超高温高密度钻井液体系的研究与应用

李雄; 董晓强; 金军斌; 杨小华

doi:10.3969/j.issn.1001-5620.2020.06.003

超高温高密度钻井液体系的研究与应用

doi: 10.3969/j.issn.1001-5620.2020.06.003

李雄^1,2,
董晓强^1,2,
金军斌^1,2,
杨小华^1,2

1. 页岩油气富集机理与有效开发国家重点实验室, 北京 100101;
2. 中国石化石油工程技术研究院, 北京 100101

基金项目:

国家重点研发计划子课题“火成岩地区深层地热高效成井关键技术”（2019YFC0604904）、中石化科技部“超高温高密度钻井液技术研究”（P16021）、“顺北一区断溶体油藏储层保护技术研究”（P18021-4）、国家科技重大专项课题“耐高温高性能钻井液体系及井筒强化技术”（2017ZX05005-005）、国家自然科学基金重大项目“页岩油气高效开发基础理论研究”（51490650）联合资助

详细信息

作者简介:
李雄，副研究员，硕士，1983年生，毕业于中国石油大学（华东）油气井工程专业，现在从事高温高密度钻井液、钻井液工艺技术研究工作。电话（010）84988573；E-mail：lixiong.sripe@sinopec.com

中图分类号: TE254.3
计量
- 文章访问数: 623
- HTML全文浏览量: 181
- PDF下载量: 141
- 被引次数: 0
出版历程
- 收稿日期: 2020-09-23
- 刊出日期: 2020-12-28

Study and Application of an Ultra-High Temperature High Density Drilling Fluid

1. State Key Laboratory of Shale Oil and Gas Enrichment Mechanisms and Effective Development, Beijing 100101;
2. SINOPEC Research Institute of Petroleum Engineering, Beijing 100101

摘要

摘要: 针对大多数采用重晶石加重的高密度钻井液在高温下存在的流变性能调控难、高温高压滤失量大、重晶石沉降等技术难题，从抗温、降滤失、控制黏度和切力、提高沉降稳定性能等方面提出了钻井液体系的设计思路，通过研发超高温封堵降滤失剂SMPFL-UP、超高温高密度分散剂SMS-H等核心处理剂，优选抗高温封堵防塌剂SMNA-1、高温稳定剂GWW、高效润滑剂SMJH-1等关键配套处理剂，经过配方优化及评价，研发出了一套超高温高密度钻井液体系（SMUTHD），抗温达220℃。SMUTHD密度不超过2.40 g/cm³时，经220℃老化后流变性能稳定，高温高压滤失量小于12 mL，极压润滑系数为0.178，在220℃下静置7 d沉降系数（SF）小于0.54，表现出良好流变性能、滤失性能和高温沉降稳定性能。SMUTHD在顺南蓬1井五开进行了成功应用，累计进尺581 m，井底温度为207.4℃，实钻钻井液密度为1.75～1.80 g/cm³，不同施工阶段井浆的SF均小于0.52，施工期间钻井液性能稳定，井下安全，取心顺利。SMUTHD的成功研发及现场应用，有力保障了深部油气层的勘探发现、增储建产和低成本高效开发，提高了我国超高温高密度钻井液技术的自主化水平。
- 超高温 /
- 高密度 /
- 水基钻井液 /
- 顺南蓬1井
Abstract: Most of the high-density drilling fluids weighted with barite are often faced with high temperature problems such as difficulty in rheology control, high HTHP filter loss and barite sag etc. A drilling fluid design clue is presented to deal with these problems. An ultra-high temperature high density drilling fluid SMUTHD was formulated with a self-developed ultra-high temperature filter loss reducer SMPFL-UP, a self-developed dispersant for use in ultra-high temperature high density fluids, a high temperature plugging antisloughing agent SMNA-1, a high temperature stabilizer GWW and a high-efficiency lubricant SMJH-1 etc. The SMUTHD drilling fluid can be used at high temperatures up to 220 ℃. At density of less than 2.40 g/cm³, the SMUTHD drilling fluid had stable rheology, HTHP filter loss of less than 12 mL and extreme friction coefficient of 0.178 after aging at 220 ℃. The settling factor (SF) of SMUTHD standing for 7 d at 220 ℃ was less than 0.54. These data indicate that the SMUTHD drilling fluid has good rheological and filtration control properties as well as high temperature settling performance when its density is not higher than 2.40 g/cm³. The SMUTHD drilling fluid has been successfully used in drilling the 5th interval of the well Shunnanpeng-1, with total footage of 581 m drilled. The bottom hole temperature of this well was 207.4 ℃, and the density of the drilling fluid was 1.75-1.80 g/cm³. Drilling fluids in different operational stages all had SF of less than 0.52. The properties of the drilling fluid were stable and no downhole troubles happened during drilling. Coring operation was performed smoothly. The development of SMUTHD has not only greatly ensured the exploration and discovering of deep oil and gas reservoirs, the increase of petroleum reserves and production as well as oil and gas development with low cost and high efficiency, it has also improved the level of autonomy of China’s ultra-high temperature and high density drilling fluid technology.
- Ultra-high temperature /
- High density /
- Water base drilling fluid /
- Well Shunnanpeng-1

HTML全文

参考文献(11)

[1]	ADAMSON K, BIRCH G, GAO E, et al. Highpressure, high-temperature well construction[J]. Oilfield Review, 1998(6):36-49.
[2]	张勇. 南海莺琼地区高温高压钻井技术的探索[J]. 天然气工业, 1999, 19(1):71-75. ZHANG Yong. A study of the drilling techniques of high temperature and high pressure wells in Yingqiong region of South China Sea[J]. Natural Gas Industry, 1999, 19(1):71-75.
[3]	袁建强, 何振奎, 刘霞. 泌深1井钻井设计与施工[J]. 石油钻探技术, 2010, 38(1):42-45. YUAN Jianqiang, HE Zhenkui, LIU Xia. Well Bishen-1 drilling design and operation[J]. Petroleum Drilling Techniques, 2010, 38(1):42-45.
[4]	李公让, 薛玉志, 刘宝峰, 等. 胜科1井四开超高温高密度钻井液技术[J]. 钻井液与完井液, 2009, 26(2):12-15. LI Gongrang,XUE Yuzhi,LIU Baofeng, et al. High temperature high density drilling fluid technology for the forth interval of well Shengke-1[J]. Drilling Fluid & Completion Fluid, 2009, 26(2):12-15.
[5]	王显光, 任立伟. 超高温降滤失剂在徐闻X3井成功应用[J]. 石油钻探技术, 2010, 38(6):112. WANG Xianguang, REN Liwei. Ultra-high temperature fluid loss agent in the successful application of well Xuwen X3 [J]. Petroleum Drilling Techniques,2010,38(6):112.
[6]	林永学, 杨小华, 蔡利山, 等. 超高密度钻井液技术[J]. 石油钻探技术, 2011, 39(6):1-5. LIN Yongxue, YANG Xiaohua, CAI Lishan, et al. Ultra-high density drilling fluid technology[J]. Petroleum Drilling Techniques, 2011, 39(6):1-5.
[7]	王中华. 国内外超高温高密度钻井液技术现状与发展趋势[J]. 石油钻探技术, 2011, 39(2):1-7. WANG Zhonghua. Current situation and development trend of ultra-high temperature and high density drilling fluid technology at home and abroad[J]. Petroleum Drilling Techniques, 2011, 39(2):1-7.
[8]	孔勇, 杨小华, 徐江,等. 抗高温强封堵防塌钻井液体系研究与应用[J]. 钻井液与完井液, 2016, 33(6):17-22. KONG Yong, YANG Xiaohua, XU Jiang, et al. Study and application of a high temperature drilling fluid with strong plugging capacity[J]. Drilling Fluid & Completion Fluid, 2016, 33(6):17-22.
[9]	王建, 彭芳芳, 徐同台, 等. 钻井液沉降稳定性测试与预测方法研究进展[J]. 钻井液与完井液, 2012, 29(5):79-83. WANG Jian,PENG Fangfang, XU Tongtai, et al. Research progress in the methods of testing and predicting the settling stability of drilling fluid[J]. Drilling Fluid & Completion Fluid, 2012, 29(5):79-83.
[10]	JASON MAXEY. Rheological analysis of static and dynamic sag in drilling fluids[C]. Annual transactions of the Nordic Rheology Society,vol. 15,2007.
[11]	JEFFERSON D T. New procedure helps monitor sag in the field[C]. ASME 91-PET-3. Energy Sources Technology Conference and Exhibition, New Orleans, 20-24 Jan 1991.
