川深1井钻井液关键技术

魏昱; 白龙; 王骁男

doi:10.3969/j.issn.1001-5620.2019.02.011

川深1井钻井液关键技术

doi: 10.3969/j.issn.1001-5620.2019.02.011

1. 中国地质大学(北京)工程技术学院, 北京 100083;
2. 中石化西南石油工程有限公司重庆钻井分公司钻井液技术服务中心, 重庆 400042

基金项目:

国家自然科学基金面上项目“绳索取心钻杆内壁结垢机理与控制方法”（41772388）资助

详细信息

作者简介:
魏昱,在读硕士研究生,1994年生,现主要从事钻井液技术研究工作。电话18630942927;E-mail:759502778@qq.com

中图分类号: TE254.3
计量
- 文章访问数: 471
- HTML全文浏览量: 134
- PDF下载量: 252
- 被引次数: 0
出版历程
- 收稿日期: 2018-01-11
- 刊出日期: 2019-04-30

Key Drilling Fluid Technology for Well Chuanshen-1

1. China University of Geosciences(Beijing), School of Engineering and Technology, Beijing 100083;
2. Sinopec Southwest Petroleum Engineering Co., Ltd. Drilling Fluid Technology Service Center of Chongqing Drilling Branch, Chongqing 400042

摘要

摘要: 川深1井是中石化部署在川东北地区的一口超深预探井，完钻井深为8420.00 m。该井面临着井温高、地层条件复杂、地质资料少及井壁易失稳等诸多技术难点。针对高密度钻井液技术难点，通过室内实验优选出抗高温处理剂：2% SPNH、2% SMP-3、0.5% SMPFL（DSP-1）、3% SMT（SMS-H）、3% RHJ-3、1% HPA、3%纳米SiO₂。通过钻井液体系正交实验得出了流变性好、抑制性强、抗温性强、沉降稳定性好、抗污染能力强的高密度聚磺钻井液，并在该井四开井段取得了成功应用。最后，对现场应用过程中的钻井液关键技术进行了系统的阐述，如气液转换技术、特殊地层处理方法、钻井液的现场维护技术措施及保护油气层技术等，主要取得以下认识：①加重时循环混入低黏度切力的高密度钻井液，逐步降低膨润土含量；②通过固控设备严格控制固相含量；③钻遇盐膏层时可提高钻井液密度，并严格控制滤失量，保证钻井液pH值不低于10；④酸性地层可适量提高Cl-含量对钻井液进行预处理提高其抗盐性能；⑤破碎地层须提高钻井液密度并加入相应处理剂，从力化耦合角度防止井壁失稳；⑥易漏地层应严格控制钻井液密度，适当减少排量及提高黏度和切力，可加入不同粒径可酸化的封堵材料，进行屏蔽暂堵。
- 钻井液 /
- 川深1井 /
- 高温 /
- 盐膏层 /
- 井壁稳定
Abstract: Well Chuanshen-1 is an ultra-deep exploratory well drilled in northeast Sichuan by Sinopec. Drilling of this well was faced with several technical difficulties such as high formation temperature, complex formations penetrated, less geological data available, borehole wall instability and high mud density etc. Drilling fluid additives were selected through laboratory experiment to deal with the high-density problem. The additives selected and their concentrations were:2%SPNH, 2%SMP-3, 0.5%SMPFL (DSP-1), 3%SMT (SMS-H), 3%RHJ-3, 1%HPA, 3%nanophase SiO². A high-density polymer sulfonate drilling fluid with good rheology, strong inhibitive capacity, high temperature resistance, good settling stability and high resistance to contamination, was formulated through orthogonal experiment. This drilling fluid was successfully applied in the fourth interval of the well Chuanshen-1. Difficulties encountered in filed operations and technical measures (such as gas-liquid conversion, drilling fluid treatment for special formations, mud property maintenance in field operations and reservoir protection etc.) are discussed in this paper. The major technical measures include:1) When weighing the active mud, high density mud with low viscosity low gel strength should be used and the MBT of the mud should be reduced gradually. 2) Solids control equipment should be used to control solids content strictly under designed value. 3) Drilling fluid density can be increased when drilling into salt and gypsum formations and filter loss should be strictly controlled. pH value of the drilling fluid should be no less than 10. 4) When drilling formations with acidic fluids, pretreat the drilling fluid with high chloride content, thereby enhancing its ability to resist salt contamination. 5) High density with some additives can be used to drill broken formations, borehole instability can be resolved through coupling of mechanical and chemical measures. 6) Drilling fluid density should be strictly controlled when drilling formations at which mud losses are easy to take place. Meanwhile the flow rate should be appropriately reduced, and mud viscosity and gel strength should be increased to some extent. Temporary plugging with acid soluble lost circulation materials of different particle sizes can be used to control mud losses.
- Drilling fluid /
- Well Chuanshen-1 /
- High temperature /
- Salt and gypsum formations /
- Borehole wall stabilization

HTML全文

参考文献(14)

[1]	蒋祖军, 郭新江, 王希勇. 天然气深井超深井钻井技术[M]. 北京:中国石化出版社, 2011:1-21. JIANG Zujun, GUO Xinjiang, WANG Xiyong. Drilling technology for natural gas deep/ultra-deep wells[M]. Beijing:Sinopec Press, 2011:1 -21.
[2]	蔡利山, 林永学, 杨小华, 等. 官深1井超高密度钻井液技术[J]. 石油学报, 2013, 34(1):169-177. CAI Lishan, LIN Yongxue, YANG Xiaohua, et al. A study on the ultra-high density drilling fluid of Well Guanshen-1[J]. Acta Petrolei Sinica, 2013, 34(1):169-177.
[3]	胡德云. 超高密度(ρ ≥ 3.00 g/cm³)钻井液的研究与应用[J]. 钻井液与完井液, 2001, 18(1):6-11. HU Deyun. Study and application of ultra-high density drilling fluid[J]. Drilling Fluid & Completion Fluid, 2001, 18(1):6-11.
[4]	张东海, 马洪会. 超高密度钻井液在官7井的应用[J]. 钻井液与完井液, 2006, 23(5):8-11. ZHANG Donghai, MA Honghui. The application of ultra-high density mud in well Guan-7[J]. Drilling Fluid & Completion Fluid, 2006, 23(5):8-11.
[5]	蔡利山, 胡新中, 刘四海, 等. 高密度钻井液瓶颈技术问题分析及发展趋势探讨[J]. 钻井液与完井液, 2007, 24(S1):38-44. CAI Lishan, HU Xinzhong, LIU Sihai, et al. High density drilling fluids:bottleneck technologies and the progresses[J]. Drilling Fluid & Completion Fluid, 2007, 24(S1):38-44.
[6]	刘四海, 蔡利山. 深井超深井钻探工艺技术[J]. 钻井液与完井液, 2002,19(6):121-126. LIU Sihai, CAI Lishan. Drilling technologies for deep wells and ultra-deep wells[J]. Drilling Fluid & Completion Fluid, 2002,19(6):121-126.
[7]	鄢捷年. 钻井液工艺原理[M]. 东营:中国石油大学出版社, 2011:149-150. YAN Jienian. Drilling fluid technology principle[M]. Dongying:China University of Petroleum Press,2011:149 -150.
[8]	周华安. 川东地区深井高密度聚合物钻井液技术问题的研究[J]. 钻井液与完井液, 1995, 12(1):44-48. ZHOU Hua'an. Technique problems of high density polymer mud encountered in the deep well of Chuandong area[J]. Drilling Fluid & Completion Fluid, 1995, 12(1):44-48.
[9]	闫光庆, 张金成. 中国石化超深井钻井技术现状与发展建议[J]. 石油钻探技术, 2013, 41(2):1-6. YAN Guangqing, ZHANG Jincheng. Status and proposal of the Sinopec ultra-deep drilling technology[J]. Petroleum Drilling Techniques, 2013, 41(2):1-6.
[10]	石秉忠, 欧彪, 徐江,等. 川西深井钻井液技术难点分析及对策[J]. 断块油气田, 2011, 18(6):799-802. SHI Bingzhong, OU Biao,XU Jiang. et al. Analysis and measure of technological difficulty of deep-well drilling fluid in West Sichuan[J]. Fault-Block Oil & Gas Field, 2011, 18(6):799-802.
[11]	宋明全, 王悦坚, 江山红. 塔河油田深井超深井钻井液技术难点与对策[J]. 石油钻探技术, 2005, 33(5):83-85. SONG Mingquan, WANG Yuejian, JIANG Shanhong. Technical challenges and solutions of drilling fluid techniques in deep and ultra-deep wells in Tahe oilfield[J]. Petroleum Drilling Techniques, 2005, 33(5):83-85.
[12]	于培志, 徐国良. 钻井液实验与指导[M]. 北京:地质出版社,2014:55-62. YU Peizhi, XU Guoliang. Drilling fluid experiment and guidance[M]. Beijing:Geology Press. 2014:55 -62.
[13]	American Petroleum Institute. Recommended practice for field testing water-based drilling fluids[S]. API RP 13B-1, 2009.
[14]	ZIAD ABDULLRAHMAN ALABDULLATIF, ABDULLAH SALEH AL-YAMI,VIKRANT BHAVANISHANKAR WAGLE,et al. Development of new kill fluids with minimum sagging problems for high pressure Jilh formation in Saudi Arabia[J]. SPE 171683 MS,2015.
