A High Temperature Block Removal Fluid for Offshore Application
-
摘要: 海上油田X-1井砂岩储层具有高温、异常高压和低渗等特征,且储层岩样溶蚀孔发育,含有一定的粒间缝被黏土矿物充填,黏土矿物较多,易造成水敏、速敏。针对上述问题研制出一种高温低渗敏感性储层解堵液体系。实验表明,在170℃的条件下,解堵液体系对钢片的平均腐蚀速率为62.880 g/m2·h,达到行业一级标准,且该体系具有较低的表面张力,鲜酸和残酸表面张力均低于24.0 mN/m。解堵液体系有较好的稳定铁离子能力,稳定铁量高达263 mg/mL。解堵液体系具有较好的防膨效果,终膨胀率降低值为32.19%,能有效控制黏土膨胀,抑制水敏伤害。岩心中注入解堵液体系后,渗透率呈明显的上升趋势,由于该体系对黏土矿物和基质的溶蚀率均较大,且不宜引起出砂堵塞孔喉,渗透率增加倍比约为3.5倍,是较为理想的适用于高温低渗储层的解堵液体系。现场应用表明,解堵液基本解除井筒附近堵塞,对比酸化前后日产气量,本次酸化对该井起到了很好的解堵效果。Abstract: The sandstone reservoir penetrated by the well X-1 in an offshore oilfield has the characteristics of high temperature, abnormally high pressure and low permeability. Dissolution pores are developed in the reservoir rocks. Intergranular fractures in the reservoir rocks are full of various kinds of clays which are easy to cause water sensitivity and flow velocity sensitivity. To solve these problems, a blocking removal fluid was developed for use in the high temperature low permeability sensitive reservoirs. Laboratory experimental results showed that at 170℃, the average corrosion rate of the steel strip in the blocking removal fluid is 62.880 g/cm2·h, meeting the first-grade standard of the industry. The blocking removal fluid has lower surface tension, the surface tensions of the fresh acid and residue acid are all less than 24.0 mN/m. The blocking removal fluid has good ferric ion stability, it can stabilize 263 mg/mL of ferric ions in a system. The blocking removal fluid has good clay swelling inhibition capacity, the final rate of swelling of a sample can be controlled below 32.19%, this is helpful to effectively inhibit water sensitivity impairment to the reservoir. After injecting the blocking removal fluid into a core, the permeability of the core was apparently increasing. The blocking removal fluid is ideal for removing blocks existed in high temperature low permeability reservoirs because the dissolution rates of the blocking removal fluid to clay minerals and the matrix of the rock are high, the blocking removal fluid do not cause pore throats to be blocked by the produced sands, and the permeability of the core can be increased by 3.5 times. Field application showed that the blocking removal fluid removed almost all the blockage near the wellbore. Comparison of the daily gas production rates before and after acidification of the reservoir showed that the acidizing job has done very well in removing the blockage in the reservoir formation.
-
Key words:
- High temperature /
- Low permeability reservoir /
- Blocking removal fluid /
- Corrosion inhibitor /
- Acidize
-
[1] 曾凡辉, 郭建春. 东河油田CⅢ油组低渗储层的伤害及改造[J]. 油田化学, 2011, 28(3):296-300.ZENG Fanhui, GUO Jianchun. Damage and acidizing of the low permeability formation in Donghe Oilfield CⅢ[J].Oilfield Chemistry, 2011, 28(3):296-300. [2] 徐杏娟, 刘音, 付月永, 等. 高温碳酸盐岩酸化用胶凝酸体系研究[J].石油天然气学报,2014,36(11):197-200.XU Xingjuan, LIU Ying, FU Yueyong, et a1. The gelled acid system carbonate acidizing under high temperature[J].Journal of Oil and Gas Technology, 2014, 36(11):197-200. [3] 侯帆, 徐艳艳, 张艾, 等. 超深高温碳酸盐岩自生酸深穿透酸压工艺研究与应用[J].钻采工艺,2016,41(1):35-37.XU Fan, XU Yanyan, ZHANG Ai, et a1. Research andapplication of deep penetration acid fracturing by authigenic acid in extra deep high temperature carbonate rocks[J].Drilling Production Technology, 2016, 41(1):35-37. [4] 吕宝强, 李向平, 李建辉, 等. 我国重复酸化酸液体系的应用[J]. 油田化学, 2014, 31(1):136-140.LYU Baoqiang, LI Xiangpin, LI Jianhui, et a1. Application situation of reacidizing system in China[J]. Oilfield Chemistry, 2014, 31(1):136-140. [5] 唐甜甜, 李克华, 胡琳莉, 等. 两种曼尼希碱缓蚀剂的缓蚀性能[J]. 腐蚀与防护, 2017, 38(4):262-266.TANG Tiantian, LI Kehua, HU Linli, et a1.Corrosion inhibition of two kinds of mannich base inhibitors[J]. Corrosion & Protection, 2017, 38(4):262-266. [6] 中华人民共和国石油天然气行业标准SY/T 5405. 酸化用缓蚀剂性能试验方法及评价指标[S]. 中国石油天然气总公司, 1996. Petroleum and natural gas industry standard of the People's Republic of China SY/T 5405. performance test method and evaluation index of corrosion inhibitor for acidizing[S].CNPC, 1996. [7] 中华人民共和国石油天然气行业标准SY/T 5971. 注水用黏土稳定剂性能评价方法[S]. 中国石油天然气总公司, 1994. Petroleum and natural gas industry standard of the people's Republic of China SY/T 5971. Performance evaluation method of clay stabilizer for water injection[S]. CNPC, 1994. [8] 中华人民共和国石油天然气行业标准SY/T 6571. 酸化用铁离子稳定剂性能评价方法[S]. 国家能源局.2012. Petroleum and natural gas industry standard of the people's Republic of China SY/T 6571. Performance evaluation method of iron ion stabilizer for acidification[S]. National energy administration, 2012. 期刊类型引用(6)
1. 火丽娟. 完井液用环保缓蚀剂的制备与性能研究. 化学工程师. 2023(02): 50-52+88 . 百度学术
2. 薛森. 完井液用缓蚀剂研究进展. 化工管理. 2023(20): 110-113 . 百度学术
3. 黄治华,周书胜. 完井液用缓蚀剂的合成及性能评价. 当代化工. 2023(08): 1929-1932 . 百度学术
4. 宋晓伟. 具有黏土稳定作用的缓蚀剂在酸性完井液中的性能研究. 辽宁化工. 2022(04): 463-465+485 . 百度学术
5. 舒曼,周书胜. 食用香料二烯丙基四硫环保型缓蚀剂性能研究. 石油化工应用. 2022(12): 96-100 . 百度学术
6. 郝少军,施晓雯,安小絮,何宏林,管璐. 裂缝性高温基岩气井硫酸钙溶垢研究及现场应用. 钻井液与完井液. 2022(06): 787-792 . 本站查看
