抗高温油基钻井液主乳化剂的合成与评价

覃勇,  蒋官澄,  邓正强,  葛炼

downloadPDF
文章导航 > 钻井液与完井液  > 2016 >  33(1): 6-10
覃勇, 蒋官澄, 邓正强, 葛炼. 抗高温油基钻井液主乳化剂的合成与评价[J]. 钻井液与完井液, 2016, 33(1): 6-10. doi: 10.3969/j.issn.1001-5620.2016.01.002
引用本文: 覃勇, 蒋官澄, 邓正强, 葛炼. 抗高温油基钻井液主乳化剂的合成与评价[J]. 钻井液与完井液, 2016, 33(1): 6-10. doi: 10.3969/j.issn.1001-5620.2016.01.002
shu
QIN Yong, JIANG Guancheng, DENG Zhengqiang, GE Lian. Synthesis and Evaluation of A Primary Emulsifier for High Temperature Oil Base Drilling Fluid[J]. DRILLING FLUID & COMPLETION FLUID, 2016, 33(1): 6-10. doi: 10.3969/j.issn.1001-5620.2016.01.002
Citation: QIN Yong, JIANG Guancheng, DENG Zhengqiang, GE Lian. Synthesis and Evaluation of A Primary Emulsifier for High Temperature Oil Base Drilling Fluid[J]. DRILLING FLUID & COMPLETION FLUID, 2016, 33(1): 6-10. doi: 10.3969/j.issn.1001-5620.2016.01.002
shu

抗高温油基钻井液主乳化剂的合成与评价

doi: 10.3969/j.issn.1001-5620.2016.01.002
  • 1.

    川庆钻探工程有限公司钻井液技术服务公司, 成都 610051

  • 2. 中国石油大学(北京), 北京 102200

基金项目: 中国石油天然气集团公司重大科技专项"复杂地质条件钻井液技术研究"(CQ2013B-39-2-3)
详细信息
    作者简介:

    覃勇,1963年生,毕业于西南石油大学石油工程专业,现从事钻井液技术研究及管理工作。电话18518989324;E-mail:Qinyong_sc@cnpc.com.cn。

  • 中图分类号: TE254.4

Synthesis and Evaluation of A Primary Emulsifier for High Temperature Oil Base Drilling Fluid

  • 1.

    Drilling Fluid Service of CNPC Chuanqing Drilling Engineering Company Ltd., Chengdu Sichuan 610051, China

  • 2. China University of Petroleum-Beijing, Beijing 102200, China

    摘要
  • 摘要: 以妥尔油脂肪酸和马来酸酐为主要原料合成了一种油基钻井液抗高温主乳化剂HT-MUL,并确定了妥尔油脂肪酸单体的最佳酸值及马来酸酐单体的最优加量。对HT-MUL进行了单剂评价,结果表明HT-MUL的乳化能力良好,配制的油水比为60:40的油包水乳液的破乳电压最高可达490 V,90:10的乳液破乳电压最高可达1000 V。从抗温性、滤失性、乳化率方面对HT-MUL和国内外同类产品进行了对比,结果表明HT-MUL配制的乳液破乳电压更大、滤失量更小、乳化率更高,整体性能优于国内外同类产品。应用主乳化剂HT-MUL配制了高密度的油基钻井液,其性能评价表明体系的基本性能良好,在220℃高温热滚后、破乳电压高达800 V,滤失量低于5 mL。HT-MUL配制的油基钻井液具有良好的抗高温性和乳化稳定性。



    Abstract: A primary emulsifier, HT-MUL, for high temperature oil base drilling fluid was developed using tall oil fatty acids and maleic anhydride, and the optimum acid value of tall oil fatty acids and optimum concentration of maleic anhydride for the reaction were determined. Evaluation of HT-MUL shows that HT-MUL performs very well as an emulsifier. Using HT-MUL, a water-in-oil emulsion (O/W ratio=60:40) was formulated, having electrical stability of 490 V, and another water-in-oil emulsion (O/W ratio=90:10), having electrical stability of 1,000 V. Comparison of HT-MUL with other primary emulsifiers demonstrates that emulsions formulated with HT-MUL have higher electrical stability voltage, lower filter loss and higher rate of emulsion, proving that HT-MUL has better general performance than other emulsifiers. A high performance high density oil base drilling fluid was formulated using HT-MUL, retaining electrical stability of 800 V and filter loss less than 5 mL after hot rolling at 220℃. Oil base drilling fluids formulated with HT-MUL have good high temperature performance and emulsion stability.



    • HTML全文
    • 参考文献(9)
  • 鄢捷年. 钻井液工艺学[M]. 石油大学出版社,2012:89-110. Yan Jienian. Drilling fluid technology[M]. University of petroleum press,2012:89-110.
    王中华. 国内外油基钻井液研究与应用进展[J]. 断块油气田,2011,18(4):533-537. Wang Zhonghua. The domestic and foreign research and application progress of oil-base drilling fluid[J]. Fault-Block Oil & Gas Field, 2011,18(4):533-537.
    何涛,李茂森,杨兰平,等. 油基钻井液在威远地区页岩气水平井中的应用[J]. 钻井液与完井液,2012, 29(3):1-5. He Tao, Li Maosen, Yang Lanping,et al. The application of oil-base drilling fluid for Shale gas horizontal well in Weiyuan region[J]. Drilling Fluid & Completion Fluid, 2012,29(3):1-5.
    王旭东, 郭保雨, 张海青, 等. 抗高温油包水型乳化剂的研制与应用[J]. 钻井液与完井液,2013,30(4):9-12. Wang Xudong, Guo Baoyu, Zhang Haiqing, et al. Development and application of water-in-oil type emulsifier for high temperature[J]. Drilling Fluid & Completion Fluid, 2013,30(4):9-12.
    刘明华,张滨,王阳,等. 油基钻井液用粉状乳化剂性能评价[J]. 钻井液与完井液,2015,32(5):7-9. Liu Minghua, Zhang Bin, Wang Yang,et al. The performance evaluation of the powder emulsifier in the oil-base drilling fluid[J]. Drilling Fluid & Completion Fluid, 2015, 32(5):7-9.
    田松柏, 马秀艳.石油及石油产品酸值测定方法的比较[J]. 石油炼制与化工,2002,33(12):49-53. Tian Songbai, Ma Xiuyan. The comparison of measurement for acid value in oil and oil products[J]. Petroleum processing and petrochemicals, 2002,33(12):49-53.
    王卫红. 原油酸值测定的探讨[J]. 河南化工,2008, 25(3):44-47. Wang Weihong. The discussion and measurement of acid value for crude oil[J]. Henan Chemical Industry, 2008, 25(3):44-47.
    王茂功,徐显广,苑旭波. 抗高温气制油基钻井液用乳化剂的研制和性能评价[J]. 钻井液与完井液,2012, 29(6):4-5, 9. Wang Maogong, Xu Xianguang, Yuan Xubo. The development and performance evaluation of the gas oilbase drilling fluid emulsifier for high temperature[J]. Drilling Fluid & Completion Fluid, 2012,29(6):4-5, 9.
    刘扣其,邱正松,曹杰,等. 油基钻井液流变参数影响因素探讨[J]. 西安石油大学学报(自然科学版), 2014,29(2):78-83. Liu Kouqi, Qiu Zhengsong, Cao Jie,et al. The exploring of influencing factors for reheological parameter in oil-based drilling fluid[J]. Journal of Xi'an Petroleum University(Natural Science Column), 2014,29(2):78-83.
