Study on Mud Loss Control under Pressure in Drilling Fractured Carbonate Reservoirs in Block Tahe 10
-
摘要: 针对塔河油田10区奥陶系裂缝型储层裂隙发育、井漏多发的问题,设计了一种桥堵颗粒粒度级配方法,并通过酸溶性材料优选,研制了承压堵漏配方。粒度级配方法以裂缝尺寸为基础,采用漏失量为主要评价指标,借助曲面响应优化设计法确定了粒度级配。实验评价结果表明,采用该粒度级配混配的桥堵材料颗粒粒度分布曲线连续、跨度广,无论是封堵较大裂缝,还是封堵中等裂缝或小裂缝,都有充足的对应粒度的桥堵颗粒。以该粒度级配方法为基础,设计的3套针对不同裂缝宽度范围的承压堵漏体系,堵漏性能良好,承压大于8 MPa,3 mm裂缝漏失量低于200 mL,2 mm和1 mm裂缝漏失量低于50 mL。堵漏配方中堵漏材料酸溶率高,在99%以上,形成的封堵层酸溶率可达98.4%。Abstract: A mud loss control fluid was formulated to control mud loss under pressure during drilling the fractured Ordovician reservoirs in the Block Tahe 10, where mud losses prevailed in the past drilling operations. This mud loss control fluid was formulated with optimized sized acid soluble materials. In determining the sizing of the particles of the lost circulation materials (LCM), the amount of mud losses was used as the main evaluation index based on the sizes of the fractures found in the formations of the reservoir, and the response surface methodology (RSM) was used for optimized design of the sizing of the particles. Laboratory evaluation results showed that the particle size distribution has a continuous and wide-spanned distribution curve. Fractures of any sizes can be plugged with enough particles of matching sizes. Three mud loss control (under pressure) fluids for different sizes of fractures were formulated using the particle sizing technique. These fluids performed very well in controlling mud losses and pressure bearing capacity was greater than 8 MPa. The volume of mud loss through 3 mm fractures was less than 200 mL, and the volume of mud loss through 2 mm and 1 mm fractures was less than 50 mL. More than 99% of the LCM was dissolved by acids, while 98.4% of the particles in the layers of LCM formed on the surfaces of the borehole wall can be acid dissolved.
-
Key words:
- Mud loss control /
- Fracture width /
- Rate or acid dissolution /
- Particle size distribution
-
[1] 鄢捷年. 钻井液工艺学[M]. 东营:中国石油大学出版社, 2012:385-396. YAN Jienian. Drilling fluid technology[M].Dongying:China University of Petroleum Press, 2012:385-396. [2] 徐同台,刘玉杰,申威,等. 钻井工程防漏堵漏技术[M]. 北京:石油工业出版社, 1997:88-147. XU Tongtai, LIU Yujie, SHEN Wei, et al. Lost circulation control and plugging[M].Beijing:Petroleum Industrry Press, 1997:88-147. [3] 李松. 海相碳酸盐岩层系钻井液漏失诊断基础研究[D]. 成都:西南石油大学, 2014. LI Song. Basic research on drilling fluid losses diagnosis in marine carbonate layers[D]. Chengdu:Southwest Petroleum University, 2014. [4] SY/T 5840-2007钻井液用桥接堵漏材料室内试验方法[S]. SY/T 5840-2007 Recommend practice for laboratory testing of bridging material for drilling fluids[S]. [5] 王悦坚. 塔河油田恶性漏失堵漏与大幅度提高地层承压技术[J]. 钻井液与完井液, 2013, 30(4):33-36WANG Yuejian.Technology on mud lost control of severe lost circulation and improving formation pressure containment in Tahe oilfield[J].Drilling Fluid & Completion Fluid, 2013, 30(4):33-36. [6] ABRAMS A. Mud design to minimize rock impairment dueto particle invasion[J].Journal of Petroleum Technology, 1977:586-592. [7] 黄春雨. 阿姆河地区碳酸盐岩裂缝性地层堵漏技术研究[D]. 西南石油大学, 2015. HUANG Chunyu. Mud loss control in fractured-type carbonate reservoir in the Amu Darya area[D]. Southwest Petroleum University, 2015. [8] 康毅力, 余海峰, 许成元, 等. 毫米级宽度裂缝封堵层优化设计[J]. 天然气工业, 2014, 34(11):88-94.KANG Yili, YU Haifeng, XU Chengyuan, et al. An optiamal design for millimeter-wide fracture-plugged zones[J].Natural Gas Industry, 2014, 34(11):88-94. [9] GELAN E LOEPPKE, DAVID A GLOWKA, ELTON K WRIGHT.Design and evalution of lost-circulation materials for severe environments[J].Journal of Petroleum Technology, 1990, 42(3):328-337. [10] 袁恩熙. 工程流体力学[M]. 北京:石油工业出版社, 2013:146-154. YUAN Enxi. Engineering fluid mechanics[M] Beijing:Petroleum Industrry Press, 2013:146-154. -
