Effects of Temperature on Mechanical Property of Set Cement and Analysis Thereof
-
摘要: 为了表征长封固段固井水泥石在温度梯度下的机械性能，研究了不同温度下水泥石机械性能非线性变化规律并分析了原因。通过检测在用水泥石在30～160℃温度区间下的机械性能，分别建立了水泥石抗压强度、杨氏模量及泊松比随温度变化的关系曲线，同时拟合了水泥石机械性能随温度变化的函数关系式，并形成了考虑温度对水泥石机械性能影响的非线性物理方程；利用热重和XRD实验，对不同温度养护的水泥石进行了物性分析，通过SEM对水泥石的微观形貌进行了对比分析，初步探索了温度影响水泥石机械性能的内在原因。研究发现：相同养护天数下，水泥石在60℃及80℃条件下，机械性能存在突变区间，而80℃以上养护的水泥石其机械性能没有显著差异，同时发现温度介于突变区间以下，机械性能呈二次函数变化，高于突变区间则呈指数函数变化；结合微观分析结果发现，水泥石水化产物及水化程度的不同，是导致水泥石机械性能存在突变区间的原因。Abstract: To characterize the mechanical property of the long set cement under a certain temperature gradient, the nonlinear changing pattern of the mechanical property of set cement at different temperatures was studied, and the causes for the changing pattern was analyzed. Curves describing changes of compressive strength, Young's modulus and Poisson ratio with temperature were drawn using the mechanical properties of set cement at temperatures between 30℃ and 160℃, and a functional equation was established by fitting the mechanical property of set cement with temperature. A nonlinear physical equation taking into account the eff3ects of temperature on the mechanical property of set cement was formulated. Analyses of the physical properties of set cement cured at different temperatures were done with the data obtained through TGA and XRD experiments. Using SEM, the micro morphology of set cement was analyzed, and the inherent causes of temperature affecting the mechanical property of set cement were primarily studied. It was found that at the same time of curing, the mechanical property of set cement had sudden changes at 60℃ and 80℃. At temperatures over 80℃, no obvious difference in the mechanical property was found of the cured set cement. It was also found that at temperatures below the temperature at which the sudden change takes place, the mechanical property changes in a pattern of quadratic function; at temperatures above the temperature at which the sudden change takes place, the mechanical property changes in a pattern of exponential function. Combined with the data obtained from micro analyses, it was found that different hydration products of cement and the different degrees of hydration reactions are what cause the mechanical property of the set cement to have sudden changes.
-
[1] WILCOX B,OYENEYIN B.HPHT well integrity and cement failure[C]//SPE Nigeria International Conference and Exhibition,2016. [2] LI B,LI H,GUO B,et al.Effect of cement sheath induced stress on well integrity assessment in carbon sequestration fields[J].Journal of Natural Gas Science & Engineering,2017(46):46-50. [3] ZHANG H,SHEN R,YUAN G,et al.Cement sheath integrity analysis of underground gas storage well based on elastoplastic theory[J]. Journal of Petroleum Science & Engineering,2017(159):818-829. [4] 王浩,张志超,程晓辉. 基于热力学理论的水泥石热-力耦合本构模型和有限元分析[J]. 岩石力学与工程学报,2018,37(1):67-76.WANG Hao,ZHANG Zhichao,CHENG Xiaohui. A thermal-mechanical constitutive model for cement rock based on thermodynamics and its finite element application[J].Chinese Journal of Rock Mechanics and Engineering,2018,37(1):67-76. [5] ZHANG Z,XU H,SHI T,et al.Influence of the WHCP on cement sheath stress and integrity in HTHP gas well[J].Journal of Petroleum Science & Engineering, 2015(126):174-180. [6] ZHANG Z,WANG H.Effect of thermal expansion annulus pressure on cement sheath mechanical integrity in hpht gas wells[J]. Applied Thermal Engineering,2017(118):600-611. [7] CHU W,SHEN J,YANG Y,et al.Calculation of micro-annulus size in casing-cement sheath-formation system under continuous internal casing pressure change[J].Petroleum Exploration & Development Online, 2015,42(3):414-421. [8] GHOLAMI R,AADNOY B,FAKHARI N.A thermoporoelastic analytical approach to evaluate cement sheath integrity in deep vertical wells[J].Journal of Petroleum Science & Engineering,2016(147):536-546. [9] 程小伟,刘开强,李早元,等. 油井水泥浆液-固态演变的结构与性能[J]. 石油学报,2016,37(10):1287-1292.CHENG Xiaowei,LIU Kaiqiang,LI Zaoyuan,el al. Structure and properties of oil well cement slurry during liquid-solid transition[J]. Acta Petrolei Sinica,2016,37(10):1287-1292. [10] 程小伟,王升正,时宇,等. 稻壳灰对油井水泥性能的影响及作用机理初探[J]. 硅酸盐通报,2015,34(8):2171-2176.CHENG Xiaowei,WANG Shengzheng,SHI Yu,el al. Effect of the rice husk ash on oil cement and mechanism of action[J].Bulletin of the Chinese ceramic society, 2015,34(8):2171-2176. [11] GAËL B,CHRISTELLE T,GILLES E,et al. Determination of the proportion of anhydrous cement using SEM image analysis[J].Construction & Building Materials,2016(126):157-164. -
