Drilling Fluid Technology for “Three High” Wells in Qaidam Basin in Qinghai
-
摘要: 柴达木盆地的牛东、冷湖、扎哈泉和英西区块地层岩性复杂,有盐层、盐膏层、芒硝层、硬脆性泥岩、高压盐水层,以往钻井事故和复杂频发,盆地阿尔金山前带牛东鼻隆构造,受造山运动影响,整体地层倾角为60°~70°,地应力较高且存在高压盐水层,压力系数多变,裸眼井段井壁失稳现象时有发生。2013年至今,在柴达木盆地应用BH-WEI抗三高钻井液服务各类井20口,为做好各区块钻井液技术服务,施工前查阅相关资料,结合室内实验与现场试验,总结得出低活度、弱水化与强封堵、强抑制有利于井壁稳定的结论,已完成青海油田1字号重点风险预探井4口、第1口分支水平井和扎哈泉第1口水平井,最高使用钻井液密度为2.35 g/cm3,平均井径扩大率为4.67%,电测成功率为100%。其中应用井扎平1井是油田公司在扎哈泉致密油区块部署的第1口水平井;东坪区块仅在2013年采用威德福MEG钻井液完成1口四开水平井,因漏失严重且井下复杂提前完钻,而2013~2014年在该区块应用BH-WEI钻井液顺利完成水平井6口,实现零事故复杂;2014年初投产的坪1H-2-2和坪1H-2-1井,完井测试均为区块高产井,平均日产天然气50×104 m3/d。现场应用情况表明,抗三高钻井液体系配方简单,维护方便,具有良好的剪切稀释性,具备动塑比高、塑性黏度低等特性,环空压耗小,井眼清洁,具有良好的润滑防卡和防塌能力,可防止侏罗系深灰色泥岩垮塌及水平井定向托压及黏附卡钻,形成一套适合青海油田复杂区块探井、水平井钻井液工艺技术。Abstract: Four blocks in the Qaidam Basin, Niudong, Lenghu, Zahaquan and Yingxi, have formation rocks with complex lithology, such as salt, gypsum, mirabilite, and hard and brittle shales etc. Downhole troubles have been frequently encountered in previous drilling operations. The Niudong nasal structure in the piedmont of the Altun Mountain in the basin, affected by the orogenesis, has overall formation dipping angles between 60° and 70°. High formation stress, high pressure saltwater and varied coeffcients of pressure have resulted in frequent borehole wall instability in open hole section. A BH-WEI drilling fluid for the so-called "three high" (high pressure, high sulfde, and high risk area) wells, has been used in drilling 20 wells since 2013. To perform well in drilling fluid technical service, relevant data were investigated prior to drilling. Based on laboratory experiment and feld practice, it was concluded that drilling fluid with low activity, strong plugging and inhibitive capacity was benefcial to borehole wall stability. Four key exploratory wells, the frst multi-lateral horizontal well and the frst horizontal well in Zahaquan have been completed, the maximum mud density used was 2.35 g/cm3, the average percentage of hole enlargement was 4.67%, and the ratio of successful wireline logging was 100%. The well Zaping-1 is the frst horizontal well targeted with tight oil reservoir in Zahaquan. In the block Dongping, a four-interval horizontal well was drilled in 2013 with Weatherford's MEG drilling fluid. This well was not be able to drill to the designed depth because of severe mud losses and other downhole troubles. Using the BH-WEI drilling fluid, six horizontal wells were completed successfully in 2013-2014 in the same block, and no downhole trouble has been encountered throughout the drilling operations. Two horizontal wells, Ping-1H-2-1 and Ping-1H-2-2, put into production in 2014, were both high production rate wells in the same block; the average daily gas production rate was 50×104 m3/d. Field application has shown that the BH-WEI drilling fluid had simple formulation, and the mud properties were thus easy to maintain. The BH-WEI drilling fluid had good shear thinning property, high YP/PV ratio, low plastic viscosity, low pressure loss in annular space, good hole cleaning performance and good lubricity and inhibitive capacity. Using this drilling fluid, borehole collapse in drilling the dark gray Jurassic mudstone, inability to exert WOB in horizontal drilling and differential pipe sticking were avoided. To concluded, the BH-WEI drilling fluid is a unique drilling fluid suitable for use in drilling exploratory well and horizontal well in the troublesome drilling areas in Qinghai oilfeld.
-
[1] 张民立, 尹达, 何勇波, 等. BH-WEI抗"三高"钻井液技术在克深208井的应用[J]. 钻井液与完井液, 2014, 31(1):32-36.ZHANG Minli, YIN Da, HE Yongbo, et al. Application of BH-WEI three-high drilling fluid in Well KeShen-208[J]. Drilling Fluid & Completion Fluid, 2014, 31(1):32-36. [2] 左凤江, 贾东民, 刘德庆, 等. 钻井液快速封堵油层保护技术[J]. 钻井液与完井液, 2005, 22(6):76-77.ZUO Fengjiang, JIA Dongmin, LIU Deqing, et al. Drilling fluid instant sealing technology for formation damage control[J]. Drilling Fluid & Completion Fluid, 2005, 22(6):76-77. [3] 郑力会, 王志军, 张民立. 盐膏层用高密度有机盐钻井液的研究与应用[J]. 钻井液与完井液,2004,21(4):37-39.ZHENG Lihui, WANG Zhijun, ZHANG Minli. Study and application of high density organic salt drilling fluid for gypsum/salt bed[J]. Drilling Fluid & Completion Fluid, 2004, 21(4):37-39. [4] 汪海, 王信, 张民立, 等.BH-WEI完井液在迪西1井的应用[J]. 钻井液与完井液, 2013, 30(4):88-90.WANG Hai, WANG Xin, ZHANG Minli, et al. Application of BH-WEI completion fluid in Well Daxi1[J]. Drilling Fluid & Completion Fluid, 2013, 30(4):88-90. [5] 张民立, 穆剑雷, 尹达, 等. BH-ATH"三高"钻井液的研究与应用[J]. 钻井液与完井液, 2011, 28(4):14-18.ZHANG Minli, MU Jianlei, YIN Da, et al. Research and appli-cation of BH-ATH(Anti-three high)drilling fluid system[J]. Drilling Fluid & Completion Fluid, 2011, 28(4):14-18. [6] 许京国, 郑淑杰, 陶瑞东, 等. 高陡构造克深206井钻井提速配套技术[J]. 石油钻采工艺, 2013, 35(5):29-32.XU Jingguo, ZHENG Shujie, TAO Ruidong, et al. Auxiliary technology of drilling speed improving for Well Keshen-206 with high and steep structures[J]. Oil Drilling & Production Technology, 2013, 35(5):29-32. [7] 刘庆来, 方彬, 李德江. 塔里木超深复杂井钻井液工艺技术[J]. 钻井液与完井液, 2002, 19(6):82-84.LIU Qinglai, FANG Bin, LI Dejiang. Drilling fluid technology for the ultra-deep complex wells in Tarim[J]. Drilling Fluid & Completion Fluid, 2002, 19(6):82-84.
