基于Cohesive单元法的弃置井水泥塞-套管界面胶结失效数值模拟

蒋记伟; 李军; 柳贡慧; 连威; 杨宏伟

doi:10.3969/j.issn.1001-5620.2020.03.014

基于Cohesive单元法的弃置井水泥塞-套管界面胶结失效数值模拟

doi: 10.3969/j.issn.1001-5620.2020.03.014

蒋记伟¹,
李军^1,2,
柳贡慧^1,3,
连威¹,
杨宏伟¹

1. 中国石油大学(北京)石油工程学院, 北京 102249;
2. 中国石油大学(北京)克拉玛依校区石油学院, 新疆克拉玛依 834000;
3. 北京工业大学, 北京 100124

基金项目:

国家自然科学基金联合基金重点项目“页岩气水平井井筒完整性失效机理与控制方法研究”（U1762211），国家自然科学基金重点项目“深水油气钻采井筒压力控制基础研究”（51734010）

详细信息

作者简介:
蒋记伟,在读博士研究生,主要从事井筒完整性、固井工艺方面的研究。电话15201169756;E-mail:tianya0603@qq.com

中图分类号: TE254
计量
- 文章访问数: 726
- HTML全文浏览量: 225
- PDF下载量: 93
- 被引次数: 0
出版历程
- 收稿日期: 2020-01-29
- 刊出日期: 2020-06-28

Numerical Simulation of Failed Bonding between Cement Plug and Casing String in Abandoned Wells Based on Cohesive Element Method

1. College of Petroleum Engineering, China University of Petroleum-Beijing, Beijing 102249;
2. School of Petroleum, China University of Petroleum-Beijing At Karamay, Karamay 834000;
3. Beijing University of Technology, Beijing 100192

摘要

摘要: 水泥塞-套管界面胶结失效对弃置井井筒完整性提出了严峻挑战。考虑地下流体与水泥塞的流固耦合作用，基于cohesive单元方法，建立水泥塞-套管-水泥环-地层系统三维有限元模型，模拟垂直井水泥塞-套管界面裂缝剥离过程，研究地应力对界面裂缝损伤演化的影响，并分析水平地应力、水泥塞力学参数及界面性质对裂缝剥离高度的影响。结果显示：水平地应力均匀时剥离裂缝沿着整个界面圆周延伸且高度相等，水平地应力非均匀时剥离裂缝倾向于沿着界面某一圆周角扩展且在最大水平地应力方向具有较大的高度；水泥塞弹性模量从30 GPa减小到1 GPa，裂缝剥离高度降低9.3 m，临界法向强度从0.25 MPa增大到2.0 MPa，裂缝剥离高度降低6.5 m，表明较低的弹性模量及较大的临界法向强度有利于减小水泥塞-套管界面胶结失效的风险；水泥塞泊松比从0.35减小到0.10，裂缝剥离高度仅降低2.0 m，临界剪切强度从0.5 MPa增加到4.0 MPa，裂缝剥离高度仅降低3.3 m，表明泊松比和临界剪切强度对界面胶结失效影响较小。建立的模型能够为水泥浆配方优选和井筒弃置工艺优化提供指导。
- 弃置井 /
- 水泥塞-套管界面 /
- 胶结失效 /
- 裂缝剥离高度 /
- cohesive单元方法 /
- 数值模拟
Abstract: Failure of bonding between cement plug and casing string in abandoned wells imposes a rigorous challenge to the borehole integrity. A 3D finite element model of cement plug, casing string, cement sheath and formation was established to simulate the stripping process of cement plug-surface of casing in vertical wells, to study the effects of geostress on the evolution of failure of the interface between cement plug and casing string, and to analyze the effects of horizontal geostresses, mechanical parameters of cement plug and the property of the interface on the height of the stripping fractures. The establishment of the 3D finite model takes into account the fluid-solid coupling effect between underground fluids and cement plug and is based on Cohesive element method. It was found in the study that when the horizontal geostresses are uniform, the stripping fractures extend along the entire circumference of the interface and have the same height. When the elastic modulus of the cement plug is reduced from 30 GPa to 1 GPa, the height of the stripping fracture is decreased by 9.3 m. When the critical normal strength is increased from 0.25 MPa to 2.0 MPa, the height of the stripping fracture is reduced by 6.5 m. These data indicate that low elastic modulus and high critical normal strength are beneficial to the mitigation of failure of bonding between cement plug and casing string. When the Poisson's ratio of the cement plug is reduced from 0.35 to 0.10, the height of stripping fracture is reduced only by 2.0 m. When the critical shear strength is increased from 0.5 MPa to 4.0 MPa, the height of stripping fracture is reduced only by 3.3 m, indicating that Poisson's ratio and critical shear strength play a minor role in the failure of the bonding. The model established is believed to be instructive to the optimization of cement slurry composition and techniques for well abandonment.
- Abandoned well /
- Interface between cement plug and casing /
- Failure of bonding /
- Height of fracture stripping /
- Cohesive element method /
- Numerical simulation

HTML全文

参考文献(26)

[1]	杨永斌. 海上平台弃置技术及市场前景预测[J]. 中国海洋平台, 2013, 28(4):4-7. YANG Yongbin. Offshore platform decommissioning technology and dismantling market prospect forecast[J]. China Offshore Platform, 2013, 28(4):4-7.
[2]	李祝军, 韩成, 魏安超, 等. 海上超高温高压探井弃井水泥塞技术[J]. 钻井液与完井液, 2019, 36(5):617-621. LI Zhujun, HAN Cheng, WEI Anchao, et al.The technology of setting cement plug for offshore ultra high temperature and ultra high pressure abandoned wells[J]. Drilling Fluid & Completion Fluid, 2019, 36(5):617-621.
[3]	KAISER M J.Rigless well abandonment remediation in the shallow water US Gulf of Mexico[J].Journal of Petroleum Science and Engineering, 2017(151):94-115.
[4]	VRÅLSTAD T, SAASEN A, FJÆR E, et al.Plug & abandonment of offshore wells:Ensuring long-term well integrity and cost-efficiency[J].Journal of Petroleum Science and Engineering, 2019(173):478-491.
[5]	WATSON T L, BACHU S.Evaluation of the potential for gas and CO₂ leakage along wellbores[J].SPE Drilling & Completion, 2009, 24(1):115-126.
[6]	PORTMAN L. Cementing through coiled tubing:common errors and correct procedures[R]. SPE 89599, 2004.
[7]	BOIS A P, VU M H, NOËL K, et al.Evaluating cement-plug mechanical and hydraulic integrity[J].SPE Drilling & Completion, 2019, 34(2):92-102.
[8]	LECAMPION B, QUESADA D, LOIZZO M, et al. Interface debonding as a controlling mechanism for loss of well integrity:Importance for CO₂ injector wells[J]. Energy Procedia, 2011(4):5219-5226.
[9]	MOEINIKIA F, FORD E P, LOHNE H P, et al. Leakage calculator for plugged-and-abandoned wells[J]. SPE Production & Operations, 2018, 33(4):790-801.
[10]	NAGELHOUT A, BOSMA M G R, MUL P, et al. Laboratory and field validation of cement systems for critical plug-and-abandon applications[R].SPE 97347, 2005.
[11]	NAGELHOUT A, BOSMA M G R, MUL P, et al. Laboratory and field validation of a sealant system for critical plug-and-abandon applications[J].SPE Drilling & Completion, 2010, 25(3):314-321.
[12]	VAN EIJDEN J, CORNELISSEN E, RUCKERT F, et al.Development of experimental equipment and procedures to evaluate zonal isolation and well abandonment materials[R].SPE 184640, 2017.
[13]	OPEDAL N, CORINA A N, VRÅLSTAD T.Laboratory test on cement plug integrity[R].OMAE 78347, 2018.
[14]	YAO Y, GOSAVI S V, SEARLES K H, et al. Cohesive fracture mechanics based analysis to model ductile rock fracture[R].ARMA10-140, 2017.
[15]	WANG W, TALEGHANI A D.Three-dimensional analysis of cement sheath integrity around Wellbores[J]. Journal of Petroleum Science and Engineering, 2014(121):38-51.
[16]	GUO J, ZHAO X, ZHU H, et al.Numerical simulation of interaction of hydraulic fracture and natural fracture based on the cohesive zone finite element method[J]. Journal of Natural Gas Science and Engineering, 2015(25):180-188.
[17]	ZHU H, ZHAO X, GUO J, et al.Coupled flow-stressdamage simulation of deviated-wellbore fracturing in hard-rock[J].Journal of Natural Gas Science and Engineering, 2015(26):711-724.
[18]	FENG Y, LI X, GRAY K E.Development of a 3D numerical model for quantifying fluid-driven interface debonding of an injector well[J].International Journal of Greenhouse Gas Control, 2017(62):76-90.
[19]	陈晓华, 邱正松, 杨鹏, 等. 基于ABAQUS的裂缝性漏失过程动态模拟研究[J]. 钻井液与完井液, 2019, 36(1):15-19. CHEN Xiaohua, QIU Zhengsong, YANG Peng, et al. Dynamic simulation of mud losses into fractured formations using ABAQUS software[J].Drilling Fluid & Completion Fluid, 2019, 36(1):15-19.
[20]	GASDA S E, CELIA M A, WANG J Z, et al. Wellbore permeability estimates from vertical interference testing of existing wells[J].Energy Procedia, 2013, 37:5673-5680.
[21]	TAHERDANGKOO R, TATOMIR A, ANIGHORO T, et al.Modeling fate and transport of hydraulic fracturing fluid in the presence of abandoned wells[J].Journal of contaminant hydrology, 2019(221):58-68.
[22]	GASDA S E, BACHU S, CELIA M A.Spatial characterization of the location of potentially leaky wells penetrating a deep saline aquifer in a mature sedimentary basin[J].Environmental geology, 2004, 46(6-7):707-720.
[23]	BUJOK P, PORZER M, LABUS K, et al. Experimental modeling of abandoned shallow oil wells convergence[J]. Engineering Geology, 2013(157):1-7.
[24]	ZIELONKA M G, SEARLES K H, NING J, et al. Development and validation of fully-coupled hydraulic fracturing simulation capabilities:in Proceedings of the SIMULIA community conference[C].USA:SCC, 2014.
[25]	BOUKHELIFA L, MORONI N, JAMES S, et al. Evaluation of cement systems for oil and gas well zonal isolation in a full-scale annular geometry[J].SPE Drilling & Completion, 2005, 20(1):44-53.
[26]	赵效锋, 管志川, 史玉才, 等. 固井界面微环隙产生机制及计算方法[J]. 中国石油大学学报:自然科学版, 2017, 41(5):94-101. ZHAO Xiaofeng, GUAN Zhichuan, SHI Yucai, et al. An assessment method for occurrence of micro-annular fractures on cementing interfaces of oil and gas well casing[J].Journal of China University of Petroleum(Edition of Natural Science), 2017, 41(5):94-101.
