A Compound Acid for Medium to High Water-cut Screen Pipe Completed Wells in Wenchang Oilfield
-
摘要: 南海西部文昌油田群部分油井已进入中高含水期，储层具有胶结疏松、非均质性强等特点，多采用悬挂筛管完井，酸化时很难实现均匀布酸，往往出现增液不增油的现象。针对储层特点及完井方式，研发出了WZX-02自转向酸+WHS-05缓速酸的复合酸液体系，该体系能有效抑制酸液进入高渗层，避免酸化后含水大幅上升。该体系在文昌M油田D井进行了先导性试验，酸化前产液量为68 m3/d，产油量为32 m3/d，含水53%，酸化后产液量为207 m3/d，产油量为117 m3/d，含水43%，增产效果显著，可为类似中高含水筛管井酸化提供借鉴。Abstract: Some oil wells in the Wenchang Oilfield (located in the west of South China Sea), which were completed with screen pipe, are now having high water-cut. In acidizing operations, acids are difficult to be distributed evenly, thus the production of fluid is increased, while the production of oil remains low. Based on the characteristics of the reservoir rocks and the well completion method used, a compound acids, formulated with a self-diverting acid WZX-02 and a retarding acid WHS-05, was developed to deal with the said problems. The compound acids are able to control themselves from entering into formations of high permeability, thereby avoiding water-cut increase after acidizing operations. The compound acids have been pilot tested on the Well D in Block M in Wenchang oilfield. Prior to acidizing, the well had liquid production of 68 m3/d, oil production of 32 m3/d, and water-cut of 53%. After acidizing, the liquid production increased to 207 m3/d, oil production to 117 m3/d, and water-cut reduced to 43%, demonstrating that the compound acids had remarkable ability in oil production enhancement, and can be used in acidizing screen pipe completed wells with high water-cut.
-
Key words:
- Wenchang oilfield /
- Medium to high water-cut /
- Screen pipe completion /
- Acidizing /
- Self diverting acid
-
[1] 董景锋,阿不都卡德尔·阿不都热西提,李晓艳,等. 一种新型两性表面活性剂自转向酸体系[J]. 钻井液与完井液,2016,33(1):102-106.DONG Jingfeng, Abudukadeer·Abudurexiti, LI Xiaoyan, et al. A new amphoteric surfactant self-diverting acid system[J]. Drilling Fluid & Completion Fluid, 2016,33(1):102-106. [2] 曲占庆,曲冠政,齐宁,等. 自转向酸主剂的合成及其转向性能实验研究[J]. 钻井液与完井液,2012,29(5):65-69.QU Zhanqing, QU Guanzheng, QI Ning, et al. Synthesis and evaluation on main agent of self-diverting acid[J]. Drilling Fluid & Completion Fluid,2012,29(5):65-69. [3] 刘京,徐建华,乔煊威,等. 清洁自转向酸液的研制及性能评价[J]. 石油天然气学报,2009,31(3):302-305.LIU Jing, XU Jianhua, QIAO Xuanwei, et al. Development and performance evaluation of clean self -turning acid[J]. Journal of Oil and Gas Technology, 2009,31(3):302-305. [4] 何春明,陈红军,刘岚,等.VES自转向酸变黏机理研究[J]. 钻井液与完井液,2010,27(4):84-86.HE Chunming, CHEN Hongjun, LIU Lan, et al. Study on viscositify mechanism of VES self-diversion acid[J]. Drilling Fluid & Completion Fluid,2010,27(4):84-86. [5] 马利成,李爱山,张晓云,等. 新型黏弹性表面活性自转向酸的研制及性能评价[J]. 油气地质与采收率, 2007,14(5):98-100.MA Licheng, LI Aishan, ZHANG Xiaoyun, et al. Performance appraisal of a new self-diverting acid with viscoelasticity and surface activity[J]. Petroleum Geology and Recovery Efficiency, 2007,14(5):98-100. [6] 石油工业标准化技术委员会.SY/T 5405-1996酸化用缓蚀剂性能试验方法及评价指标[S]. 北京:中国石油天然气总公司,1996. Standardization Technical Committee of Petroleum Industry. SY/T 5405-1996 Experimental instruction and standards for inhibitive performance of inhibitors in acidizing[S].Beijing:China National Petroleum Corporation,1996. [7] 石油工业标准化技术委员会.SY/T 5971-94注水用黏土稳定剂性能评价方法[S]. 北京:中国石油天然气总公司,1994. Standardization Technical Committee of Petroleum Industry. SY/T 5971-94 Performance evaluation methods of clay stabilizer[S]. Beijing:China National Petroleum Corporation,1994. [8] 国家经济贸易委员会.SY/T 6571-2003酸化用铁离子稳定剂性能评价方法[S]. 北京:石油工业出版社, 2003. State Economic and Trade Commission. SY/T 6571-2003 Performance evaluation method of ferric ion stabilizer[S].Beijing:Petroleum Industry Press,2003. [9] 石油工业标准化技术委员会.SY/T 5755-1995压裂酸化用助排剂性能评价方法[S]. 北京:中国石油天然气总公司,1995. Standardization Technical Committee of Petroleum Industry. SY/T 5755-1995 Performance evaluation method of auxiliary agent for fracturing and acidizing[S]. Beijing:China National Petroleum Corporation,1995. -
