Synthesis and Performance of High Temperature Filter Loss Reducer ZFA-1 for Oil Well Cement Slurries
-
摘要: 针对水溶性聚合物在强碱下耐高温性能的局限性，笔者突破传统水溶性共聚物的研究思路，设计并合成了无机非金属材料-有机聚合物高温降失水剂ZFA-1。通过实验确定了ZFA-1的最佳合成工艺：AM：IA：AMPS物质的量比为6.0：2.5：1.5，分子量调节剂加量为0.005%，偶联剂加量为0.5%，无机材料加量为5%，引发剂加量为0.5%，单体质量分数为25%，体系pH值为6，引发温度为55℃，反应时间为6 h；分别采用红外光谱（FT-IR）、热重分析（DSC/DTG）对ZFA-1进行了表征。结果表明，ZFA-1为预期结构的产物，在326℃时失重率仅为7.81%，主要是由于偶联剂和无机材料的引入增加了其在高温下的稳定性。对ZFA-1的性能评价结果表明，当ZFA-1加量为1.0%~1.5%时，可将水泥浆在93~200℃、6.9 MPa时的失水量控制在50 mL以内，具有优良的抗盐性能，且对水泥石的抗压强度无不良影响。Abstract: Water-soluble polymers have limited temperature resistance in high pH environment. To improve the high temperature performance of filter loss reducers, a new high temperature filter loss reducer, ZFA-1, was developed using a quite different way of synthesis than conventional way of synthesizing water-soluble copolymers. ZFA-1 is an inorganic non-metallic material compounded with organic polymer. The optimum synthesis conditions was determined as follow through experiment:molar ratio of AM:IA:AMPS=6.0:2.5:1.5, the concentration of molecular weight modifier=0.005%, concentration of coupling agent=0.5%, concentration of inorganic material=5%, concentration of initiator=0.5%, mass fraction of monomers=25%, pH of the reaction system=6, initiation temperature=55℃, and the reaction time=6 h. Characterization of the synthesis product with FT-IR and DSC/DTG showed that the product obtained had the molecular structure as expected. The ratio of weight loss of ZFA-1 at 326℃ was only 7.81%, which can be credited to the introduction of coupling agent and inorganic material that improve the high temperature stability of the final product ZFA-1. Laboratory evaluation of ZFA-1 showed that at concentrations of 1.0% -1.5%, the filtration rate of cement slurries can be controlled within 50 mL at 93-200℃ and 6.9 MPa. ZFA-1 has excellent salt-resistance and no negative effect on the compressive strength of set cement.
-
[1] 刘学鹏, 刘仍光. 油井水泥降失水剂的作用机理研究[J]. 化学研究与应用, 2017, 29(12):1928-1932.LIU Xuepeng, LIU Rengguang.Mechanisms involved in fluid loss control of oilwell cement slurries by watersoluble polymer[J].Chemical Research and Application, 2017, 29(12):1928-1932. [2] 韩亮, 唐欣, 杨远光, 等. 新型两性离子固井降失水剂的合成与性能评价[J]. 钻井液与完井液, 2018, 35(2):85-91.HAN Liang, TANG Xin, YANG Yuanguang, et al. Synthesis and evaluation of a new amphoteric filter loss reducer for cement slurry[J].Drilling Fluid & Completion Fluid, 2018, 35(2):85-91. [3] CORBIN D, LIN Yingying, TENN TAILIANG. Polyeclectrolyte-complex nanoparticles for fluidloss control in oilwell cementing[J].SPE Drilling & Completion, 2019, 34(2):11-22. [4] WILLIAM PEARL, SAMUEL LEWIS, JOHN SINGH. Relationship between the 2-acrylamido-2-methylpropan sulfonic acid-NNDMA copolymer properties and fluid loss and mixability in cementing fluids[R].SPE 1935537, 2019. [5] 李晓岚, 国安平, 孙举. 三元共聚物油井水泥降失水剂的室内研究[J]. 钻井液与完井液, 2013, 30(1):56-59.LI Xiaolan, GUO Anping, SUN Ju.Research on terpolymer of oil well cement filtrate reducer[J].Drilling Fluid & Completion Fluid, 2013, 30(1):56-59. [6] 李皋, 付强, 余杭航, 等. 四元共聚物抗高温抗盐油井水泥浆降失水剂的合成[J]. 天然气工业, 2018, 38(12):96-101.LI Gao, FU Qiang, YU Hanghang, et al.Synthesis and performance evaluation of quadripolymer as a temperature-and salt-resistance oil well cement filtrate reducer[J].Natural Gas Indusdtry, 2018, 38(120):96-101. [7] 李雨威, 黄志宇. 抗高温油井水泥降失水剂SZ1-1的研制与应用[J]. 钻采工艺, 2018, 41(6):94-98.LI Yuwei, HUANG Zhiyu.Development and application of high temperature oil well cement filtrate reducer SZ1-1[J].Drilling & Production Technology, 2018, 41(6):94-98. [8] ARNAUD CADIX, VINCENT MOLINIE, JAMES WILSON. Effect of fluid loss polymers architecture on cement slurry rheology:impact of adsorption and microstructure[R]. SPE 193620, 2019. -
