 ℃、16 h 46.25 27.5 18.75 7/10.0 3.0 1%CaCl2 老化前 26.00 18.0 8.00 4/6.0 1.8 80 ℃、16 h 29.00 15.5 13.50 4/4.0 2.8
下载: 导出CSV
表 4 JS6-3P02井实钻过程中钻井液的性能
井深/m ρ/(g·cm−3) PV/mPa·s YP/Pa φ3/φ6 FLAPI/mL 摩阻系数 2446 1.40 30 21.0 8.0/14.0 3.4 / 2600 1.42 29 18.0 7.0/12.0 3.3 0.061 3031 1.42 32 21.0 8.0/15.0 3.2 0.058 3224 1.42 32 21.5 8.0/15.0 3.4 0.058 3506 1.42 35 22.0 7.0/14.0 3.3 0.058 3810 1.42 36 22.5 7.0/15.0 3.2 0.058 4065 1.44 36 23.0 6.0/14.0 3.3 0.058 4140 1.44 36 22.5 8.0/15.0 3.4 0.058 4260 1.44 38 23.0 8.0/15.0 3.4 0.058 4506 1.44 38 19.0 7.0/15.0 3.3 0.058
下载: 导出CSV
-
[1] 周立宏, 熊先钺, 丁蓉, 等. 煤岩气内涵、富集机理及实践意义[J]. 天然气工业, 2025, 45(3): 1-15. doi: 10.3787/j.issn.1000-0976.2025.03.001Zhou Lihong, Xiong Xianyue, Ding Rong, et al. Connotation, enrichment mechanism and practical significance of coal-rock gas[J]. Natural Gas Industry, 2025, 45(3): 1-15. doi: 10.3787/j.issn.1000-0976.2025.03.001 [2] 周立宏, 李勇, 丁蓉, 等. 煤层(岩)气"同生异构"控藏特征及开发实践: 以鄂尔多斯盆地大吉区块石炭系本溪组8号煤为例[J]. 石油勘探与开发, 2025, 52(4): 772-781. doi: 10.11698/PED.20250175Zhou Lihong, Li Yong, Ding Rong, et al. Differential accumulation characteristics and production of coalbed methane/coal-rock gas: a case study of the No. 8 coal seam of the carboniferous Benxi formation in the Daji block, Ordos Basin, NW China[J]. Petroleum Exploration and Development, 2025, 52(4): 772-781. doi: 10.11698/PED.20250175 [3] 周立宏, 熊先钺, 李勇, 等. 深层煤层( 岩) 气革命性突破及关键理论与技术[J]. 天然气工业, 2025, 45(5): 17-30. doi: 10.3787/j.issn.1000-0976.2025.05.002Zhou Lihong, Xiong Xianyue, Li Yong, et al. Revolutionary breakthroughs and key theories and technologies in deep coalbed methane development[J]. Natural Gas Industry, 2025, 45(5): 17-30. doi: 10.3787/j.issn.1000-0976.2025.05.002 [4] 周立宏, 李曙光, 王渊, 等. 深层煤岩气效益开发关键技术与实践: 以鄂尔多斯盆地大宁—吉县区块为例[J]. 石油学报, 2025, 46(8): 1536-1549. doi: 10.7623/syxb202508007Zhou Lihong, Li Shuguang, Wang Yuan, et al. Key technologies and practices for cost-effective development of deep coal-rock gas: a case study of the Daning-Jixian block in Ordos Basin[J]. Acta Petrolei Sinica, 2025, 46(8): 1536-1549. doi: 10.7623/syxb202508007 [5] 徐凤银, 侯伟, 熊先钺, 等. 中国煤层气产业现状与发展战略[J]. 石油勘探与开发, 2023, 50(4): 669-682. doi: 10.11698/PED.20220856Xu Fengyin, Hou Wei, Xiong Xianyue, et al. The status and development strategy of coalbed methane industry in China[J]. Petroleum Exploration and Development, 2023, 50(4): 669-682. doi: 10.11698/PED.20220856 [6] 徐凤银, 闫霞, 李曙光, 等. 鄂尔多斯盆地东缘深部(层)煤层气勘探开发理论技术难点与对策[J]. 煤田地质与勘探, 2023, 51(1): 115-130. doi: 10.3969/j.issn.1001-1986.2023.01.009Xu Fengyin, Yan Xia, Li Shuguang, et al. Theoretical and technological difficulties and countermeasures of deep CBM exploration and development in the eastern edge of Ordos Basin[J]. Coal Geology & Exploration, 2023, 51(1): 115-130. doi: 10.3969/j.issn.1001-1986.2023.01.009 [7] 王在明, 陈金霞, 沈园园, 等. JN1H井煤岩气长水平段钻井井壁稳定技术[J]. 钻井液与完井液, 2023, 40(3): 356-362. doi: 10.12358/j.issn.1001-5620.2023.03.011Wang Zaiming, Chen Jinxia, Shen Yuanyuan, et al. Borehole wall stabilization technology for drilling the long horizontal section coal rock gas well JN1H[J]. Drilling Fluid & Completion Fluid, 2023, 40(3): 356-362. doi: 10.12358/j.issn.1001-5620.2023.03.011 [8] 吕坤鸿, 张辉, 田得粮, 等. 鄂尔多斯盆地深部煤层井壁失稳机理及钻井液对策[J]. 钻井液与完井液, 2024, 41(5): 564-573. doi: 10.12358/j.issn.1001-5620.2024.05.001Lyu Kunhong, Zhang Hui, Tian Deliang, et al. Mechanisms of borehole wall instability of deep coal seam in ordos basin and drilling fluid countermeasures[J]. Drilling Fluid & Completion Fluid, 2024, 41(5): 564-573. doi: 10.12358/j.issn.1001-5620.2024.05.001 [9] 侯雨庭, 许朝阳, 刘双全, 等. 鄂尔多斯盆地深层煤岩气水平井钻井液技术进展及展望[J]. 钻采工艺, 2024, 47(6): 110-116. doi: 10.3969/J.ISSN.1006-768X.2024.06.14Hou Yuting, Xu Chaoyang, Liu Shuangquan, et al. Development and prospect of drilling fluid technology for deep coal gas horizontal wells in ordos Basin[J]. Drilling & Production Technology, 2024, 47(6): 110-116. doi: 10.3969/J.ISSN.1006-768X.2024.06.14 [10] 阎荣辉, 王京光, 何旺, 等. 鄂尔多斯盆地深层煤岩气井储层坍塌及伤害主控因素研究[J]. 钻采工艺, 2023, 46(6): 8-13. doi: 10.3969/J.ISSN.1006-768X.2023.06.02Yan Ronghui, Wang Jingguang, He Wang, et al. Study on the main controlling factors of reservoir collapse and damage in deep coal gas wells in Ordos Basin[J]. Drilling & Production Technology, 2023, 46(6): 8-13. doi: 10.3969/J.ISSN.1006-768X.2023.06.02 [11] Miao Qing, Liu Hongtao, Wang Yubin. et al. Quantitative mechanisms of long-term drilling-fluid–coal interaction and strength deterioration in deep CBM formations[J]. Processes, 2025, 13(10): 3183. doi: 10.3390/pr13103183 [12] Wang Wei, Xin Jiafeng, Xin Jiang, et al. Damage mechanism of deep coalbed methane reservoir and novel anti-waterblocking protection technology[J]. Processes, 2024, 12: 2735. doi: 10.3390/pr12122735 [13] 王维, 韩金良, 王玉斌, 等. 大宁-吉县区块深层煤岩气水平井钻井技术[J]. 石油机械, 2023, 51(11): 70-78. doi: 10.16082/j.cnki.issn.1001-4578.2023.11.009Wang Wei, Han Jinliang, Wang Yubin, et al. Drilling technology for deep coal rock gas horizontal wells in Da'ning-Jixian block[J]. China Petroleum Machinery, 2023, 51(11): 70-78. doi: 10.16082/j.cnki.issn.1001-4578.2023.11.009 [14] 苗强, 韩金良, 王维, 等. 深层煤岩气超2000m水平井段钻井关键技术[J]. 石油钻采工艺, 2025, 47(5): 545-553. doi: 10.13639/j.odpt.202507021Miao Qiang, Han Jinliang, Wang Wei, et al. Exploration and practice of key drilling technology for long horizontal sections over 2000 m in deep coalbed methane(CBM) wells[J]. Oil Drilling & Production Technology, 2025, 47(5): 545-553. doi: 10.13639/j.odpt.202507021 [15] 黄红星, 石军太, 陈国辉, 等. 鄂尔多斯盆地大宁: 吉县区块深层8号煤夹矸特征及其与产能关系分析[J]. 中国石油勘探, 2025, 30(4): 108-119. doi: 10.3969/j.issn.1672-7703.2025.04.008Huang Hongxing, Shi Juntai, Chen Guohui, et al. Characteristics of gangues in deep No. 8 coal seam and their relationship with production capacity in Daning-Jixian block, Ordos basin[J]. China Petroleum Exploration, 2025, 30(4): 108-119. doi: 10.3969/j.issn.1672-7703.2025.04.008 [16] 徐凤银, 聂志宏, 孙伟, 等. 鄂尔多斯盆地东缘深部煤层气高效开发理论技术体系[J]. 煤炭学报, 2024, 49(1): 528-544. doi: 10.13225/j.cnki.jccs.YH23.1290Xu Fengyin, Nie Zhihong, Sun Wei, et al. Theoretical and technological system for highly efficient development of deep coalbed methane in the eastern edge of Erdos basin[J]. Journal of China Coal Society, 2024, 49(1): 528-544. doi: 10.13225/j.cnki.jccs.YH23.1290 [17] 王艳. 多元协同井壁稳定水基钻井液研究[D]. 成都: 西南石油大学, 2016.Wang Yan. Research on multi element collaborative well wall stable water based drilling fluid[D]. Chengdu: Southwest Petroleum University, 2016. -
