Enhancing Pressure Bearing Capacity of Formation to Control Mud Losses in Deep Shale Gas Drilling With Oil Base Drilling Fluids
-
摘要: 随着涪陵页岩气向深层开发,钻井液密度达到1.75 g/cm3,固井水泥浆密度达到1.85~1.89 g/cm3,为了提高固井质量,防止水泥浆漏失,需要提高油基钻井液应用井段承压能力。国外新型油基堵漏材料在涪陵二期深层页岩气焦页XX井进行了应用。应用效果表明,该技术能够实行随钻封堵,对钻井液的流变性能没有副作用,在提承压作业过程中,对部分漏失层段进行承压作业,承压能力能够从1.75 g/cm3提至1.80 g/cm3。最后对全部漏失层段进行承压作业,采用国外油基堵漏剂和自研油基堵漏材料T150联合堵漏,承压能力提高至1.85 g/cm3。研究结果表明,该油基堵漏技术适用性强,配方简化,亲油性强,可操作性好,可以进行推广应用。Abstract: With the advancement of shale gas drilling to deeper reservoirs, the density of drilling fluid has approached 1.75 g/cm3, and the density of cement slurry approached 1.85-1.89 g/cm3. To improve the quality of well cementing and prevent the losses of cement slurry, the pressure bearing capacity of the open hole to oil base drilling fluids should be improved. The application of an imported new lost circulation material (LCM) for use in oil base mud on the deep shale gas well Jiaoye-XX (a well drilled in the second phase of shale gas development in Fuling, Sichuan) showed that the oil base mud LCM is able to plug lost circulation zones while drilling, and imposes no negative effect on the rheology of the drilling fluid. The pressure bearing capacity of part of the lost circulation zones was enhanced, from pressure bearing capacity of 1.75 g/cm3 to 1.80 g/cm3. Finally, all the lost circulation zones had their pressure bearing capacity enhanced. Using the imported LCM and an oil base mud LCM T150 of independent intellectual property rights, the pressure bearing capacity of the formations prone to lost circulation was enhanced to 1.85 g/cm3. Study results showed that control of oil base mud losses with the two strongly LCMs is widely applicable and easy to operate. The two strongly lipophilic LCMs are a worth popularizing in controlling oil base mud losses.
-
Key words:
- Deep shale gas /
- Oil base mud /
- Lost circulation control under pressure /
-
[1] 舒曼,赵明琨,许明标. 涪陵页岩气田油基钻井液随钻堵漏技术[J]. 石油钻探技术,2017,45(3):21-26.SHU Man,ZHAO Mingkun,XU Mingbiao. Plugging while drilling technology using oil-based drilling fluid in Fuling shale gas field[J]. Petroleum Drilling Techniques, 2017,45(3):21-26. [2] 朱怀江,王平美,刘强,等.一种适用于高温高盐油藏的柔性堵剂[J]. 石油勘探与开发,2007,34(2):230-233.ZHU Huaijiang, WANG Pingmei,LIU Qiang,et al. A kind of flexible water shutoff agent applicable to reservoirs with high temperature and salinity[J].Petroleum Exploration & Development,2007,34(2):230-233. [3] 聂勋勇,王平全,张新民. 聚合物凝胶堵漏技术研究进展[J]. 钻井液与完井液,2007,24(1):82-84.NIE Xunyong, WANG Pingquan,ZHANG Xinmin. Progresses in gelling polymer sealing technology research[J].Drilling Fluid & Completion Fluid,2007, 24(1):82-84. [4] 张新民,聂勋勇,王平全,等. 特种凝胶在钻井堵漏中的应用[J]. 钻井液与完井液,2007,24(5):83-84.ZHANG Xinmin, NIE Xunyong, WANG Pingquan,et al. A special gel for mud loss control[J].Drilling Fluid & Completion Fluid,2007,24(5):83-84. [5] 李家学,黄进军,罗平亚,等.随钻防漏堵漏技术研究[J]. 钻井液与完井液,2008,25(3):25-26.LI Jiaxue,HUANG Jinjun,LUO Pingya,et al. Researches on mud losses prevention and control[J]. Drilling Fluid & Completion Fluid,2008,25(3):25-26. -
