High Performance Drilling Fluid for Horizontal Drilling in the Well Jiaoye18-10HF in Fuling Shale Gas Field
-
摘要: 焦页18-10HF井是中石化在涪陵页岩气田部署的一口开发井,完钻井深4560 m,水平段长度1378 m。该工区三开井段页岩脆性矿物含量高,微纳米级孔隙裂缝和层理发育,一直使用油基钻井液应对井下复杂情况。针对龙马溪五峰组页岩裂缝发育等特性,通过核心处理剂端胺基聚醚抑制页岩表面水化,植物油酰胺极压减摩剂有效润滑减阻,纳米封堵封固,构建了JHGWY-1高性能水基钻井液,页岩滚动回收率大于98%,极压润滑系数0.16,钻井液封堵泥饼承压超过10MPa,满足龙马溪五峰组页岩微裂缝发育、脆弱胶结面对封堵封固及水平段润滑减阻要求。该体系首次在涪陵工区的焦页18-10HF井三开井段代替油基钻井液,在设计垂厚10 m、实钻8~10 m的五峰组中顺利穿行,起下钻畅通,钻完井顺利。该体系表现出良好的流变性、低滤失量和稳定页岩井壁能力,完井作业顺利,满足了该井三开钻完井工程需要。Abstract: The well Jiaoye18-10HF is a development well drilled in Fuling Shale Gas Field (Sinopec), with completion depth of 4 560 m and horizontal length of 1 378 m. The shales encountered in the third section of the wells in this area have high content of brittle minerals. Micro-fractures of micrometer and nanometer in size and bedding planes are so rich in the formations that oil base drilling fluids had to be used to minimize downhole troubles. Based on the study on the nature of the fractured shales encountered in the Wufeng Formation in Longmaxi block, a high performance water base drilling fluid, JHGWY-1, has recently been formulated with several major additives; PEA (amine-terminated polyether) as the core additive to inhibit the surface hydration of shales, vegetable oil oleamide as an extreme pressure lubricant to effectively reduce friction and nanometer plugging agent to strengthen borehole walls. In laboratory experiment, JHGWY-1 showed percent recovery of shale cuttings of more than 98%, coefficient of friction of 0.16 and pressure bearing capacity of the mud cake formed of more than 10 MPa. These properties satisfied the needs of drilling operation in Longmaxi area, such as drilling the micro-fracture-enriched Wufeng Formation, plugging and strengthening of formation with weak cementation, and good lubricity of the drilling fluid in horizontal drilling. This drilling fluid was first used in place of oil base drilling fluids in drilling the third interval of the well Jiaoye18-10HF which penetrated through the Wufeng Formation with designed vertical thickness of 10 m (actually 8-10 m during drilling). Tripping of drill string was smooth and the well was successfully completed. The mud had good rheology, low filtration rate and strong inhibition to shale during drilling, and the needs of drilling the third interval of the well was satisfied.
-
[1] 梁文利,宋金初,陈智源,等. 涪陵页岩气水平井油基钻井液技术[J]. 钻井液与完井液,2016,33(5):19-24.LIANG Wenli,SONG Jinchu,CHEN Zhiyuan,et al. Oil base drilling fluid for drilling shale gas wells in fuling[J]. Drilling Fluid & Completion Fluid,2016,33(5):19-24. [2] 何恕,李胜,王显光,等. 高性能油基钻井液的研制及在彭页3HF井的应用[J]. 钻井液与完井液,2013, 30(5):1-4.HE Shu,LI Sheng,WANG Xianguang,et al. Researh on high performance oil-based drilling fluid and it's application on well Pengye3HF[J]. Drilling Fluid & Completion Fluid,2013,30(5):1-4. [3] 于成旺,杨淑君,赵素娟. 页岩气井钻井液井眼强化技术[J]. 钻井液与完井液,2018,35(6):49-54.YU Chengwang,YANG Shujun,ZHAO Sujuan. Borehole wall strengthening with drilling fluids in shale gas drilling[J]. Drilling Fluid & Completion Fluid,2018, 35(6):49-54. [4] 孙金声,刘敬平,闫丽丽,等. 国内外页岩气井水基钻井液技术现状及中国发展方向[J]. 钻井液与完井液, 2016,33(5):1-8.SUN Jinsheng,LIU Jingping,YAN Lili,et al. Status quo of water base drilling fluid technology for shale gas drilling in China and abroad and its developing trend in China[J]. Drilling Fluid & Completion Fluid,2016,33(5):1-8. [5] JULIOCM,ERICVO,RICARDOB, et al. Using a lowsalinity high-performance water-based drilling fluid for improved drilling performance in Lake Maracaibo[C]. SPE 110366, 2007. [6] JAY P DEVILLE, BRADY FRITZ, MICHAEL JARRETT. Development of water-based drilling fluids customized for shale reservoirs[C]. SPE 140868,2011. [7] 闫丽丽,李丛俊,张志磊,等. 基于页岩气"水替油"的高性能水基钻井液技术[J]. 钻井液与完井液,2015, 32(5):1-7.YAN Lili,LI Congjun,ZHANG Zhilei,et al.High performance water-based drilling fluid based on shale gas "Water Replacement Oil" technology[J].Drilling Fluid & Completion Fluid,2015,32(5):1-7. [8] 刘凡,蒋官澄,王凯,等. 新型纳米材料在页岩气水基钻井液中的应用研究[J]. 钻井液与完井液,2018, 35(1):27-33.LIU Fan,JIANG Guancheng, WANG Kai,et al. Research on application of a novel nanophase material in water base drilling fluids for shale drilling[J].Drilling Fluid & Completion Fluid,2018,35(1):27-33. [9] 梁文利. 四川盆地涪陵地区页岩气高性能水基钻井液研发及效果评价[J]. 天然气勘探与开发, 2019,42(1):120-129.Liang Wenli.Application of water-based drilling fluid with high performance to shale gas, Fuling area, Sichuan Basin[J].Natural Gas Exploration and Development, 2019,42(1):120-129. [10] 叶海超,光新军,王敏生,等. 北美页岩油气低成本钻完井技术及建议[J]. 石油钻采工艺,2017,39(5):552-558.YE Haichao, GUANG Xinjun, WANG Minsheng, et al. Low-cost shale oil and gas drilling and completion technologies used in the North America and the suggestions[J]. Oil Drilling & Production Technology, 2017, 39(5):552-558. -
