Study on Weighted Slick Water Fracturing Fluid for Deep Buried Oil and Gas
-
摘要: 塔里木库车山前区块作为典型的超深层气藏,75%施工井泵压在100 MPa以上,最高施工压力达到136 MPa,压裂增产改造一直是制约其油气开发的技术瓶颈,施工排量也受到极大限制。据统计超深加重压裂液施工井,普遍存在液体密度增加,施工压力降低幅度未达到理论效果,基于理论分析及加重压裂液实际应用中存在的问题,借鉴页岩气用滑溜水成功应用的经验和加重压裂液的优点,通过优选加重剂、耐高盐降阻剂和助排剂形成了加重滑溜水体系。该体系加重密度为1.35 g/cm3,耐氯化钙35×104 mg/L,能有效降低施工压力和施工风险,降阻率为62%,与常规瓜胶压裂液减阻率相当,并具有良好的耐温耐剪切性能和助排性能,岩心伤害率为11.2%,对储层伤害低,为超高压超深井储层改造提供新的技术支持。Abstract: In fracturing the ultradeep gas reservoirs in the piedmont structure in Kuche, Tarim Basin, 75% of the wells were operated at pump pressures above 100 MPa, the highest pump pressure being 136 MPa. The development of the gas reservoirs has long been limited by the fracturing operation because of the high pump pressures. Statistic data showed that when fracturing ultradeep wells, an increase in the density of the fracturing fluid did not result in the designed pump pressure decrease. Based on theoretical analysis and problems encountered in fracturing with high density fracturing fluids, a weighted slick water fracturing fluid was developed with several agents selected such as a weighting agent, a salt resistant friction reducer and a cleanup additive. In developing the slick water fracturing fluid, experiences of successfully using slick water in shale gas development were borrowed, and the advantages of weighted fracturing fluids were taken. The slick water fracturing fluid has a density of 1.35 g/cm3 and is resistant to the contamination by 35×104 mg/L of CaCl2. With this slick water, the operation pressure can be effectively reduced and operation risks minimized. Similar to conventional guar gum fracturing fluids, this slick water can reduce friction by 62%. The slick water has good high temperature stability and cleanup ability. It is resistant to shearing. Cores tested with this slick water had permeability impairment of only 11.2%. The development of the slick water fracturing fluid has provided a technical support to the stimulation of ultra-high pressure and ultradeep reservoirs.
-
[1] 翁定为, 张庆九, 蒙炯, 等. 鸭西区块异常高应力储层加砂压裂探索与实践[J]. 石油天然气学报(江汉石油学院学报), 2014, 36(8):121-124. WENG Dingwei, ZHANG Qingjiu, MENG Jiong, et al. Study and practice of sand fracturing in abnormal high stress reservoirs in block Yaxi[J].Journal of Oil and Gas Technology, 2014, 36(8):121-124. [2] 范宇恒, 肖勇军, 郭兴午, 等. 清洁滑溜水压裂液在长宁H26平台的应用[J].钻井液与完井液, 2018, 35(2):122-125.FAN Yuheng, XIAO Yongjun, GUO Xingwu, et al. Application of clear slick water fracturing fluid on Changning-H26 platform[J].Drilling Fluid & Completion Fluid, 2018, 35(2):122-125. [3] 王静仪. 适用于页岩气开发的高效滑溜水压裂液体系研究[J]. 能源化工, 2019, 40(2):51-55.WANG Jingyi.Study on high efficiency slick water fracturing system suitable for shale gas reservior[J]. Energy Chemical Industry, 2019, 40(2):51-55. [4] 陆丽, 陈英, 徐婷婷, 等.页岩储层增产改造工作液的研究与应用[J]. 钻井液与完井液, 2016, 33(2):111-116.LU Li, CHEN Ying, XU Tingting, et al.Study and application of stimulation f luid for shale reservoirs[J]. Drilling Fluid & Completion Fluid, 2016, 33(2):111-116. [5] 程兴生, 张福祥, 徐敏杰, 等. 低成本加重瓜胶压裂液的性能与应用[J]. 石油钻采工艺, 2011, 33(2):91-93.CHENG Xingsheng, ZHANG Fuxiang, XU Minjie, et al.Performance and application of weighted GHPG fracturing fluid with low cost[J].Oil Drilling & Production Technology, 2011, 33(2):91-93. [6] 段志英. 高压深井压裂液加重技术研究进展[J]. 断块油气田, 2010, 17(4):500-502.DUAN Zhiying.Research progress on weighted fracturing fluid technology for deep well with high pressure[J].FaultBlock Oil & Gas Field, 2010, 17(4):500-502. [7] 任占春. 甲酸盐加重瓜胶压裂液体系[J]. 钻井液与完井液, 2017, 34(1):122-126.REN Zhanchun.Guar gum fracturing fluids weighted with formates[J].Drilling Fluid & Completion Fluid, 2017, 34(1):122-126. [8] 王彦玲,张悦,刘飞,等.复合无机盐加重压裂液研究[J]. 精细石油化工, 2017, 34(5):6-8.WANG Yanling, ZHANG Yue, LIU Fei, et al. Research of compound inorganic salt aggravating fracturing fluids[J].Speciality Petrochemicals, 2017, 34(5):6-8. [9] 崔会杰, 余东合, 李建平, 等.高密度瓜胶压裂液体系的研究与应用[J].石油钻采工艺, 2013, 35(5):64-66.CUI Huijie, YU Donghe, LI Jianping, et al.Research and application of high density guar gum fracturing fluid system[J].Oil Drilling & Production Technology, 2013, 35(5):64-66. -
