Application of Low Density Solids-free Seawater Drilling Fluid in D Gas Field in Western South China Sea
-
摘要: 南海西部D气田目前在生产的浅层气藏,属上第三系莺歌海组地层,是中孔中渗的泥岩储层,该地层较复杂,钻进时易发生掉块、井塌、卡钻等井下复杂。在研究储层岩石性质及现有钻井液性能存在问题基础上,提出应提高体系的封堵性能以及抑制性能,措施为:在φ311.1 mm井段原PRG钻井液配方中增加VIS,降低滤液侵入速度,降低钻井液对于井壁的冲刷作用;降低PLUS的含量和增加PF-FLOTROL,降低黏度并增强降滤失性能;在φ215.9 mm井段原PRF钻井液配方中增加Greenseal,形成致密隔离层带,封堵微裂缝和孔喉,降低滤液渗透,延长井壁稳定时间;增加EZCARB的含量并且使用KCl加重,增加抑制性能。评价结果表明,PRG和PRF钻井液具有滤失量低(API滤失量为2.1 mL,高温高压滤失量约为4.3 mL)、流变性好、抑制性强(滚动回收率约为90%)和抗污染能力强(抗盐达10%,抗钙达2%)等特点。在D气田P3H井和D4H井的现场应用表明,使用PRG和PRF钻井液,有效抑制了泥包卡钻、井漏等井下复杂的发生,使用效果良好。
-
关键词:
- 低密度无固相海水钻井液 /
- PRG钻井液 /
- PRF钻井液 /
- 防止地层损害 /
- 南海西部气田
Abstract: The shallow gas reservoir presently produced in the D gas feld in western South China Sea is located in the Yinggehai formation of the Tertiary System, which is a medium porosity medium permeability mudstone reservoir. This formation has complex geological characteristics, and sloughing, borehole collapsing and pipe sticking have all been encountered during drilling operation in the past. Based on the studies on the rock properties of the reservoir and the problems associated with the drilling fluids it was concluded that the plugging and inhibitive capacity of the drilling fluids should be strengthened. That being said, the drilling fluid (PRG) previously used to drill the φ311.1 mm was treated with VIS to retard the invasion of mud fltrate into the formation and to minimize the erosion of drilling fluid to the borehole wall. The concentration of PLUS in the drilling fluid was reduced and PFFLOTROL increased to reduce viscosity and flter loss. In the φ215.9 mm interval, the PRF mud was treated with Greenseal to plug micro fractures and pore throats, and to retard the fltration of mud fltrate, thereby prolonging the time of borehole wall stability. Using more EZCARB and weighting the mud with KCl, the inhibitive capacity of the mud was improved. Evaluation experimental results showed that PRG and PRF muds had low flter loss (API fltration rate was 2.1 mL and and HTHP fltration rate was 4.3 mL), good rheology, strong inhibitive capacity (shale cuttings recovery on hot rolling test was ±90%) and excellent contamination resistance (salt resistance to 10% and calcium resistance to 2%). Application of the PRG and PRF drilling fluids on well P3H and D4H in D gas feld showed that downhole troubles previously encountered, such as bit balling, pipe sticking and mud losses were successfully avoided. -
[1] 胡进军, 夏小春, 孙强, 等. JFC钻井液体系升级研究及应用[J]. 钻采工艺, 2013, 36(4):79-82.HU Jinjun, XIA Xiaochun, SUN Qiang, et al. JFC upgrade research and application of drilling fluid system[J]. Drilling & Production Technology, 2013, 36(4):79-82. [2] 苏慧敏, 王欣, 覃和. 标准SY/T 5946-94中岩心线性膨胀降低率测定方法中存在问题的讨论[J]. 石油工业技术监督, 2000(7):10-12. SU Huimin, WANG Xin, QIN He. Discussion on the problems in the method of determination of core linear expansion in standard SY/T 5946-94[J]. Petroleum industry technical supervision, 2000(7):10-12. [3] 刘庆旺, 高大鹏, 徐博韬.PEM钻井液体系性能评价与应用[J]. 科学技术与工程, 2009, 9(11):3060-3062.LIU Qingwang, GAO Dapeng, XU Botao. Performance evaluation and application of PEM drilling fluid system[J]. Science Technology and Engineering, 2009, 9(11):3060-3062. [4] L. J. Leising, I. C. Walton, 徐梅, 等. 连续油管钻井过程中钻屑的携带问题及其解决方法[J]. 国外油田工程, 2000(11):9-15. LEISING L J, WALTON I C, XU Mei, et al. The problems and solutions of drilling cuttings in the continuous pipeline drilling process[J]. Foreign oil field engineering, 2000(11):9-15. [5] 唐军, 朱树兵. 低渗透油层水平井钻井液工艺技术及现场应用[J]. 钻采工艺, 1998(5):68-71. TANG Jun, ZHU Shubing. Technology of drilling fluid technology and field application of low permeability oil horizontal wells[J]. Drilling & Production Technology, 1998(5):68-71. [6] 郭祥鹃. 钻井液用润滑降滤失剂的研究与应用[D]. 济南:山东大学, 2007. GUO Xiangjuan. Research and application of lubrication fluid loss for drilling fluid[D]. Jinan:Shandong university, 2007. [7] 时冠兰, 熊汉桥, 王建, 等. 甲酸钠完井液体系系列化实验研究[J]. 钻井液与完井液, 2011, 28(6):30-31.SHI Guanlan, XIONG Hanqiao, WANG Jian, et al. hongfu. A series of experimental studies on the liquid series of sodium formate.[J]. Drilling Fluid & Completion Fluid, 2011, 28(6):30-31. [8] 孔勇, 杨小华, 徐江, 等. 抗高温强封堵防塌钻井液体系研究与应用[J]. 钻井液与完井液, 2016, 33(6):17-22.KONG Yong, YANG Xiaohua, XU Jiang, et al. Research and application of anti-collapse drilling fluid system in high temperature and strong sealing[J]. Drilling Fluid & Completion Fluid, 2016, 33(6):17-22. -
