Resource Utilization of Pyrolyzed Oil Cuttings (Ⅱ): Study on the Performance of Cement Slurry with Drilled Cuttings Residue
-
摘要: 针对油基钻屑热解吸处理后产生的残渣,尝试将其替代部分油井水泥(YJ)用于制备固井用水泥浆。首先研究了热解油基钻屑(PODC)掺量和水固比对油井水泥浆体性能的影响,同时利用等温量热仪(ICC)、X射线衍射分析仪(XRD)、压汞仪(MIP)和扫描电镜(SEM)分别测试了掺PODC水泥浆体早期水化放热量、水泥石水化产物、孔结构及微观形貌,并以降失水剂CHL、硅灰和晶体膨胀剂KW-4优化了掺PODC水泥浆体的工程性能。结果表明,随着PODC掺量增加,浆体流动度增大,密度减小,凝结时间延长,水泥石抗压强度有所下降;形成了技术套管用掺渣水泥浆体系PODC-6 :40% YJ+60% PODC+3% CHL+4%硅灰+2% KW-4,油层套管(非产层段)用掺渣水泥浆体系PODC-3 :70% YJ+30% PODC+3% CHL+3%硅灰+2% KW-4,水固比均为0.40,掺渣水泥浆体系各项工程性能均满足固井施工基本技术要求。微观分析表明,掺PODC水泥浆体的水化放热量降低,其水化产物主要为C—S—H凝胶和CH,较净浆水泥石水化产物明显减少,密实度有所降低。该研究可为热解油基钻屑资源化利用提供一种新途径,具有潜在的环保效益和经济效益。Abstract: Residues from pyrolyzed drilled cuttings from wells drilled with oil base muds are tried to replace part of the oil well cement (YJ) to make cement slurry for well cementing. Studies have been conducted on the effects of the concentration of pyrolyzed oil drilled cuttings (PODC) and water/solid ratio on the properties of cement slurry. The PODC was measured for its early heat of hydration, hydration products of set cement, pore structure and microscopic morphology with ICC, XRD, MIP and SEM, respectively. The PODC was optimized for its engineering performance with filter loss reducer CHL, silica fume and crystal expansion agent KW-4. It was found that with an increase in the concentration of PODC, the mobility of the cement slurry was increased, the density of the cement slurry was reduced, the setting time of the cement slurry was prolonged, and the compressive strength of the set cement was reduced to some extent. At water/solid ratio of 0.40, a cement slurry with drilled cuttings residue for intermediate casing cementing, PODC-6:40% YJ + 60% PODC + 3% CHL + 4% silica fume + 2% KW-4, and a cement slurry with drilled cuttings residue for production casing (nonproductive section) cementing, PODC-3:70% YJ + 30% PODC + 3% CHL + 3% silica fume + 2% KW-4, were formulated respectively. The engineering properties of the cement slurries with drilled cuttings residue have satisfied the needs of well cementing operations. Microscopic analyses of the cement slurries indicated that cement slurries with PODC had low heat of hydration, and the hydration products of the cement slurries were C-S-H gel and CH. Compared with cement slurry not treated with PODC, the PODC cement slurries had less hydration products, and the degree of density of the PODC cement slurries was also slightly reduced. It is expected that this study will provide a new approach to resource utilization of PODC, and is of potential environmental benefit and economic benefit.
-
[1] 蔡浩,姚晓,肖伟,等. 热解油基钻屑资源化利用(Ⅰ):废渣基固化剂固化实验研究[J]. 钻井液与完井液, 2017, 34(4):59-64.CAI Hao,YAO Xiao,XIAO Wei, et al. Resource utilization of pyrolyzed oil cuttings(Ⅰ):Study on solidification of oil cuttings with waste-slag solidifier[J]. Drilling Fluid & Completion Fluid, 2017, 34(4):59-64. [2] 何涛, 李茂森, 杨兰平, 等. 油基钻井液在威远地区页岩气水平井中的应用[J]. 钻井液与完井液, 2012,29(3):1-5.HE Tao, LI Maosen, YANG Lanping, et al. Application of oil-based drillings fluis in shale gas horizontal well in district of Weiyuan[J]. Drilling Fluid & Completion Fluid,2012,29(3):1-5. [3] 李学庆, 杨金荣, 尹志亮, 等. 油基钻井液含油钻屑无害化处理工艺技术[J]. 钻井液与完井液, 2013(4):81-83. LI Xueqing, YANG Jinrong, YIN Zhiliang, et al. Novel har mLess treatment technology of oily cuttings[J]. Drilling Fluid & Completion Fluid, 2013(4):81-83. [4] ALMUDHHI S M. Environmental impact of disposal of oil-based mud waste in Kuwait[J].Petroleum Science & Technology,2016,34(1):91-96. [5] 孙静文, 许毓, 刘晓辉, 等. 油基钻屑处理及资源回收技术进展[J]. 石油石化节能, 2016, 6(1):30-33.SUN Jingwen, XU Yu, LIU Xiaohui, et al. Progress of oil-based mud treatment and resource recovery technology[J].Energy Conservation in Petroleum & Petrochemical Industry, 2016, 6(1):30-33. [6] 朱冬昌, 付永强, 马杰, 等. 长宁、威远页岩气开发国家示范区油基岩屑处理实践分析[J]. 石油与天然气化工, 2016, 45(2):62-66.ZHU Dongchang, FU Yongqiang, MA Jie, et al. Treatment practical analysis of oily cuttings in changning and Weiyuan national demonstration shale gas area[J]. Chemical Engineering of Oil & Gas, 2016, 45(2):62-66. [7] 黄磊, 姚晓, 孟佳佳, 等. 富镁矿渣-水泥复合注浆材料的制备及性能研究[J]. 硅酸盐通报, 2014, 33(3):482-486.HUANG Lei, YAO Xiao, MENG Jiajia, et al. Study on preparation and properties of blended magnesium rich slag-cement grouting material[J]. Bulletin of the Chinese Ceramic Society, 2014, 33(3):482-486. [8] 孟佳佳, 姚晓, 黄磊. 富镁矿渣对油井水泥浆体膨胀性能的影响及水化机理[J]. 材料导报, 2014(10):123-127. MENG Jiajia,YAO Xiao,HUANG Lei. Effects of magnesium-rich slag on expansive property of oil well cement slurry and its hydration mechanism[J]. Materials Review, 2014(10):123-127. -
