A Synthetic Resin Filter Loss Reducer Made from Environmentally Friendly Biomasses
-
摘要: 绿色高性能钻井液已经成为发展趋势，降滤失剂作为核心处理剂，不仅要求其抗温、抗盐和降滤失性能好，还要求其易生物降解。以木质素为原料，经生物降解和化学反应得到生物质合成树脂降滤失剂LDR-501。性能测试结果表明：LDR-501的BOD5/CODCr为0.26，可生物降解；EC50为440 000 mg/L，无毒；浊点盐度为160 g/L，用其处理的基浆在180℃老化16 h后的高温高压滤失量为18.6 mL，抗温、抗盐、降滤失性能好。环保型生物质合成树脂降滤失剂的成功研发，为促进生物质资源在钻井液领域的应用，提高水基钻井液绿色环保性奠定了基础。Abstract: With more and more stringent environment protection requirements imposed on the petroleum exploration industry, drilling fluid additives are required to be nontoxic and have high performance. As the core additive of drilling fluids, filter loss reducer is required to have properties such as high temperature resistance, salt resistance, good filtration control performance, lowor nontoxicity, and good biodegradation. Using lignin as a raw material, a biomass synthetic resin filter loss reducer, LDR-501, was produced through biodegradation and chemical reaction. Evaluation of LDR-501 showed that the BOD5/CODCr value is 0.26, indicating that LDR-501 is biodegradable. The EC50 of LDR-501 is 440 000 mg/L, and the cloud point salinity of LDR-501 is 160 g/L. A base mud treated with LDR-501 had HTHP filtration rate of 18.6 mL after aging at 180℃ for 16 h, indicating that LDR-501 has good high temperature resistance, salinity resistance and good filtration control performance. The development of LDR-501 has accelerated the application of biomass resources in drilling fluid industry and laid the foundation of improving the environmental friendliness of water base drilling fluids.
-
Key words:
- Filter loss reducer /
- Biomass /
- Lignin /
- Synthetic resin /
- Biodegradability
-
[1] 李尧,黄进军,杨国兴,等.阳离子化磺化两性酚醛树脂降滤失剂XNSMPⅢ 的研制[J]. 油田化学, 2009,26(4):351-353.LI Yao,HUANG Jinjun,YANG Guoxing,et al. Preparation of amphoteric phenol-formaldehyde resin as filtration loss reducer XNSMP-Ⅲ for water base drilling fluids[J].Oilfield Chemistry,2009,26(4):351-353. [2] 黄宁. 天然多元酚制备磺化酚醛树脂降滤失剂的研究[J]. 精细石油化工,1996(4):9-11. HUANG Ning.Study on the sulfonated phenol formaldehyde resin fil tration loss controller from natural polyphenois[J]. Speciality Chemicals, 1996(4):9-11. [3] 于培志, 李均, 吴文辉.两性离子型酚醛树脂钻井液降滤失剂的合成与性能[J]. 油田化学, 2004, 21(1):1-4.YU Peizhi,LI Jun,WU Wenhui.Synthesis and performance properties of amphoteric phenolic resin as filtration loss reducer for drilling fluids. Oilfield chemistry[J].Oilfield Chemistry,2004,21(1):1-4. [4] 张丽君,王旭,胡小燕,等.抗温270℃钻井液聚合物降滤失剂的研制[J]. 石油化工,2017,46(1):117-123.ZHANG Li ju n,WANG Xu,HU Xiaoya n,et al. Development of the polymer filtreate reducer used for 270℃ ultra-high temperature drilling fluid[J]. Petrochemical Technology,2017,46(1):117-123. [5] 王中华,王旭,杨小华. 超高温钻井液体系研究(Ⅱ)- 聚合物降滤失剂的合成与性能评价[J]. 石油钻探技术, 2009,37(4):1-6.WANG Zhonghua,WANG Xu,YANG Xiaohua. Ultra-high temperature drilling fluid system study (2):synthesisi and evaluation of a polymer fluid loss additives[J].Petroleume Drilling Techniques,2009,37(4):1-6. [6] 张喜凤,李天太,施里宇,等. 深井抗高温高密度盐水钻井液实验研究[J]. 西安石油大学学报:自然科学版,2007,22(5):37-41.ZHANG Xifeng,LI Tiantai,SHI Liyu,et al. Experimental study of the high-density salt water drilling fluid with high-temperature resistance for deep wells[J]. Journal of Xi'an Shiyou University:Natural Science Edition,2007,22(5):37-41. [7] LI YIDAN,ELISABETH R,ARGILLIER J F. Correlation between filter cake structure and filtration properties of model drilling fluids[C].SPE 28961,1995. [8] 黄维安,邱正松,乔军,等. 抗温抗盐聚合物降滤失剂的研制及其作用机制[J]. 西南石油大学学报:自然科学版, 2013, 35(1):129-134.HUANG Weian,QIU Zhengsong,QIAO Jun,et al. Development of anti high temperature and salt polymer fluid loss agent and study on its operation mechanisms[J]. Journal of Southwest Petroleum University(Science & Technology Edition), 2013, 35(1):129-134. -
