高温深井复杂岩性气藏压裂技术

刘彝; 颜菲; 吴均; 罗成; 徐建华

doi:10.3969/j.issn.1001-5620.2018.06.020

高温深井复杂岩性气藏压裂技术

doi: 10.3969/j.issn.1001-5620.2018.06.020

中石油冀东油田公司钻采工艺研究院, 河北唐山 063002

基金项目:

国家重大专项“南堡凹陷油气富集规律与增储领域”（2011ZX05050）油田重大项目“南堡5号构造天然气勘探钻采关键技术攻关及钻-完-试-采一体化设计”（KT2017A03-06）

详细信息

作者简介:
刘彝,工程师,2008年获西南石油大学应用化学专业硕士学位,主要从事压裂改造技术研究工作。E-mail:liu0yi@163.com

中图分类号: TE357.12
计量
- 文章访问数: 415
- HTML全文浏览量: 132
- PDF下载量: 186
- 被引次数: 0
出版历程
- 收稿日期: 2018-10-05
- 刊出日期: 2018-11-30

Technology of Fracturing Complex Lithologic Gas Reservoirs in High Temperature Deep Wells

Research Institute of Drilling and Production Technology, Jidong Oilfield, Tangshan, Hebei 063002

摘要

摘要: 冀东油田五号构造沙河街组属于复杂岩性气藏，岩性主要以玄武岩、火山碎屑岩为主，埋深4781.6~5200 m，储层温度170~180℃，物性差（0.04~0.4 mD），前期采用φ139.7 mm套管压裂，排量2 m³/min时，压力70 MPa，停泵压力61 MPa，导致施工失败。通过对该气田火山岩岩心全岩、X射线衍射分析、酸溶、地应力及天然裂缝识别实验，认为天然裂缝发育且裂缝充填物多为酸溶矿物，提出了前置酸压+压裂改造工艺。从耐170℃高温有机硼低残渣瓜胶压裂液、稠化酸、优化射孔方式，提高地面设备承压、自降解降滤失剂封堵天然裂缝等综合处理措施出发，实现了适合南堡五号构造裂缝性火山岩深井压裂的顺利实施，并对前期失败井再施工，排量为5 m³/min时，最高压力为74 MPa，共加砂60 m³，顺利完成了施工。该技术在该区块现场实施3口井，单井最高加砂量125 m³，最高套压85 MPa，NP5-A井压后φ6.35 mm油嘴放喷，日产气量为10.7×10⁴ m³。
- 火山岩 /
- 高温深井 /
- 酸压 /
- 压裂改造 /
- 高温有机硼低残渣压裂液
Abstract: The Shahejie Formation of the No.5 structure in Jidong Oilfield is a complex lithologic gas reservoir, the lithology of which is mainly basalt and volcaniclastic rocks. The reservoir, which has poor physical properties (porosity in a range of 0.04-0.4 mD) is buried in depths between 4,781.6 m and 5,200 m, with formation temperature between 170℃ and 180℃. The reservoir has previously undergone fracturing operation in the φ139.7 mm casing, with flowrate of 2 m³/min and pressure of 70 MPa. The pressure after stopping pumping was 61 MPa, and the operation was failed. From laboratory experiments (total analysis, Xray diffraction analysis, acid dissolution, ground stress and natural fracture identification) it was determined that natural fracture is developed in the reservoir and the fillings of the fractures are mainly acid-soluble minerals. Based on these analyses a technique of using pre-pad acid fracturing followed by fracturing operation was presented to improve the production of the reservoir. Using a high temperature organoboron low residue guar gum fracturing fluid (functioning at temperature up to 170℃), a thickened acid, combined with other measures such as optimized perforation method, increased compressive strengths of the surface equipment and plugging natural fractures with selfdegrading filter loss reducing materials etc., the fracturing operation was successfully performed in deep wells penetrating the fractured volcanic rock reservoirs in the No. 5 structures in Nanpu area. The well with failed fracturing operation previously was fractured again with flowrate of 5 m³/min and the maximum pressure of 74 MPa. Total amount of sand added was 60 m³, and the fracturing operation was successfully performed. The technology described above was used on 3 wells in Nanpu area.The maximum amount of sand added in a single well was 125 m³, and the maximum casing pressure was 85 MPa. The well NP5-A, after fracturing operation, was flowing with a φ6.35 mm choke, and the daily gas production output was 10.7×10⁴ m³.
- Volcanic rock /
- High temperature deep well /
- Acid fracturing /
- Fracturing /
- High temperature organoboron crosslinked low esidue fracturing fluid

HTML全文

参考文献(9)

[1]	张冲,刘立宏,刘清华,等. 松南火山岩气藏压裂技术研究与应用[J]. 钻采工艺,2015,38(1):51-54. ZHANG Chong,LIU Lihong,LIU Qinghua,et al. Research and application of fracturing technology used in songnan volcanic rocks gas reservoir[J].Drilling and Production Technology,2015,38(1):51-54.
[2]	姚锋盛,蒋佩,何平,等. 火山岩储层增产改造技术研究与应用[J]. 重庆科技学院学报(自然科学版), 2013,15(1):55-58. YAO Fengsheng,JIANG Pei,HE Ping,et al. The research and application of stimulation and modification technology in volcanic reservoir[J]. Journal of Chongqing University of Science and Technology(Natural Sciences Edition),2013,15(1):55-58.
[3]	王玉斌. 火山岩裂缝储层压裂工艺技术[J]. 化学工程与装备,2017(7):112-114. WANG Yubing.The fracturing technology in volcanic reservoir[J].Chemical Engineering and Equipment,2017 (7):112-114.
[4]	罗天雨,潘竟军,吕毓刚,等. 新疆油田火山岩气藏体积压裂机理研究及应用[J]. 中外能源,2013,(2):45-50. LUO Tianyu,PAN Jingjun,LYU Yugang,et al. Research and application of volume fracturing mechanism on volcanic gas reservoir in Xinjing oilfield[J]. Sino-Global Energy,2013 ,(2):45-50.
[5]	党建锋,郭建设,郑波,等. 牛东区块火山岩油藏压裂改造技术研究与应用[J]. 西部探矿工程,2011,(12):86-90. DANG Jianfeng,GUO Jianshe,ZHENG Bo,et al.The application and research of volcanic fracturing technology in nui dong reservoir[J].West-China Exploration Engineering,2011 ,(12):86-90.
[6]	王宝峰. 南堡油田高温深层玄武岩气藏压裂技术研究与应用[D]. 河北:中国科学院研究生院(渗流流体力学研究所),2013. WANG Baofeng.The research and application of high temperature volcanic gas reservoir in nanpu oil field[D]. Hebei:Institute of Porous Flow and Fluid Mechanics, 2013.5
[7]	刘彝,李良川,刘京,等. 低浓度瓜胶压裂液在高温大斜度井中的应用研究[J]. 钻采工艺,2015,40(4):89-92. LIU Yi,LI Liangchuan,LIU Jing,et al. The research and application of low concentration guar fracturing fluid in high temperature and highly-deviated wells[J].Drilling and Production Technology,2015,40(4):89-92.
[8]	钟安海. 压裂过程中多裂缝产生因素分析及处理措施[J]. 断块油气田,2010,17(5):617-620. ZHONG Anhai.Analysis of factors producing multiple fractures during hydraulic fracturing and treatment measures[J].Fault-Block Oil and Gas Field,2010,17(5):617-620.
[9]	贾利春,陈勉,张伟,等. 火山岩特性试验研究[J]. 科学技术与工程,2014,14(5):13-16. JIA Lichun,CHEN Mian,ZHANG Wei,et al. Experimental study on rock mechanics of volcanic rock[J]. Science Technology and Engineering,2014,14(5):13-16.
