Drilling Fluid Technology for Ultra-High Temperature Fractured Bedrock Reservoirs
-
摘要: 昆特依气田位于柴达木盆地北缘昆特依凹陷潜伏I号构造，其基岩储层裂缝发育且含风化壳，地层中存在薄弱层段与天然漏失通道，同时面临超高温（约200 ℃）和异常高压（压力系数达1.63）的复杂地质条件。为解决超高温基岩地层钻井液存在的泥饼虚厚、承压能力低、易漏失等难题，通过协同设计核心处理剂，优化出超高温强封堵、防漏失钻井液体系：以 “磺酸盐共聚物SC-200+羧羟基烷烯共聚物Redu240” 构建抗高温胶体稳定骨架，结合 “纳米SiO2+白沥青NFA-25” 实现多尺度裂缝封堵，达成 “滤失控制+裂缝封堵+井壁稳定” 一体化功能。实验证实，该体系耐温达200 ℃，老化后表观黏度、塑性黏度变化率均小于3%，高温高压滤失量小于12 mL，可抗 15%NaCl 污染，同时老化后砂床滤失量仅4.2 mL，封堵滤失量8.6 mL，具备优异封堵裂缝能力与地层承压能力，对于超高温裂缝性地层钻井中防漏失与井壁稳定效果明显。现场应用于K2-3井（井深7150 m，井底温度199.5 ℃），基岩段实现“零漏失”作业，全井段未发生任何因井漏或钻井液性能引发的井下复杂情况，复杂时效为0，显著减少了因漏失导致的非生产时间，为该地区超深井安全高效钻井提供了可靠的技术支撑。Abstract: The Kunteyi gas field is located in the #1 buried structure of the Kunteyi sag on the northern margin of the Qaidam Basin, the bedrock reservoirs of which are developed with fractures and have a weathering crust, and the formations of which have weak segments and natural channels for mud losses, together with complex geological conditions such as ultra-high temperatures (approximately 200 ℃) and abnormal high pressures (pressure coefficient up to 1.63). To address the drilling fluid challenges confronted in drilling ultra-high temperature bedrock reservoir formations, such as thick and loose mud cakes, low pressure-bearing capacity and ease of lost circulation etc., an ultra-high temperature drilling fluid with high plugging capacity for the prevention of lost circulation was developed through synergistic design of core additives. In the drilling fluid “SC-200+Redu240” are used to construct a high-temperature colloidally stable framework, and “nano-silica + white asphalt NFA-25” used to achieve plugging of the multiscale fractures and finally an integrated function of “filtration control + fracture plugging + wellbore stability” is realized. Experimental results confirm that this drilling fluid functions normally at temperatures up to 200 ℃. After aging, the rates of change in the apparent viscosity and plastic viscosity are both less than 3%, the high-temperature high-pressure filtration rate is less than 12 mL, and the drilling fluid can resist contamination by 15%NaCl. Additionally, the sand-bed filtration rate of the drilling fluid after aging is only 4.2 mL, and the filtration rate for fracture plugging is 8.6 mL, indicating that the drilling fluid has excellent fracture plugging capacity and formation pressure-bearing capacity. This drilling fluid exhibits remarkable effects in lost circulation control and wellbore stabilization in drilling ultra-high temperature fractured formations. In field application of this drilling fluid in the well K2-3 (well depth 7170 m, and bottomhole temperature 199.5 ℃), “zero mud loss” was achieved in drilling the bedrock section, and no downhole complex situation caused by lost circulation or drilling fluid properties occurred throughout the whole drilling process, with a complex time efficiency of zero. The application of this drilling fluid technology significantly reduced the non-productive time due to lost circulation, providing reliable technical support for the safe and efficient drilling of ultra-deep wells in this area.
-
Key words:
- Bedrock /
- Fracture /
- Ultra-high temperature /
- Lost circulation prevention /
- Plugging
-
表 1 不同降滤失剂复配比例对抗超高温有机盐钻井液性能的影响
SC-200/% Redu240/% 实验条件 AV/mPa·s PV/mPa·s YP/Pa FLAPI/mL FLHTHP/mL 0 0 老化前 30.0 22.0 8.0 3.8 210 ℃、16 h 24.5 19 5.5 16.0 全滤失 2 2 老化前 82.0 70.0 12.0 1.8 210 ℃、16 h 71.0 60.0 11.0 1.4 24.6 2 3 老化前 94.0 80.0 14.0 1.6 210 ℃、16 h 83.0 71.0 12.0 1.5 20.4 2 4 老化前 108.0 90.0 18.0 1.3 210 ℃、16 h 99.0 84.0 15.0 1.2 16.2 3 2 老化前 93.0 78.0 15.0 1.6 210 ℃、16 h 82.0 69.0 13.0 1.3 22.4 3 3 老化前 109.0 92.0 17.0 1.1 210 ℃、16 h 101.0 86.0 15.0 0.9 17.8 3 4 老化前 119.0 99.0 20.0 0.8 210 ℃、16 h 110.0 93.0 17.0 0.4 14.8 注：基浆：300 mL 清水+0.3%Na2CO3+2%Visco1+30%Weigh2+2%IND30+1.2%胺基抑制剂WX+2%RH220+2%PGCS-1+0.3%抗氧化剂；FLHTHP在190 ℃测定。
下载: 导出CSV
表 2 不同纳米SiO2与NFA-25复配比例对抗超高温有机盐钻井液性能的影响
配方 纳米SiO2/% NFA-25/% 实验条件 AV/mPa·s PV/mPa·s YP/Pa FLHTHP/mL 1# 2 3 老化前 112.5 92.0 20.5 12.6 210 ℃、16 h 105.0 86.5 18.5 13.8 2# 2 4 老化前 116.0 93.0 23.0 11.8 210 ℃、16 h 111.5 89.0 22.5 13.2 3# 3 3 老化前 118.0 95.0 23.0 11.2 210 ℃、16 h 114.0 91.0 23.0 12.4 4# 3 4 老化前 122.0 96.0 26.0 10.0 210 ℃、16 h 118.5 93.2 24.5 10.5 5# 4 3 老化前 120.5 95.5 25.0 10.8 210 ℃、16 h 115.5 92.0 23.5 11.6 6# 4 4 老化前 125.0 99.5 25.5 10.6 210 ℃、16 h 123.0 99.0 24.0 11.2 注：0#：基浆+3%SC-200+4%Redu240；FLHTHP在190 ℃测定。
下载: 导出CSV
表 3 优化后钻井液的抗NaCl污染评价（210 ℃、16 h）
NaCl/% AV/mPa·s PV/mPa·s YP/Pa FLHTHP/mL 性能变化特征 0（空白） 117.7 93.2 24.5 10.5 基准状态，性能稳定 5 123.0 97.5 25.5 11.2 黏度微升（+3.8%），滤失量增幅≤6.7% 10 128.0 101.0 27.0 12.0 黏度可控（+8.1%），滤失量仍≤15 mL 15 135.0 106.5 28.5 13.8 黏度超阈值（+13.9%），滤失量仍满足要求 注：FLHTHP在190 ℃测定。
下载: 导出CSV
表 4 优化前后钻井液体系的高温砂床实验与封堵性能评价
样品 砂床滤失量/mL 砂床侵入深度/mm 封堵滤失量*/mL 封堵层渗透率*/mD 优化体系（老化后） 4.2 1.5 8.6 1.2 0#基浆（老化后） 全滤失 >50 全滤失 >5.0 性能改善说明 滤失量降低>80%，
防漏效果显著侵入深度减少>97%，
封堵层致密高温高压下仍具
良好封堵能力渗透率降低>76%，
封堵效率高注：*实验条件为190 ℃、3.5 MPa。
下载: 导出CSV
表 5 K2-3井四开部分井段钻井液的性能（210 ℃、16 h）
井深/m ρ/（g·cm−3） FV/s PV/mPa·s YP/Pa φ6 φ3 FLAPI/mL FLHTHP/mL pH 6807 1.66 95 94 12 6 3 0.8 8.6 9 6827 1.67 132 109 13 6 4 0.6 8.8 9 6869 1.66 121 106 15 8 6 0.6 8.6 9 6942 1.62 116 97 13 7 4 0.7 9.0 9 7010 1.62 120 90 11 5 3 0.8 9.2 9 7107 1.62 104 86 12 6 4 0.8 9.4 9 7130 1.62 116 94 13 5 3 0.6 8.4 9 7150 1.65 98 95 13 6 4 0.6 8.6 9 注：FLHTHP在190 ℃测定。
下载: 导出CSV
-
[1] 方俊伟, 张翼, 李双贵, 等. 顺北一区裂缝性碳酸盐岩储层抗高温可酸溶暂堵技术[J]. 石油钻探技术, 2020, 48(2): 17-22. doi: 10.11911/syztjs.2020006FANG Junwei, ZHANG Yi, LI Shuanggui, et al. Acid-soluble temporary plugging technology for ultra-deep fractured carbonate reservoirs in block 1 of the Shunbei area[J]. Petroleum Drilling Techniques, 2020, 48(2): 17-22. doi: 10.11911/syztjs.2020006 [2] LI S, SONG S. Ultra-high temperature cementing slurry technology for well Songke-2[J]. Drilling Fluid& Completion Fluid, 2018, 35(2): 92-97. [3] 乌效鸣, 郑文龙, 邹玉亮. 松科2井深部高温龟裂岩层封堵型钻井液稳定井壁技术[J]. 地球科学, 2020, 45(9): 3502-3508.WU Xiaoming, ZHENG Wenlong, ZOU Yuliang. Well bore stability technology using blocking drilling fluid system suitable for the deep high temperature cracked strata in well Songke-2[J]. Earth Science, 2020, 45(9): 3502-3508. [4] 叶成, 高世峰, 鲁铁梅, 等. 玛 18 井区水平井井壁失稳机理及强封堵钻井液技术研究[J]. 石油钻采工艺, 2023, 45(1): 38-46.YE Cheng, GAO Shifeng, LU Tiemei, et al. Well instability mechanism and strong plugging drilling fluid technology of horizontal well in Ma 18 well block[J]. Oil Drilling & Production Technology, 2023, 45(1): 38-46 [5] QIU Z S, BAO D, LI J, et al. Mechanisms of wellbore strengthening and new advances in lost circulation control with dense pressure bearing zone[J]. Drilling Fluid & Completion Fluid, 2018, 35(4): 1-6. [6] 孙金生, 杨敬彬, 白英睿, 等. 裂缝性地层桥接封堵技术研究进展与展望[J]. 石油科学通报, 2023, 8(4): 415-431.SUN Jinsheng, YANG Jingbin, BAI Yingrui, et al. Review and prospect of bridging plugging technology in fractured formations[J]. Petroleum Science Bulletin, 2023, 8(4): 415-431. [7] IADC Lexicon Committee. Drilling fluid[EB/OL]. (2019-01-12) [2024-05-20]. https://iadclexicon.org/drilling-fluid/.IADC Lexicon Committee. Drilling fluid[EB/OL]. (2019-01-12) [2024-05-20]. https://iadclexicon.org/drilling-fluid/. [8] 石亚军. 柴达木盆地南翼山油田裂缝性储层研究[J]. 天然气工业, 2005, 25: 46-48.SHI Yajun. Research on the fractured reservoirs in Nanyishan oll field of Chaidamu basin[J]. Natural Gas Industry, 2005, 25: 46-48. [9] 郝少军, 安小絮, 韦西海, 等. 碱探1井超高温水基钻井液技术[J]. 钻井液与完井液, 2021, 38(3): 292-297. doi: 10.3969/j.issn.1001-5620.2021.03.005HAO Shaojun, AN Xiaoxu, WEI Xihai, et al. Ultra-High temperature drilling fluid technology for drilling well Jiantan-1[J]. Drilling Fluid & Completion Fluid, 2021, 38(3): 292-297. doi: 10.3969/j.issn.1001-5620.2021.03.005 [10] 常晨, 许明标, 由福昌. 超高温水基钻井液的室内研究[J]. 钻井液与完井液, 2012, 29(3): 36-37. doi: 10.3969/j.issn.1001-5620.2012.03.011CHANG Chen, XU Mingbiao, YOU Fuchang. Laboratory study on ultra-high temperature water-based drilling fluid[J]. Drilling Fluid & Completion Fluid, 2012, 29(3): 36-37. doi: 10.3969/j.issn.1001-5620.2012.03.011 [11] HE B. Analysis of drilling fluid technology for leak prevention and plugging in low-permeability oil reservoirs[J]. Petrochemical Industry Technology, 2024, 31(5): 114-116. [12] 陈庚绪, 刘奥, 王茜, 等. 适用于页岩气井的强抑制防塌高性能水基钻井液体系[J]. 断块油气田, 2018, 25(4): 529-532. doi: 10.6056/dkyqt201804026CHEN Gengxu, LIU Ao, WANG Qian, et al. High inhibition and anti-sloughing water-based drilling fluid system for shale gas horizontal wells[J]. Fault-Block Oil and Gas Field, 2018, 25(4): 529-532. doi: 10.6056/dkyqt201804026 [13] 苏俊霖, 王雷雯, 刘禧元, 等. 表层裂缝漏失凝胶随钻堵漏技术及应用[J]. 钻采工艺, 2018, 41(2): 23-25.SU Junlin, WANG Leiwen, LIU Xiyuan, et al. Study and application of gel lost circulation material while drilling for surface fracture leakage[J]. Drilling & Production Technology, 2018, 41(2): 23-25. [14] 孟丽艳, 张麒麟, 黄宁. 硅铝钻井液体系的室内研究及现场应用[J]. 精细石油化工进展, 2015, 16(1): 16-19, 31. doi: 10.3969/j.issn.1009-8348.2015.01.005MENG Liyan, ZHANG Qilin, HUANG Ning. Laboratory research on silicate-aluminate drilling fluid system and its field application[J]. Advances in Fine Petrochemicals, 2015, 16(1): 16-19,31. doi: 10.3969/j.issn.1009-8348.2015.01.005 [15] SUN J, YANG J, BAI Y, et al. Numerical simulation of borehole wall strengthening in fractured bedrock[J]. Journal of Petroleum Science and Engineering, 2024, 235: 112105. [16] Q/SH 1025 0033-2023 超高温钻井液技术规范[S].Q/SH 1025 0033-2023 Technical specification for ultra-high temperature drilling fluid[S]. -
