裸眼事故复杂高压气井注侧钻水泥塞技术

党冬红; 宋元洪; 吴永超; 王冲; 韩革委; 吴晋波; 尹璐

doi:10.3969/j.issn.1001-5620.2019.01.018

裸眼事故复杂高压气井注侧钻水泥塞技术

doi: 10.3969/j.issn.1001-5620.2019.01.018

1. 渤海钻探第一固井公司, 河北任丘 062552;
2. 渤海钻探油气测试公司, 河北廊坊 065007;
3. 长庆油田分公司第二采油厂, 甘肃庆阳 745100

详细信息

作者简介:
党冬红,高级工程师,毕业于西安石油大学。电话(0317)2786230;E-mail:dangdonghong@cnpc.com.cn

中图分类号: TE256.6
计量
- 文章访问数: 458
- HTML全文浏览量: 144
- PDF下载量: 211
- 被引次数: 0
出版历程
- 收稿日期: 2018-10-09
- 刊出日期: 2019-02-28

Pumping Cement Slurry and Drilling Set Cement Plug in High Pressure Open Hole Gas Well

1. No.1 Cementing Branch of CNPC Bohai Drilling Engineering Company Limited, Renqiu, Hebei 062552;
2. Oil and Gas Well Logging Branch of BHDC, Langfang, Hebei 065207;
3. The 2nd Oil Production Plant of PetroChina Changqing Oilfield Company, Qingyang, Gansu 745100

摘要

摘要: SBC-200井是委内瑞拉东部油气田的一口复杂油气井，三开φ244.5 mm技术套管下深4864 m，四开φ215.7mm井眼钻至4945.12 m卡钻，多种方法处理未解卡，套铣爆破松扣，鱼顶深度4897.56 m。使用的油基钻井液体系密度为1.415g/cm³时发生油气侵，密度为1.44 g/cm³时建立井下压力平衡，当量密度1.49 g/cm³发生井漏。为了完成钻井进尺，对鱼顶以上35.53 m裸眼井段实施水泥回填侧钻。固井采用高致密、高强度、低失水水泥浆，复合功能前置液体系及相应工艺技术措施，完成注水泥塞作业，满足侧钻质量要求。
- 气侵 /
- 井漏 /
- 鱼顶 /
- 前置液 /
- 水泥塞 /
- 侧钻
Abstract: Well SBC-200 is a complex well drilled in a oil and gas field in east Venezuela. Technical casing of φ244.5 mm was run to 4,864 m in this well. Pipe sticking was encountered when drilling the 4th interval (hole size φ215.7 mm) to 4 945.12 m, and several methods of freeing the pipe sticking were tried and failed. Breaking out by explosion was performed and the top of the fish was at depth of 4,897.56 m. Gas cut occurred during drilling with an oil base drilling fluid of 1.415 g/cm³, and was stopped when mud density was 1.44 g/cm³. Mud losses occurred when mud density was 1.49 g/cm³. In order to drill to the designed depth, the open hole 35.53 m above the top of the fish was filled with cement slurry and the well was sidetracked. The well was finally cemented with a cement slurry of high density, high strength and low filtration rate. The cement plug was made to satisfy the needs of sidetracking, using prepad with complex functions and techniques suitable for the well conditions.
- Gas cut /
- Mud loss /
- Top of fish /
- Prepad /
- Cement plug /
- Sidetrack

HTML全文

参考文献(7)

[1]	刘振通,宋志强,王军,等. 硅酸钠前置液在委内瑞拉重油带固井中的应用[J]. 钻井液与完井液,2015, 32(6):96-99. LIU Zhentong,SONG Zhiqiang,WANG Jun, et al. Application of sodium silicate prepad fluid in cementing heavy oil zones in Venezuela[J]. Drilling Fluid & Completion Fluid, 2016, 32(6):96-99.
[2]	郭文猛,张小建,刘振通,等. 油基泥浆条件下固井隔离液研究与应用[J]. 新疆石油科技,2013(2):13-16. GUO Wenmeng, ZHANG Xiaojian, LIU Zhentong, et al. Study and application of isolation fluid for cementing wells under oil base mud conditions[J]. Xinjiang Petroleum Science & Technology,2013 (2):13-16.
[3]	马文英, 张辉, 田军, 等. 提高第二界面固井质量的钻井液与前置液研究[J]. 钻井液与完井液,2003,20(4):27-30. MA Wenying, ZHANG Hui, TIAN Jun, et al. Study on drilling fluid and perflush for improving cementing quality of the second contact surface[J]. Drilling Fluid & Completion Fluid,2003,20(4):27-30.
[4]	刘振通,宋元洪,吴洪波,等. 特殊注水泥作业"插旗杆" 事故案例分析与思考[J]. 钻井液与完井液,2011,28(6):81-83. LIU Zhentong, SONG Yuanhong, WU Hongbo, et al. Analysis on trouble of pipe stuck while cementing in special cementing job[J]. Drilling Fluid & Completion Fluid, 2011, 28(6):81-83.
[5]	李坤,徐孝思,黄柏宗. 紧密堆积优化水泥浆体系的优势与应用[J]. 钻井液与完井液,2002,19(1):1-6. LI Kun, XU Xiaosi, HUANG Baizong.Advantages and application of the novel cement slurry systems developed by the concept of high packing density[J]. Drilling Fluid & Completion Fluid,2002,19(1):1-6.
[6]	赵普春,娄京伟. 塔河碳酸盐岩缝洞油藏深井裸眼段打水泥塞工艺技术[J]. 石油钻探技术,2006,34(6):77-79. ZHAO Puchun,LOU Jingwei. Drilling cementing plug in open-hole section located on carbonate crack reservoir in the Tahe Oilefield[J]. Petroleum Drilling Techniques, 2006,34(6):77-79.
[7]	李鹏晓,孙富全,何沛其,等. 紧密堆积优化固井水泥浆体系堆积密实度[J]. 石油钻采工艺,2017, 39(3):307-312. LI Pengxiao, SUN Fuquan, HE Peiqi, et al. Packing compactness of cementing slurry system for close packing optimization[J]. Oil Drilling & Production Technology, 2017,39(3):307-312.
